Q7FVERS1QBLUETOOTH AUDIO BOX

Title page: _______________________ Vers Q Sound Systems 1 CHARGE ....................................................................................................2 2 POWER ON ................................................................................................3 3 PLAY ..........................................................................................................4 AUDIO OPTIONS .........................................................................................5 SPECIFICATIONS ........................................................................................6 CAUTION......................................................................................................7 FCC INFORMATION ...................................................................................8 WARRANTEE ..............................................................................................9 Page 2: _______________________ 1 CHARGE USB Connector Plug the USB cable into the power adaptor then into the outlet. Q comes partially charged, but should be charged for 5 hours before using. Select the appropriate plug end for your country. 5 hrs. to fully charge USB cable Plug Ends Australia EU UK Power Adaptor Page 3: _______________________ 2 POWER ON Power/Link button To turn on, press and hold the Power/Link button. Q is now ready to initiate Bluetooth pairing. Q can connect with any Bluetooth device. To turn off, press the Power/Link button. Refer to the Power/Link Button Functions on page 4. Page 4: _______________________ 3 PLAY Open the Bluetooth settings panel on your device (see your device’s instructions for details). Select Vers Q from the list and your device will automatically establish a connection. Your Q will “Tweet” to tell you a connection has been made, and will play music automatically. Q can connect with any Bluetooth device as well as any device with a headphone jack via the 3.5 mm cable. Power/Link Button Functions Blinking white Bluetooth connection established. Sound: Tweet Steady white Power on, full charge archived. Sound: One bell Blinking white–red Power on, no Bluetooth connection. Sound: One bell Blinking red Power on, low battery Sound: two bells Steady red When charging. Page 5: _______________________ AUDIO OPTIONS Aux in Connect any device directly to Q with the 3.5 mm cable. Stereo out (1Q only) Connect a second Q to Aux in with the 3.5 mm cable for stereo sound. Q (Aux in) 3.5 mm cable Second (Stereo out) Page 6: _______________________ SPECIFICATIONS Battery life ................................................................1Q ~10 hours, 2Q ~8 hours, depending on use Bluetooth ...................................................................v2.1 EDR Power ........................................................................1Q 6.5 W, 2Q 10 W Speaker ......................................................................1 - 2” full range driver (mono) > 2" full range driver Frequency ..................................................................(-3dB): 80Hz – 20 kHz AC adaptor input ........................................................100–240V @ 50–60 Hz, 500m A AC adaptor output ......................................................5V @ 2100 mA through 1 USB port > 5V @ 2100 mA Range ......................................................................... ~30 feet Page 7 _______________________ CAUTION WARNING Please read these safety warnings and cautions carefully to ensure your personal safety and prevent property damage. Fire and Electric Shock Hazard • Do not expose your Q Speaker to liquid, moisture, humidity, or rain. • Do not use the Q Speaker near a bathtub, sink, sauna, pool, or steam room. Exposure of the Q Speaker to moisture could result in electric shock. • Do not drop, disassemble, open, crush, bend, deform, puncture, shred, microwave, incinerate, paint, or insert foreign objects in to the Q Speaker. Such actions could result in electric shock. • Clean the Q Speaker only with a dry cloth. • Do not expose your Q Speaker to extremely high or low temperatures. • Do not leave your Q Speaker in direct sunlight for extended periods of time. Do not leave your Q Speaker near open flames such as cooking burners, candles, or fireplaces. • Do not block any ventilation openings. Battery/Charger Hazard • Do not dispose of your Q Speaker in a fire. The battery could explode causing injury or death. • Only charge the battery in accordance with the user instructions supplied with the Q Speaker. • Do not attempt to disassemble the Q Speaker charger or force open the built-in battery because this may result in electric shock. • Do not charge the Q Speaker in damp areas or in extremely high or low temperatures because this could result in electric shock. • Do not clean the Q Speaker when it is being charged. Always unplug the charger first before cleaning the Q Speaker. Automobile Accident Hazard • Do not leave or store the Q Speaker or any of its accessories near or over your automobile’s air bag because serious injury may result when an air bag deploys. Fall Hazard • Do not place the Q Speaker on high surfaces such as shelves. During music playback t he Q Speaker may move which could cause the Q Speaker to shift and fall off of the edge. Page 8 _______________________ CAUTION • Do not use abrasive cleaners to clean your Q Speaker because this could cause scratches and damage. • Do not bring your Q Speaker in to contact with any sharp objects because this could cause scratches and damage. • Do not insert anything into your Q Speaker unless otherwise specified in the user instructions. This may damage the internal components. • Do not attempt to repair, modify, or disassemble your Q Speaker yourself, it does not contain any user-serviceable components. • Do not attempt to replace your Q Speaker battery, it is built-in and is not changeable. • Use only the manufacturer supplied charger to charge your Q Speaker. Other chargers may look …

Text truncated - open the document above for the full version.

Date: Sept.28, 2012 To: Federal Communications Commission, Authorization & Evaluation Division, 7435 Oakland Mills Road, Columbia, MD 21046 To Whom It May Concern: The Lepide Technology Co., Limited, the undersigned, hereby authorizes Mr.Wu Xuewen from Shenzhen Morlab Communications Technology Co., Ltd., to act on the behalf of the Lepide Technology Co., Limited solely in matters relating to the application for an FCC equipment authorization for FCC ID:Q7FVERS1Q including the signing of documents in connection with this Application. Necessary acts carried out by Lepide Technology Co., Limited on our behalf of the Lepide Technology Co., Limited in connection with the Application shall have the same effect as acts of the Lepide Technology Co., Limited. The Lepide Technology Co., Limited also hereby certify that no party to this application is subject to a denial of benefits, including FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 853(a). Thank you for your attention to this matter. Yours Sincerely,

Date: Sept.28, 2012 To: Federal Communications Commission, Authorization & Evaluation Division, 7435 Oakland Mills Road, Columbia, MD 21046 Re: Lepide Technology Co., Limited FCC ID: Q7FVERS1Q FCC Part 15 Certification Confidentiality Request Gentlemen: This letter is to comply with 47 CFR 0.457 and 0.459 pertaining to confidentiality material. Lepide Technology Co., Limited requests that the following documents regarding this submission for FCC ID: Q7FVERS1Q be kept confidential: Exhibit Type File Name Block Diagram Block Diagram.pdf Schematics Schematics.pdf Operational Description Circuit Description.pdf Part list BOM.pdf Those documents contain detailed system and equipment description and related information about the product which Lepide Technology Co., Limited considers to be confidential proprietary, a custom design and, otherwise, not releasable to the general public. Since this design is a basis form which future technological products will evolve, Lepide Technology Co., Limited considers this information would be of benefit to its competitors, and that the disclosure of the information in these documents would give competitors an unfair advantage in the market. Thank you for your attention to this matter. Yours Sincerely,

External Photos

FCC ID: Q7FVERS1Q Label Label Location

Internal Photos

Report No.: SZ12080097E02 Page 2 of 16 TABLE OF CONTENTS 1. GENERAL INFORMATION .................................................................................................... 3 1.1 EUT Description ......................................................................................................................... 3 1.2 Test Standards and Results ........................................................................................................ 4 1.3 Facilities and Accreditations ...................................................................................................... 5 1.3.1 Facilities .................................................................................................................................... 5 1.3.2 Test Environment Conditions .................................................................................................... 5 1.3.3 Measurement Uncertainty ......................................................................................................... 5 2. TEST CONDITIONS SETTING............................................................................................... 6 2.1 Test Mode .................................................................................................................................... 6 2.2 Test Setup and Equipments List ................................................................................................ 7 2.2.1 Conducted Emission.................................................................................................................. 7 2.2.2 Radiated Emission ..................................................................................................................... 8 3. 47 CFR PART 15B REQUIREMENTS .................................................................................. 11 3.1 Conducted Emission ................................................................................................................. 11 3.1.1 Requirement ............................................................................................................................ 11 3.1.2 Test Description ...................................................................................................................... 11 3.1.3 Test Result ............................................................................................................................... 11 3.2 Radiated Emission .................................................................................................................... 13 3.2.1 Requirement ............................................................................................................................ 13 3.2.2 Test Description ...................................................................................................................... 13 3.2.3 Test Result ............................................................................................................................... 13 Change History Issue Date Reason for change 1.0 September 28, 2012 First edition Report No.: SZ12080097E02 Page 3 of 16 1. GENERAL INFORMATION 1.1 EUT Description EUT Type ........................Bluetooth Speaker Serial No. ........................(n.a., marked #1 by test site) Hardware Version .......... .V0.1 Software Version ............. Applicant ......................... Manufacturer .................. . V2.12 Lepide Technology Co., Limited Unit 302,303, 3/F, Building C, Hi-tech Innovation Centre, No. 16, Huifeng 2nd road east, Zhongkai district, Huizhou, Guangdong, China Lepide Technology Co., Limited Unit 302,303, 3/F, Building C, Hi-tech Innovation Service Centre, No. 16, Huifeng 2nd road east, Zhongkai district, Huizhou, Guangdong, China Modulation Type ............ .FHSS Power Supply ..................Battery Brand Name: N/A Model No.: 824452 Serial No.: (n.a. marked #1 by test site) Capacitance: 2000mAh Rated Voltage: 3.7V Ancillary Equipment 1.AC Adapter Brand Name: Vers Model No.: GPE010H-050210-Z Serial No.: (n.a. marked #1 by test site) Rated Input: 100-240V, 300mA, 50/60Hz Rated Output: 5V, 2100mA Ancillary Equipment 2 ... .USB Power Cable Ancillary Equipment 3 ... .Audio Cable NOTE: 1. The EUT is a Bluetooth Speaker, it’s a small portable music player, speaker and amplifier. It supports ISM 2.4GHz Bluetooth band which was tested in this report. 2. The EUT is equipped with a micro-USB port, an aux in port for audio input, and an line out port which can be connected with other voice box for audio output. 3. Please refer to ANNEX A for the photographs of the EUT. For a more detailed description, please refer to Specification or User’s Manual supplied by the applicant and/or manufacturer. Report No.: SZ12080097E02 Page 4 of 16 1.2 Test Standards and Results The objective of the report is to perform testing according to 47 CFR Part 15 Subpart B: No. Identity Document Title 1 47 CFR Part 15 (11-10-01 Edition) Radio Frequency Devices Test detailed items/section required by FCC and results are as below: No. Section Description Result 1 15.107 Conducted Emission PASS 2 15.109 Radiated Emission PASS NOTE: The tests were performed according to the method of measurements prescribed in ANSI C63.4 2009. Report No.: SZ12080097E02 Page 5 of 16 1.3 Facilities and Accreditations 1.3.1 Facilities Shenzhen Morlab Communications Technology Co., Ltd. Morlab Laboratory is a testing organization accredited by China National Accreditation Service for Conformity Assessment (CNAS) according to ISO/IEC 17025. The accreditation certificate number is L3572. All measurement facilities used to collect the measurement data are located at 3/F, Electronic Testing Building, Shahe Road, Xili, Nanshan District, Shenzhen, 518055 P. R. China. The test site is constructed in conformance with the requirements of ANSI C63.7, ANSI C63.4 and CISPR Publication 22; the FCC registration number is 741109. 1.3.2 Test Environment Conditions During the measurement, the enviro…

Text truncated - open the document above for the full version.

Test Setup Photos 1. CE 2．RE
