PY7PM-0820GSM/WCDMA/LTE mobile phone

www.sonymobile.com Sony Mobile Communications AB 221 88 Lund, Sweden 1222-9266.14 ©2014 Important information Sony Consumer Web site At www.sonymobile.com/support there is a support section where help and tips are only a few clicks away. Here you will find the latest computer software updates and tips on how to use your product more efficiently. Service and support You have access to a portfolio of exclusive service advantages such as: • Global and local Web sites providing support. • A global network of Contact Centers. • An extensive network of Sony service partners. • A warranty period. Learn more about the warranty conditions in the Limited Warranty section. At www.sonymobile.com/support or www.sonymobile.com/contact, you can find the latest support tools and information. For operator-specific services and features, please contact your network operator. You can also contact our Contact Centers or contact your local dealer. (Calls are charged according to national rates, including local taxes, unless it is a toll-free number.) If your product needs service, please contact the dealer from whom it was purchased, or one of our service partners. To make a claim under the limited warranty, proof of purchase is required. Guidelines for Safe and Efficient Use Please follow these guidelines. Failure to do so might entail a potential health risk or product malfunction. If in doubt as to its proper function, have the product checked by a certified service partner before charging or using it. Recommendations for care and safe use of our products • Handle with care and keep in a clean and dust-free place. • Warning! May explode if disposed of in fire. • Do not use in environments where relevant IP rating limitations, if applicable, are exceeded (including excess depths and/or pressures of liquid and/or dust) or expose to excess humidity. • For optimum performance, the product should not be operated in temperatures below -10°C(+14°F) or above +45°C(+113°F). Do not expose the battery to temperatures above +60°C(+140°F). • Do not expose to flames or lit tobacco products. • Do not drop, throw or try to bend the product. 2 • Do not paint or attempt to disassemble or modify the product. Only Sony authorised personnel should perform service. • Consult with authorised medical staff and the instructions of the medical device manufacturer before using the product near pacemakers or other medical devices or equipment. • Discontinue use of electronic devices, or disable the radio transmitting functionality of the device, where required or requested to do so. • Do not use where a potentially explosive atmosphere exists. • Do not place the product, or install wireless equipment, in the area above an air bag in a car. • Caution: Cracked or broken displays may create sharp edges or splinters that could be harmful upon contact. • Do not use a Bluetooth Headset in positions where it is uncomfortable or will be subject to pressure. C hildren Warning! Keep out of the reach of children. Do not allow children to play with mobile devices or accessories. They could hurt themselves or others. Products may contain small parts that could become detached and create a choking hazard. Power supply (Charger) Connect the charger to power sources as marked on the product. Do not use outdoors or in damp areas. Do not alter or subject the cord to damage or stress. Unplug the unit before cleaning it. Never alter the plug. If it does not fit into the outlet, have a proper outlet installed by an electrician. When a power supply is connected there is a small drain of power. To avoid this small energy waste, disconnect the power supply when the product is fully charged. Use of charging devices that are not Sony branded may pose increased safety risks. Battery New or idle batteries can have short-term reduced capacity. Fully charge the battery before initial use. Use for the intended purpose only. Charge the battery in temperatures between +5°C(+41°F) and +45°C(+113°F). Do not put the battery into your mouth. Do not let the battery contacts touch another metal object. Turn off the product before removing the battery. Performance depends on temperatures, signal strength, usage patterns, features selected and voice or data transmissions. Only Sony service partners should remove or replace built-in batteries. Use of batteries that are not Sony branded may pose increased safety risks. Replace the battery only with another Sony battery that has been qualified with the product per the standard IEEE-1725. Use of an unqualified battery may present a risk of fire, explosion, leakage or other hazard. 3 Personal medical devices Mobile devices / devices with radio transmitters may affect implanted medical equipment. Reduce risk of interference by keeping a minimum distance of 15 cm(6 inches) between the Sony product and the medical device. Use the Sony device at your right ear, when applicable. Do not carry the device in your breast pocket. Turn off the device if you suspect interference. For use in proximity to personal medical devices, please consult a physician and the device manufacturer. D riving In some cases, vehicle manufacturers may forbid the use of mobile devices in their vehicles unless a handsfree kit with an external antenna supports the installation. Check with the vehicle manufacturer's representative to be sure that a mobile device or Bluetooth handsfree will not affect the electronic systems in the vehicle. Full attention should be given to driving at all times and local laws and regulations restricting the use of wireless devices while driving must be observed. GPS/Location based functions Some products provide GPS/Location based functions. Location determining functionality is provided “As is” and “With all faults”. Sony does not make any representation or warranty as to the accuracy of such location information. Use of location-based information by the device may not be uninterrupted or error free and may additionally be depend…

Text truncated - open the document above for the full version.

SAR Information FCC Statement Declaration of Conformity Sony D2533 UMTS HSPA Band 1 2 5 8 GSM GPRS/EDGE 850/900/1800/1900 LTE Band 1 3 7 8 28 Important Information United States & Canada THIS PHONE MODEL HAS BEEN CERT IFIED IN COMPLIANCE WITH THE GOVERNMENT’S REQUIREMENTS FOR EXPOSURE TO RADIO WAVES. The D2533 Series mobile phones have been designed to comply with applicable safety requirements for exposure to radio waves. Your wireless phone is a radio transmitter and receiver. It is designed to not exceed the limits* of exposure to radio frequency (RF) energy set by governmental authorities. These limits establish permitted levels of RF energy for the general population. The guidelines are based on standards that were developed by international scientific organizations through periodic and thorough evaluation of scientific studies. The standards include a safety margin designed to assure the safety of all individuals, regardless of age and health. The radio wave exposure guidelines employ a unit of measurement known as the Specific Absorption Rate (SAR). Tests for SAR are conducted using standardized methods with the phone transmitting at its highest certified power level in all used frequency bands. While there may be differences between the SAR levels of various phone models, they are all designed to meet the relevant guidelines for exposure to radio waves. For more information on SAR, please refer to the Important Information chapter in the User Guide. The highest SAR value as reported to the authorities for this phone model when tested for use by the ear is 0.907 W/kg*, and when worn on the body is 1.244 W/kg*. For body-worn operation, the phone has been tested when positioned a minimum of 15 mm from the body without any metal parts in the vicinity of the phone or when properly used with an appropriate accessory and worn on the body. For devices which include “WiFi hotspot” functionality, SAR measurements for the device operating in WiFi hotspot mode were taken using a separation distance of 10 mm. Use of third-party 2 accessories may result in different SAR levels than those reported. **Before a phone model is available for sale to the public in the US, it must be tested and certified by the Federal Communications Commission (FCC) that it does not exceed the limit established by the government-adopted requirement for safe exposure*. The tests are performed in positions and locations (i.e., by the ear and worn on the body) as required by the FCC for each model. The FCC has granted an Equipment Authorization for this phone model with all reported SAR levels evaluated as in compliance with the FCC RF exposure guidelines. While there may be differences between the SAR levels of various phones, all mobile phones granted an FCC equipment authorization meet the government requirement for safe exposure. SAR information on this phone model is on file at the FCC and can be found under the Display Grant section of http://transition.fcc.gov/oet/ea/fccid after searching on FCC ID PY7PM-02. Additional information on SAR can be found on the Mobile Manufacturers Forum EMF website at http://www.emfexplained.info/. * In the United States and Canada, the SAR limit for mobile phones used by the public is 1.6 watts/kilogram (W/kg) averaged over one gram of tissue. The standard incorporates a margin of safety to give additional protection for the public and to account for any variations in measurements. **This paragraph is only applicable to authorities and customers in the United States. 3 Renseignements importants États-Unis et Canada CE MODÈLE DE TÉLÉPHONE A ÉTÉ CE RTIFIÉ CONFORME AUX EXIGENCES GOUVERNEMENTALES RELATIVES À L'EXPOSITION AUX ONDES RADIOÉLECTRIQUES. Les téléphones mobiles de la D2533 ont été conçus pour répondre aux normes de sécurité en vigueur en matière d'exposition aux ondes radioélectriques. Votre téléphone sans fil est un émetteur et un récepteur radio. Il est conçu de manière à ne pas dépasser les limites* d'exposition à l'énergie des fréquences radio (RF) établies par les autorités gouvernementales. Ces limites fixent les niveaux maximaux d'énergie RF auxquels peut être soumis le grand public. Ces lignes directrices sont basées sur des normes qui ont été élaborées par des organisations scientifiques internationales par le biais d'évaluations périodiques et approfondies des études scientifiques. Ces normes prévoient une marge de sécurité visant à assurer la protection de tous les individus, peu importe leur âge et leur état de santé. Les lignes directrices relatives à l'exposition aux ondes radioélectriques utilisent une unité de mesure appelée « Taux d'absorption spécifique » (TAS). Les tests de TAS sont effectués selon des méthodes standardisées dans lesquelles le téléphone émet dans toutes les bandes de fréquences utilisées, à la plus forte puissance pour laquelle il a été homologué. Bien que le TAS puisse être différent d'un modèle de téléphone à un autre, tous les appareils sont conçus pour respecter les lignes directrices relatives aux ondes radioélectriques. Pour en savoir plus sur le DAS, reportez-vous au chapitre sur les renseignements importants du guide de l'utilisateur. Le DAS le plus élevé relevé par les autorités pour ce modèle de téléphone est de 0.907 W/kg* lorsqu'il est testé en utilisation près de l'oreille, et de 1.244 W/kg* lorsqu'il est porté sur le corps. En mode d’utilisation porté sur le corps, le téléphone a été testé lorsqu’il est à au moins 15 mm du corps et à l’écart de toute pièce en métal, ou lorsqu’il est utilisé de façon adéquate 4 avec un accessoire et porté sur le corps. Pour les appareils munis de la fonctionnalité « point d'accès WiFi », les mesures du DAS de l'appareil en mode WiFi ont été prises à une distance de sécurité de 10 mm. L'utilisation d'accessoires tiers peut produire des niveaux de DAS différents de ceux relevés. **Avant qu'un modèle de téléphone ne soit mis en vente auprès du public aux États-Unis, la Commission fédérale des c…

Text truncated - open the document above for the full version.

Important Information Before you use your device, please read the Important Information provided in your device regarding warranty, safety and handling information. Overview 23 7 8 9 10 6 541 12 19 17 1314 16 18 1511 1. Charging/Notification light 2. Proximity/Light sensor 3. Ear speaker 4. Front camera lens 5. Front camera light 6. Micro SIM card slot cover 7. Power key 8. Volume/Zoom key 9. Camera key 10. Main microphone 11. Wi-Fi/GPS/Bluetooth antenna area 12. Main camera lens 13. Main camera light 14. Second microphone 15. Headset jack 16. Port for charger/USB cable 17. Memory card slot cover 18. NFC™ detection area 19. Speaker Assembly To insert the micro SIM card If you insert a micro SIM card while the device is powered on, the device restarts automatically. 1 To insert a memory card Basics Turning on the device Make sure that the battery is charged for at least 30 minutes before you turn on the device for the first time. To turn on the device 1 Press and hold down the power key until the device vibrates. 2 Wait a while for the device to start. Waking up the screen To activate the screen • Briefly press the power key . Setting up your device Setup guide The first time you start your device, a setup guide opens to help you configure basic settings, sign in to some accounts (for example, your Google™ account), and personalise your device. You can also manually access the setup guide at a later stage. To access the setup guide manually 1 From the Home screen, tap . 2 Tap > Setup guide. Accessing settings View and change settings for your device from the Settings menu. The Settings menu is accessible from both the Application screen and the Quick settings panel. To access your device settings 1 From your Home screen, tap . 2 Find and tap . Transferring your contacts Xperia™ Transfer is an application within the PC Companion and the Sony Bridge for Mac computer programs that helps you to collect contacts from your old device and transfer them to your new device. Xperia™ Transfer supports several device brands, including iPhone, Samsung, HTC, BlackBerry, LG, and Nokia. You need: • An Internet-connected computer. • A USB cable for your old device. • A USB cable for your new Android™ device. • Your old device. • Your new Android™ device. To transfer contacts to your new device 1 Search and download PC Companion (on a PC) or Bridge for Mac (on a Mac computer) from www.sonymobile.com if the application is not already installed. 2 After successful installation, open the PC Companion application or the Sony Bridge for Mac application, then click Xperia™ Transfer and follow the relevant instructions to transfer your contacts. Finding your way Using the keys Back navigation key • Go back to the previous screen within an application or close the application. Home navigation key • Exit an application and go back to the Home screen. Task navigation key • Open the recently used applications window and the small apps bar. Application screen • Open the Application screen. Basic applications and settings Make phone calls by dialling the number manually or by using the smart dial function. Use the Messaging application to send and receive text and multimedia messages. Go to Google Play™ to download free and paid applications for your device. Optimise the device settings to suit your own requirements. Status and notifications To open or close the Notification panel Drag down two fingers instead of one to open the Quick settings panel instead. Support on the web Visit www.sonymobile.com/support to access a range of support options for your device, including downloads, troubleshooting tips and a User guide. Legal information Sony D2533 Publication number: 1285-9771.1 This Startup guide is published by Sony Mobile Communications AB or its local affiliated company, without any warranty. Improvements and changes to this Startup guide necessitated by typographical errors, inaccuracies of current information, or improvements to programs and/or equipment, may be made by Sony Mobile Communications AB at any time and without notice. Such changes will, however, be incorporated into new editions of this Startup guide. All illustrations are for illustration only and may not accurately depict the actual device. See regulatory information such as the CE mark in the relevant label tray in the device. All product and company names mentioned herein are the trademarks or registered trademarks of their respective owners. Any rights not expressly granted herein are reserved. Visit www.sonymobile.com/us/legal/ for more information. Product compliance: This product has been manufactured by or on behalf of Sony Mobile Communications, Mobilvägen, SE-221 88 Lund, Sweden. Inquiries related to product compliance based on national legislation shall be addressed to Sony Mobile Quality Officer, Sony Mobile Communications AB, Mobilvägen, SE-221 88 Lund, Sweden. For any service or guarantee matters, please refer to the contact details provided in the separate service or guarantee documents. © 2014 Sony Mobile Communications AB. All rights reserved. To view the CE mark and the FCC ID 1 Detach the memory card slot cover. 2 Insert the tip of an unfolded paper clip (or a similar object with a long, fine tip) into the hole in the label tray, then drag the tray outwards. The information is displayed on the tray. Startup guide Xperia ™ C3 D2533 Sony Mobile Communications AB SE-221 88 Lund, Sweden www.sonymobile.com

Sony Mobile Communications Prepared by SEM/CGQTAGC LEI 3 CHEN Contents responsible if other than preparer Approved by SEM/CGQTAGC (YUSHENG WU) It is the responsibility of the user to ensure that they have a correct and valid version. Any outdated hard copy is invalid 3GPP Rel 10 3GPP Rel 103GPP Rel 10 3GPP Rel 10 PY7PM PY7PMPY7PM PY7PM- -- - Applied to: Type number PM-0820-BV Sony Mobile hereby declares that are listed in below NAS (Non Access Stratum; Layer 3): - ISR enhancement, in TS 24.301 CR0758, CR0931, CR1199, CR1362. - CSFB enhancement, in TS 24.301 CR0800, CR0959, CR1202. - Extend Periodic Timers, in TS - Backoff Timers enhancement, in TS 24.301 CR1047, CR1197, CR1260, CR1279, CR1312, CR1216, CR1238, CR1323, CR1371. - Emergency Bearer Services, in TS 24.301 CR1029, CR1155, CR1320. AS (Access Stratum; Layer 2/3): - Change to Buffer Status possible. - CSFB AC Barring, in TS 36.331 CR0477, CR0623 CR0490. - RLF Reporting Enhancement, in TS 36.331 CR548r4, CR664r1, CR672r2. - Others in TS 36 TS36.212 CR152, in TS36.213 CR385, CR402 And below Rel.10 - Mobility enhancement - Scheduling request improvement - Periodic CQI/PMI/RI mask - RSRQ-based cell selection/reselection - NULL integrity protection algorithm No other features from Rel.10 are supported by this device. Other device capabilities are unchanged from Rel.8. Carrier Aggregation is not supported. RF performance such as RF related to Layer 2/3. Confidential LETTER Document number 6/0061-22/FCP 119 1492 Uen Date 2014-06-27 Remarks This document is managed in metaDoc. It is the responsibility of the user to ensure that they have a correct and valid version. Any outdated hard copy is invalid and must be removed from possible use. 3GPP Rel 10 3GPP Rel 103GPP Rel 10 3GPP Rel 10- -- -Feature FeatureFeature Feature- -- -Support Declaration for Support Declaration for Support Declaration for Support Declaration for - -- -0820 08200820 0820 Applied to: Type number FCC ID BV PY7PM-0820 Sony Mobile hereby declares that for this device, the only Rel.10 features supported are listed in below: NAS (Non Access Stratum; Layer 3): ISR enhancement, in TS 24.301 CR0758, CR0931, CR1199, CR1362. CSFB enhancement, in TS 24.301 CR0800, CR0959, CR1202. Extend Periodic Timers, in TS 24.301 CR1098. Backoff Timers enhancement, in TS 24.301 CR1047, CR1197, CR1260, CR1279, CR1312, CR1216, CR1238, CR1323, CR1371. Emergency Bearer Services, in TS 24.301 CR1029, CR1155, CR1320. AS (Access Stratum; Layer 2/3): Change to Buffer Status Reporting, BSR size can be extended to reflect higher payloads CSFB AC Barring, in TS 36.331 CR0477, CR0623 CR0490. RLF Reporting Enhancement, in TS 36.331 CR548r4, CR664r1, CR672r2. Others in TS 36.331 CR1064, CR1084, CR1214, CR1223, CR1281, CR1 TS36.212 CR152, in TS36.213 CR385, CR402 Rel.10 features inherited from Rel.9 are also supported by this device Mobility enhancement Scheduling request improvement Periodic CQI/PMI/RI mask based cell selection/reselection integrity protection algorithm o other features from Rel.10 are supported by this device. Other device capabilities are unchanged from Rel.8. Carrier Aggregation is not supported. And all the above listed features do not affect RF performance such as RF output power, modulation or data rate since they are related to Layer 2/3. 1(2) Revision B This document is managed in metaDoc. must be removed from possible use. Support Declaration for Support Declaration for Support Declaration for Support Declaration for this device, the only Rel.10 features supported ISR enhancement, in TS 24.301 CR0758, CR0931, CR1199, CR1362. CSFB enhancement, in TS 24.301 CR0800, CR0959, CR1202. Backoff Timers enhancement, in TS 24.301 CR1047, CR1197, CR1260, CR1279, Emergency Bearer Services, in TS 24.301 CR1029, CR1155, CR1320. Reporting, BSR size can be extended to reflect higher payloads CSFB AC Barring, in TS 36.331 CR0477, CR0623 CR0490. RLF Reporting Enhancement, in TS 36.331 CR548r4, CR664r1, CR672r2. .331 CR1064, CR1084, CR1214, CR1223, CR1281, CR1327 in from Rel.9 are also supported by this device. o other features from Rel.10 are supported by this device. Other device ll the above listed features do not affect output power, modulation or data rate since they are Yours sincerely ------------------------------------------ Yusheng Wu Manager Sony Mobile Communications China Confidential LETTER Document number 6/0061-22/FCP 119 1492 Uen Yours sincerely ------------------------------------------ Yusheng Wu Sony Mobile Communications China 2(2) Revision B

June 23 rd , 2014 Federal Communications Commission Office of Engineering and Technology Equipment Authorization Division 7345 Oakland Mills Road Columbia, Maryland 21046 Subject: Permanent Confidentiality request for FCC ID: PY7PM-0820 To Whom It May Concern, Pursuant to sections 0.457 and 0.459 of CFR 47, the applicant requests permanent confidential treatment of the following information accompanying this application: - Block Diagram - Schematics - Operational Description - BOM list/Tune-Up-Procedure The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the applicant and provide unjustified benefits to its competitors. Yours Sincerely, Yusheng Wu (武予生) Manager Sony Mobile Communications

__2014-6-23__ Federal Communications Commission Office of Engineering and Technology Equipment Authorization Division 7345 Oakland Mills Road Columbia, Maryland 21046 Subject: SHORT-TERM Confidentiality request for FCC ID: PY7PM-0820 To Whom It May Concern, Pursuant to sections 0.457 and 0.459 of CFR 47 and to avoid premature release of sensitive information prior to marketing or release of the product to the public, the applicant requests the following documents contained in this certification application be temporarily withheld from public disclosure for an initial period of 45 days:
External Photos
Internal Photos
Test Setup Photos
User’s Manual The applicant also acknowledges that they will also provide appropriate notice to ACB should either of the following occur: a) if the applicant requires additional 45 day extension periods they will notify ACB with a new request letter at least 7 days prior to the short- term confidentiality expiration date - [Note: up to a maximum of 3 extensions only are allowed], or b) immediately notify ACB in the event the information regarding the product or the product is made available to the public. ACB will then release the documents listed above for public disclosure pursuant to FCC Public Notice DA 04-1705. Yours sincerely, Yusheng Wu (武予生) Manager Sony Mobile Communications

No.I14Z46714-EMC01 Page 81 of 90 ANNEX C: EUT photograph Mobile Phone Mobile Phone No.I14Z46714-EMC01 Page 82 of 90 Mobile Phone Mobile Phone No.I14Z46714-EMC01 Page 83 of 90 Mobile Phone Mobile Phone No.I14Z46714-EMC01 Page 89 of 90 Travel Charger Label of Travel Charger No.I14Z46714-EMC01 Page 90 of 90 USB Cable ***END OF REPORT***

Label Location of PM7PM-0820

1(2) Document number Revision 1288-4987 1 Sony Mobile Communications AB Prepared by Date Robert Shi (28851919) 2014-05-12 Contents responsible if other than preparer Remarks Approved by Robert Shi (28851919) Phone Label, Content, Made in... Gina 1 General information 2 Printing Information, CU label Content Format Line 1 (2,0/2,0) Model Name “Model: D2502” Text, height 1,2 mm, According to Chapter 1 in MLCI. Line 2a (4,5/2,0) Type number of the phone, “TYPE: PM-0820-BV”. Text, height 1,2 mm. According to Chapter 1 in MLCI. Line 2b (4,5/14,0) HW & SW identification field, if applicable; “EFF” Text, height 1,2 mm. According to Type-testing report under Product Model Specifying Document Line 3a (6,5/2,0) “FCC ID: PY7PM-0820” Text, height 1,2 mm, According to Chapter 1 in MLCI. Line 3b (6,5/14,0) Production week (flash), “00W01” (00 = year, 01 = week) Text, height 1,2 mm. Line 4 (8,5/2,0) Product number with revision of the Sales Item in which the phone is packed, if applicable. “SI XXXX-XXXX” Text, height 1,2 mm. Mobile Phone label part no  1285-0372 Bar code  Print quality: according to COSMETIC GUIDELINE – Bar code labels document 1222-6072 Uen This document needs to be updated with 2D barcodes, for the standard for 2D barcodes in this project see below, line 6b  Quiet zone: No bar codes are allowed to be closer to a label edge than 1 mm! Text If applicable, or nothing else specified, Zebra printer Arial Narrow is imposed. When needed, the text is adjusted to fit the label. 2(2) Document number Revision 1288-4987 1 Sony Mobile Communications AB Prepared by Date Robert Shi (28851919) 2014-05-12 Contents responsible if other than preparer Remarks Approved by Robert Shi (28851919) Line 5 (10,5/2,0) Actual electronic serial number (IMEI) of the mobile phone, “00000000-000000-0” Text, height 1,2 mm. In the format TAC-SNR-CD. TAC and SNR derived from pos 500 in BOM. CD = check digit according to the Luhn formula (ISO/IEC 7812), GSM 02.16. Line 6a (12,5/2,0) Marking of origin. “Made in Xxx”; “Xxx” = actual country of production of the included telephone, in English Text, height 1,2 mm. Line 6b (12,0/13,5) Line 6b in 2D-bar code, just digits, 15 characters, according to IMEI number in line 5. The bar code contains IMEI-number Data Matrix; x-dimension 0,20 mm. Symbol type ECC 200.Code type for USA and Western Europe (7-pieces, ACII). NB – the 2D bar code needs quiet zoon for 1 mm around the whole bar code. Height of barcode 4,0 mm 3 Printing Information, CE label 4 Layout The conceptual picture (for Zebra 90XiII printer, or equivalent) should not be considered as specifications, but as an additional help for setting up the label. Conceptual picture CU label CE label double underlined = major changes since last revision.

No.I14Z46714-EMC01 Page 84 of 90 Mobile Phone Disassembly and Inbuilt Battery Mobile Phone Disassembly and Inbuilt Battery No.I14Z46714-EMC01 Page 85 of 90 Mobile Phone Disassembly Mobile Phone Disassembly No.I14Z46714-EMC01 Page 86 of 90 Mobile Phone Disassembly Mobile Phone Disassembly No.I14Z46714-EMC01 Page 87 of 90 Mobile Phone Disassembly Mobile Phone Disassembly No.I14Z46714-EMC01 Page 88 of 90 Mobile Phone Disassembly

Page 1 of 167 Sony Mobile Communications (China) Co., Ltd. Test Laboratory Test Report Report Title: PM-0820-BV SAR FCC Test Report Report NO: TARC-PM-0820-BV-SAR-FCC-01 Report Date: 2014-06-26 Initial Test Report / Test Report replace <document ID> Prepared by: Zhou, Zhili Reviewed by: Tang, Hailiang Approval by: Wu, Yusheng Title： Test Engineer Title：Lab Supervisor Title：Authorized Signatory Date: 2014/07/07 Date: 2014/07/07 Date: 2014/07/07 Note: The test results in this test report relate only to the devices listed in this report. This report shall not be reproduced except in full without the written approval of Sony Mobile Communications (China) Co., Ltd. Test Laboratory. Test Laboratory: CNAS (17025) : No.L6619 FCC 2.948 Listed: No.634550 Sony Mobile Communications (China) Co., Ltd. Test Laboratory Address: 20 Tian Zhu West Road, A Area Tian Zhu airport Industrial Zone. Shun Yi District, Beijing 101312 P. R. China Tel: +86 1080481188 - 68138, Fax: +86 1058659049 Email: [email protected] Sony Mobile Communications (China) Co., Ltd. Test Laboratory Report No.：TARC-PM-0820-BV- SAR-FCC-03 PM-0820-BV SAR FCC Test Report Edition 3 Revision 0 ___________________________________________________________________________ Page 2 of 167 Report Edition Report Number Edition Date Memo TARC-PM-0820-BV- SAR-FCC-01 1 2014-06-23 Initial creation of test report TARC-PM-0820-BV- SAR-FCC-02 2 2014-07-04 Updated test report per 15862 - TCB Comments TARC-PM-0820-BV- SAR-FCC-03 3 2014-07-07 Removed phone test setup photos from main report Sony Mobile Communications (China) Co., Ltd. Test Laboratory Report No.：TARC-PM-0820-BV- SAR-FCC-03 PM-0820-BV SAR FCC Test Report Edition 3 Revision 0 ___________________________________________________________________________ Page 3 of 167 Laboratory Name: Sony Mobile Communications (China) Co., Ltd. Test Laboratory Contact window: Ma, Gang Title: Laboratory Manager Telephone: +86 10 80481188-68138 E-mail: [email protected] Applicant Information Company Name: Sony Mobile Communications INC Address: No.15 Tian Zhu Road, ShunYi District City: Beijing Country: P. R. China Contact Window： Chen, Lei Telephone: +86 10 80481188-68125 Fax: +86 10 58656688 Manufacturer Information Company Name: Sony Mobile Communications INC Address: 1…
