Q8NAWU2000B2.4GHz WLAN USB Stick

Wireless LAN USB Stick AWU2000b User Manual 15.19 (FCC DoC Labeling) AIN AWU2000b Wireless LAN USB Stick FOR HOME OR OFFICE USE 15.21 CAUTION: Any changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. Caution Statement of the FCC Radio Frequency Exposure This Wireless LAN radio device has been evaluated under FCC Bulletin OET 65C and found compliant to the requirements as set forth in CFR 47 Sections 2.1091, 2.1093, and 15.247(b)(4) addressing RF Exposure from radio frequency devices. The radiation output power of this Wireless LAN device is far below the FCC radio frequency exposure limits. Nevertheless, this device shall be used in such a manner that the potential for human contact during normal operation — as a mobile or portable device but use in a body - worn way is strictly prohibit. Prohibition of co-location This device must not be co-located or operating in conjunction with any other antenna or transmitter Tested to Comply With FCC Standard 15.105 Federal Communications Commission (FCC) Requirements, Part 15 This equipment has been tested and found to comply with the limits for a class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: ---Reorient or relocate the receiving antenna. ---Increase the separation between the equipment and receiver. ---Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. ---Consult the dealer or an experienced radio/TV technician for help. Regulatory information / Disclaimers Installation and use of this Wireless LAN device must be in strict accordance with the instructions included in the user documentation provided with the product. Any changes or modifications (including the antennas) made to this device that are not expressly approved by the manufacturer may void the user’s authority to operate the equipment. The manufacturer is not responsible for any radio or television interference caused by unauthorized modification of this device, or the substitution of the connecting cables and equipment other than manufacturer specified. It is the responsibility of the user to correct any interference caused by such unauthorized modification, substitution or attachment. Manufacturer and its authorized resellers or distributors will assume no liability for any damage or violation of government regulations arising from failing to comply with these guidelines. Content 1. Product Introduction............................................................................................2 2. AWU2000b Installation.........................................................................................4 3. Software Installation.............................................................................................6 4. Ad-Hoc (Peer-to-Peer) Mode Setup..........................................................................11 Application 1: Access the Internet without an AP Application 2: Data sharing between computers 5. Technical Support...............................................................................................20 AIN AWU2000b WLAN USB STICK 1 AIN AWU2000b WLAN USB STICK 2 1. Product Introduction Thank you for using AIN’s WLAN product. This installation guide will help you install AWU2000b and connect to the Internet quick & easy. ■ Package Contents 1. AWU2000b WLAN USB STICK 2. Quick Installation Guide 3. Manual & Driver CD Disc 4. USB cable (Optional) ■ Form Factor ■ System Requirements 1. Desktop/ Laptop with USB port and CD-ROM driver 2. Operating System: Linux/ Mac OS X/ Windows 98 SE/ME/2000/XP High performance antenna LED Indicator: Green: Connected Blinking: Not connected AIN AWU2000b WLAN USB STICK 3 ■ Applied Environments There are two application modes for this WLAN card, the “Ad-Hoc mode” and the “Infrastructure mode”. (For further explain, please refer to the “WLAN Application Modes” below) Different modes require different settings. Please check the environment first. Infrastructure mode: Via “Access Point” (AP) to connect to the Internet. This mode further gives wireless access to Internet or data sharing under a previously wired environment. Ad-Hoc mode: Connecting to other computer with WLAN card. This mode does not need AP to connect to each other. ■ WLAN Application Modes Ad-Hoc Mode Ad-Hoc mode is a Peer-to-Peer mode. Without an AP, computers can also connect to each other by AWU2000b USB stick. With this mode, computers are able to share data or connect to the Internet if one of them is already connected to. Infrastructure Mode Infrastructure mode including an AP, unlike Ad-Hoc mode, enabling users to best utilizes the frequency bandwidth of the AP. This mode enables users to integrate wired and wireless infrastructures. Through APs, wireless users are able to access wired resources, for example: Internet, database, and printers. Advantages Comparing to Ad-Hoc mode, Infrastructure mode has the following advantages: 9 Longer distance: Through AP, the wireless access distance is longer. 9 Roaming: The wireless devices can move within the AP support area. 9 Integration of wired and wireless environment. iMac LoadBatter yLine On On Ba t ter y Sm a rt Bo o s t Replace Ba t tery Tes t INFRASTRUCTURE WIRELESS Ad-Hoc Infrastructure mode Ad-Hoc …

Text truncated - open the document above for the full version.

AIN COMM. TECHNOLOGY CO., LTD. 2F, No. 76, Sec. 2, Mintzu Rd., Jung-Li City, Taoyuan 320, Taiwan TEL: +886-3- 4938448 FAX: +886-3- 4938804 FCC ID: Q8NAWU2000B Federal Communications Commission Authorization and Evaluation Division Confidentiality Request Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, the Applicant hereby requests confidential treatment of information accompanying this Application as outlined below: Schematics Block Diagram The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the Applicant and provide unjustified benefits to its competitors. The Applicant understands that pursuant to Rule 0.457, disclosure of this Application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely Yours, Ming-Yi Lay, Ph. D. AIN COMM. TECHNOLOGY CO., LTD. TEL: +886-3-4938448 FAX: +886-3-4938804 Email: [email protected]

AIN COMM. TECHNOLOGY CO., LTD. 2F, No. 76, Sec. 2, Mintzu Rd., Jung-Li City, Taoyuan 320, Taiwan TEL: +886-3- 4938448 FAX: +886-3- 4938804 POWER OF ATTORNEY To Whom It May Concern: We, the undersigned, AIN COMM. TECHNOLOGY CO., LTD., hereby authorize Advance Data Technology Corp. (ADT) of Taiwan to act on our behalf in all matters relating to all processes required in the FCC Part 15C. Any and all acts carried out by ADT on our behalf shall have the same effects as acts of our own. If you had any question regarding the authorization, please don’t hesitate to contact us. Thank you! Sincerely Yours, Ming-Yi Lay, Ph. D. AIN COMM. TECHNOLOGY CO., LTD. TEL: +886-3-4938448 FAX: +886-3-4938804 Email: [email protected]

[email protected] www.adt.com.tw ADVANCE DATA TECHNOLOGY CORPORATION FEDERAL COMMUNICATIONS COMMISSION DECLARATION OF CONFORMITY (DoC) FOR THE FOLLOWING EQUIPMENT: PRODUCT NAME: 2.4GHz WLAN USB Stick (Receiver Part) MODEL NO.: AWU2000b TRADE NAME: AIN IS HEREWITH CONFIRMED AND FOUND TO COMPLY WITH THE REQUIREMENTS OF CFR 47 PART 15 REGULATION. THE RESULTS OF ELECTROMAGNETIC EMISSION EVALUATION ARE SHOWN IN THE REPORT NO.: D920526R01 THIS DEVICE COMPLIES WITH PART 15 OF THE FCC RULES. OPERATION IS SUBJECT TO THE FOLLOWING TWO CONDITIONS: (1) THIS DEVICE MAY NOT CAUSE HARMFUL INTERFERENCE AND, (2) THIS DEVICE MUST ACCEPT ANY INTERFERENCE RECEIVED, INCLUDING INTERFERENCE THAT MAY CAUSE UNDESIRED OPERATION. THE FOLLOWING LOCAL MANUFACTURER/IMPORTER IS RESPONSIBLE FOR THIS DECLARATION ManufacturerUSA Local Representative Company name: AIN COMM.TECHNOLOGY CO., LTD. To Be Determined. Address: 2F,No.76,Sec.2, Mintzu Rd.,Jung Li City, Taoyuan 320, Taiwan Contact Person: Ming-Yi Lay Title: Manager Tel/Fax: TEL.:+886+3- FAX:+886+3-

American Telecommunications Certification Body Inc. 6731 Whittier Ave, McLean, VA 22101 July 28, 2003 RE: FCC ID: Q8NAWU2000B Attention: Ellis Wu I have a few comments on this Application. 1. Please note that on page 2 of the manual you state that a ‘certain’ distance must be maintained between the user and the device. However, the SAR was tested at 0 distance. Since the SAR report was tested with the antenna in contact with the phantom, you should remove the last sentence in the statements on page 2 of the manual referring to distance requirements. 2. Please note that since this is a portable device (i.e. capable of being used within 20 cm of the body) and since it was tested for SAR, the MPE statement on page 3 of the manual is not appropriate. It should be removed or restated to reflect SAR evaluation. 3. FYI - Please note that AC conducted average limits are ALWAYS applicable, even if the average limit is shown compliant using QP readings. This means that your tables for conducted emissions are only partially correct in that only compliance to the QP limit has been shown. Please note that even though the QP is under the average limit, BOTH QP and average limits MUST be reported using those QP values. The easiest way is to show compliance to the average limit using QP values. This condition meets the requirement of BOTH limits being met. When the QP is over the average limit then averaging is required. 4. Dennis Ward mailto:[email protected] The items indicated above must be submitted before processing can continue on the above referenced application. Failure to provide the requested information may result in application termination. Correspondence should be considered part of the permanent submission and may be viewed from the Internet after a Grant of Equipment Authorization is issued. Please do not respond to this correspondence using the email reply button. In order for your response to be processed expeditiously, you must submit your documents through the AmericanTCB.com website. Also, please note that partial responses increase processing time and should not be submitted. Any questions about the content of this correspondence should be directed to the sender.

Page 6 Page 7

0 0 0 D 2 F 1 2 3 4 5 6 S/N: 22222333334444 30 mm 20 mm FCC ID:Q8NAWU2000B MAC Address Barcode

Page 1 ANNEX PHOTOGRAPHS OF EUT Page 2 Page 3 Page 4 Page 5

FCC ID: Q8NAWU2000B Report No.920526R01 Operational Description The transmitter of the EUT is powered by host equipment. The antenna used in this product is External antenna with URL connector. Under normal use condition, the user has to keep at least 2.5cm separation distance between radiator and the body of the user. The other instruction, please have a look at the users manual. DSSS Information This device is Direct Sequence Spread Spectrum, the data is mixed by pseudorandom code which is an orthogonal code. The mixed data is digital modulated by BPSK and QPSK technique depends on the data rates. The CCK coding is applied for increasing the data rate, and also the processing gain will be increased. The bit rates are 1,2,5.5,11Mbps, the symbol rates are 1,1,1.375,1.375Mbps, the chip rates are always 11Mbps. So, the Chip/symbol is 11,11,8 and 8 respectively. Although is higher bit rate, the processing gain is lower than 10, but the CCK coding used in higher bit rate will provide 2.2dB coding gain.

FCC ID:Q8NAWU2000B Report No.: SA920526R011Issued: June 09 th 2003 SAR TEST REPORT REPORT NO.: SA920526R01 MODEL NO.: AWU2000b RECEIVED: June 9 2003 TESTED: June 9 2003 APPLICANT: AIN COMM. TECHNOLOGY ADDRESS: 2F,No.76,Sec.2, Mintzu Rd.,Jung Li City,Taoyuan 320, Taiwan ISSUED BY: Advance Data Technology Corporation LAB LOCATION: 47 14th Lin, Chiapau Tsun, Linko, Taipei, Taiwan, R.O.C. This test report consists of 31 pages in total except Appendix. It may be duplicated completely for legal use with the approval of the applicant. It should not be reproduced except in full, without the written approval of our laboratory. The client should not use it to claim product endorsement by CNLA, NVLAP or any government agencies. The test results in the report only apply to the tested sample. FCC ID:Q8NAWU2000B Report No.: SA920526R012Issued: June 09 th 2003 Table of Contents 1.CERTIFICATION........................................................................................................................ 3 2.GENERAL INFORMATION........................................................................................................ 4 2.1GENERAL DESCRIPTION OF EUT.......................................................................................... 4 2.2GENERAL DESCRIPTION OF APPLIED STANDARDS ........................................................... 5 2.3GENERAL INOFRMATION OF THE SAR SYSTEM ................................................................. 5 2.4 GENERAL DESCRIPTION OF THE SPATIAL PEAK SAR EVALUATION AND PROBE SCAN.. 9 3.DESCRIPTION OF TEST MODES AND CONFIGURATIONS................................................ 13 4.DESCRIPTION OF SUPPORT UNITS .................................................................................... 14 5.TEST RESULTS ...................................................................................................................... 15 5.1TEST PROCEDURES .............................................................................................................15 5.2MEASURED SAR RESULT ..................................................................................................... 16 5.3SAR LIMITS ............................................................................................................................. 18 5.4RECIPES FOR TISSUE SIMULATING LIQUIDS .................................................................... 18 5.5TEST EQUIPMENT FOR TISSUE PROPERTY...................................................................... 20 6.SYSTEM VALIDATION ............................................................................................................21 6.1TEST EQUIPMENT ................................................................................................................. 21 6.2TEST PROCEDURE................................................................................................................ 21 6.3VALIDATION RESULT............................................................................................................. 23 6.4SYSTEM VALIDATION UNCERTAINTIES .............................................................................. 24 7.MEASUREMENT SAR PROCEDURE UNCERTAINTIES ...................................................... 25 7.1PROBE CALIBRATION UNCERTAINTY ................................................................................. 25 7.2ISOTROPY UNCERTAINTY .................................................................................................... 25 7.3BOUNDARY EFFECT UNCERTAINTY ................................................................................... 26 7.4PROBE LINEARITY UNCERTAINTY ...................................................................................... 26 7.5READOUT ELECTRONICS UNCERTAINTY .......................................................................... 26 7.6RESPONSE TIME UNCERTAINTY ......................................................................................... 27 7.7INTEGRATION TIME UNCERTAINTY .................................................................................... 28 7.8PROBE POSITIONER MECHANICAL TOLERANCE ............................................................. 28 7.9PROBE POSITIONING............................................................................................................29 7.10 PHANTOM UNCERTAINTY..................................................................................................... 29 7.11 DASY4 UNCERTAINTY BUDGET........................................................................................... 30 8.INFORMATION ON THE TESTING LABORATORIES............................................................ 31 APPENDIX A: TEST CONFIGURATIONS AND TEST DATA APPENDIX B: ADT SAR MEASUREMENT SYSTEM APPENDIX C: PHOTOGRAPHS OF SYSTEM VALIDATION APPENDIX D: SYSTEM CERTIFICATE & CALIBRATION FCC ID:Q8NAWU2000B Report No.: SA920526R013Issued: June 09 th 2003 1. CERTIFICATION PRODUCT : 2.4GHz WLAN USB Stick MODEL NO. : AWU2000b BRAND NAME : AIN APPLICANT : AIN COMM. TECHNOLOGY STANDARDS : 47 CFR Part 2 (Section 2.1093), FCC OET Bulletin 65, Supplement C (01-01), RSS-102 We, Advance Data Technology Corporation, hereby certify that one sample of the designation has been tested in our facility on 09 th June 2003. The test record, data evaluation and Equipment Under Test (EUT) configurations represented herein are true and accurate, and it was tested according to the standards listed above. This device was found to be in compliance with the Specific Absorption Rate (SAR) requirement specified in FCC part 2.1093 under General Population / Uncontrolled Exposure condition. FCC ID:Q8NAWU2000B Report No.: SA920526R014Issued: June 09 th 2003 2. GENERAL INFORMATION 2.1 GENERAL DESCRIPTION OF EUT PRODUCT 2.4GHz WLAN USB Stick MODEL NO. AWU2000b POWER SUPPLY 3.3VDC powered by host equipment CLASSIFICATION Portable device, production unit MODULATION TYPE BPSK, QPSK, CCK RADIO TECHNOLOGY DSS…

Text truncated - open the document above for the full version.

FCC ID: Q8NAWU2000B Report No.: RF920526R011Issued: June 30, 2003 FCC TEST REPORT REPORT NO.: RF920526R01 MODEL NO.: AWU2000b RECEIVED: May 26, 2003 TESTED: June 5 ~ June 6, 2003 APPLICANT: AIN COMM.TECHOLOGY ADDRESS: 2F,No.76,Sec.2, Mintzu Rd.,Jung Li City, Taoyuan 320, Taiwan ISSUED BY: Advance Data Technology Corporation LAB LOCATION: 47 14th Lin, Chiapau Tsun, Linko, Taipei, Taiwan, R.O.C. This test report consists of 48 pages in total. It may be duplicated completely for legal use with the approval of the applicant. It should not be reproduced except in full, without the written approval of our laboratory. The client should not use it to claim product endorsement by CNLA, NVLAP or any government agencies. The test results in the report only apply to the tested sample. 0528 ILAC MRA Lab Code: 200102-0 FCC ID: Q8NAWU2000B Report No.: RF920526R012Issued: June 30, 2003 Table of Contents 1CERTIFICATION........................................................................................... 4 2SUMMARY OF TEST RESULTS .................................................................. 5 3GENERAL INFORMATION ........................................................................... 6 3.1GENERAL DESCRIPTION OF EUT ............................................................. 6 3.2DESCRIPTION OF TEST MODES ............................................................... 7 3.3GENERAL DESCRIPTION OF APPLIED STANDARDS............................... 7 3.4DESCRIPTION OF SUPPORT UNITS.......................................................... 8 4TEST TYPES AND RESULTS ...................................................................... 9 4.1CONDUCTED EMISSION MEASUREMENT................................................ 9 4.1.1 LIMITS OF CONDUCTED EMISSION MEASUREMENT ............................. 9 4.1.2 TEST INSTRUMENTS .................................................................................. 9 4.1.3 TEST PROCEDURES ................................................................................ 10 4.1.4 DEVIATION FROM TEST STANDARD ....................................................... 10 4.1.5 TEST SETUP.............................................................................................. 11 4.1.6 EUT OPERATING CONDITIONS ............................................................... 11 4.1.7 TEST RESULTS ......................................................................................... 12 4.2RADIATED EMISSION MEASUREMENT................................................... 18 4.2.1 LIMITS OF RADIATED EMISSION MEASUREMENT ................................ 18 4.2.2 TEST INSTRUMENTS ................................................................................ 19 4.2.3 TEST PROCEDURES ................................................................................ 20 4.2.4 DEVIATION FROM TEST STANDARD ....................................................... 20 4.2.5 TEST SETUP.............................................................................................. 21 4.2.6 EUT OPERATING CONDITIONS ............................................................... 21 4.2.7 TEST RESULTS ......................................................................................... 22 4.36dB BANDWIDTH MEASUREMENT .......................................................... 26 4.3.1 LIMITS OF 6dB BANDWIDTH MEASUREMENT........................................ 26 4.3.2 TEST INSTRUMENTS ................................................................................ 26 4.3.3 TEST PROCEDURE ................................................................................... 27 4.3.4 DEVIATION FROM TEST STANDARD ....................................................... 27 4.3.5 TEST SETUP.............................................................................................. 27 4.3.6 EUT OPERATING CONDITIONS ............................................................... 27 4.3.7 TEST RESULTS ......................................................................................... 28 4.4MAXIMUM PEAK OUTPUT POWER .......................................................... 32 4.4.1 LIMITS OF MAXIMUM PEAK OUTPUT POWER MEASUREMENT........... 32 4.4.2 TEST INSTRUMENTS ................................................................................ 32 4.4.3 TEST PROCEDURES ................................................................................ 33 4.4.4 DEVIATION FROM TEST STANDARD ....................................................... 33 4.4.5 TEST SETUP.............................................................................................. 33 4.4.6 EUT OPERATING CONDITIONS ............................................................... 33 4.4.1 TEST RESULTS ......................................................................................... 34 4.5POWER SPECTRAL DENSITY MEASUREMENT ..................................... 35 FCC ID: Q8NAWU2000B Report No.: RF920526R013Issued: June 30, 2003 4.5.1 LIMITS OF POWER SPECTRAL DENSITY MEASUREMENT ................... 35 4.5.2 TEST INSTRUMENTS ................................................................................ 35 4.5.3 TEST PROCEDURE ................................................................................... 36 4.5.4 DEVIATION FROM TEST STANDARD ....................................................... 36 4.5.5 TEST SETUP.............................................................................................. 36 4.5.6 EUT OPERATING CONDITION.................................................................. 36 4.5.7 TEST RESULTS ......................................................................................... 37 4.6BAND EDGES MEASUREMENT................................................................ 41 4.6.1 LIMITS OF BAND EDGES MEASUREMENT ............................................. 41 4.6.2 TEST INSTRUMENTS ................................................................................ 41 4.6.3 TE…

Text truncated - open the document above for the full version.

FCC ID: Q8NAWU2000B Report No.: RF920526R0146Issued: June 30, 2003 5 PHOTOGRAPHS OF THE TEST CONFIGURATION CONDUCTED EMISSION TEST FCC ID: Q8NAWU2000B Report No.: RF920526R0147Issued: June 30, 2003 RADIATED EMISSION TEST
