PY7TM-0020Tablet PC with WLAN, BT, RFID

SAR Information FCC Statement Declaration of Conformity Sony SGP351 UMTS HSPA Band 1 2 4 5 8 GSM GPRS/EDGE 850/900/1800/1900 LTE Band 4 Important Information Unit ed States & Canada THIS TABLET PC MODEL HAS BEEN CERTIFIED INCOMPLIANCE WITH THE GOVERNMENT’S REQUIREMENTSFOR EXPOSURE TO RADIO WAVES. The SGP351 Series tablets personal computers have been designed to comply with applicable safety requirements for exposure to radio waves. Your wireless tablet personal computer is a radio transmitter and receiver. It is designed to not exceed the limits* of exposure to radio frequency (RF) energy set by governmental authorities. These limits establish permitted levels of RF energy for the general population. The guidelines are based on standards that were developed by international scientific organizations through periodic and thorough evaluation of scientific studies. The standards include a safety margin designed to assure the safety of all individuals, regardless of age and health. The radio wave exposure guidelines employ a unit of measurement known as the Specific Absorption Rate (SAR).Tests for SAR are conducted using standardized methods with the tablet personal computer transmitting at its highest certified power level in all used frequency bands. While there may be differences between the SAR levels of various tablet personal computer models, they are all designed to meet the relevant guidelines for exposure to radio waves. For more information on SAR, please refer to the important information chapter in the User Guide. The highest SAR value as reported to the authorities for this tablet personal computer model when tested for use against the body is 1.49 W/kg*. The tablet personal computer has been tested when positioned of 0 mm from the body without any metal parts in the vicinity of the tablet personal computer or when properly used with an appropriate Sony. For devices which include “WiFi hotspot” functionality, SAR measurements for the device operating in WiFi hotspot mode were taken using a separation distance of 0 mm. 2 **Before a tablet personal computer model is available for sale to the public in the US, it must be tested and certified by the Federal Communications Commission (FCC) that it does not exceed the limit established by the government-adopted requirement for safe exposure*. The tests are performed in positions and locations (i.e., by the ear and worn on the body) as required by the FCC for each model. The FCC has granted an Equipment Authorization for this tablet personal computer model with all reported SAR levels evaluated as in compliance with the FCC RF exposure guidelines. While there may be differences between the SAR levels of various tablet personal computer, all mobile tablet personal computers granted an FCC equipment authorization meet the government requirement for safe exposure. SAR information on this tablet personal computer model is on file at the FCC and can be found under the Display Grant section of http://www.fcc.gov/oet/fccid after searching on FCC ID PY7TM-0020. Additional information on SAR can be found on the Cellular Telecommunications & Internet Association (CTIA) website at http://www.phonefacts.net* In the United States and Canada, the SAR limit for mobile tablet personal computers used by the public is 1.6 watts/kilogram (W/kg) averaged over one gram of tissue. The standard incorporates a margin of safety to give additional protection for the public and to account for any variations in measurements. * In the United States and Canada, the SAR limit for mobile tablet personal computers used by the public is 1.6 watts/kilogram (W/kg) averaged over one gram of tissue. The standard incorporates a margin of safety to give additional protection for the public and to account for any variations in measurements. ** This paragraph is only applicable to authorities and customers in the United States. 3 Renseignements importants État s-Unis et Canada CE MODÈLE DE TABLETTE ÉLECTRONIQUE A ÉTÉ CERTIFIÉ CONFORME AUX EXIGENCES GOUVERNEMENTALES RELATIVES À L'EXPOSITION AUX ONDES RADIOÉLECTRIQUES. Les tablettes électroniques de la série SGP351 ont été conçues pour répondre aux normes de sécurité en vigueur en matière d'exposition aux ondes radioélectriques. Votre tablette électronique sans fil est un émetteur et un récepteur radio. Elle est conçue de manière à ne pas dépasser les limites* d'exposition à l'énergie radiofréquence (RF) établies par les autorités gouvernementales. Ces limites fixent les niveaux maximaux d'énergie RF auxquels peut être soumis le grand public. Ces lignes directrices sont basées sur des normes qui ont été élaborées par des organisations scientifiques internationales par le biais d'évaluations périodiques et approfondies des études scientifiques. Ces normes prévoient une marge de sécurité visant à assurer la protection de tous les individus, peu importe leur âge et leur état de santé. Les lignes directrices relatives à l'exposition aux ondes radioélectriques utilisent une unité de mesure appelée « Débit d'absorption spécifique » (DAS). Les tests de DAS sont effectués selon des méthodes standardisées dans lesquelles la tablette électronique émet dans toutes les bandes de fréquences utilisées, à la plus forte puissance pour laquelle elle a été homologuée. Bien que le DAS puisse être différent d'un modèle de tablette électronique à un autre, tous les appareils sont conçus pour respecter les lignes directrices relatives aux ondes radioélectriques. Pour en savoir plus sur le DAS, reportez-vous au chapitre sur les renseignements importants du guide de l'utilisateur. Le DAS le plus élevé relevé par les autorités pour ce modèle de tablette électronique est de 1.49 W/kg* lorsqu'il est testé en utilisation près du corps. La tablette électronique a été testée lorsqu’elle est à 0 mm du corps et à l’écart de toute pièce en métal, ou lorsqu’elle est utilisée de façon adéquate avec un 4 accessoire Sony. Pour les appareils munis de la fonctionnali…

Text truncated - open the document above for the full version.

Startup guide Xperia ™ Tablet Z SGP321/SGP351 Sony Mobile Communications AB SE-221 88 Lund, Sweden www.sonymobile.com 1272-5409.1 To insert the micro SIM card Do not insert the micro SIM card into the memory card slot. 1 45 2 3 Inserting the micro SIM card into the device without the SIM card holder could damage your micro SIM card or your device, and Sony does not warrant and will not be responsible for any damages caused by such action. Device overview 12 34 6 7 5 8 9 Not For Sales 00440254-021066-7 FFGG 2012/10 MADE IN CHINA 1011 1415 12 1318 19 1617 1. Light sensor 2. Front camera 3. Speaker A 4. Speaker B 5. Charging dock connector 6. Volume key 7. Notification light 8. Power key 9. Headset jack 10. Microphone 11. Infrared sensor 12. Main camera 13. Speaker B (same as 4) 14. Port for charger/USB cable 15. Hole for attaching the charger port cover 16. SIM card slot 17. Memory card slot 18. Speaker A (same as 3) 19. NFC™ detection area Use the accessories provided with your device, or other compatible accessories, for optimal performance. Turning on the device To turn on the device Make sure that the battery is charged for at least 30 minutes before you turn on the device for the first time. 1 Press and hold down the power key until the notification light flashes once. 2 Wait a while for the device to start. Finding your way Waking up the screen To activate the screen • Briefly press the power key . • If Tap to wake up mode is enabled, double-tap the screen. To enable Tap to wake up mode, go to the Home screen, then tap > Settings > Display > Tap to wake up. To unlock the screen • Drag up or drag down. Basic settings The first time you start your device, a setup guide explains basic device functions and helps you enter essential settings. You can also access the setup guide later. To access the setup guide manually 1 From the Home screen, tap . 2 Tap Settings > Setup guide. Using the keys Back • Go back to the previous screen. • Close the on-screen keypad, a dialog box, an options menu, or the Notification panel. Home • Go to the Home screen. Task • Tap to open a window showing your most recently used applications. Small apps launcher • Tap to open a list of all small apps. Small app shortcut • Tap to launch a pre-selected small app. You can create a shortcut for any small app by touching and holding a small app icon in the small apps launcher. Home screen You can customise your Home screen with widgets, shortcuts, folders, themes, wallpaper and other items. You can also add more panes to it. You can view content in other panes of the Home screen by flicking left or right. The items in the bar at the top of the screen are always available for quick access. To go to the Home screen • Press . To browse the Home screen • Flick right or left. To add a widget to the Home screen 1 Touch and hold an empty area on your Home screen, then tap Widgets. 2 Find and tap the widget that you want to add. Application screen The Application screen, which you open from your Home screen, contains the applications that come pre- installed on your device as well as the applications you download. The Application screen extends beyond the regular screen width, so you need to flick left and right to view all content. To open the Application screen • From your Home screen, tap . Status and notifications The status bar in the lower right corner of your screen shows what's going on in your device. For example, calendar notifications appear here. To open the Notification panel • Tap the status bar. Welcome Important Information Before you use your device, please read the Important Information provided in your device or in the box. Water and dust resistance Your device has IP (Ingress Protection) ratings of IP5X, IPX5 and IPX7. This means that your device is dust protected and protected against the effects of immersion in water in depths of between 0 to 100 cm for up to 30 minutes, and is also protected against the effects of a low pressure water stream. The covers for the micro USB port, the micro SD card, the micro SIM card and the headset connector must be firmly closed in order for the device to meet the stated IP rating. More information about IP codes and important details about your device’s resistance to water can be found in the User guide for your device and on the Sony Mobile support website. www.sonymobile.com/support Assembly To insert the memory card Do not insert a micro SIM card into the memory card slot. 1 2 The memory card may not be included at purchase in all markets. March 25, 2013 09:13:46 SGP321-SGP351__Booklet_EN_1272-5409.1.pdf 1 of 2 Set up your device Settings menu View and change settings for your device from the Settings menu. To access your device settings 1 From your Home screen, tap . 2 Find and tap Settings. You can also tap the status bar on the Home screen and then tap > to access your device settings. Connecting to wireless networks You can access the Internet wirelessly from your device using Wi-Fi® technology. This way you can browse the web and share media files over the same Wi-Fi® network with other DLNA Certified™ devices, for example, TVs and computers. If your company or organisation has a virtual private network (VPN), you can connect to this network using your device. You can use a VPN to access intranets and other internal services at your company. To turn on Wi-Fi® 1 From your Home screen, tap . 2 Find and tap Settings. 3 Drag the slider beside Wi-Fi® to the right to turn on the Wi-Fi® function. It may take a few seconds before Wi-Fi® is enabled. To connect to a Wi-Fi® network 1 From the Home screen, tap . 2 Find and tap Settings. 3 Make sure that the Wi-Fi® function is on. Tap Wi-Fi . 4 Available Wi-Fi® networks are displayed. The available networks may be open or secured. Open networks are indicated by and secured networks are indicated by next to the Wi-Fi® network name. 5 Tap a Wi-Fi® network to connect to it. If you are trying to connect to a secure network, you…

Text truncated - open the document above for the full version.

Sony Mobile Communications Confidential LETTER 1(1) Document number Revision 1 10/0061-LXE 110 1479 A Prepared by Date SEM/CGQBAD RAZVAN BUJILA 2013-04-18 Contents responsible if other than preparer Remarks This document is managed in metaDoc. Approved by SEM/CGQBAD RAZVAN BUJILA Telecommunication Certification Body CETECOM GmbH Im Teelbruch 116 45219 Essen Germany Confidentiality request letter - PY7TM-0020 Subject: Certification Application FCC ID: PY7TM-0020, Type number TM-0020-BV It is requested that the following information is to be held confidential on behalf of Sony Mobile Communications AB pursuant to FCC Rules Parts 0.457 and 0.459:  Blo ck Diagrams  Sche matics  Parts List  Tune Up Information  Operation Description These items contain detailed system and equipment description and related information about the product which Sony Mobile Communications AB considers to be proprietary, confidential and a custom design which otherwise would not be released to the general public. Since this design is a basis from which future technological products will evolve, Sony Mobile Communications AB also feels that this information would be of benefit to its competitors, and that the disclosure of the information in these exhibits would give our competitors an unfair advantage in the market. Please contact the undersigned if there are any further questions or additional information needed in this matter. Yours sincerely Razvan Bujila Global Type Approval Sony Mobile Communications Tel: +46 10 801 53 23 Mobilvägen 10, SE-221 88 Lund, Sweden [email protected]

Federal Communication Commission Equipment Authorization Devision, Application Processing Branch 7435 Oakland Mills Road Columbia, MD 21048 Certification and Engineering Bureau Industry Canada Spectrum Engineering Branch 3701 Carling Avenue, Building 94 Ottawa, Ontario K2H 8S2 Declaration on Electrically Identical Models TO WHOM IT MAY CONCERN We Sony Mobile communications AB, declare on our sole responsibility that the models SGP351 and SGP341 with FCC ID: PY7TM-0020 and IC: 4170B-TM0020 are identical in hardware. The only difference between the model SGP351 and SGP 341 is: - LTE band IV operations is disabled by software for model SPG341 We attest that the software for both devices are identically except as mentioned above. Also we attest that a submitted test reports in these filings represent both models. If you have any questions, please feel free to contact us at the address shown below Sincerely,

Sony Mobile Communications Confidential LETTER 1(1) Document number Revision 14 14/0061-LXE 110 1479 A Prepared by Date SEM/CGQBAD RAZVAN BUJILA 2013-04-18 Contents responsible if other than preparer Remarks This document is managed in metaDoc. Approved by SEM/CGQBAD RAZVAN BUJILA Federal Communication Commision Equipment Authorization Division, Application Processing Branch 7435 Oakland Mills Road Columbia, MD 21048 UNII Device Declaration Letter - PY7TM-0020 To whom it may concern: We have declared below featured for FCC equipment authorization, Device FCC ID: PY7PM-0020 1. DFS Device:  Master  Client with Radar detection capability  N/A  Client without radar detection capability, 2. Active / Passive Scanning , adhoc mode access point capability Frequency Band (MHz) Active Scanning (the device can transmit a probe (beacon)) passive scanning (where the device is can listen only with no probes) Ad Hoc Mode capability Access point capability 2412-2462  Yes  No  Yes  No  Yes  No  Yes  No 5745-5825  Yes  No  Yes  No  Yes  No  Yes  No 5755-5795  Yes  No  Yes  No  Yes  No  Yes  No 5180-5240  Yes  No  Yes  No  Yes  No  Yes  No 5190-5230  Yes  No  Yes  No  Yes  No  Yes  No 5260-5320  Yes  No  Yes  No  Yes  No  Yes  No 5270-5310  Yes  No  Yes  No  Yes  No  Yes  No 5500-5700  Yes  No  Yes  No  Yes  No  Yes  No 5510-5670  Yes  No  Yes  No  Yes  No  Yes  No 3. Country code selection ability  Yes  No 4. Meet 15.202 requirement  Yes  No please check below:  A master device is defined as a device operating in a mode in which it has the capability to transmit without receiving an enabling signal. In this mode it is able to select a channel and initiate a network by sending enabling signals to other devices  A client device is defined as a device operating in a mode in which the transmissions of the device are under control of the master. A device in client mode is not able to initiate a network. 5. For client devices that have software configuration control to operate in different modes (active scanning in some and passive scanning in others) in different bands (devices with multiple equipment classes or those that operate on non- DFS frequencies) or modular devices which configure the modes of operations through software, the application must provide software and operations description on how the software and / or hardware is implemented to ensure that proper operations modes can not be modified by end user or an installer.  Apply  Does not apply (If apply, please help to provide explanation on it was implement, and how software was controlled) Best regards --------------------------------------- Razvan Bujila Global Type Approval Sony Mobile Communications AB Mobilvägen 10, SE-221 88 Lund, Sweden

Test report no.: 1-5831/13-11-01_AnnexA 2013-04-15 Page 1 of 5 Annex A This test report annex is electronically signed and valid without handwriting signature. For verification of the electronic signatures, the public keys can be requested at the testing laboratory. Test report annex authorised: Marco Bertolino Testing Manager Test report no.: 1-5831/13-11-01_AnnexA 2013-04-15 Page 2 of 5 External photos of the EUT Photo documentation: Photo 1: Test report no.: 1-5831/13-11-01_AnnexA 2013-04-15 Page 3 of 5 Photo 2: Photo 3: Test report no.: 1-5831/13-11-01_AnnexA 2013-04-15 Page 4 of 5 Photo 4: Photo 5: Test report no.: 1-5831/13-11-01_AnnexA 2013-04-15 Page 5 of 5 Document history Version Applied changes Date of release 1.0 Initial release 2013-04-15

Sony Mobile Communications Confidential DESIGN INFORMATION 1(3) Document number Revision 6/159 61-1/FCP 119 1315 Uen C Prepared by Date SEM/CGVOPPR NORIAKI TAIRA 2013-03-22 Contents responsible if other than preparer Remarks This document is managed in metaDoc. Approved by SEM/CGVOPPR (NORIAKI TAIRA) It is the responsibility of the user to ensure that they have a correct and valid version. Any outdated hard copy is invalid and must be removed from possible use. Commercial Name Type Number FCC ID IC SGP321 (Gina) TM-0030-BV PY7TM-0030 4170B-TM0030 SGP351 (Rex) TM-0020-BV PY7TM-0020 4170B-TM0020 SGP341 (Rita) TM-0020-CV PY7TM-0020 4170B-TM0020 1 Laser marking on bottom panel .................................................................. 2 2 CE marking and FCC ID ............................................................................. 3 3 Confidential DESIGN INFORMATION 2(3) Document number Revision 6/159 61-1/FCP 119 1315 Uen C 1 Laser marking on bottom panel SGP321 SGP351/SGP341 Confidential DESIGN INFORMATION 3(3) Document number Revision 6/159 61-1/FCP 119 1315 Uen C 2 CE marking and FCC ID

Test report no.: 1-5831/13-11-01_AnnexB 2013-04-15 Page 1 of 10 Annex B This test report annex is electronically signed and valid without handwriting signature. For verification of the electronic signatures, the public keys can be requested at the testing laboratory. Test report annex authorised: Marco Bertolino Testing Manager Test report no.: 1-5831/13-11-01_AnnexB 2013-04-15 Page 2 of 10 Internal photos of the EUT Photo documentation: Photo 1: Test report no.: 1-5831/13-11-01_AnnexB 2013-04-15 Page 3 of 10 Photo 2: Photo 3: Test report no.: 1-5831/13-11-01_AnnexB 2013-04-15 Page 4 of 10 Photo 4: Photo 5: Test report no.: 1-5831/13-11-01_AnnexB 2013-04-15 Page 5 of 10 Photo 6: Photo 7: Test report no.: 1-5831/13-11-01_AnnexB 2013-04-15 Page 6 of 10 Photo 8: Photo 9: Test report no.: 1-5831/13-11-01_AnnexB 2013-04-15 Page 7 of 10 Photo 10: Photo 11: Test report no.: 1-5831/13-11-01_AnnexB 2013-04-15 Page 8 of 10 Photo 12: Photo 13: Test report no.: 1-5831/13-11-01_AnnexB 2013-04-15 Page 9 of 10 Photo 14: Test report no.: 1-5831/13-11-01_AnnexB 2013-04-15 Page 10 of 10 Document history Version Applied changes Date of release 1.0 Initial release 2013-04-15

Page 1 of 7 Annex C Photo documentation Appendix to Test Report No.: 1-5831/13-26-02 Testing Laboratory CETECOM ICT Services GmbH Untertürkheimer Straße 6 – 10 66117 Saarbrücken/Germany Phone: + 49 681 5 98 - 0 Fax: + 49 681 5 98 - 9075 Internet: http://www.cetecom.com e-mail: [email protected] Accredited Test Laboratory: The testing laboratory (area of testing) is accredited according to DIN EN ISO/IEC 17025 (2005) by the Deutsche Akkreditierungsstelle GmbH (DAkkS) The accreditation is valid for the scope of testing procedures as stated in the accreditation certificate with the registration number: D-PL-12076-01-01 Annex C to Test report no.: 1-5831/13-26-02 Page 2 of 7 Photo 1: Measurement System DASY 5 Photo 2: DUT - front view Annex C to Test report no.: 1-5831/13-26-02 Page 3 of 7 Photo 3: DUT - top edge view Photo 4: DUT - rear view Annex C to Test report no.: 1-5831/13-26-02 Page 4 of 7 Photo 5: DUT - rear view (label) Photo 6: Test position rear side without any distance Annex C to Test report no.: 1-5831/13-26-02 Page 5 of 7 Photo 7: Test position rear side without any distance with headset Photo 8: Test position right side without any distance Annex C to Test report no.: 1-5831/13-26-02 Page 6 of 7 Photo 9: Test position top edge side without any distance Photo 10: Test position left edge side without any distance Annex C to Test report no.: 1-5831/13-26-02 Page 7 of 7 Photo 11: Test of the power back off function

Page 1 of 77 Annex E Appendix to Test Report No.: 1-5831/13-26-02 Testing Laboratory CETECOM ICT Services GmbH Untertürkheimer Straße 6 – 10 66117 Saarbrücken/Germany Phone: + 49 681 5 98 - 0 Fax: + 49 681 5 98 - 9075 Internet: http://www.cetecom.com e-mail: [email protected] Accredited Test Laboratory: The testing laboratory (area of testing) is accredited according to DIN EN ISO/IEC 17025 (2005) by the Deutsche Akkreditierungsstelle GmbH (DAkkS) The accreditation is valid for the scope of testing procedures as stated in the accreditation certificate with the registration number: D-PL-12076-01-01 Appendix with Calibration data, Phantom certificate and system check information 2013-04-18 Annex E to Test report no.: 1-5831/13-26-02 Page 2 of 77 1 Table of contents 1 Table of contents ....................................................................................................................................... 2 2 Calibration report “Probe ET3DV6” ......................................................................................................... 3 3 Calibration report “Probe EX3DV4” ...................................................................................................... 15 4 Calibration report “900 MHz System validation dipole” ...................................................................... 26 5 Calibration report “1800 MHz System validation dipole” .................................................................... 35 6 Calibration report “1900 MHz System validation dipole” .................................................................... 44 7 Calibration report “2450 MHz System validation dipole” .................................................................... 53 8 Calibration report “5GHz System check dipole” ................................................................................. 61 9 Calibration certificate of Data Acquisition Unit (DAE) ........................................................................ 70 10 Certificate of “SAM Twin Phantom V4.0/V4.0C’’ .......................................................................... 71 11 Application Note System Performance Check .............................................................................. 72 11.1 Purpose of system performance check ................................................................................. 72 11.2 System Performance check procedure .................................................................................. 72 11.3 Uncertainty Budget ................................................................................................................... 73 11.4 Power set-up for validation ...................................................................................................... 76 11.5 Laboratory reflection ................................................................................................................ 77 11.6 Additional system checks ........................................................................................................ 77 Annex E to Test report no.: 1-5831/13-26-02 Page 3 of 77 2 Calibration report “Probe ET3DV6” Annex E to Test report no.: 1-5831/13-26-02 Page 4 of 77 Annex E to Test report no.: 1-5831/13-26-02 Page 5 of 77 Annex E to Test report no.: 1-5831/13-26-02 Page 6 of 77 Annex E to Test report no.: 1-5831/13-26-02 Page 7 of 77 Annex E to Test report no.: 1-5831/13-26-02 Page 8 of 77 Annex E to Test report no.: 1-5831/13-26-02 Page 9 of 77 Annex E to Test report no.: 1-5831/13-26-02 Page 10 of 77 Annex E to Test report no.: 1-5831/13-26-02 Page 11 of 77 Annex E to Test report no.: 1-5831/13-26-02 Page 12 of 77 Annex E to Test report no.: 1-5831/13-26-02 Page 13 of 77 Annex E to Test report no.: 1-5831/13-26-02 Page 14 of 77 Annex E to Test report no.: 1-5831/13-26-02 Page 15 of 77 3 Calibration report “Probe EX3DV4” Annex E to Test report no.: 1-5831/13-26-02 Page 16 of 77 Annex E to Test report no.: 1-5831/13-26-02 Page 17 of 77 Annex E to Test report no.: 1-5831/13-26-02 Page 18 of 77 Annex E to Test report no.: 1-5831/13-26-02 Page 19 of 77 Annex E to Test report no.: 1-5831/13-26-02 Page 20 of 77 Annex E to Test report no.: 1-5831/13-26-02 Page 21 of 77 Annex E to Test report no.: 1-5831/13-26-02 Page 22 of 77 Annex E to Test report no.: 1-5831/13-26-02 Page 23 of 77 Annex E to Test report no.: 1-5831/13-26-02 Page 24 of 77 Annex E to Test report no.: 1-5831/13-26-02 Page 25 of 77 Annex E to Test report no.: 1-5831/13-26-02 Page 26 of 77 4 Calibration report “900 MHz System validation dipole” Annex E to Test report no.: 1-5831/13-26-02 Page 27 of 77 Annex E to Test report no.: 1-5831/13-26-02 Page 28 of 77 Annex E to Test report no.: 1-5831/13-26-02 Page 29 of 77 Annex E to Test report no.: 1-5831/13-26-02 Page 30 of 77 Antenna Parameters with Head TSL From cal. data Measured 2012-09-03 Impedance; transformed to feed point 49.8Ω - 5.0jΩ 45.6Ω +0.6jΩ Return Loss -26.0dB -23.6dB Antenna Parameters with Body TSL From cal. data Measured 2012-09-03 Impedance; transformed to feed point 45.8Ω - 6.4jΩ 45.5Ω +6.8jΩ Return Loss -22.0dB -20.5dB Annex E to Test report no.: 1-5831/13-26-02 Page 31 of 77 Annex E to Test report no.: 1-5831/13-26-02 Page 32 of 77 Annex E to Test report no.: 1-5831/13-26-02 Page 33 of 77 Annex E to Test report no.: 1-5831/13-26-02 Page 34 of 77 Annex E to Test report no.: 1-5831/13-26-02 Page 35 of 77 5 Calibration report “1800 MHz System validation dipole” Annex E to Test report no.: 1-5831/13-26-02 Page 36 of 77 Annex E to Test report no.: 1-5831/13-26-02 Page 37 of 77 Annex E to Test report no.: 1-5831/13-26-02 Page 38 of 77 Annex E to Test report no.: 1-5831/13-26-02 Page 39 of 77 Antenna Parameters with Head TSL From cal. data Measured 2012-09-03 Impedance; transformed to feed point 49.4Ω - 5.4jΩ 51.6Ω -6.2jΩ Return Loss -25.3dB -23.0dB Antenna Parameters with Body TSL From cal. data Measured 2012-09-03 Impedance; transformed to feed point 45.3Ω - 4.8jΩ 46.8Ω -7.…

Text truncated - open the document above for the full version.

Page 1 of 135 TEST REPORT Test Report No.: 1-5831/13-26-02 Testing Laboratory Applicant CETECOM ICT Services GmbH Untertürkheimer Straße 6 – 10 66117 Saarbrücken/Germany Phone: + 49 681 5 98 - 0 Fax: + 49 681 5 98 - 9075 Internet: http://www.cetecom.com e-mail: [email protected] Accredited Test Laboratory: The testing laboratory (area of testing) is accredited according to DIN EN ISO/IEC 17025 (2005) by the Deutsche Akkreditierungsstelle GmbH (DAkkS) The accreditation is valid for the scope of testing procedures as stated in the accreditation certificate with the registration number: D-PL-12076-01-01 Sony Mobile Communications AB Nya Vattentornet 22188 Lund/SWEDEN Phone: +46 46 19 30 00 Contact: Fredrik Björk e-mail: Fr [email protected] Phone: +46 1 08 01 46 75 Fax: +46 1 08 00 24 41 Manufacturer Sony Mobile Communications AB Nya Vattentornet 22188 Lund/SWEDEN Test Standard/s IEEE 1528-2003 Recommended Practice for Determining the Peak Spatial-Average Specific Absorption Rate (SAR)in the Human Head from Wireless Communications Devices: Measurement Techniques OET Bulletin 65 Supplement C Evaluating Compliance with FCC Guidelines for Human Exposure to Radiofrequency Electromagnetic Fields RSS-102 Issue 4 Radio Frequency Exposure Compliance of Radiocommunication Apparatus (All Frequency Bands) For further applied test standards please refer to section 3 of this test report. Test Item Kind of test item: Tablet PC Device type: portable device Model name: SGP351 S/N serial number: CB5A1PALR4 / CB5A1PALSP FCC-ID: PY7TM-0020 IC: 4170B-TM0020 IMEI-Number: 00440245-090548-8 / 00440245-090551-2 Hardware status: AP1 Software status: 10.1.1.A.1.11 / s_atp_pollux_us_0_0_36_6 Frequency: see technical details Antenna: integrated antenna Battery option: Integrated battery Accessories: Stereo headset MH-EX300AP SN: 1238SSP00000735 Test sample status: identical prototype Exposure category: general population / uncontrolled environment Test Report authorised: Test performed: 2013-04-18 Thomas Vogler 2013-04-18 Oleksandr Hnatovskiy Senior Testing Manager Testing Manager Test report no.: 1-5831/13-26-02 Page 2 of 135 1 Table of contents 1 Table of cont…

Text truncated - open the document above for the full version.
