Q2I202401GWireless Door Chime

Trouble shooting 1. Check doorbell receiver volume, make sure it is not in lowest mode. 2. Ensure push button is not mounted on metal, near metal studs or near the floor. 3. Try a new location for the Doorbell. Functional range may be adversely affected by one or more of the following factors: weather, radio frequency interference, low transmitter battery or obstructions between the transmitter and receiver. 4. If the Doorbell and push button(s) do not operate, please clear doorbell setting, then pair push button and receiver again. Clear setting and pairing steps as above (Fig4 to Fig 7). Features: Content: 1. Wireless Plug-in Doorbell 2. Operating range up to 150 metres on open air. 3. 32 sounds selectable on receiver,4 volume level selectable. 4. With Self-learning technology. 5. Power supply: bell push 1pc CR2032 battery, receiver: 110V AC power. Receiver unit US Plug Clear setting: Fig.4 A.Power off receiver, keep holding “melody selection /pairing button” and plug into socket to power on. B.Wait for around 5 seconds, you will hear 2 “Ding Dong” sounds, which means receiver disconnect with all push buttons. Fig.8 C.Press “melody selection / pairing button” of receiver to confirm action at last, push button and receiver finished pairing(Fig.8). Fig.3 Volume selection: Press “volume control” button on receiver directly to set volume (There are 4 levels volume, volume changes by each pressing), choose volume you need. Fig.6 B.(Please finish this step within 30 seconds) Press push button needed one time, receiver will make a “Ding” indicate sound (Fig.6) . If there are 2 push buttons needed, please press the second push button successively(Fig.7). First push button Fig.7 The second push button Melody selection: Press “melody selection/pairing button” on receiver directly to set melody(There are 32 melodies optional, melody changes by each pressing), choose melody you need. Fig.5 A.Keep holding “melody selection /pairing button” of receiver for around 5 seconds, receiver will make “Ding Ding” indicate sound: it entered pairing mode (release “melody selection/pairing button”) Fig .5. Pairing Step: This push button and receiver have been paired in factory. If you need to add an extra push button or receiver, please follow the steps below. G Wireless door chime Transmitter unit “Ding Dong” 4s “Ding” “Ding” “Ding Dong” 4s Melody Selection/Pairing Button Volume Control 1pc transmitter, 1pc receiver, 1pc CR2032 battery, 2 pcs screws and knot, 1pc double tape, 1pc user manual. Fig. 2 Method 2 Screw Mounting Screws Fig. 1 Method 1 Adhesive patch mounting Adhesive Tape CR2032 3V battery Use flat screw driver to push the hole, to open the cover. Push button 0 , 5 W ~ 60 H z 0 V W , 90 - 110 N . A . 1 0 m R ece i v e r 80 d B N . A R a d i o T r a n s m i ss i ∽ AI t e rna t i v e C urre n t ( A C ) =- D i rec t C u r r en t ( D T r a nsm i tt e 4 33 . 0 5 0 M H z - 4 3 4 . 7 90 M - 4 3 4 . 7 90 MH 4 33 . 0 5 0 M H 1 5 0 1 5 0 回 E q u i p men t w i t hl e v e l c l a ss l 5 0 °C - 2 0 °C t o 5 0 o °C m - 2 0 ° C t FF r o I n d oo r use on l P us h B u tt o D oo r b e l l n y m r o l m m z z H z r C on . W 3 V 5 - V o l t a g e M a x P o w e P o w e r ( m a x S o u n d l ev e l ( m ax / r e c e i v e R a d i o T r a n s m i t t e R a d i o F r e q u e n c d O p t e a a n t c n e g max i s i tem p r e a r i a n t g O pe t ure r ( ) y r i ) ) r RE CO MME N DAT IONS 1 . T hi s p ro d u c t i s no t s u i t a b l e f o r p eo p l e w i t h h ea r t p acema k er s , an d d oe s no t a d a p t t o t h e u senea r h os p i t a l s a n d m e d i ca l f a c i li t i e s . 2 . U s e t hi s p r o d uc t i n t h e f o ll o w i n g p l a c e s m a y s h o r t e n r e m o t e con t r o l d i s t a n ce , e v en f u nc t i on f a i l u re : - b e ll p us h a n d r ece i v e r h a v e m e t a l d oo r s a n d w i n d o w s a n d r e i n f o r ce d co n c r e t e b u i l d i n g s t r u c t u r e b l oc k . - w a ll h a s a me t a l f i l m i ns u l a t i o n m a t e r i a l . - a r ou n d h a v e m o r e m e t a l f u rn i t u r e o r ca b i n e t s . - i ns t a ll t h e b e l l p us h w i t h s t a i n l ess s t ee l s t r i p s s h a d e - b e ll p us h e q u i p p e d w i t h hidd en i ns id e a w a l l . 3 . A s o n e o f t h e f o l l o w i n g a pp l i a n ces i n u se a r o u n d m a y a l so a f f e c t t h e p r o d uc t p e r f o rm a nce . - co m p u t e r s , m i cro w a v e o v en s , w i r e l ess i n t e r c om , w i re l e ss com p o s i t e a i rcr a f t , t h e RF w i r e l ess r em o t e con t r o l , l o w f r e q u en c y , hi g h f r e q u enc y , o r m i c r o w a v e t h e r a py a pp a r a t u s , nea r t h e TV b r oa d cas t i n g , a v a r i e t y o f w i r e l ess r a di o , ce l l p h one t o w er s , hi g h v o l t a g e t r a ns m i ss i on li ne . W arn i n g 1 . K e e p m i n i m u m di s t an c e ( 1 0 cm , w e su gg e s t , c o u ld c h a n g e ) a r ou n d t h e a p p a r a t us f o r su f i c i e n t v e n t i l a l t i o n . 2 . T h e v e n t i l a t i o n s h o u ld n o t b e i m p e d e d b y co v er i n g t h e v e n t il a t i o n o p e n i n g s w i t h i t e ms , suc h as n e w s p a p e r s , t a b l ec l o t h s , c u r t a i n s , e t c . 3 . N o na k e d fi r e s o u rces , s u c h a s l i g h t e d can dl e s , s h o u l d b e p l ace d on t h e a pp a r a t us . 4 . T hi s d oor c hi me rece i v e r i s i n t e n d e d f o r i n d oor u se on l y . D o no t e x p o s e t o c o n t i n u o u s d i r ec t s u n l i g h t o r h um i d en v i r onme n t - t h i s w i ll a d v e r se l y a f f e c t t h e u n i t . M a x i m u m o p e r a t i n g t em p e r a t u r e 5 0 C 5 . T h i s a pp l i an c e i s no t i n t en d e d f o r use b y p e r s on s ( i n c l u d i n g c hild r e n ) w i t h di sa b i l t i e s or i n t e ll ec t u a l di s a bil t e s , o r l a c k o f e x p e r i ence an d k no w l e d g e . FCC COMPLIANCE STATEMENT: This device complies with part 15…

Text truncated - open the document above for the full version.

1/1 FCC US Agent, LLC US Agent for Service of Process LETTER OF ATTESTATION TO: Office of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 US Agent for Service of Process: Company Name: FCC US Agent, LLC FRN: 0033402884 Contact Name: Tim Payne Address: 3722 Illinois Avenue, Saint Charles, IL, 60174, USA Telephone No: 708-571-3148 Email: [email protected] Applicant: Company name: FOSHAN SHUNDE ADVANTE ELECTRON LTD. Product Description: Wireless Door Chime Grantee code: Q2I FCC ID: Q2I202401G FRN： 0008596090 Contact Name: Steven Zou Address: North Second XinXi Road, LunJiao Industrial Avenue, LunJiao, Shunde, Foshan, Guangdong, China Telephone No: 86-757-29995218 Extension: 333 Email: [email protected] [FOSHAN SHUNDE ADVANTE ELECTRON LTD.] certifies that, as of the date of this filing of the application with the TCB, [FCC US Agent, LLC] is our designated US agent for service of process for the above referenced FCC ID. [FOSHAN SHUNDE ADVANTE ELECTRON LTD.] accepts to maintain an agent for no less than one year after the grantee has terminated all marketing and importation or the conclusion of any commission related proceeding involving equipment. [FCC US Agent, LLC] accepts, as of the date of the filing of the application, the obligation of the designated US agent for service of process for the above reference FCC ID. The US Agent for Service of Process is aware of and agrees to comply with the requirements outlined in the FCC Equipment Authorization Program, Report and Order FCC 22-84, and clause § 2.911. The Applicant is aware of and agrees to comply with the requirements outlined in the FCC Equipment Authorization Program, Report and Order FCC 22-84, and clause § 2.911. Date: 2024/09/13 Applicant’s Name: Steven Zou US Agent’s Name: Tim Payne Title:Technical Manager Title: Manager Signature Signature

C5266091_X24_Ed.2 1/1 “Attestation Statements” TO: Office of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 The Commission adopted rules that prohibit equipment authorization for “covered” telecommunications equipment and video surveillance equipment produced by entities identified on the Commission’s Covered List 1 , which is periodically updated. See the Covered List for more details. This Attestation Statement is to confirm that we follow the Section 2.911(d)(5)(i)-(ii) Applicant Company name: FOSHAN SHUNDE ADVANTE ELECTRON LTD. Grantee code: Q2I FRN: 0008596090 FCC ID: Q2I202401G Contact Name: Steven Zou Address: North Second XinXi Road, LunJiao Industrial Avenue, LunJiao, Shunde, Foshan, Guangdong, China Telephone No: 86-757-29995218 Extension: 333 Fax No: 86-757-25663105 Email: [email protected] i. [FOSHAN SHUNDE ADVANTE ELECTRON LTD.] (“the applicant”) certifies that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. The applicant must sign this certification. ii. [FOSHAN SHUNDE ADVANTE ELECTRON LTD.] (“the applicant”) certifies that, as of the date of the filing of the application, the applicant [is not] (as a specifically named entity or any of its subsidiaries or affiliates) identified on the Covered List as an entity producing “covered” equipment. The applicant must sign this certification. [ FOSHAN SHUNDE ADVANTE ELECTRON LTD.] (“the applicant”) certifies that, as of the date of the filing of the application, the applicant [is not] identified on the Covered List as an entity producing “covered” equipment . Date: 08/20/2024 Applicant’s Name: Steven Zou Title: Technical Manager Signature 1 The Commission’s Covered List is published by the Public Safety and Homeland Security Bureau and posted on the Commission’s website. This Covered List, which is periodically updated, identifies particular equipment, produced by particular entities, that constitutes “covered” equipment. https://www.fcc.gov/supplychain/coveredlist

FOSHAN SHUNDE ADVANTE ELECTRON LTD. North Second XinXi Road, LunJiao Industrial Avenue LunJiao, Shunde, Foshan, Guangdong, China Product Similarity Declaration Product name: Wireless Door Chime Model name: G, GP, FL, FLP, FLD, FY FCC ID: Q2I202401G We (FOSHAN SHUNDE ADVANTE ELECTRON LTD.) hereby state that all the models are electrical identical including the same hardware design (i.e., circuit design, PCB Layout, RF module/circuit, antenna type(s) and antenna location, components on PCB, etc.,), The differences are model name due to marketing purpose. Please kindly handle on the project. Signature: Name: Steven Zou Title: Technical Manager 2024/08/20

C5266091_X8_Ed.1 1/1 Letter of Authorization Company: FOSHAN SHUNDE ADVANTE ELECTRON LTD. Address: North Second XinXi Road, LunJiao Industrial Avenue, LunJiao, Shunde, Foshan, Guangdong, China Product Name: Wireless Door Chime Model Number: G, GP, FL, FLP, FLD, FY FCC Identifier: Q2I202401G We authorize LGAI Technological Center S.A., Ronda de la Font del Carme, s/n, 08193 Bellaterra, Spain, to act on our behalf on all matters concerning the above named equipment. Any individual within LGAI Technological Center S.A. is authorized to act on our behalf and take action on the application. We declare that authorize LGAI Technological Center S.A., Ronda de la Font del Carme, s/n, 08193 Bellaterra, Spain, is allowed to forward all information related to the approval project to the Federal Communication Commission and to discuss any issues concerning the approval application. Any and all acts carried out by LGAI Technological Center S.A. on our behalf shall have the same effect as acts of our own. Name: Steven Zou Date: 08/20/2024 Title: Technical Manager Signature of applicant:

C5266091_X10_Ed.1 1/1 FOSHAN SHUNDE ADVANTE ELECTRON LTD. Office of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 Date: 08/20 /2024 Subject: Request for Confidentiality FCC ID: Q2I202401G To Whom It May Concern, Pursuant to the provisions of Sections 0.457 and 0.459 of Commission's rules (47CFR0.457, 0.459), we are requesting the Commission to withhold the following attachment(s) as confidential document from public disclosure. Exhibits Long-Term Confidentiality Short-Term Confidentiality ID Label/Location No No Attestation Statement No No External Photos No Block Diagram Schematics Test Report No No Test Setup Photos No User’s Manual Internal Photos Parts List / Tune Up RF Exposure Info Operational Description Cover Letter(s) No No SDR Software / Security Info No Above mentioned document contains detailed system and equipment description are considered as proprietary information in operation of the equipment. The public disclosure of above documents might be harmful to our company and would give competitor an unfair advantage in the market. It is our understanding that all measurement test reports, FCC ID label format and correspondent during certification review process cannot be granted as confidential documents and those information will be available for public review once the grant of equipment authorization is issued. Sincerely, Signature: Name: Steven Zou Title: Technical Manager

FCC ID: Q2I202401G External photos FCC ID: Q2I202401G FCC ID: Q2I202401G

36*18mm Model: G Voltage: 3.0V Frequency: 433.918MHz Wireless Door Chime 36*18m 36*18mm Foshan Shunde Advante Electron Ltd.Shunde Advante Electron Ltd. Voltage: 3.0V FCC ID: Q2I202401G Label & Location

FCC ID: Q2I202401G Internal photos FCC ID: Q2I202401G RF Antenna RF Chip

Report No.: NTC2408240F01 Dongguan Nore Testing Center Co., Ltd. Address: Building D, Gaosheng Science and Technology park, Hongtu road, Nancheng district, Dongguan city, Guangdong province, China Web: www.ntc-c.com Tel:+86-769-2202 2444 Fax:+86-769-2202 2799 Page 1 of 10 RF EVALUATION TEST REPORT Applicant.......................... : FOSHAN SHUNDE ADVANTE ELECTRON LTD. Address........................... : North Second XinXi Road, LunJiao Industrial Avenue LunJiao, Shunde, Foshan, Guangdong, China Manufacturer..................... : FOSHAN SHUNDE ADVANTE ELECTRON LTD. Address............................. : North Second XinXi Road, LunJiao Industrial Avenue LunJiao, Shunde, Foshan, Guangdong, China Factory............................ : FOSHAN SHUNDE ADVANTE ELECTRON LTD. Address............................ : North Second XinXi Road, LunJiao Industrial Avenue LunJiao, Shunde, Foshan, Guangdong, China Product Name................... : Wireless Door Chime Brand Name..................... : N/A Model No. ....................... : G, GP, FL, FLP, FLD, FY (For model difference refer to section 2) FCC ID........................... : Q2I202401G Measurement Standard....... : 47 CFR PART 2, Section 2.1093 Receipt Date of Samples.... : August 12, 2024 Date of Tested.................. : August 13, 2024 to August 20, 2024 Date of Report.................. : September 07, 2024 This report shows that above equipment is technically compliant with the requirements of the standards above. All test results in this report apply only to the tested sample(s). Without prior written approval of Dongguan Nore Testing Center Co., Ltd, this report shall not be reproduced except in full. Prepared by Alina Guo / Project Engineer Approved by Iori Fan / Authorized Signatory Report No.: NTC2408240F01 Page 2 of 10 Table of Contents 1. General Description of EUT ................................................................................................................................ 4 2. Test Facility and Location ................................................................................................................................... 5 3. Applicable Standards and References ................................................................................................................ 7 4. Maximum Permissible Exposure Limit ................................................................................................................ 8 5. RF Exposure Evaluation Results ...................................................................................................................... 10 Report No.: NTC2408240F01 Page 3 of 10 Revision History Report Number Description Issued Date NTC2408240F01 Ini tia l Issue 2024-09-07 Report No.: NTC2408240F01 Page 4 of 10 1. General Description of EUT Product Information Product Name: Wireless Door Chime Main Model Name: G Additional Model Name: GP, FL, FLP, FLD, FY Model Difference: These models have the same circuit schematic, construction, PCB Layout and critical components. Their differences are model name due to trading purpose. S/N: 2408-4625 Brand Name: N/A Hardware Version: V01 Software Version: V01 Rating: DC 3V CR2032 battery Typical arrangement: Table-top I/O Port: Refer to the user manual Accessories Information Adapter: N/A Cable: N/A Other: N/A Additional Information Note: According to the model difference and manufacturer’s requirement, all tests were performed on model G. Remark: All the information above are provided by the manufacturer. More detailed feature of the EUT please refers to the user manual. Report No.: NTC2408240F01 Page 5 of 10 Technical Specification Declaring the Frequency: 433.918MHz Modulation Type: ASK Antenna Type: Spring antenna Antenna Gain: 0 dBi (Declared by manufacturer) Number of Channels: 1 Report No.: NTC2408240F01 Page 6 of 10 2. Test Facility and Location Test Site : Dongguan Nore Testing Center Co., Ltd. (Dongguan NTC Co., Ltd.) Accreditations and Authorizati ons : The Laboratory has been assessed and proved to be in compliance with CNAS/CL01 Listed by CNAS, August 13, 2018 The Certificate Registration Number is L5795. The Certificate is valid until August 13, 2030 The Laboratory has been assessed and proved to be in compliance with ISO17025 Listed by A2LA, November 01, 2017 The Certificate Registration Number is 4429.01 The Certificate is valid until December 31, 2025 Listed by FCC, November 06, 2017 Test Firm Registration Number: 907417 Listed by Industry Canada, June 08, 2017 The Certificate Registration Number. Is 46405-9743A The CAB identifier number: CN0015 Test Site Location : Building D, Gaosheng Science and Technology Park, Hongtu Road, Nancheng District, Dongguan City, Guangdong Province, China Report No.: NTC2408240F01 Page 7 of 10 3. Applicable Standards and References According to the specifications of the manufacturer, the EUT must comply with the requirements of the following standards: Test Standards: 47 CFR Part 1, 1.1307 47 CFR Part 2, 2.1093 KDB 447498 D04 v01 Report No.: NTC2408240F01 Page 8 of 10 4. Maximum Permissible Exposure Limit According to 47 CFR Part 1, 1.1307, for single RF sources (i.e., any single fixed RF source, mobile device, or portable device, as defined in paragraph (b)(2) of this section): A single RF source is exempt if: 47 CFR Part 1, 1.1307 (A) The available maximum time- averaged power is no more than 1 mW, regardless of separation distance. This exemption may not be used in conjunction with other exemption criteria other than those in paragraph (b)(3)(ii)(A) of this section. Medical implant devices may only use this exemption and that in paragraph (b)(3)(ii)(A); (B) Or the available maximum time- averaged power or effective radiated power (ERP), whichever is greater, is less than or equal to the threshold P th (mW) described in the following formula. This method shall only be used at separation distances (cm) from 0.5 centimeters to 40 centimeters and at frequencies from 0.3 GHz …

Text truncated - open the document above for the full version.

Report No.: NTC2408240FV00 Dongguan Nore Testing Center Co., Ltd. Address: Buil ding D, Gaosheng Science and Technology park, Hongtu road, Nancheng district, Dongguan city, Guangdong province, China Web: www.ntc-c.com Tel:+86-769-2202 2444 Fax:+86-769-2202 2799 Page 1 of 29 FCC RADIO TEST REPORT Applicant............................ : FOSHAN SHUNDE ADVANTE ELECTRON LTD. Address............................. : North Second XinXi Road, LunJiao Industrial Avenue LunJiao, Shunde, Foshan, Guangdong, China Manufacturer....................... : FOSHAN SHUNDE ADVANTE ELECTRON LTD. Address.............................. : North Second XinXi Road, LunJiao Industrial Avenue LunJiao, Shunde, Foshan, Guangdong, China Factory............................... : FOSHAN SHUNDE ADVANTE ELECTRON LTD. Address............................. : North Second XinXi Road, LunJiao Industrial Avenue LunJiao, Shunde, Foshan, Guangdong, China Product Name..................... : Wireless Door Chime Brand Name....................... : N/A Model No. .......................... : G, GP, FL, FLP, FLD, FY (For model difference refer to section 2) FCC ID............................... : Q2I202401G Measurement Standard.......... : 47 CFR FCC Part 15, Subpart C (Section 15.231) Receipt Date of Samples....... : August 12, 2024 Date of Tested..................... : August 13, 2024 to August 20, 2024 Date of Report..................... : September 07, 2024 This report shows that above equipment is technically compliant with the requirements of the standards above. All test results in this report apply only to the tested sample(s). Without prior written approval of Dongguan Nore Testing Center Co., Ltd, this report shall not be reproduced except in full. Pr epared by Alina Guo / Project Engineer Approved by Iori Fan / Authorized Signatory Report No.: NTC2408240FV00 Page 2 of 29 Table of Contents 1. Summary of Test Result ...................................................................................................................................... 4 2. General Description of EUT ................................................................................................................................ 5 3. Test Channels and Modes Detail ........................................................................................................................ 7 4. Configuration of EUT ........................................................................................................................................... 7 5. Modification of EUT ............................................................................................................................................. 7 6. Description of Support Device ............................................................................................................................. 7 7. Test Facility and Location ................................................................................................................................... 8 8. Applicable Standards and References ................................................................................................................ 9 9. Deviations and Abnormalities from Standard Conditions ................................................................................... 9 10. Test Conditions ................................................................................................................................................. 9 11. Measurement Uncertainty ............................................................................................................................... 10 12. Sample Calculations ....................................................................................................................................... 11 13. Duty Cycle ....................................................................................................................................................... 12 14. Test Items and Results ................................................................................................................................... 13 14.1 Conducted Emissions Measurement ............................................................................................................ 13 14.2 Radiated Spurious Emissions Measurement ................................................................................................ 15 14.3 20dB Occupied Bandwidth ............................................................................................................................ 24 14.4 Transmission time ......................................................................................................................................... 26 14.5 Antenna Requirement ................................................................................................................................... 28 15. Test Equipment List......................................................................................................................................... 29 Report No.: NTC2408240FV00 Page 3 of 29 Revision History Report Number Description Issued Date NTC2408240FV00 Initial Issue 2024-09-07 Report No.: NTC2408240FV00 Page 4 of 29 1. Summary of Test Result FCC Rules Description of Test Result Remarks §15.207 (a) AC Power Line Conducted Emission N/A see note 2 --- §15.231(b) & 15.209 Radiated Spurious Emission PASS --- §15.231(c) 20 dB Occupied bandwidth PASS --- §15.231(a) Transmission time PASS --- §15.203 Antenna Requirement PASS --- Note: 1. The EUT has been tested as an independent unit. And continual transmitting in maximum power (New batteries were used during test) 2. AC Power Conducted Emission is not applicable due to the EUT only can be powered by battery. Report No.: NTC2408240FV00 Page 5 of 29 2. General Description of EUT Product Information Product Name: Wireless Door Chime Main Model Name: G Additional Model Name: GP, FL, FLP, FLD, FY Model Difference…

Text truncated - open the document above for the full version.

ANTENNA SPECIFICATION Manufacture 厂商 : FOSHAN SHUNDE ADVANTE ELECTRON LTD. Address 地址 : North Second XinXi Road, LunJiao Industrial Avenue LunJiao, Shunde, Foshan, Guangdong, China Product type 产品类型 : Sping Antenna Antenna model 填写型号 : G-ANTENNA Material 材料 : Metal Gain : 0dBi(typical) Frequency 频率 : 433.918±0.05MHz 请附上天线尺寸图：（参考以下尺寸图） Please attach the dimensional drawing of antenna (see below for example) Unit: mm

FCC ID: Q2I202401G Test Photo Radiated emission (Below 30MHz) Radiated emission (30-1000MHz) FCC ID: Q2I202401G Radiated emission (Above 1000MHz)
