Q639604

Iridium Satellite LLC

Hybrid LTE-M Cellular + IRIDIUM Satellite + GNSS module for IoT

Application Details

Equipment Class: TNB - Licensed Non-Broadcast Station Transmitter
Date of Grant: Apr 09, 2026
Application Purpose: Original Equipment
Equipment Note: Hybrid LTE-M Cellular + IRIDIUM Satellite + GNSS module for IoT
Frequency Range: 1616.00000000 - 1626.00000000
Company: Iridium Satellite LLC
Country: United States

Documents & Files

Select a file to view

Attestation Statements

Cover Letter(s)

ID Label/Location Info

RF Exposure Info

Test Report

Contact Information

Applicant

Kara Azocar(Vice President, Regulatory)

[email protected]Fax: 703-287-7425

Technical Contact

Iridium Satellite LLCKara Azocar

[email protected]

1750 Tysons Blvd. Ste. 1400 · McLean, 22102 · United States

Test Firm

SGS Taiwan Ltd. Central RF LabRyan WANG

[email protected]

Technical Specifications

#	Rule Parts	Frequency Range	Power Output	Emission	Tolerance
1	25	1.62 GHz - 1.63 GHz	1.718 W	41K7Q7D	10.0000000000ppm

Modular Type

Single Modular Approval

Confidentiality

Long Term

Grant Notes

Output power listed is conducted. Single Modular Approval. Approval is limited to OEM installation only. Compliance of this device in all final host configurations is the responsibility of the Grantee. This device is to be used only for mobile and fixed applications. OEM integrators must be provided labeling requirements for finished products. This grant is valid only when the device is sold to OEM integrators and the OEM integrators are instructed to ensure that the end user has no manual instructions to remove or install the device. Separate approval is required for all other operating configurations, including portable configurations with respect to 2.1093 and different antenna configurations. The module antenna(s) must be installed to meet the RF exposure compliance separation distance of 20 cm and any additional testing and authorization process as required. Co-location of this module with other transmitters that operate simultaneously are required to be evaluated using the FCC multi-transmitter procedures. This module can only be used with a host antenna circuit trace layout design in strict compliance with the OEM instructions provided. L-band downlink frequency range 1616-1626.5 MHz.
