Q93-F006DIGITAL AUDIO PLAYER

DSP IC1 LCD Driver LCD Key Matrix FM IC Crystal 24.576 MHz Earphone Internal Memory U3 Li Polymer Battery Block Diagram of DFP3001/DFP3002 Crystal 32768Hz MIC USB AVC Technology Limited Model: DFP3001/DFP3002 Revision: 0 Date: 15 Dec 2003 Power Management IC U9, U10

Operation Description The Digital Audio Player is a standalone multi-function product, powered by one 3.7 V built- in rechargeable battery pack, built-in 128MB / 256 MB memory. The Digital Audio Player has 4 different features: 1. Music Player (supports MP3, WMA and WAV) 2. FM turner (with memory function - Preset channel) 3. Voice recording 4. USB interface for PC uploading and downloading files.

TEST REPORT This document shall not be reproduced either in full or in part except with written approval by the Authorized Representative of CMA Testing. Room 1401-3, Yan Hing Centre, 9-13 Wong Chuk Yeung St.., Fo Tan, Shatin, Hong Kong. Tel: (852) 2698 8198 Fax: (852) 2695 4177 E-mail: [email protected] Web Site: http://www.cmatcl.com Report No. : AD022693-1 Date : 2004 March 24 Applicant : AVC Technology Limited Units 11-15, 11 th Floor, Block A, Focal Ind. Ctr., 21 Man Lok Street, Hunghom, Kowloon, Hong Kong. Sample Description : One(1) submitted sample stated to be : Model Name : Digital Audio Player Model No. : DFP3001 and DFP3002 Rating : 1 x 3.7 V Built-in Rechargeable battery pack No. of sample(s) : Two(2) pieces *** Date Received : 2003 December 24. 2004 February 26. Test Period : 2003 December 24 ñ 2004 January 09. 2004 February 26 ñ 2004 March 03. Test Requested : FCC Part 15 Certification Test Method : FCC Rules and Regulations Part 15 ñ July 2003 ANSI C63.4 ñ 1992 Test Result : See attached sheet(s) from page 2 to 18. Conclusion : The submitted sample was found to comply with requirement of FCC Part 15 Subpart B. For and on behalf of CMA Testing and Certification Laboratories Authorized Signature : Page 1 of 18 Danny Chui EMC Engineer - EL. Division FCC ID : Q93-F006 TEST REPORT This document shall not be reproduced either in full or in part except with written approval by the Authorized Representative of CMA Testing. Room 1401-3, Yan Hing Centre, 9-13 Wong Chuk Yeung St.., Fo Tan, Shatin, Hong Kong. Tel: (852) 2698 8198 Fax: (852) 2695 4177 E-mail: [email protected] Web Site: http://www.cmatcl.com Report No. : AD022693-1 Date : 2004 March 24 Table of Contents 1 General Information........................................................................................................................ 3 1.1 General Description.................................................................................................................. 3 1.2 Related Submittal Grants.......................................................................................................... 3 1.3 Location of the test site............................................................................................................. 4 1.4 List of measuring equipment..................................................................................................... 5 1.5 List of support equipment......................................................................................................... 6 2 Description of the radiated emission test.......................................................................................... 7 2.1 Test Procedure......................................................................................................................... 7 2.2 Test Result............................................................................................................................... 7 2.3 Radiated Emission Measurement Data....................................................................................... 8 2.3 Radiated Emission Measurement Data....................................................................................... 9 2.3 Radiated Emission Measurement Data..................................................................................... 10 2.3 Radiated Emission Measurement Data..................................................................................... 11 2.3 Radiated Emission Measurement Data..................................................................................... 12 2.3 Radiated Emission Measurement Data..................................................................................... 13 2.3 Radiated Emission Measurement Data..................................................................................... 14 2.3 Radiated Emission Measurement Data..................................................................................... 15 3 Description of the Line-conducted Test.......................................................................................... 16 3.1 Test Procedure....................................................................................................................... 16 3.2 Test Result............................................................................................................................. 16 3.3 Graph and Table of Conducted Emission Measurement Data.................................................... 16 4 Photograph................................................................................................................................... 17 4.1 Photographs of the Test Setup for Radiated Emission and Conduction Emission........................ 17 4.2 Photographs of the External and Internal Configurations of the EUT......................................... 17 5 Supplementary document............................................................................................................... 17 6 Appendices............................................................................................................................... 18 Page 2 of 18 FCC ID : Q93-F006 TEST REPORT This document shall not be reproduced either in full or in part except with written approval by the Authorized Representative of CMA Testing. Room 1401-3, Yan Hing Centre, 9-13 Wong Chuk Yeung St.., Fo Tan, Shatin, Hong Kong. Tel: (852) 2698 8198 Fax: (852) 2695 4177 E-mail: [email protected] Web Site: http://www.cmatcl.com Report No. : AD022693-1 Date : 2004 March 24 1 General Information 1.1 General Description The equipment under test (EUT) is a standalone multi-function product, powered by one 3.7 V build- in rechargeable battery pack, built-in 128 MB / 256 MB memory. The EUT has 4 different features: 1. Music Player (supports MP3, WMA and WAV) 2. FM Turner (with memory function ñ Preset channel) 3. Voice Recording 4. USB interface for PC uploading and downloading files A brief circuit d…
