QC4-VSMRTAHRV-Smart, A, H, R RFID Reader

Bioscrypt, Inc.

Click to zoom

Application Details

Equipment Class: DXX - Part 15 Low Power Communication Device Transmitter
Date of Grant: Aug 13, 2006
Application Purpose: Original Equipment
Date of Application: Aug 13, 2006
Equipment Note: V-Smart, A, H, R RFID Reader
Frequency Range: 13.56000000 - 13.56000000
Company: Bioscrypt, Inc.
Country: Canada
