Q3L-Q10600TAG reader system

12V , 800 mA BiblioWand TM Read carefully before use! User Manual Overview Carrying caseNetwork adapter Security precautions Connector for network adapter (charging) Power Display Attachment for PDA Attachments for wand holder Power status display Wand holder Adjustable shoulder strap RFID-Reader Wand Handheld-PC: IPAQ Pocket PC with data cable RF-Button ON / OFF Warning: electromagnetic field Used outlets must be installed in conformity to standards, and be easy to reach. Unplugging can cause disconnection from the net. (charging adapter) When not in use, disconnect from the net. (charging adapter) Only use specific betteries. (type 11151202) Use without regard for instructions or security precautions can be dangerous. Hand Scanner Network part General Disconnect scanner from net prior to cleaning. Do not clean scanner with fluids. Do not use cleaning agents. Use only indoors. Protect scanner from contact with water. Do not open scanner. All repairs only through dealers/customer service. Remove battery prior to disposal. Dispose of battery and scanner in accordance with environmental standards either at a location designated for disposal or at location where scanner was purchased. Battery Running Time Type RFID Reader Max. Temperature Rating Network Adapter Input Voltage Capacity Output Voltage Technical Data 40 °C 13,56 MHz 100 - 240 VAC 24 W 15 VDC 2 Stunden NiMHd Carrier Frequency Only use adapter included in delivery (Egston N2UFSW3) ergonomic communication ® 1103_2 1234 5 7 12 9 1011 8 6 Wand goes in holder Connect wand with RIFD-Reader RFID-Reader shoulder strap Connect it handheld PC Activate RFID-Reader Take wand in hand Activate wand Place wand in holder Tu r n o ff RFID Reader Disconnect handheld PC from RFID Reader Battery:fullhalf fullempty adjustable To load battery: max. time: 4h RFID use not possible Staying as parallel as possible with spine of book Hold as close to book as possible Take handheld PC in other hand or fasten onto carrying belt Press RF button during search Position scanner in front of book case Activating the handheld PC

montena emc sa CH-1728 Rossens – phone ++41 (0)26/411 93 33 – fax ++41(0)26/411 93 30 - http://www.montena.com August 20, 2004 Federal Communication Commission Confidentiality request FCC ID: Q3L-Q10600 Applicant: Bibliotheca RFID Library Systems AG Schwerzelrain 6 CH-6315 Oberaegeri Switzerland To whom it may concern: Bibliotheca RFID Library Systems AG requests that the documents listed below be withheld from public inspection in accordance with section 0.459 of the Commissions Rules. Documents for which the confidentiality request is sought: File name: Information contained: - OpDescription.pdf Operational description - BlockDiagram.pdf Block Diagram - SchematicsRF.pdf Schematics of RF part All of these documents treat confidential business information which. Disclosure would, in effect, give away the fruits of the labours of Bibliotheca’s engineering department and personnel, who have designed the equipment and manufacturing process. Disclosure would also offer competitors additional unwarranted insight into the state of the product development. The information contained in these documents is kept confidential by Bibliotheca RFID Library Systems AG and not made available to third parties except to non-disclosure agreements. The material should not be disclosed for at least 25 years. While improvements in the design are made relatively frequently, disclosure of the design information would lead so insights into both design and manufacturing techniques that could have an adverse competitive effect for many years to come. Thank you for your consideration in this matter Sincerely Erich Staub [email protected] montena emc sa

FCC ID Q3L-Q10600 Mandate no: 20035871 1/3 montena emc sa CH-1728 Rossens – phone ++41(-0)26 411 93 33 – fax ++41(-0)26 411 93 30 - http://www.emc.montena.com External Photos General view with central unit, antenna and pocket PC (the pocket PC is not part of the equipment under test, every PC with RS232 port may be used) Central unit with antenna FCC ID Q3L-Q10600 Mandate no: 20035871 2/3 montena emc sa CH-1728 Rossens – phone ++41(-0)26 411 93 33 – fax ++41(-0)26 411 93 30 - http://www.emc.montena.com Central unit Close up of central unit FCC ID Q3L-Q10600 Mandate no: 20035871 3/3 montena emc sa CH-1728 Rossens – phone ++41(-0)26 411 93 33 – fax ++41(-0)26 411 93 30 - http://www.emc.montena.com Antenna

FCC ID Q3L-Q10600 Mandate no: 20035871 1/1 montena emc sa CH-1728 Rossens – phone ++41(-0)26 411 93 33 – fax ++41(-0)26 411 93 30 - http://www.emc.montena.com ID-Label/Location Info Label location Label

FCC ID Q3L-Q10600 Mandate no: 20035871 1/2 montena emc sa CH-1728 Rossens – phone ++41(-0)26 411 93 33 – fax ++41(-0)26 411 93 30 - http://www.emc.montena.com Internal Photos PCB’s mounted in central unit RF-PCB Supply PCB RF-PCB in central unit Supply PCB FCC ID Q3L-Q10600 Mandate no: 20035871 2/2 montena emc sa CH-1728 Rossens – phone ++41(-0)26 411 93 33 – fax ++41(-0)26 411 93 30 - http://www.emc.montena.com Antenna

1 / 23 montena emc sa CH-1728 Rossens - Switzerland - phone +41 26 411 93 33 - fax +41 26 411 93 30 - www.emc.montena.com - [email protected] Test laboratory accredited by metas, the Swiss Federal Office of Metrology and Accreditation Laboratoire d'essai accrédité par metas, l'Office fédéral de métrologie et d'accréditation Prüflabor akkreditiert durch metas, das Bundesamt für Metrologie und Akkreditierung Registration number Numéro d'accréditation Akkreditierungsnummer STS 024 Schweizerischer Prüfstellendienst Service suisse d'essai Swiss testing service Date of test: Date de l'essai: Prüfdatum: 3. & 7.10.2003; 11-14.05. & 18.6.2004 Report no: Rapport no: Bericht Nr: 13'797 Mandate no: Mandat no: Auftrag Nr: 2003-5871 Report: Rapport: Bericht: Electromagnetic compatibility Product name: Nom du produit: Produktname BiblioWand Customer: Client: Kunde: Bibliotheca RFID Library Systems AG Serial no: No de série: Seriennummer: Prototyp V1.0 Standards / Normes / Normen Result Résultat Ergebnis CFR 47, Part 15, Subpart B, Unintentional radiator Pass CFR 47, Part 15, Subpart C, Intentional radiator Pass Test performed by Essai effectué par : Prüfer Test report prepared by Rapport d’essai préparé par : Berichterstatter Test report controlled and approved by Rapport d’essai contrôlé et approuvé par : Prüfbescheinigung M. Portmann / E. de Raemy M. Portmann / E. de Raemy E. Staub Rossens, June 30, 2004 (Issue Date / Date d'édition / Ausstelldatum) V20040606 Main language / Langue principale / Hauptsprache : english / franÁais / deutsch The present document results from tests on a specimen and does not prejudge to the conformity of all the manufactured products. - Le présent document résulte d'essais sur un spécimen. Il ne préjuge pas de la conformité de l'ensemble des produits fabriqués à l'objet essayé. - Dieser Bericht beinhaltet die Prüfergebnisse eines Mustergerätes. Es kann daraus nicht auf die Übereinstimmung der Seriegeräte mit dem Mustergerät geschlossen werden. q:\mandats\20035871_z ̧hlke_bibliowand\13797 fcc zuehlke.doc No. / Nr. : 13'797 (2003-5871) Page / Seite 2 / 23 montena emc sa CH-1728 Rossens - Switzerland - phone +41 26 411 93 33 - fax +41 26 411 93 30 - www.emc.montena.com - [email protected] Contents / Table des matières / Inhaltsverzeichnis Page/Page/Seite 1. SUMMARY OF TEST RESULTS / RÉSUMÉ DES RÉSULTATS D'ESSAIS / ZUSAMMENFASSUNG DER PRÜFERGEBNISSE......................................................................................................................... 3 2. APPLIED STANDARDS / NORMES APPLIQUEES / VERWENDETE NORMEN............................................ 3 3. CLIENT / CLIENT / KUNDE............................................................................................................... 4 4. EQUIPMENT UNDER TEST / EQUIPEMENT A L'ESSAI / PRÜFLING......................................................... 4 4.1 Identification / Identification / Identifikation ....................................................................... 4 4.2 Pictures of the EUT / Photos de l’EST / Fotos des Prüflings ........................................... 5 4.3 Classification / Classification / Klassierung ...................................................................... 5 4.4 Connected cables / Câble connectés / Angeschlossene Kabel ....................................... 5 4.5 Modifications before the tests / Modifications apportées avant les essais / Vor den Prüfungen angebrachte Änderungen ............................................................................... 6 5. TEST CONDITIONS / CONDITIONS D'ESSAI / TESTBEDINGUNGEN........................................................ 6 5.1 Climatic conditions / conditions climatiques / klimatische Bedingungen .......................... 6 5.2 Location and Date / Lieu et date / Ort und Datum............................................................ 6 5.3 Persons present / Personnes présentes / Anwesende Personen.................................... 6 5.4 Test configuration / Configuration d’essai / Prüfkonfiguration .......................................... 6 5.5 Operating conditions / Conditions de fonctionnement / Betriebszustand......................... 7 5.6 Auxillary equipment / Matériel auxiliaire / Zusatzgeräte ................................................... 7 6. EMISSION TEST............................................................................................................................. 8 6.1 Interference voltage .......................................................................................................... 9 6.2 Radiated electromagnetic field (unwanted emissions of an intentional radiator) ........... 12 6.3 Radiated electromagnetic field (carrier analysis) ........................................................... 16 6.4 Radiated electromagnetic field (unwanted emissions of an unintentional radiator) ....... 19 No. / Nr. : 13'797 (2003-5871) Page / Seite 3 / 23 montena emc sa CH-1728 Rossens - Switzerland - phone +41 26 411 93 33 - fax +41 26 411 93 30 - www.emc.montena.com - [email protected] 1. Summary of test results / Résumé des résultats d'essais / Zusammenfassung der Prüfergebnisse
Pass / Réussi / Bestanden  Fail / Echoué / Nicht bestanden
Not applicable to this product / Pas applicable à ce produit / Nicht anwendbar für dieses Produkt  Not tested / Pas testé / Nicht geprüft No requirements / Pas d’exigence / Keine Anforderung § Test Type / Type d’essai / Art der Prüfung Standard /Norme /Norm Result / Résultat / Ergebnis 6 Emission / Emission / Störaussendung 6.1 Mains terminal interference voltage Tension perturbatrice aux bornes d'alimentation Störspannung auf den Energieversorgungsleitungen CFR 47 ß 15.107 /15.207
6.2 Radiated electromagnetic field Champ perturbateur Störfeldstärke CFR 47 ß 15.209
6.3 Carrier frequency analysis Analyse de la fréquence porteuse Trägerfrequenzuntersuchung CFR 47 ß 15.225
6.4 Radiated electromagnetic field (incl. …

Text truncated - open the document above for the full version.

FCC ID Q3L-Q10600 Mandate no: 20035871 1/1 montena emc sa CH-1728 Rossens – phone ++41(-0)26 411 93 33 – fax ++41(-0)26 411 93 30 - http://www.emc.montena.com Test setup photos For the test setups please see test report (13797 FCC zuehlke.pdf)
