FCC Confidentiality Request To the FCC and FCC TCB handling this application for certification Pursuant to 47 CFR Section 0.459(a) & (b), we, (the applicant / grantee) Company name GUANGZHOU C&Q TELECOM EQUIPMENT CO.,LTD Addresss No.9 Shenzhou Rd, Guangzhou Science City City Guangzhou Country China request non-disclosure and confidential treatment for our certification under: Grantee Code Product Number FCC ID: Q8C RC9712C of the following materials submitted within this certification application: (please cross what is applicable, or add other documents) x Operational Description x Block Diagrams x Schematics Diagrams Bill of Materials Above materials contain secrets, proprietary and technical information, which would customarily be guarded from competitors under 47 CFR, section 0.457(d)(2). Disclosure or publication or any portion of this company confidential material to other parties could cause substantial competitive harm and provide unjustified benefits for competitors. We understand that pursuant to 47 CFR section 0.457(d)(1)(ii) disclosure of the applicant and all accompanying documentation will not be made before the date of the grant. Attestation: City and Country: Date: Name: (this must be a person) Function: Signature: (or official company stamp) Guangzhou 2013/1/28 Li Ma Certification Executive

APPENDIX-PHOTOGRAPHS OF EUT CONSTRUCTIONAL DETAILS Photo 1 Photo 2 Photo 3 Photo 4 Photo 5 Photo 6 Photo 7 Photo 8

Labei will be printed on the above 4.4*4.6cm

Photo 9 Photo 10 Photo 11 Photo 12 Photo 13 Photo 14 Photo 15 Photo 16

Letter of Certification This is to formally certify that: The tune up procedures of MID (RC9712C)is not open to end user. The end user is not allowed to perform finaltune. All the power and frequency set up were finished at the manufacturer stage. IEEE 802.11b max possible output power (AV,conducted) ：9±0.5dbm IEEE 802.11g max possible output power(AV, conducted) ：8±1dbm IEEE 802.11n max possible output power(AV, conducted) ：7±1dbm Regards, Yours sincerely, Signatory Signature Name: L i M a Title: Certification Executive Tel: 020-85571601-3032 Company : GUANGZHOU C&Q TELECOM EQUIPMENT CO.,LTD Add: No.9 Shenzhou Rd, Guangzhou Science City, Guangzhou, China

RF EXPOSURE EVALUATION METHOD SAR Test Exclusion Thresholds for 100 MHz – 6 GHz and ≤ 50 mm Approximate SAR Test Exclusion Power Thresholds at Selected Frequencies and Test Separation Distances are illustrated in the following Table. Maximum measured transmitter power. 802.11B frequency range Maximum Peak Conducted Output Power (dBm) Maximum Conducted Output Power(AV) (dBm) Maximum Conducted Output Power (mW) 2412 11.95 9.45 8.81 2437 11.72 9.32 8.55 2462 11.84 9.12 8.17 802.11G frequency range Maximum Peak Conducted Output Power (dBm) Maximum Conducted Output Power(AV) (dBm) Maximum Conducted Output Power (mW) 2412 9.76 7.43 5.53 2437 9.87 7.25 5.31 2462 9.57 7.19 5.24 802.11N frequency range Maximum Peak Conducted Output Power (dBm) Maximum Conducted Output Power(AV) (dBm) Maximum Conducted Output Power (mW) 2412 8.97 7.01 5.02 2437 8.68 6.68 4.66 2462 8.55 6.54 4.51 Referto44749825D01GeneralRFExposureGuidancev05AppendixA, youseethatfor Maximum Conducted Output Power8.81mW(<10mW),sonoSAR is required. For Tune Up information IEEE 802.11b max possible output power (AV) ：9.0±0.5dbm youseethatforMaximum Conducted Output Power8.91mW(9.5dBm)(<10mW),so noSAR is required.

FCC RADIO TEST REPORT Prepared For GUANGZHOU C&Q TELECOM EQUIPMENT CO.,LTD Product Name: MID Trade Name: N/A Model Name : RC9712C FCC ID: Q8CRC9712C Prepared By DongGuan Precise Testing Service Co.,Ltd. F616A Room, 6th Floor, Meixin Business Center, Dongcheng Middle Road, Dongguan, Guangdong, China Report No. PTS201301070F1 Test Date: Jan.05, 2013~ Jan 25, 2013 Date of Report : Jan 25, 2013 Page 2 of 84 Report No.: PTS201301070F1 VERIFICATION OF COMPLIANCE Applicant: GUANGZHOU C&Q TELECOM EQUIPMENT CO.,LTD Address No.9 shenzhou Rd, Guangzhou Science City, China Manufacturer Name: GUANGZHOU C&Q TELECOM EQUIPMENT CO.,LTD Address: No.9 shenzhou Rd, Guangzhou Science City, China Product Description: MID Brand Name: N/A Model Name: RC9712C Model difference: N/A Test procedure ANSI C63.4, DA00-705 Standards FCC Part15.247 Prepared by : Assistant Reviewer : Supervisor Approved & Authorized Signer : Jacky Ou / Manager Page 3 of 84 Report No.: PTS201301070F1 Table of Contents Page 1 . SUMMARY OF TEST RESULTS 5 1.1 TEST FACILITY 6 1.2 MEASUREMENT UNCERTAINTY 6 2 . GENERAL INFORMATION 7 2.1 GENERAL DESCRIPTION OF EUT 7 2.2 DESCRIPTION OF TEST MODES 9 2.3 TABLE OF PARAMETERS OF TEXT SOFTWARE SETTING 9 2.4 BLOCK DIGRAM SHOWING THE CONFIGURATION OF SYSTEM TESTED 10 2.5 DESCRIPTION OF SUPPORT UNITS(CONDUCTED MODE) 11 2.6 EQUIPMENTS LIST FOR ALL TEST ITEMS 12 3 . EMC EMISSION TEST 13 3.1 CONDUCTED EMISSION MEASUREMENT 13 3.1.1 POWER LINE CONDUCTED EMISSION LIMITS 13 3.1.2 TEST PROCEDURE 14 3.1.3 DEVIATION FROM TEST STANDARD 14 3.1.4 TEST SETUP 14 3.1.5 EUT OPERATING CONDITIONS 14 3.1.6 TEST RESULTS 15 3.2 RADIATED EMISSION MEASUREMENT 17 3.2.1 RADIATED EMISSION LIMITS 17 3.2.2 TEST PROCEDURE 18 3.2.3 DEVIATION FROM TEST STANDARD 18 3.2.4 TEST SETUP 19 3.2.5 EUT OPERATING CONDITIONS 20 3.2.6 TEST RESULTS (BELOW 30 MHZ) 21 3.2.7 TEST RESULTS (BETWEEN 30M – 1000 MHZ) 22 3.2.8 TEST RESULTS (ABOVE 1000 MHZ) 24 3.2.9 TEST RESULTS (RESTRICTED BANDS REQUIREMENTS) 42 4 . NUMBER OF HOPPING CHANNEL 54 4.1 APPLIED PROCEDURES / LIMIT 54 4.1.1 TEST PROCEDURE 54 4.1.2 DEVIATION FROM STANDARD 54 4.1.3 TEST SETUP 54 4.1.4 EUT OPERATION CONDITIONS 54 Page 4 of 84 Report No.: PTS201301070F1 Table of Contents Page 4.1.5 TEST RESULTS 55 5 . AVERAGE TIME OF OCCUPANCY 56 5.1 APPLIED PROCEDURES / LIMIT 56 5.1.1 TEST PROCEDURE 56 5.1.2 DEVIATION FROM STANDARD 56 5.1.3 TEST SETUP 57 5.1.4 EUT OPERATION CONDITIONS 57 5.1.5 TEST RESULTS 58 6 . HOPPING CHANNEL SEPARATION MEASUREMENT 60 6.1 APPLIED PROCEDURES / LIMIT 60 6.1.1 TEST PROCEDURE 60 6.1.2 DEVIATION FROM STANDARD 60 6.1.3 TEST SETUP 60 6.1.4 EUT OPERATION CONDITIONS 60 6.1.5 TEST RESULTS 61 7 . BANDWIDTH TEST 67 7.1 APPLIED PROCEDURES / LIMIT 67 7.1.1 TEST PROCEDURE 67 7.1.2 DEVIATION FROM STANDARD 67 7.1.3 TEST SETUP 67 7.1.4 EUT OPERATION CONDITIONS 67 7.1.5 TEST RESULTS 68 8 . PEAK OUTPUT POWER TEST 74 8.1 APPLIED PROCEDURES / LIMIT 74 8.1.1 TEST PROCEDURE 74 8.1.2 DEVIATION FROM STANDARD 74 8.1.3 TEST SETUP 74 8.1.4 EUT OPERATION CONDITIONS 74 8.1.5 TEST RESULTS 75 9 . ANTENNA REQUIREMENT 82 9.1 STANDARD REQUIREMENT 82 9.2 EUT ANTENNA 82 10 . EUT TEST PHOTO 83 APPENDIX-PHOTOGRAPHS OF EUT CONSTRUCTIONAL DETAILS Page 5 of 84 Report No.: PTS201301070F1 1. SUMMARY OF TEST RESULTS Test procedures according to the technical standards: FCC Part15 (15.247) , Subpart C& DA00-705 Standard Section Test Item Judgment Remark 15.207 Conducted Emission PASS 15.247(a)(1) Hopping Channel Separation PASS 15.247(b)(1) Peak Output Power PASS 15.247(c) Radiated Spurious Emission PASS 15.247(a)(iii) Number of Hopping Frequency PASS 15.247(a)(iii) Dwell Time PASS 15.247(a)(1) Bandwidth PASS 15.205 Band Edge Emission PASS 15.203 Antenna Requirement PASS NOTE: (1)” N/A” denotes test is not applicable in this Test Report Page 6 of 84 Report No.: PTS201301070F1 1.1 TEST FACILITY NTEK Testing Technology Co., Ltd Add. : 1/F, Building E, Fenda Science Park, Sanwei Community, Xixiang Street, Bao’an District, Shenzhen P.R. China. FCC Registration No.:238937; IC Registration No.:9270A-1 1.2 MEASUREMENT UNCERTAINTY The reported uncertainty of measurement y ± U，where expended uncertainty U is based on a standard uncertainty multiplied by a coverage factor of k=2，providing a level of confidence of approximately 95 %。 No. Item Uncertainty 1 Conducted Emission Test ±1.38dB 2 RF power,conducted ±0.16dB 3 Spurious emissions,conducted ±0.21dB 4 All emissions,radiated(<1G) ±4.68dB 5 All emissions,radiated(>1G) ±4.89dB 6 Temperature ±0.5°C 7 Humidity ±2% Page 7 of 84 Report No.: PTS201301070F1 2. GENERAL INFORMATION 2.1 GENERAL DESCRIPTION OF EUT Equipment MID Trade Name N/A Model Name RC9712C Serial Model N/A Model Difference N/A Product Description The EUT is a MID Operation Frequency: 2402~2480 MHz Modulation Type: BT(1Mbps): GFSK BT EDR(2Mbps): ∏ /4-DQPSK BT EDR(3Mbps): 8-DPSK Bit Rate of Transmitter 1Mbps/2Mbps/3Mbps Number Of Channel 79 CH Antenna Designation: Please see Note 3. Output Power(Conducted): BT(1Mbps): 1.011dBm BT EDR(2Mbps): -0.135dBm BT EDR(3Mbps): -0.363dBm Based on the application, features, or specification exhibited in User's Manual, the EUT is considered as an ITE/Computing Device. More details of EUT technical specification, please refer to the User's Manual. Channel List Please refer to the Note 2. Adapter Battery Rated Voltage: 3.7V Capacity :6600mAh Connecting I/O Port(s) Please refer to the User's Manual Note: 1. For a more detailed features description, please refer to the manufacturer’s specifications or the User's Manual. Page 8 of 84 Report No.: PTS201301070F1 2. Channel List Channel Frequency (MHz) Channel Frequency (MHz) Channel Frequency (MHz) 00 2402 27 2429 54 2456 01 2403 28 2430 55 2457 02 2404 29 2431 56 2458 03 2405 30 2432 57 2459 04 2406 31 2433 58 2460 05 2407 32 2434 59 2461 06 2408 33 2435 60 2462 07 2409 34 2436 61 2463 08 2410 35 2437 62 2464 09 2411 36 2438 63 2465 10 2412 37 2439 64 2466 11 2413 38 2440 65 2467 12 2414 39 2441 66 2468 13 2415 40 2442 67 2469 1…

Text truncated - open the document above for the full version.

FCC RADIO TEST REPORT Prepared For GUANGZHOU C&Q TELECOM EQUIPMENT CO.,LTD Product Name: MID Trade Name: N/A Model Name : RC9712C FCC ID: Q8CRC9712C Prepared By DongGuan Precise Testing Service Co.,Ltd. F616A Room, 6th Floor, Meixin Business Center, Dongcheng Middle Road, Dongguan, Guangdong, China Report No. PTS201301070F1 Test Date: Jan.05, 2013~ Jan 25, 2013 Date of Report : Jan 25, 2013 Page 2 of 72 Report No.: PTS201301070F1 VERIFICATION OF COMPLIANCE Applicant: GUANGZHOU C&Q TELECOM EQUIPMENT CO.,LTD Address No.9 shenzhou Rd, Guangzhou Science City, China Manufacturer Name: GUANGZHOU C&Q TELECOM EQUIPMENT CO.,LTD Address: No.9 shenzhou Rd, Guangzhou Science City, China Product Description: MID Brand Name: N/A Model Name: RC9712C Model difference: N/A Test procedure ANSI C63.4, KDB558074 Standards FCC Part15.247 Prepared by : Assistant Reviewer : Supervisor Approved & Authorized Signer : Jacky Ou / Manager Page 3 of 72 Report No.: PTS201301070F1 Table of Contents Page 1 . SUMMARY OF TEST RESULTS 5 1.1 TEST FACILITY 6 1.2 MEASUREMENT UNCERTAINTY 6 2 . GENERAL INFORMATION 7 2.1 GENERAL DESCRIPTION OF EUT 7 2.2 DESCRIPTION OF TEST MODES 9 2.3 BLOCK DIGRAM SHOWING THE CONFIGURATION OF SYSTEM TESTED 10 2.4 DESCRIPTION OF SUPPORT UNITS(CONDUCTED MODE) 11 2.5 EQUIPMENTS LIST FOR ALL TEST ITEMS 12 3 . EMC EMISSION TEST 13 3.1 CONDUCTED EMISSION MEASUREMENT 13 3.1.1 POWER LINE CONDUCTED EMISSION LIMITS 13 3.1.2 TEST PROCEDURE 14 3.1.3 DEVIATION FROM TEST STANDARD 14 3.1.4 TEST SETUP 14 3.1.5 EUT OPERATING CONDITIONS 14 3.1.6 TEST RESULTS 15 3.2 RADIATED EMISSION MEASUREMENT 17 3.2.1 RADIATED EMISSION LIMITS 17 3.2.2 TEST PROCEDURE 18 3.2.3 DEVIATION FROM TEST STANDARD 18 3.2.4 TEST SETUP 19 3.2.5 EUT OPERATING CONDITIONS 20 3.2.6 TEST RESULTS (BETWEEN 9KHZ – 30 MHZ) 21 3.2.7 TEST RESULTS (BETWEEN 30MHZ – 1GHZ) 22 3.2.8 TEST RESULTS (ABOVE 1000 MHZ) 24 4 . POWER SPECTRAL DENSITY TEST 54 4.1 APPLIED PROCEDURES / LIMIT 54 4.1.1 TEST PROCEDURE 54 4.1.2 DEVIATION FROM STANDARD 54 4.1.3 TEST SETUP 54 4.1.4 EUT OPERATION CONDITIONS 54 4.1.5 TEST RESULTS 55 5 . BANDWIDTH TEST 61 Page 4 of 72 Report No.: PTS201301070F1 Table of Contents Page 5.1 APPLIED PROCEDURES / LIMIT 61 5.1.1 TEST PROCEDURE 61 5.1.2 DEVIATION FROM STANDARD 61 5.1.3 TEST SETUP 61 5.1.4 EUT OPERATION CONDITIONS 61 5.1.5 TEST RESULTS 62 6 . PEAK OUTPUT POWER TEST 68 6.1 APPLIED PROCEDURES / LIMIT 68 6.1.1 TEST PROCEDURE 68 6.1.2 DEVIATION FROM STANDARD 68 6.1.3 TEST SETUP 68 6.1.4 EUT OPERATION CONDITIONS 68 6.1.5 TEST RESULTS 69 7 . ANTENNA REQUIREMENT 70 7.1 STANDARD REQUIREMENT 70 7.2 EUT ANTENNA 70 8 . EUT TEST PHOTO 71 APPENDIX-PHOTOGRAPHS OF EUT CONSTRUCTIONAL DETAILS Page 5 of 72 Report No.: PTS201301070F1 1. SUMMARY OF TEST RESULTS Test procedures according to the technical standards: FCC Part15 (15.247) , Subpart C& KDB558074 Standard Section Test Item Judgment Remark 15.207 Conducted Emission PASS 15.247 (a)(2) 6dB Bandwidth PASS 15.247 (b) Peak Output Power PASS 15.247 (c) Radiated Spurious Emission PASS 15.247 (d) Power Spectral Density PASS 15.205 Band Edge Emission PASS 15.203 Antenna Requirement PASS NOTE: (1)” N/A” denotes test is not applicable in this Test Report Page 6 of 72 Report No.: PTS201301070F1 1.1 TEST FACILITY NTEK Testing Technology Co., Ltd Add.:1/F, Building E, Fenda Science Park, Sanwei Community, Xixiang Street, Bao’an District, Shenzhen P.R. China. FCC Registration No.:238937; IC Registration No.:9270A-1 1.2 MEASUREMENT UNCERTAINTY The reported uncertainty of measurement y ± U，where expended uncertainty U is based on a standard uncertainty multiplied by a coverage factor of k=2，providing a level of confidence of approximately 95 %。 No. Item Uncertainty 1 Conducted Emission Test ±1.38dB 2 RF power,conducted ±0.16dB 3 Spurious emissions,conducted ±0.21dB 4 All emissions,radiated(<1G) ±4.68dB 5 All emissions,radiated(>1G) ±4.89dB 6 Temperature ±0.5°C 7 Humidity ±2% Page 7 of 72 Report No.: PTS201301070F1 2. GENERAL INFORMATION 2.1 GENERAL DESCRIPTION OF EUT Equipment MID Trade Name N/a Model Name RC9712C Model Difference N/A Product Description The EUT is a MID Operation Frequency: 802.11b/g/n:2412~2462 MHz Modulation Type: CCK/OFDM/DBPSK/DAPSK Bit Rate of Transmitter 802.11b:11/5.5/2/1 Mbps 802.11g:54/48/36/24/18/12/9/6 Mbps 802.11n:72.2/52/6.5 Mbps Number Of Channel 802.11b/g/n: 11CH Antenna Designation: Please see Note 3. Output Power(Conducted): 802.11b: 11.95 dBm (Max.) 802.11g: 9.87 dBm (Max.) 802.11n: 8.97 dBm (Max.) Antenna Gain (dBi) 1.0dbi Based on the application, features, or specification exhibited in User's Manual, the EUT is considered as an ITE/Computing Device. More details of EUT technical specification, please refer to the User's Manual. Channel List Please refer to the Note 2. Adapter Battery Rated Voltage: 3.7V Capacity :6600mAh Connecting I/O Port(s) Please refer to the User's Manual Page 8 of 72 Report No.: PTS201301070F1 Note: 1. For a more detailed features description, please refer to the manufacturer’s specifications or the User's Manual. 2. Channel List for 802.11b/g/n Channel Frequency (MHz) Channel Frequency (MHz) Channel Frequency (MHz) Channel Frequency (MHz) 01 2412 04 2427 07 2442 10 2457 02 2417 05 2432 08 2447 11 2462 03 2422 06 2437 09 2452 3. Table for Filed Antenna Ant . Brand Model Name Antenna Type Connector Gain (dBi) NOTE A N/A N/A Chip Antenna N/A 1.0 N/A Page 9 of 72 Report No.: PTS201301070F1 2.2 DESCRIPTION OF TEST MODES To investigate the maximum EMI emission characteristics generates from EUT, the test system was pre-scanning tested base on the consideration of following EUT operation mode or test configuration mode which possible have effect on EMI emission level. Each of these EUT operation mode(s) or test configuration mode(s) mentioned above was evaluated respectively. Pretest Mode Description Mode 1 802.11b CH1/ CH6/ CH11 Mode 2 802.11g CH1/ CH6/ CH11 Mode 3 802.11n CH1/ CH6/ CH11 Mode 4 Link Mode For Conducted Emission Final Test Mode Description …

Text truncated - open the document above for the full version.

Page 71 of 72 Report No.: PTS201301070F1 8. EUT TEST PHOTO Radiated Measurement Photos Page 72 of 72 Report No.: PTS201301070F1 Conducted Measurement Photos
