Exhibit – MBR 144 OEM model difference overview The MBR 144 OEM has three HVIN model variations under the same IC: Product: IC: HVIN: PMN: 1 5637A-M144M2OEM M144M2OEM MBR 144 OEM 2 5637A-M144M2OEM M144M2SUB MBR 144 Submersible 3 5637A-M144M2OEM M144M2FNet FishNet 144 The RF design for all HVINs is identical, and the performance for each version is the same. The difference is mechanical housing for different environments the products will be used in. The antenna design are identical for M144M2OEM and M144M2FNet, and M144M2SUB has a different coax feed but same antenna gain and performance. The three different HVINs are described below: HVIN: M144M2OEM This is the basic product for all HVIN types within IC: 5637A-M144M2OEM HVIN: M144M2SUB This product variation is a pressure housing around the MBR 144 OEM product: HVIN: M144M2FNet This product variation is a plastic housing around the MBR 144 OEM product:

To Whomever it may concern POWER OF ATTORNEY The undersigned, Sigfred Vetti Avdal, hereby confirms the authorization to David Moller Hagen Project Manager MBR, Research & Development Dep. Kongsberg Seatex AS PB 1203 Pirsenteret N-7462 Trondheim Mobile: +47 952 44 228 [email protected] gsberg.com to sign the following documents, ref: . Product Name: MBR 144 FCC ID: Q8lM L44M2FIX IC: 5637 A-Ml44M2FLX . Product Name: MBR 144 OEM FCC ID: Q8lML44M2OEM IC 5637A-M144M2OEM . Product Name: MBR 144 Personal FCC ID: Q8IM144M2PER IC 5637A-M 144M2PER on behalf of Business name: Kongsberg Seatex AS, org. no. 982 786 185 Contact Name: Mr Sigfred Avdal Company Address: Pirsenteret, Trondheim, N-7 462, Norway. FRN: 0009071892 CN: 56374 KONGSBERG SEATEX AS Pirsenteret, N-7462 Trondheim, Norway Enterprise number NO 982 786 185 MVA I(ONGSBERG eim, April 2, 2020 V, 0""' V. Avdal Telephone +47 13 54 55 00 [email protected] www.kongsberg.com

FCC Exhibit – External Photos - MBR 144 OEM Front: Side: Rear:

FCC Exhibit – Product label – MBR 144 Submersible The marking plates are fixed with a self-adhesive tape on the aluminium parts of the product. The label is made from aluminium foil or moulded material designed for unprotected outdoor use, corresponding to an ingress protection IP66. The marking plate has been tested with isopropyl alcohol and a mechanical test as specified in ExTAG/67/CD. The marking is highly durable. The label is located at the bottom of the product: (mock-up showing lable position)

FCC Exhibit – Product label - MBR 144 OEM The marking plates are fixed with a self-adhesive tape on the aluminium parts of the product. The label is made from aluminium foil or moulded material designed for unprotected outdoor use, corresponding to an ingress protection IP66. The marking plate has been tested with isopropyl alcohol and a mechanical test as specified in ExTAG/67/CD. The marking is highly durable. The label is located at the rear side of the product:

FCC/IC Exhibit – Internal Photos - MBR 144 OEM Internal Parts: Both PCBs side A: Both PCBs side B: Aluminium shielding and housing parts: Stacked assembly:

Exhibit – Tune-up tolerance statement The output power variation due to frequency and temperature is +1 to -3 dB from the stated nominal figures.

FCC ID: Q8IM144M2OEM MPE Calculation for FCC Uncontrolled Environment Formula from page 18 of OET Bulletin 65, Edition 97-01 where:S = power density P = power input to the antenna G = power gain of the antenna in the direction of interest relative to an isotropic radiator R = distance to the center of radiation of the antenna Source Based Time Averaged Duty Cycle is 100% in calculation below Maximum peak output power at antenna input terminal:29.47(dBm) Maximum peak output power at antenna input terminal:0.885(W) Maximum antenna gain:6.00(dBi) Maximum antenna gain:3.981(numeric) Prediction distance:20(cm) Prediction frequency:5800(MHz) Time Averaged Duty Cycle100% MPE limit for uncontrolled exposure at prediction frequency:10.00(W/m^2) Power density at prediction frequency:0.7010(mW/cm^2) Power density at prediction frequency:7.010(W/m^2) Maximum allowable antenna gain:7.54(dBi) Margin of Compliance:1.54(dB) 2 4R PG S p =

Report No. 379761-01-R00 Template version: C Nemko Norway Nemko AS, Instituttveien 6, P.O. Box 96 Kjeller, 2027 Kjeller, Norway TEL +47 22 96 03 30 FAX +47 22 96 05 50 EMAIL [email protected] ENTERPRISE NUMBER NO974404532 nemko.com/no Test Report Product Maritime Broadband Radio Name and address of the applicant Kongsberg Seatex AS Pirsenteret, N-7492 Trondheim, Norway Name and address of the manufacturer Kongsberg Seatex AS Pirsenteret, N-7492 Trondheim, Norway Model MBR 144 OEM Rating 24Vdc Trademark Kongsberg seatex Serial number 9532 Additional information The tested device contains radio module operates in U-NII Band III. Tested according to FCC Part 15.407 Unlicensed National Information Infrastructure Devices (U-NII) Industry Canada RSS-247, Issue 2 Licence-Exempt Local Area Network (LE-LAN) Devices Order number 379761 Tested in period 2019.10.10 - 2019.10.26 Issue date 2020.04.30 Name and address of the testing laboratory Instituttveien 6 Kjeller, Norway www.nemko.com CAB Number FCC: NO0001 ISED: NO0470 TEL: +47 22 96 03 30 FAX: +47 22 96 05 50 An accredited technical test executed under the Norwegian accreditation scheme Prepared by [G.Suhanthakumar] Approved by [Frode Sveinsen] This report shall not be reproduced except in full without the written approval of Nemko. Opinions and interpretations expressed within this report are not part of the current accreditation. This report was originally distributed electronically with digital signatures. For more information contact Nemko. TEST REPORT FCC Part 15.407 Report no.: 379761-01-R00 FCC ID: Q8IM144M2OEM Nemko Norway, Instituttveien 6, Kjeller, Norway Page 2 (54) CONTENTS 1 INFORMATION ......................................................................................................................... 3 1.1 Test Item .................................................................................................................................... 3 1.3 Normal test conditions ............................................................................................................... 4 1.4 Test Engineer(s) ........................................................................................................................ 4 1.5 Description of modification for Modification Filing ...................................................................... 4 1.6 Family List Rational ................................................................................................................... 4 1.7 Antenna Requirement ................................................................................................................ 4 1.8 Worst-Case Configuration ......................................................................................................... 4 1.9 EUT Operating Modes ............................................................................................................... 4 1.10 Comments ................................................................................................................................. 4 1.11 EUT Power settings ................................................................................................................... 5 1.12 TEST REPORT SUMMARY ...................................................................................................... 6 1.13 General ...................................................................................................................................... 6 1.14 Test Summary ........................................................................................................................... 7 2 TEST RESULTS ........................................................................................................................ 8 2.1 Power Line Conducted Emissions ............................................................................................. 8 2.2 Maximum Output Power, e.i.r.p. .............................................................................................. 10 2.3 Emission Bandwidth ................................................................................................................ 19 2.4 DTS Bandwidth ........................................................................................................................ 24 2.5 Peak Power Spectral Density .................................................................................................. 27 2.6 Unwanted Emissions ............................................................................................................... 30 2.7 Restricted Bands of operation.................................................................................................. 32 2.8 Radiated Emissions, 30 – 1000 MHz ....................................................................................... 33 2.9 Radiated Emissions, 1 – 40 GHz ............................................................................................. 35 3 Measurement Uncertainty ..................................................................................................... 51 4 LIST OF TEST EQUIPMENT................................................................................................... 52 5 BLOCK DIAGRAM .................................................................................................................. 53 5.1 Power Line Conducted Emission ............................................................................................. 53 5.2 Conducted Tests ...................................................................................................................... 53 5.3 Test Site Radiated Emission .................................................................................................... 54 TEST REPORT FCC Part 15.407 Report no.: 379761-01-R00 FCC ID: Q8IM144M2OEM Nemko Norway, Instituttveien 6, Kjeller, Norway Page 3 (54) 1 INFORMATION 1.1 Test Item Name Kongsberg seatex Model MBR 144 OEM FCC ID Q8IM144M2OEM I…

Text truncated - open the document above for the full version.

TEST SET-UP PHOTOS Projectno.: 379761 FCC ID: Q8IM144M2OEM Page 1 (2) PHOTOS OF TEST SET-UP Radiated emission 30 - 1000 MHz Radiated emissions above 1 GHz TEST SET-UP PHOTOS Projectno.: 379761 FCC ID: Q8IM144M2OEM Page 2 (2) Power line Conducted Emissions Test
