Q5EKI60PTToC Radio

K-I60 User Manual Get to Know the Product Install / Remove the Antenna Align the antenna with the antenna connector on the top of the walkie‑talkie, rotate clockwise until tight. To remove, rotate counterclockwise. Install / Remove the Belt Clip Installation: Insert the belt clip into the battery groove until the spring locks. Removal: Insert fingernail or tool into upper groove, flip up the catch and push the clip upward to remove. Install Accessories Remove the side accessory port cover, insert external audio accessories into the universal port, and secure with screws. Install / Remove SIM & TF Cards Position 1 Use a small Phillips screwdriver to loosen the TF card cover screw. Flip the cover left to access SIM and TF slots. Removal order: Push TF card right → pull SIM holder spring left. Installation order: Install SIM first, then TF. Position 2 The card tray is on the left side (marked with a triangle). Pull out the tray, insert cards, then push back firmly. Install the Battery 1. Align the top plugs of the battery with the battery compartment slots and insert. 2. Push the battery latch into position. 3. Press the bottom gently until locked. Type‑C Charging Lift and rotate the Type‑C port cover to expose the port and indicator. • Red light on: Charging • Red light flashing: Charging error • Red light off: Fully charged Basic Operations 1. Power On / Off On: Rotate Power/Volume knob clockwise until click. Off: Rotate counterclockwise until click. 2. Select Channel Rotate the channel knob. Channels can be analog or digital (set by dealer via software). 3. Adjust Volume Clockwise to increase, counterclockwise to decrease. Turn past min to power off. 4. Make a Call • Default contact: Hold PTT. • Select contact: Enter Contacts → hold PTT. • Manual dial: Enter ID → hold PTT. 5. Receive a Call Green LED on; display shows caller info. Hold PTT to reply during call hold time. 6. Emergency Alarm Send emergency alert and voice to designated group at any time. 7. Call Records View outgoing, incoming, and missed calls. 8. Positioning System Enable via software or Positioning menu. Device shows location and updates to server. Troubleshooting No. Symptom Cause & Solution 1 Will not power on A. Low battery: Charge/replace. B. Poor contact: Reinstall battery. C. Dirty contacts: Clean terminals. 2 Cannot communicate A. Loose antenna: Tighten. B. Wrong frequency: Match RX/TX. C. Mismatched codes: Reprogram. D. Out of range. 3 No positioning A. Wrong settings: Reconfigure. B. Shielded area: Move to open space. 4 Programming failure A. Bad cable: Check connection. B. Poor port: Inspect/replace board. FCC Statement 15.19 Labeling requirements. This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. 15.21 Information to user. Any Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. 15.105 Information to user. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: -- Reorient or relocate the receiving antenna. -- Increase the separation between the equipment and receiver. -- Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. -- Consult the dealer or an experienced radio/TV technician for help. Specific Absorption Rate (SAR) information: This product meets the government's requirements for exposure to radio waves. The guidelines are based on standards that were developed by independent scientific organizations through periodic and thorough evaluation of scientific studies. The standards include a substantial safety margin designed to assure the safety of all persons regardless of age or health. FCC RF Exposure Information and Statement The SAR limit of USA (FCC) is 1.6 W/kg averaged over one gram of tissue. This device was tested for typical body-worn operations when the device used at 25mm from front face and 10mm from the product, 0mm from the belt, for maintain compliance with FCC RF exposure requirements. The use of belt clips, holsters and similar accessories should not contain metallic components in its assembly. The use of accessories that do not satisfy these requirements may not comply with FCC RF exposure requirements, and should be avoided.

Test Laboratory: Huatongwei International Inspection Co., Ltd.,SAR LabDate: 2026/4/21 LTE Band 17 Body-worn Communication System: UID 0, Generic LTE-FDD (0); Frequency: 709 MHz;Duty Cycle: 1:1 Medium parameters used: f = 709 MHz; σ = 0.911 S/m; ε r = 41.79; ρ = 1000 kg/m 3 Phantom section: Flat Section Ambient Temperature:23.4°C;Liquid Temperature:22.6°C; DASY Configuration: lProbe: EX3DV4 - SN7494; ConvF(10.55, 10.55, 10.55) @ 709 MHz; Calibrated: 2025/7/10 lSe nsor-Surface: 1.4mm (Mechanical Surface Detecti on) lElectronics: DAE4 Sn1315; Calibrated: 2026/1/7 lPha ntom: ELI V8.0 ; Type: QD OVA 004 AA ; Serial: 2078 lDASY52 52.10.4(1535); SEMCAD X 14.6.14(7501) Front 10mm/CH23780/Area Scan (7x19x1): Measurement grid: dx=15mm, dy=15mm Maximum value of SAR (measured) = 0.230 W/kg Front 10mm/CH23780/Zoom Scan (5x5x7)/Cube 0: Measurement grid: dx=8mm, dy=8mm, dz=5mm Reference Value = 10.16 V/m; Power Drift = -0.08 dB Peak SAR (extrapolated) = 0.266 W/kg SAR(1 g) = 0.167 W/kg; SAR(10 g) = 0.123 W/kg Smallest distance from peaks to all points 3 dB below: Larger than measurement grid (> 16 mm) Ratio of SAR at M2 to SAR at M1 = 66.4% Maximum value of SAR (measured) = 0.225 W/kg 0 dB = 0.225 W/kg = -6.48 dBW/kg Appendix D: SAR Test Data Plots Plot No.27 Test Laboratory: Huatongwei International Inspection Co., Ltd.,SAR LabDate: 2026/4/27 LTE Band 25 Body-worn Communication System: UID 0, Generic LTE-FDD (0); Frequency: 1860 MHz;Duty Cycle: 1:1 Medium parameters used: f = 1860 MHz; σ = 1.36 S/m; ε r = 38.99; ρ = 1000 kg/m 3 Phantom section: Flat Section Ambient Temperature:22.8°C;Liquid Temperature:21.9°C; DASY Configuration: lProbe: EX3DV4 - SN7494; ConvF(8.36, 8.36, 8.36) @ 1860 MHz; Calibrated: 2025/7/10 lSe nsor-Surface: 1.4mm (Mechanical Surface Detecti on) lElectronics: DAE4 Sn1315; Calibrated: 2026/1/7 lPha ntom: ELI V8.0 ; Type: QD OVA 004 AA ; Serial: 2078 lDASY52 52.10.4(1535); SEMCAD X 14.6.14(7501) Rear 10mm/CH26140/Area Scan (7x19x1): Measurement grid: dx=15mm, dy=15mm Maximum value of SAR (measured) = 0.512 W/kg Rear 10mm/CH26140/Zoom Scan (5x5x7)/Cube 0: Measurement grid: dx=8mm, dy=8mm, dz=5mm Reference Value = 13.80 V/m; Power Drift = -0.11 dB Peak SAR (extrapolated) = 0.607 W/kg SAR(1 g) = 0.391 W/kg; SAR(10 g) = 0.221 W/kg Smallest distance from peaks to all points 3 dB below = 17.6 mm Ratio of SAR at M2 to SAR at M1 = 57.3% Maximum value of SAR (measured) = 0.503 W/kg 0 dB = 0.503 W/kg = -2.98 dBW/kg Appendix D: SAR Test Data Plots Plot No.28 Test Laboratory: Huatongwei International Inspection Co., Ltd.,SAR LabDate: 2026/4/23 LTE Band 26 Body-worn Communication System: UID 0, Generic LTE-FDD (0); Frequency: 841.5 MHz;Duty Cycle: 1:1 Medium parameters used: f = 841.5 MHz; σ = 0.898 S/m; ε r = 40.667; ρ = 1000 kg/m 3 Phantom section: Flat Section Ambient Temperature:22.5°C;Liquid Temperature:22.0°C; DASY Configuration: lProbe: EX3DV4 - SN7494; ConvF(10.2, 10.2, 10.2) @ 841.5 MHz; Calibrated: 2025/7/10 lSe nsor-Surface: 1.4mm (Mechanical Surface Detecti on) lElectronics: DAE4 Sn1315; Calibrated: 2026/1/7 lPha ntom: ELI V8.0 ; Type: QD OVA 004 AA ; Serial: 2078 lDASY52 52.10.4(1535); SEMCAD X 14.6.14(7501) Front 10mm/CH26965/Area Scan (7x19x1): Measurement grid: dx=15mm, dy=15mm Maximum value of SAR (measured) = 0.356 W/kg Front 10mm/CH26965/Zoom Scan (5x5x7)/Cube 0: Measurement grid: dx=8mm, dy=8mm, dz=5mm Reference Value = 11.73 V/m; Power Drift = -0.04 dB Peak SAR (extrapolated) = 0.413 W/kg SAR(1 g) = 0.264 W/kg; SAR(10 g) = 0.188 W/kg Smallest distance from peaks to all points 3 dB below: Larger than measurement grid (> 16 mm) Ratio of SAR at M2 to SAR at M1 = 64.4% Maximum value of SAR (measured) = 0.347 W/kg 0 dB = 0.347 W/kg = -4.60 dBW/kg Appendix D: SAR Test Data Plots Plot No.2 Test Laboratory: Huatongwei International Inspection Co., Ltd.,SAR LabDate: 2026/4/29 LTE Band 41 Body-worn Communication System: UID 0, Generic LTE-TDD (0); Frequency: 2506 MHz;Duty Cycle: 1:1.57979 Medium parameters used: f = 2506 MHz; σ = 1.822 S/m; ε r = 38.57; ρ = 1000 kg/m 3 Phantom section: Flat Section Ambient Temperature:23.4°C;Liquid Temperature:22.2°C; DASY Configuration: lProbe: EX3DV4 - SN7494; ConvF(7.66, 7.66, 7.66) @ 2506 MHz; Calibrated: 2025/7/ 10 lSensor-Surface: 1.4mm (Mechanical Surface Detection) lE lectronics: DAE4 Sn1315; Calibrated: 2026/1/ 7 lPhantom: ELI V8.0 ; Type: QD OVA 004 AA ; Serial: 2078 lDASY52 52.10.4(1535); SEMCAD X 14.6.14(7501) Front 10mm/CH39750/Area Scan (8x23x1): Measurement grid: dx=12mm, dy=12mm Maximum value of SAR (measured) = 0.298 W/kg Front 10mm/CH39750/Zoom Scan (7x7x7)/Cube 0: Measurement grid: dx=5mm, dy=5mm, dz=5mm Reference Value = 6.203 V/m; Power Drift = -0.19 dB Peak SAR (extrapolated) = 0.391 W/kg SAR(1 g) = 0.210 W/kg; SAR(10 g) = 0.113 W/kg Smallest distance from peaks to all points 3 dB below = 15.3 mm Ratio of SAR at M2 to SAR at M1 = 48.1% Maximum value of SAR (measured) = 0.310 W/kg 0 dB = 0.310 W/kg = -5.09 dBW/kg Appendix D: SAR Test Data Plots Plot No.30 Test Laboratory: Huatongwei International Inspection Co., Ltd.,SAR LabDate: 2026/4/24 LTE Band 66 Body-worn Communication System: UID 0, Generic LTE-FDD (0); Frequency: 1745 MHz;Duty Cycle: 1:1 Medium parameters used: f = 1745 MHz; σ = 1.39 S/m; ε r = 39.143; ρ = 1000 kg/m 3 Phantom section: Flat Section Ambient Temperature:22.7°C;Liquid Temperature:21.9°C; DASY Configuration: lProbe: EX3DV4 - SN7494; ConvF(8.71, 8.71, 8.71) @ 1745 MHz; Calibrated: 2025/7/10 lSe nsor-Surface: 1.4mm (Mechanical Surface Detecti on) lElectronics: DAE4 Sn1315; Calibrated: 2026/1/7 lPha ntom: ELI V8.0 ; Type: QD OVA 004 AA ; Serial: 2078 lDASY52 52.10.4(1535); SEMCAD X 14.6.14(7501) Rear 10mm/CH132322/Area Scan (7x19x1): Measurement grid: dx=15mm, dy=15mm Maximum value of SAR (measured) = 0.436 W/kg Rear 10mm/CH132322/Zoom Scan (5x5x7)/Cube 0: Measurement grid: dx=8mm, dy=8mm, dz=5mm Reference Value = 13.14 V/m; Power Drift = -0.12 dB Peak SAR (extrapolated) = 0.544 W/kg SAR(1 g) = 0.290 W/kg; SAR(10…

Text truncated - open the document above for the full version.

Test setup photos-SAR Liquid depth in the ELI phantom Front-of-face(25mm) Body Front(10mm) Body Rear(10mm) Body Rear(0mm)- With Belt clip

Test setup photos-LTE

TEST REPORT For LTE Band 14 Report No......................................... : CHTW26075003 Project No ........................................ : SHT2603040705W FCC ID ............................................. : Q5EKI60 Applicant’s name ............................. : Kirisun Communication Co.,Ltd. Address ............................................ : 3rd Floor, Building A, Tongfang Information Habour, No.11 Langshan Road, Nanshan District, Shenzhen 518057, P.R.China Product Name .................................. : PTToC Radio Trade Mark....................................... : , Model No.......................................... : K-I60 Listed Model(s) ................................ : GP800 Standard .......................................... : FCC CFR Title 47 Part 2 FCC CFR Title 47 Part 90 Date of receipt of test sample..........: 2026/4/7 Date of testing.............................: 2026/4/24- 2026/6/24 Date of issue...............................: 2026/7/2 Result ................... ........................: PASS Compiled by (Position+Printed name+Signature) : File administrator Caspar Chen Supervised by (Position+Printed name+Signature) : Project Engineer Xiaodong Zhao Approved by (Position+Printed name+Signature) : RF Manager Xu Yang Testing Laboratory Name ............. : Shenzhen Huatongwei International Inspection Co., Ltd. Address ............................................ : Building 7, Baiwang Idea Factory, No.1051, Songbai Road, Yangguang Community, Xili Subdistrict, Nanshan District, Shenzhen, Guangdong, China Test Report Form No. ........................ : R0066 Test Report Form(s) Originator ......... : Shenzhen Huatongwei International Inspection Co., Ltd. Master TRF ........................................ : Dated 2025-07 Shenzhen Huatongwei International Inspection Co., Ltd. All rights reserved. This publication may be reproduced in whole or in part for non-commercial purposes as long as the Shenzhen Huatongwei International Inspection Co., Ltd. is acknowledged as copyright owner and source of the material. Shenzhen Huatongwei International Inspection Co., Ltd. takes no responsibility for and will not assume liability for damages resulting from the reader's interpretation of the reproduced material due to its placement and context.The test report merely correspond to the test sample.The authenticity of this Test Report and its contents can be verified by contacting the Laboratory, responsible for this Test Report. Report No.: CHTW26075003 Page 2 of 17 Contents 1. TE S T S T A N D A R D S A N D R E P O R T V E R S I O N 3 1.1. Applicable Standards 3 1.2. Report version information 3 2. T E S T D E S C R I P T I O N 4 3. S U M M A R Y 5 3.1. Client Information 5 3.2. Product Description 5 3.3. Radio Specification Description 6 3.4. Testing Laboratory Information 6 4. TEST CONFIGURATION 7 4.1. Test frequency list 7 4.2. Test mode 7 4.3. Test sample information 7 4.4. Support unit used in test configuration and system 8 4.5. Testing environmental condition 8 4.6. Statement of the measurement uncertainty 8 4.7. Equipments Used during the Test 9 5. T E S T C O N D I T I O N S A N D R E S U L T S 10 5.1. ERP 10 5.2. Radiated Spurious Emission 11 6. TE S T S E T U P P H O T O S O F T H E E U T 15 7. EX T E R N A L A N D I N T E R N A L P H O T O S O F T H E E U T 16 8. A P P E N D I X R E P O R T 17 Report No.: CHTW26075003 Page 3 of 17 1. TEST STANDARDS AND REPORT VERSION 1.1. Applicable Standards The tests were performed according to following standards: FCC CFR Title 47 Part 2: Frequency Allocations and Radio Treaty Matters; General Rules and Regulations FCC CFR Title 47 Part 90: Private Land Mobile Radio Services. ANSI C63.26-2015: American National Standard for Compliance Testing of Transmitters Used in Licensed Radio Services KDB 971168 D01 Power Meas License Digital Systems v03: MEASUREMENT GUIDANCE FOR CERTIFICATION OF LICENSED DIGITAL TRANSMITTERS 1.2. Report version information Revision No. Date of issue Description N/A 2026-07-02 Original Report No.: CHTW26075003 Page 4 of 17 2. Test Description Section Test Item Section in CFR 47 Result #1 Test Engineer - Conducted Output Power Part 2.1046 Pass * - - Peak-to-Average Ratio - Pass * - - 99% Occupied Bandwidth & 26 dB Bandwidth Part 2.1049 Pass * - - Band Edge Part 2.1051 Part 90.543(c) (e) Pass * - - Conducted Spurious Emissions Part 2.1051 Part 90.543(c) (e) Pass * - - Frequency stability vs temperature Part 2.1055(a)(1)(b) Part 90.213 Pass * - - Frequency stability vs voltage Part 2.1055(d)(1)(2) Part 90.213 Pass * - 5.1 ERP Part 90.542(a)(7) Pass JIAXING.SI 5.2 Radiated Spurious Emissions Part 2.1053 Part 90.543(e)(f) Pass JUNXU.LIN Note: 1) #1: The test result does not include measurement uncertainty value 2) *: Refer to module FCC ID: XMR2022SC200ENA. Report No.: CHTW26075003 Page 5 of 17 3. SUMMARY 3.1. Client Information Applicant: Kirisun Communication Co.,Ltd. Address: 3rd Floor, Building A, Tongfang Information Habour, No.11 Langshan Road, Nanshan District, Shenzhen 518057, P.R.China Manufacturer: Kirisun Communication Co.,Ltd. Address: 3rd Floor, Building A, Tongfang Information Habour, No.11 Langshan Road, Nanshan District, Shenzhen 518057, P.R.China Factory: Fujian Kirisun Communication Co., Ltd Address: Building C,Haixi Electronic Information Industry Incubation Base,Science and Industry Road,Hi-Tech Industry Park,Fengze District,Quanzhou,362000 Fujian,P.R.China 3.2. Product Description Main unit information: Product Name: PTToC Radio Trade Mark: , Model No.: K-I60 Listed Model(s): GP800 Power supply: DC 7.7V from Battery Hardware version: V1.0 Software version: V1.0 Accessory unit information: Battery information: Model: KDC-D60-A 7.7V 2400mAh/18.48Wh Adapter information: Model: TPQ-236A120100UW01 Ionput: 100-240V~50/60Hz 0.4A Output: 12.0Vd.c., 1.0A Rapid Charger information: Model: KBC-TD60-1Q Ionput: 12Vd.c. 1000mA Output: 800mA Report No.: CHTW26075003 Page 6 of 17 3.3. Radio Specifica…

Text truncated - open the document above for the full version.

TEST REPORT For LTE Band 26(814-824MHz) Report No......................................... : CHTW26065033 Project No ........................................ : SHT2603040705W FCC ID ............................................. : Q5EKI60 Applicant’s name ............................. : Kirisun Communication Co.,Ltd. Address ............................................ : 3rd Floor, Building A, Tongfang Information Habour, No.11 Langshan Road, Nanshan District, Shenzhen 518057, P.R.China Product Name .................................. : PTToC Radio Trade Mark....................................... : , Model No.......................................... : K-I60 Listed Model(s) ................................ : GP800 Standard .......................................... : FCC CFR Title 47 Part 2 FCC CFR Title 47 Part 90 Date of receipt of test sample..........: 2026/4/7 Date of testing.............................: 2026/4/24- 2026/6/24 Date of issue...............................: 2026/6/30 Result ................... ........................: PASS Compiled by (Position+Printed name+Signature) : File administrator Caspar Chen Supervised by (Position+Printed name+Signature) : Project Engineer Xiaodong Zhao Approved by (Position+Printed name+Signature) : RF Manager Xu Yang Testing Laboratory Name ............. : Shenzhen Huatongwei International Inspection Co., Ltd. Address ............................................ : Building 7, Baiwang Idea Factory, No.1051, Songbai Road, Yangguang Community, Xili Subdistrict, Nanshan District, Shenzhen, Guangdong, China Test Report Form No. ........................ : R0066 Test Report Form(s) Originator ......... : Shenzhen Huatongwei International Inspection Co., Ltd. Master TRF ........................................ : Dated 2025-07 Shenzhen Huatongwei International Inspection Co., Ltd. All rights reserved. This publication may be reproduced in whole or in part for non-commercial purposes as long as the Shenzhen Huatongwei International Inspection Co., Ltd. is acknowledged as copyright owner and source of the material. Shenzhen Huatongwei International Inspection Co., Ltd. takes no responsibility for and will not assume liability for damages resulting from the reader's interpretation of the reproduced material due to its placement and context.The test report merely correspond to the test sample.The authenticity of this Test Report and its contents can be verified by contacting the Laboratory, responsible for this Test Report. Report No.: CHTW26065033 Page 2 of 15 Contents 1. TE S T S T A N D A R D S A N D R E P O R T V E R S I O N 3 1.1. Applicable Standards 3 1.2. Report version information 3 2. T E S T D E S C R I P T I O N 4 3. S U M M A R Y 5 3.1. Client Information 5 3.2. Product Description 5 3.3. Radio Specification Description 6 3.4. Testing Laboratory Information 6 4. TEST CONFIGURATION 7 4.1. Test frequency list 7 4.2. Test mode 7 4.3. Test sample information 7 4.4. Support unit used in test configuration and system 8 4.5. Testing environmental condition 8 4.6. Statement of the measurement uncertainty 8 4.7. Equipments Used during the Test 9 5. T E S T C O N D I T I O N S A N D R E S U L T S 10 5.1. Radiated Spurious Emission 10 6. TE S T S E T U P P H O T O S O F T H E E U T 14 7. EX T E R N A L A N D I N T E R N A L P H O T O S O F T H E E U T 15 Report No.: CHTW26065033 Page 3 of 15 1. TEST STANDARDS AND REPORT VERSION 1.1. Applicable Standards The tests were performed according to following standards: FCC CFR Title 47 Part 2: Frequency Allocations and Radio Treaty Matters; General Rules and Regulations FCC CFR Title 47 Part 90: Private Land Mobile Radio Services ANSI C63.26-2015: American National Standard for Compliance Testing of Transmitters Used in Licensed Radio Services KDB 971168 D01 Power Meas License Digital Systems v03: MEASUREMENT GUIDANCE FOR CERTIFICATION OF LICENSED DIGITAL TRANSMITTERS 1.2. Report version information Revision No. Date of issue Description N/A 2026-06-30 Original Report No.: CHTW26065033 Page 4 of 15 2. TEST DESCRIPTION Section Test Item Section in CFR 47 Result #1 Test Engineer - Conducted Output Power Part 2.1046 Part 90.635(b) Pass * - - Peak-to-Average Ratio - Pass * - - 99% Occupied Bandwidth & 26 dB Bandwidth Part 2.1049 Pass * - - Band Edge Part 2.1051 Part 90.691 Pass * - - Conducted Spurious Emissions Part 2.1051 Part 90.691 Pass * - - Frequency stability vs temperature Part 2.1055(a)(1)(b) Part 90.213 Pass * - - Frequency stability vs voltage Part 2.1055(d)(1)(2) Part 90.213 Pass * - 5.1 Radiated Spurious Emissions Part 2.1053 Part 90.691 Pass JUNXU.LIN Note: 1) #1: The test result does not include measurement uncertainty value 2) *: Refer to module FCC ID: XMR2022SC200ENA. Report No.: CHTW26065033 Page 5 of 15 3. SUMMARY 3.1. Client Information Applicant: Kirisun Communication Co.,Ltd. Address: 3rd Floor, Building A, Tongfang Information Habour, No.11 Langshan Road, Nanshan District, Shenzhen 518057, P.R.China Manufacturer: Kirisun Communication Co.,Ltd. Address: 3rd Floor, Building A, Tongfang Information Habour, No.11 Langshan Road, Nanshan District, Shenzhen 518057, P.R.China Factory: Fujian Kirisun Communication Co., Ltd Address: Building C,Haixi Electronic Information Industry Incubation Base,Science and Industry Road,Hi-Tech Industry Park,Fengze District,Quanzhou,362000 Fujian,P.R.China 3.2. Product Description Main unit information: Product Name: PTToC Radio Trade Mark: , Model No.: K-I60 Listed Model(s): GP800 Power supply: DC 7.7V from Battery Hardware version: V1.0 Software version: V1.0 Accessory unit information: Battery information: Model: KDC-D60-A 7.7V 2400mAh/18.48Wh Adapter information: Model: TPQ-236A120100UW01 Ionput: 100-240V~50/60Hz 0.4A Output: 12.0Vd.c., 1.0A Rapid Charger information: Model: KBC-TD60-1Q Ionput: 12Vd.c. 1000mA Output: 800mA Report No.: CHTW26065033 Page 6 of 15 3.3. Radio Specification Description Operation Band: FDD Band 26 Operation Frequency Range: Uplink Do…

Text truncated - open the document above for the full version.

TEST REPORT For LTE Report No......................................... : CHTW26065032 Project No ........................................ : SHT2603040705W FCC ID ............................................. : Q5EKI60 Applicant’s name ............................. : Kirisun Communication Co.,Ltd. Address ............................................ : 3rd Floor, Building A, Tongfang Information Habour, No.11 Langshan Road, Nanshan District, Shenzhen 518057, P.R.China Product Name .................................. : PTToC Radio Trade Mark....................................... : , Model No.......................................... : K-I60 Listed Model(s) ................................ : GP800 Standard .......................................... : FCC CFR Title 47 Part 2 FCC CFR Title 47 Part 22 Subpart H FCC CFR Title 47 Part 24 Subpart E FCC CFR Title 47 Part 27 Date of receipt of test sample..........: 2026/4/7 Date of testing.............................: 2026/4/24- 2026/6/24 Date of issue...............................: 2026/6/30 Result ................... ........................: PASS Compiled by (Position+Printed name+Signature) : File administrator Caspar Chen Supervised by (Position+Printed name+Signature) : Project Engineer Xiaodong Zhao Approved by (Position+Printed name+Signature) : RF Manager Xu Yang Testing Laboratory Name ............. : Shenzhen Huatongwei International Inspection Co., Ltd. Address ............................................ : Building 7, Baiwang Idea Factory, No.1051, Songbai Road, Yangguang Community, Xili Subdistrict, Nanshan District, Shenzhen, Guangdong, China Test Report Form No. ........................ : R0066 Test Report Form(s) Originator ......... : Shenzhen Huatongwei International Inspection Co., Ltd. Master TRF ........................................ : Dated 2025-07 Shenzhen Huatongwei International Inspection Co., Ltd. All rights reserved. This publication may be reproduced in whole or in part for non-commercial purposes as long as the Shenzhen Huatongwei International Inspection Co., Ltd. is acknowledged as copyright owner and source of the material. Shenzhen Huatongwei International Inspection Co., Ltd. takes no responsibility for and will not assume liability for damages resulting from the reader's interpretation of the reproduced material due to its placement and context.The test report merely correspond to the test sample.The authenticity of this Test Report and its contents can be verified by contacting the Laboratory, responsible for this Test Report. Report No.: CHTW26065032 Page 2 of 42 Contents 1. TE S T S T A N D A R D S A N D R E P O R T V E R S I O N 3 1.1. Applicable Standards 3 1.2. Report version information 3 2. TE S T D E S C R I P T I O N 4 3. S U M M A R Y 5 3.1. Client Information 5 3.2. Product Description 5 3.3. Radio Specification Description 6 3.4. Testing Laboratory Information 7 4. TEST CONFIGURATION 8 4.1. Test frequency list 8 4.2. Test mode 10 4.3. Test sample information 11 4.4. Support unit used in test configuration and system 11 4.5. Testing environmental condition 11 4.6. Statement of the measurement uncertainty 11 4.7. Equipments Used during the Test 12 5. T E S T C O N D I T I O N S A N D R E S U L T S 13 5.1. ERP and EIRP 13 5.2. Radiated Spurious Emission 14 6. TE S T S E T U P P H O T O S O F T H E E U T 40 7. EX T E R N A L A N D I N T E R N A L P H O T O S O F T H E E U T 41 8. A P P E N D I X RE P O R T 42 Report No.: CHTW26065032 Page 3 of 42 1. TEST STANDARDS AND REPORT VERSION 1.1. Applicable Standards The tests were performed according to following standards: FCC CFR Title 47 Part 2: Frequency Allocations and Radio Treaty Matters; General Rules and Regulations FCC CFR Title 47 Part 22 Subpart H: Cellular Radiotelephone Service FCC CFR Title 47 Part 24 Subpart E: Broadband PCS FCC CFR Title 47 Part 27: Miscellaneous Wireless Communications Services ANSI C63.26-2015: American National Standard for Compliance Testing of Transmitters Used in Licensed Radio Services KDB 971168 D01 Power Meas License Digital Systems v03: MEASUREMENT GUIDANCE FOR CERTIFICATION OF LICENSED DIGITAL TRANSMITTERS 1.2. Report version information Revision No. Date of issue Description N/A 2026-06-30 Original Report No.: CHTW26065032 Page 4 of 42 2. TEST DESCRIPTION Section Test Item Section in CFR 47 Result #1 Test Engineer - Conducted Output Power Part 2.1046 Part 22.913(a) Part 24.232(c) Part 27.50 Pass * - - Peak-to-Average Ratio Part 24.232 Part 27.50 Pass * - - 99% Occupied Bandwidth & 26 dB Bandwidth Part 2.1049 Part 22.917(b) Part 24.238(b) Part 27.53 Pass * - - Band Edge Part 2.1051 Part 22.917 Part 24.238 Part 27.53 Pass * - - Conducted Spurious Emissions Part 2.1051 Part 22.917 Part 24.238 Part 27.53 Pass * - - Frequency stability vs temperature Part 2.1055(a)(1)(b) Part 22.355 Part 24.235 Part 27.54 Pass * - - Frequency stability vs voltage Part 2.1055(d)(1)(2) Part 22.355 Part 24.235 Part 27.54 Pass * - 5.1 ERP and EIRP Part 22.913(a) Part 24.232(b) Part 27.50 Pass JIAXING.SI 5.2 Radiated Spurious Emissions Part 2.1053 Part 22.917 Part 24.238 Part 27.53 Pass JUNXU.LIN Note: 1) #1: The test result does not include measurement uncertainty value. 2) *: Refer to module FCC ID: XMR2022SC200ENA. Report No.: CHTW26065032 Page 5 of 42 3. SUMMARY 3.1. Client Information Applicant: Kirisun Communication Co.,Ltd. Address: 3rd Floor, Building A, Tongfang Information Habour, No.11 Langshan Road, Nanshan District, Shenzhen 518057, P.R.China Manufacturer: Kirisun Communication Co.,Ltd. Address: 3rd Floor, Building A, Tongfang Information Habour, No.11 Langshan Road, Nanshan District, Shenzhen 518057, P.R.China Factory: Fujian Kirisun Communication Co., Ltd Address: Building C,Haixi Electronic Information Industry Incubation Base,Science and Industry Road,Hi-Tech Industry Park,Fengze District,Quanzhou,362000 Fujian,P.R.China 3.2. Product Description Main unit information: Product Name: PTToC Radio Trade Mark: , Model No.: K-I…

Text truncated - open the document above for the full version.

Appendix F: Dipole Calibration Certificate 45 of 51 Appendix F: Dipole Calibration Certificate 46 of 51 Appendix F: Dipole Calibration Certificate 47 of 51 Appendix F: Dipole Calibration Certificate 48 of 51 Appendix F: Dipole Calibration Certificate 49 of 51 Appendix F: Dipole Calibration Certificate 50 of 51 Appendix F: Dipole Calibration Certificate 51 of 51 Extended Dipole Calibrations Referring to KDB865664 D01, if dipoles are verified in return loss (<-20dB, within 20% of prior calibration), and in impedance (within 5 ohm of prior calibration), the annual calibration is not necessary and the calibration interval can be exte…
