Q2GIX104-119Tablet PC with Dual band WLAN mini PCI card

ix104USER’S HANDBOOK iX104 USER'S HANDBOOK 4 iX104 User’s Handbook Xplore Technologies ® has made every effort to ensure the accuracy and completeness of this document; however, because ongoing development efforts are made to continually improve the capabilities of our products, we cannot guarantee the accuracy of the contents of this document. We disclaim liability for errors, omissions, or future changes herein. Xplore and the Xplore logo are registered trademarks of Xplore Technologies Corp.; iX104 is a trademark of Xplore Technologies Corp. Kensington and MicroSaver are registered trademarks of the Kensington Technology Group. Microsoft is a registered trademark of Microsoft Corporation. Windows 2000 Professional, Windows XP Professional, and Windows XP Tablet PC Edition are trademarks of Microsoft Corporation. PCMCIA and CardBus are registered trademarks of the Personal Computer Memory Card International Association. Intel, Pentium, and SpeedStep are registered trademarks of Intel Corporation. Wi-Fi is a trademark of the Wireless Ethernet Compatibility Alliance (WECA). FireWire is a registered trademark of Apple Computer, Inc. ISODAMP is a registered trademark of Aearo Company. All other brands, product names, company names, trademarks and service marks used herein are property of their respective companies. Copyright © 2003 Xplore Technologies Corp. All rights reserved. No part of this publication may be copied, reproduced, or translated, without the prior written consent of Xplore Technologies. No part of this publication may be stored or transmitted in any electronic form without the prior consent of Xplore Technologies. Any unauthorized use is a violation of copyright laws. PN: 95-01016 Edition: Second, July 2003 DECLARATION OF CONFORMITY according to FCC Part 15 Responsible Party Name: Xplore Technologies Corp. Address: 14000 Summit Drive, Suite 900, Austin, Texas 78728 Telephone: 512.336.7797 Declares that product: Model Series: iX104 Complies with Part 15 of the FCC Rules iX104 User’s Handbook 5 This device complies with Part 15 of the FCC rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and, (2) This device must accept any interference received, including interference that may cause undesired operation. WARNING Changes or modifications to this unit not expressly approved by the party responsible for compliance may void the user’s authority to operate this equipment. For more information about FCC rules and their applicability to the iX104, see Appendix E, “Agency Notices.” Warranty Information The iX104 and iX104-TPC are backed by a standard 12-month International Limited Warranty. An extended International Limited Warranty is available. Check the service kit included with your computer for warranty terms and conditions. a 6 iX104 User’s Handbook Important safety information Before you use the iX104 or the iX104 dock, read these safety instructions and the operation instructions in this handbook. Failure to observe all these instructions voids the Limited Warranty and may lead to suspension or denial of services to the offender, or legal action, or both. Follow any special regulations governing the use of the computer and, if radio-enabled, always switch it off in areas where radio devices are forbidden or when the radio device can cause interference or danger. Always follow any safety laws and regulations pertaining to the use of cell phones and two-way radios, because these laws and regulations typically apply to the use of the wireless-enabled iX104. Observe all restrictions on the use of radio equipment in fuel depots (fuel storage and distribution areas), chemical plants, and wherever blasting operations are in progress or in any area in which restrictions on radio transmissions are imposed. Switch off the iX104 when in an aircraft. The iX104 is not FAA-approved for use on aircraft. The effect of the use of the iX104 in aircraft is unknown. Using the iX104 in an aircraft may affect aircraft instrumentation, communication, and performance; may disrupt the network; and may be illegal. Operating the wireless-enabled iX104 may interfere with the functioning of inadequately protected medical devices such as pacemakers. Consult a physician or the manufacturer of the medical device if you have any questions. Radio signals from your iX104 will not affect the operation of most modern equipment, but certain electronic equipment, including automotive systems, may not be shielded against radio signals from your iX104. Check with the manufacturer of your motor vehicle or the manufacturer’s representative to determine whether using the iX104 will present any safety issues. Avoid using the iX104 in any environment that requires your full attention, such as when driving a vehicle. If you need to use your iX104 while driving, have a passenger use it for you or find a safe location to halt your vehicle. iX104 User’s Handbook 7 WARNING Use only battery types specified in this handbook. Using any other type of battery can be dangerous and can disable the iX104. WARNING Do not use any dock or any other accessory or attachment that is not manufactured or supplied by Xplore or an authorized Xplore accessories supplier. Use of any accessory or attachment that is not supplied or approved for use with the iX104 by Xplore is not permitted because it may cause hazards. Operate the iX104 only from the type of power source indicated on the marking label. (See page 53 for more information about the battery and power supply.) Route power supply cords so that they are not likely to be walked on or pinched by items placed upon or against them. Pay particular attention to cords at plugs and convenience receptacles, and at the point where cords exit from the computer or its dock. Do not overload wall outlets, extension cords, or integral convenience receptacles because this can cause fire or electric shock. Unplug the iX104 and refer the iX10…

Text truncated - open the document above for the full version.

Xplore Technologies, Inc. 14000 Summit Road Suite 900 Austin, TX 78728 888-44-XPLORE Page 1 of 1 March 1, 2004 Federal Communication Commission Equipment Approval Service Attention: Authorization and Evaluation Division Reference: Xplore Technologies FCC ID: Q2GIX104-119 To Whom It May Concern: Subject: Request for Confidentiality Pursuant to Sections 0.457 (d)(1)(ii) and 0.459 of the Commission’s rules, the Applicant hereby requests confidential treatment of the Xplore Technologies supplied information accompanying this application. The confidential information includes the following: • Schematics • Block Diagrams • Bill of Materials • Operational Description • PCB Layout The materials contain trade secrets and proprietary information not customarily released to the public. Public disclosure of this information might be harmful to Xplore Technologies and provide unjustified benefits to our competitors. Xplore Technologies understands that pursuant to 0.457 (d)(1)(ii), disclosure of the Application and all accompanying documentation will not be made before the date of the grant.Best regards, Douglas L. Fowler Sr. Project Engineer Xplore Technologies, Inc.

Xplore Technologies, Inc. 14000 Summit Road Suite 900 Austin, TX 78728 888-44-XPLORE Page 1 of 1 5/3/2004 May 2, 2004 Reference: Xplore Technologies IC: 4596A-iX104GSM To Whom It May Concern: Subject: Declaration Xplore Technologies, Inc. declares that “The Tablet PC , model iX104, IC:4596A- iX104GSM that needs a class 2 change will have only WLAN transceivers at 2.4 GHz, 5.2GHz and 5.8 GHz bands, but only one transmitter can be turned on at any one time. Therefore there is no SAR co-location problem. Also, this tablet will not be sold with the 850/1900 MHz transceivers; thus the technical brief does not contain any test data on these frequencies.” Best regards, Douglas L. Fowler Sr. Project Engineer Xplore Technologies, Inc.

1 of 1 CETECOM Inc. 411 Dixon Landing Road Milpitas, CA 95035 U.S.A. Phone: + 1 408 586 6200 Fax: + 1 408 586 6299 e-mail: [email protected] URL: www.cetecom.com STATEMENT This filing constitutes a formal submittal and request for Equipment Authorization pursuant to Subpart C of Part 15 of FCC rules (CFR 47) regarding 2.4 & 5GHz WLAN in Tablet PC. Company Name: Xplore Technologies FCC ID: Q2GIX104-119 IC ID 4596A-iX104GSM Tablet PC model# iX104 WLAN Model# VM4-3B SUMMARY OF TESTING Xplore Tablet PC model# iX104 is equipped with WLAN model# VM4-3B; This radio is off-the shelf module and has not been modified since the FCC ID has been granted. Tablet PC iX104 provides new antenna to the module integrated in it. The radio in iX104 is not user accessible. EMC/Radio Test Reports: Test report no. EMC_620FCC15.247_2004 The above-mentioned test report covers all radiated measurements done on Tablet PC with WLAN in 2.4GHz band. Test report no. EMC_620FCC15.407_2004 The above-mentioned test report covers all radiated measurements done on Tablet PC with WLAN in 5GHz band. *Test report no. RF910819R02 The above-mentioned test report covers all conducted measurements required for WLAN in both 2.4 & 5GHz bands. *The FCC ID mentioned within the test report belongs to WLAN radio module used in this application. SAR Test Reports: Test report no. SAR_620_2004_FCC_2450 This test report covers SAR testing done on Tablet PC with WLAN in 2.4GHz band. SAR Test Reports: Test report no. SAR_620_2004_FCC_5000 This test report covers SAR testing done on Tablet PC with WLAN in 5GHz band. Harpreet Sidhu EMC & Radio Engineer

Answers to correspondence# 27033 RADIATED TESTS FOR SIMULTANEOUS TRANSMISSION Please refer to manufacturer’s declaration (“Declaration of intent_EM9”) that clearly states that EUT does not support simultaneous transmission for 2.4 & 5GHz bands. (Declaration uploaded). SAR 1. Please refer to manufacturer’s declaration (“Declaration of intent_EM9”) that clearly states that this model is not sold with any 850/1900MHz transceivers. (Declaration uploaded) 2. Please refer to updated test report. (report uploaded) 3. VPM was not used in 2.4 GHz testing. VPM corrections can be used at any frequency, but will normally only be needed and used for +5 GHz testing. When VPM correction is used we will make sure that it is clearly stated in the test report. 4) The plot is a 2 dimensional representation of the zoom scan overlayed on the phantom outline to show the location of the maximum SAR. It does not show extrapolated to surface values. Due to limitations in the graphics exporting functions some of the finer peaks, which are common above 5 GHz, will not show on the plot page. 5) There are no user-selectable parameters for VPM correction. All of the parameters used for VPM correction are determined during calibration of the SAR probe. 6) See attached pictures.(two pictures uploaded)

iX104: Exterior - F ront iX104: Exterior - B ack FCC Label iX104: Exterior – B attery Pack Removed iX104: Antenna Locations Wide A r ea Network AntennaLocal Area NetworkAntenna iX104: I/O PCB

Page 1 ANNEX PHOTOGRAPHS OF EUT Page 2 Page 6 Page 7 Page 8 Page 9

Label & Label Location FCC ID: Q2GIX104-119, IC ID: 4596A-iX104GSM FCC ID: Q2GIX104-119 IC ID: 4596A-iX104GSM Label & Label Location FCC ID: Q2GIX104-119, IC ID: 4596A-iX104GSM FCC ID: Q2GIX104-119 IC ID: 4596A-iX104GSM

iX104: Antenna Cavities WAN Antenna LAN Antenna WLAN iX104: Main Logic Board iX104: Keypad PCB iX104: I/O PCB iX104: I/O PCB Removed

Page 3 Page 4 Page 5

SAR Test Report No.: SAR_620_2004_FCC_2450 Date of Report: 04/15/2004 Appendix A Plots Page 1 of 4 Date / Time: 3/23/2004 1:20:47 PM Position: Lap Filename: *.txt Phantom: HeadBox_new_spout.csv Device Tested: Xplore Head Rotation: 0 Antenna: internal Test Frequency: 2437 Shape File: xplor802lap.csv Power Level: max Probe: 0106 Cal File: 106_2450_BODY_802_11 X Y Z Air 415 805 371 DCP 19 19 19 Cal Factors: Lin 0.585 0.585 0.585 Amp Gain: 32 Averaging: 6 Batteries Replaced: 03/23/04 Liquid: 2450 Type: Body Conductivity: 1.927 Relative Permittivity: 50.96 Liquid Temp (deg C): 22.0 Ambient Temp (deg C): 22.0 Ambient RH (%): 50 Density (kg/m3): 1000 Software Version: 0.420 ZOOM SCAN RESULTS: Start Scan End Scan Spot SAR (W/kg): 0.001 0.001 Change during Scan (%) 0.18 Max E-field (V/m): 2.30 1g 10g Max SAR (W/kg) 0.007 0.003 X Y Z Location of Max (mm): 75.0 -36.0 -172.8 AREA SCAN: Min Max Steps Y -80.0 20.0 10.0 Scan Extent: Z -200.0 -120.0 10.0 SAR Test Report No.: SAR_620_2004_FCC_2450 Date of Report: 04/15/2004 Appendix A Plots Page 2 of 4 Date / Time: 3/23/2004 1:49:10 PM Position: rear bystander touching phantom Filename: *.txt Phantom: HeadBox_new_spout.csv Device Tested: Xplore Head Rotation: 0 Antenna: internal Test Frequency: 2437 Shape File: xplor802bystand.csv Power Level: max Probe: 0106 Cal File: 106_2450_BODY_802_11 X Y Z Air 415 805 371 DCP 19 19 19 Cal Factors: Lin 0.585 0.585 0.585 Amp Gain: 32 Averaging: 6 Batteries Replaced: 03/23/04 Liquid: 2450 Type: Body Conductivity: 1.927 Relative Permittivity: 50.96 Liquid Temp (deg C): 22.0 Ambient Temp (deg C): 22.0 Ambient RH (%): 50 Density (kg/m3): 1000 Software Version: 0.420 ZOOM SCAN RESULTS: Start Scan End Scan Spot SAR (W/kg): 0.005 0.005 Change during Scan (%) 0.00 Max E-field (V/m): 4.85 1g 10g Max SAR (W/kg) 0.033 0.016 X Y Z Location of Max (mm): 75.0 0.0 -148.8 AREA SCAN: Min Max Steps Y -20.0 80.0 10.0 Scan Extent: Z -200.0 -120.0 10.0 SAR Test Report No.: SAR_620_2004_FCC_2450 Date of Report: 04/15/2004 Appendix A Plots Page 3 of 4 Date / Time: 3/23/2004 2:15:30 PM Position: rear bystander touching phantom Filename: *.txt Phantom: HeadBox_new_spout.csv Device Tested: Xplore Head Rotation: 0 Antenna: internal Test Frequency: 2412 Shape File: xplor802bystand.csv Power Level: max Probe: 0106 Cal File: 106_2450_BODY_802_11 X Y Z Air 415 805 371 DCP 19 19 19 Cal Factors: Lin 0.585 0.585 0.585 Amp Gain: 32 Averaging: 6 Batteries Replaced: 03/23/04 Liquid: 2450 Type: Body Conductivity: 1.861 Relative Permittivity: 50.96 Liquid Temp (deg C): 22.0 Ambient Temp (deg C): 22.0 Ambient RH (%): 50 Density (kg/m3): 1000 Software Version: 0.420 ZOOM SCAN RESULTS: Start Scan End Scan Spot SAR (W/kg): 0.017 0.017 Change during Scan (%) -0.08 Max E-field (V/m): 7.08 1g 10g Max SAR (W/kg) 0.071 0.038 X Y Z Location of Max (mm): 75.0 0.0 -149.9 AREA SCAN: Min Max Steps Y -20.0 80.0 10.0 Scan Extent: Z -200.0 -120.0 10.0 SAR Test Report No.: SAR_620_2004_FCC_2450 Date of Report: 04/15/2004 Appendix A Plots Page 4 of 4 Date / Time: 3/23/2004 2:59:28 PM Position: rear bystander touching phantom Filename: *.txt Phantom: HeadBox_new_spout.csv Device Tested: Xplore Head Rotation: 0 Antenna: internal Test Frequency: 2462 Shape File: xplor802bystand.csv Power Level: max Probe: 0106 Cal File: 106_2450_BODY_802_11 X Y Z Air 415 805 371 DCP 19 19 19 Cal Factors: Lin 0.585 0.585 0.585 Amp Gain: 32 Averaging: 6 Batteries Replaced: 03/23/04 Liquid: 2450 Type: Body Conductivity: 1.968 Relative Permittivity: 50.80 Liquid Temp (deg C): 22.0 Ambient Temp (deg C): 22.0 Ambient RH (%): 50 Density (kg/m3): 1000 Software Version: 0.420 ZOOM SCAN RESULTS: Start Scan End Scan Spot SAR (W/kg): 0.013 0.013 Change during Scan (%) 0.00 Max E-field (V/m): 6.58 1g 10g Max SAR (W/kg) 0.065 0.037 X Y Z Location of Max (mm): 75.0 1.0 -150.1 AREA SCAN: Min Max Steps Y -20.0 80.0 10.0 Scan Extent: Z -200.0 -120.0 10.0

SAR Test Report No.: SAR_620_2004_FCC_2450 Date of Report 4/15/2004 Appendix B Page 1 of 6 Appendix B: Photos EUT Photos: Photo 1. Antenna locations SAR Test Report No.: SAR_620_2004_FCC_2450 Date of Report 4/15/2004 Appendix B Page 2 of 6 Photo 2. EUT front SAR Test Report No.: SAR_620_2004_FCC_2450 Date of Report 4/15/2004 Appendix B Page 3 of 6 Photo 3. EUT back SAR Test Report No.: SAR_620_2004_FCC_2450 Date of Report 4/15/2004 Appendix B Page 4 of 6 Setup Photos Photo 4. Bystander position SAR Test Report No.: SAR_620_2004_FCC_2450 Date of Report 4/15/2004 Appendix B Page 5 of 6 Photo 5. Lap position SAR Test Report No.: SAR_620_2004_FCC_2450 Date of Report 4/15/2004 Appendix B Page 6 of 6 Photo 6. Photo to demonstrate 15 cm Z-axis flat phantom

SAR Test Report No.: SAR_620_2004_FCC_2450 Date of Report: 4/15/2004 Appendix C Page 1 of 36 1 Tissue Parameters 2450MHz Head liquid: Recipe: 53.74% distilled water 22.59% DGBE 22.59% triton X-100 0.98% salt 0.1% bactericide Di-electric constants measured on 3/23/2004. SAR measurements were made within 24 hours of the measurement of liquid parameters. Freq. Rel. Condy (MHz) Perm. (S/m) 2450 38.57 1.872 2450MHz Body Liquid: Recipe: 73.3% distilled water 12.88% DGBE 12.88% triton X-100 0.84% salt 0.1% bactericide Di-electric constants measured on 3/23/2004. SAR measurements were made within 24 hours of the measurement of liquid parameters. Freq. Rel. Condy (MHz) Perm. (S/m) 2412 50.96 1.861 2437 50.96 1.927 2462 50.80 1.968 Environment: 3/23/2004: Temperature: 20.1 °C – 23.9°C Humidity: 45% _ 55 % SAR Test Report No.: SAR_620_2004_FCC_2450 Date of Report: 4/15/2004 Appendix C Page 2 of 36 2 Test Equipment Instrument description Supplier / Manufacturer Model Serial No. Calibration (date) Calibration Due (date) Bench top Robot Mitsubishi supplied by IndexSAR RV-E2 EA1030108 N/A N/A SAM Phantom Upright shell phantom made by Antennessa digitized and mounted by IndexSAR SAM 03FT26 04/03 N/A Flat Phantom IndexSAR HeadBox_Spout N/A N/A N/A Software IndexSAR SARA2 v0.420 N/A N/A N/A 2450 MHz Head Tissue Simulant Cetecom Inc. 2450 Head N/A 3/23/2004 N/A 2450 MHz Body Tissue Simulant Cetecom Inc. 2450 Body N/A 3/23/2004 N/A 2450 MHz Dipole IndexSAR – IEEE 1528 design IXD-245 245-0016 07/20/2003 07/20/2004 Netwok Analyzer Agilent 8753ES US39172511 04/22/2003 04/22/2004 Signal generator Rohde and Schwartz SMP02 830228/009 05/10/2003 05/10/2004 Directional coupler Werlatone C6529 11249 N/A N/A RF Amplifier Vectawave VTL5400 N/A N/A N/A Power Meter HP EPM-442A GB37170232 8/19/2003 8/19/2004 Power Sensor HP 8481A 1926A20587 8/19/2003 8/19/2004 Power Sensor HP 8481H 3318A15893 2/10/2004 2/10/2005 SAR Probe IndexSAR IXP-050 S/N 0106 7/15/2003 7/15/2004 Probe amplifier IndexSAR IXA-010 S/N 043 N/A N/A Thermometer Control Company 4039 20410549 11/20/2001 11/20/2004 Dielectric Measurement Kit IndexSAR Di-Line N/A N/A N/A Test Equipment Model Serial SAR Test Report No.: SAR_620_2004_FCC_2450 Date of Report: 4/15/2004 Appendix C Page 3 of 36 3 Equipment Calibration/Performance Documents: Validation Dipoles Performance Measurements: Pages 4 to 9. Immersible SAR probe Calibration Report: Pages 10 to 36 Please Note: (The following pages of Appendix C show calibration documents. These calibration documents are inserted into this appendix. The header information with page numbering scheme is a part of this report and is included on all pages of the report and appendixes. This header is used to track all of the contents of this report.) SAR Test Report No.: SAR_620_2004_FCC_2450 Date of Report: 4/15/2004 Appendix C Page 4 of 36 4 Report No. SN0016_090-180-245 July 1 st 2002 INDEXSAR Validation Dipoles Type IXD-090, IXD-180 & IXD-245 Performance measurements S/N: 090-0016 S/N: 180-0016 S/N: 245-0016 MI Manning Indexsar, Oakfield House, Cudworth Lane, Newdigate, Surrey RH5 5DR. UK. Tel: +44 (0) 1306 631233 Fax: +44 (0) 1306 631834 e-mail: [email protected] SAR Test Report No.: SAR_620_2004_FCC_2450 Date of Report: 4/15/2004 Appendix C Page 5 of 36 5 1. Measurement Conditions Measurements were performed using a box-shaped phantom made of PMMA with dimensions designed to meet the accuracy criteria for reasonably-sized phantoms that do not have liquid capacities substantially in excess of the volume of liquid required to fill the Indexsar upright SAM phantoms used for SAR testing of handsets against the ear. An HP 8753B vector network analyser was used for the return loss measurements. The dipole was placed in a special holder made of low-permittivity, low-loss materials. This holder enables the dipole to be positioned accurately in the centre of the base of the Indexsar box-phantom used for flat-surface testing and validation checks. The validation dipoles are supplied with special spacers made form a low-permittivity, low-loss foam material. These spacers are fitted to the dipole arms to ensure that, when the dipole is offered up to the phantom surface, the spacing between the dipole and the liquid surface is accurately aligned according to the guidance in the relevant standards documentation. The spacers are rectangular with a central hole equal to the dipole arm diameter and dimensioned so that the longer side can be used to ensure a spacing of 15mm from the liquid in the phantom (for tests at 900MHz and below) and the shorter side can be used for tests at 1800MHz and above to ensure a spacing of 10mm from the liquid in the phantom. The spacers are made on a CNC milling machine with an accuracy of 1/40 th mm but they may suffer wear and tear and need to be replaced periodically. The material used is Rohacell, which has a relative permittivity of approx. 1.05 and a negligible loss tangent. The apparatus supplied by Indexsar for dipole validation tests thus includes: Balanced dipoles for each frequency required are dimensioned according to the guidelines given in IEEE 1528 [1]. The dipoles are made from semi-rigid 50 ohm co-ax, which is joined by soldering and is gold-plated subsequently. The constructed dipoles are easily deformed, if mis-handled, and periodic checks need to be made of their symmetry. Rohacell foam spacers designed for presenting the dipoles to 2mm thick PMMA box phantoms. These components also suffer wear and tear and should be replaced when the central hole is a loose-fit on the dipole arms or if the edges are too worn to ensure accurate alignment. The standard spacers are dimensioned for use with 2mm wall thickness (additional spacers are available for 4mm wall thickness). 2. SAR Measurement SAR Test Report No.: SAR_620_2004_FCC_2450 Date of Report: 4/15/2004 Appendix C Page 6 of 36 6 SAR validation checks using the dipoles can be performed with the box-phantom located on the SARA2 phantom supp…

Text truncated - open the document above for the full version.

TTI-P-G 081/94-A0 Accredited according to ISO/IEC 17025 Bluetooth Qualification Test Facility (BQTF) FCC listed # 101450 IC recognized # 3925 CETECOM Inc. 411 Dixon Landing Road Š Milpitas, CA 95035 Š U.S.A. Phone: + 1 (408) 586 6200 Š Fax: + 1 (408) 586 6299 Š E-mail: [email protected] Š http://www.cetecom.com CETECOM Inc. is a Delaware Corporation with Corporation number: 2113686 Board of Directors: Dr. Harald Ansorge, Dr. Klaus Matkey, Hans Peter May V.2.16M-2002-03-12 \\stupendousman\rootappsdata\emc\projects_emc\xplore\620-2004_ix104+vm4- 3b\sar\report\2_4ghz\sar_620_2004_fcc_2450_rev1.doc © Copyright by CETECOM SAR Test Report No.: SAR_620_2004_FCC_2450_REV1 for the Xplore Technologies Personal Computer Tablet Model Number: iX104 FCC ID: Q2GIX104-119 Date of Report: 4/15/2004 Date of issue: 4/15/2004 Report Copy No.: 02 SAR Test Report No. SAR_620_2004_FCC_2450_REV1 Date of Report: 4/15/2004 Page 2 of 28 Error! Reference source not found. This report shall not be reproduced except in full without the written approval of: CETECOM Inc. Š SAR Š 411 Dixon Landing Road Š Milpitas, CA 95035 Š U.S.A. Contents 1 ASSESSMENT ...................................................................................................................4 2 ADMINISTRATIVE DATA...................................................................................................5 2.1 Identification of the Testing Laboratory Issuing the SAR Assessment Report ...............5 2.2 Identification of the Client...........................................................................................5 2.3 Identification of the Manufacturer...............................................................................5 3 EQUIPMENT UNDER INVESTIGATION (EUI)...................................................................6 3.1 Identification of the Equipment under Investigation ...................................................6 3.2 Front View of the Equipment under Investigation ......................................................7 4 SUBJECT OF INVESTIGATION ........................................................................................8 4.1 The IEEE Standard C95.1 and the FCC Exposure Criteria .......................................8 4.2 Distinction Between Exposed Population, Duration of Exposure and Frequencies...8 4.3 Distinction between Maximum Permissible Exposure and SAR Limits......................9 4.4 SAR Limit ...................................................................................................................9 5 THE FCC MEASUREMENT PROCEDURE .....................................................................10 5.1 General Requirements.............................................................................................10 5.2 Device Operating Next to a Person’s Ear ................................................................10 5.3 Test Positions ..........................................................................................................11 5.4 Test positions of device relative to head..................................................................11 5.5 Test to be Performed ...............................................................................................14 5.6 Body-worn and Other Configurations.......................................................................14 5.7 Procedure for assessing the peak spatial-average SAR .........................................15 5.8 Determination of the largest peak spatial-average SAR ..........................................17 6 THE MEASUREMENT SYSTEM ......................................................................................18 6.1 Robot system specification ......................................................................................18 6.2 Probe and amplifier specification .............................................................................19 6.3 Phantoms.................................................................................................................19 6.4 SAR measurement procedure .................................................................................20 SAR Test Report No. SAR_620_2004_FCC_2450_REV1 Date of Report: 4/15/2004 Page 3 of 28 Error! Reference source not found. This report shall not be reproduced except in full without the written approval of: CETECOM Inc. Š SAR Š 411 Dixon Landing Road Š Milpitas, CA 95035 Š U.S.A. 6.5 SARA2 Interpolation and Extrapolation schemes ....................................................20 6.6 Interpolation of 2D area scan...................................................................................21 6.7 Extrapolation of 3D scan..........................................................................................21 6.8 Interpolation of 3D scan and volume averaging.......................................................21 7 UNCERTAINTY ASSESSMENT.......................................................................................23 7.1 Table of Measurement Uncertainty Values of SAR Evaluations..............................24 7.2 Table of Measurement Uncertainty Values for SAR System Verification ................25 8 TEST RESULTS SUMMARY............................................................................................26 8.1 Conducted Output Power.........................................................................................26 8.2 Test Positions and Configurations ...........................................................................26 8.3 2450 MHz band SAR Results for iX104...................................................................27 8.4 Validation Check Results .........................................................................................27 9 REFERENCES..................................................................................................................28 SAR Test Report No. SAR_620_2004_FCC_2450_REV1 Date of Report: 4/15/2004 Page 4 of …

Text truncated - open the document above for the full version.

5250 MHz verification 3/30/2004: 5800 MHz verification 4/1/2004: 2450 MHz verification 3/23/2004: Date / Time: 3/23/2004 11:53:54 AM Position: verification Filename: *.txt Phantom: HeadBox_new_spout.csv Device Tested: System Head Rotation: 0 Antenna: dipole 2450 Test Frequency: 2450 Shape File: Dipole1800.csv Power Level: 1 Watt Probe: 0106 Cal File: 106_2450_HEAD X Y Z Air 415 805 371 DCP 20 20 20 Cal Factors: Lin 0.480 0.480 0.480 Amp Gain: 2 Averaging: 6 Batteries Replaced: 03/23/04 Liquid: 2450 Type: Head Conductivity: 1.872 Relative Permittivity: 38.57 Liquid Temp (deg C): 22.0 Ambient Temp (deg C): 22.0 Ambient RH (%): 50 Density (kg/m3): 1000 Software Version: 0.420 ZOOM SCAN RESULTS: Start Scan End Scan Spot SAR (W/kg): 9.762 9.789 Change during Scan (%) 0.28 Max E-field (V/m): 182.73 1g 10g Max SAR (W/kg) 51.081 24.467 X Y Z Location of Max (mm): 75.1 -16.8 -145.0 AREA SCAN: Min Max Steps Y -40.0 40.0 10.0 Scan Extent: Z -180.0 -110.0 10.0

FCC ID: NKRVM43B Report No.: RF910819R02 1 Issued: Sep. 17, 2002 FCC TEST REPORT REPORT NO.: RF910819R02 MODEL NO.: VM4-3B RECEIVED: Aug. 19, 2002 TESTED: Sep. 3 ~ Sep. 10, 2002 APPLICANT:Wistron NeWeb Corp. ADDRESS: No. 10-1, Li-hsin Road I, Science-based Industrial Park, Hsinchu 300, Taiwan, R.O.C. ISSUED BY:Advance Data Technology Corporation LAB LOCATION:47 14 th Lin, Chiapau Tsun, Linko, Taipei, Taiwan, R.O.C. This test report consists of 183 pages in total. It may be duplicated completely for legal use with the approval of the applicant. It should not be reproduced except in full, without the written approval of our laboratory. The client should not use it to claim product endorsement by CNLA, NVLAP or any government agencies. The test results in the report only apply to the tested sample. 0528 ILAC MRA Lab Code: 200102-0 FCC ID: NKRVM43B Report No.: RF910819R02 2 Issued: Sep. 17, 2002 Table of Contents 1CER…
