Dongguan Nore Testing Center Co., Ltd. Report No.: NTC1505010F/-1 FCC ID: QCD-TS-4006 RF EXPOSURE EVALUATION EUT Specification EUT SOUND SYSTEM Frequency band (Operating) WLAN: 2.412GHz ~ 2.462GHz WLAN: 5.18GHz ~ 5.32GHz / 5.50GHz ~ 5.70GHz WLAN: 5.745GHz ~ 5825GHz Others(Bluetooth: 2.402GHz ~ 2.480GHz) Device category Portable (<20cm separation) Mobile (>20cm separation) Others ___ Antenna diversity Single antenna Multiple antennas Tx diversity Rx diversity Tx/Rx diversity Max. output power 5.45dBm(3.51mW) For BLE; 2.18dBm(1.65mW) For BT 2.1+EDR Antenna gain 0dBi (declared by manufacturer) Evaluation applied MPE Evaluation SAR Evaluation Limits for Maximum Permissible Exposure (MPE) Frequency Range(MHz) Electric Field Strength(V/m) Magnetic Field Strength(A/m) Power Density(mW/cm 2 ) Average Time (A) Limits for Occupational/Control Exposures 300-1500 -- -- F/300 6 1500-100000 -- -- 5 6 (B) Limits for General Population/Uncontrol Exposures 300-1500 -- -- F/1500 6 1500-100000 -- -- 1 30 Dongguan Nore Testing Center Co., Ltd. Report No.: NTC1505010F/-1 FCC ID: QCD-TS-4006 Friis transmission formula: Pd=(Pout*G)\(4*pi*R 2 ) Where Pd= Power density in mW/cm 2 Pout=output power to antenna in Mw G= gain of antenna in linear scale Pi=3.1416 R= distance between observation point and center of the radiator in cm Pd the limit of MPE, 1mW/cm2. If we know the maximum gain of the antenna and total power input to the antenna, through the calculation, we will know the distance where the MPE limit is reached. Measurement Result Channel Channel Frequency (MHz) Max Output power (dBm) ToleranceMax Tune-UP power (mW) Power density at 20cm (mW/ cm 2 ) Power density Limits (mW/cm 2 ) For BLE GFSK Low 2402.00 1.22 ±0.1 1.36 2.70e-4 1 Middle 2442.00 3.68 ±0.1 2.39 4.75e-4 1 High 2480.00 5.45 ±0.1 3.59 7.14e-4 1 For BT2.1+EDR GFSK Low 2402.00 -3.50 ±0.1 0.46 9.09e-5 1 Middle 2441.00 0.52 ±0.1 1.15 2.29e-4 1 High 2480.00 2.18 ±0.1 1.69 3.36e-4 1 π/4-DQPSK Low 2402.00 -3.96 ±0.1 0.41 8.18e-5 1 Middle 2441.00 0.01 ±0.1 1.03 2.04e-4 1 High 2480.00 1.68 ±0.1 1.51 3.00e-4 1 8DPSK Low 2402.00 -3.99 ±0.1 0.41 8.12e-5 1 Middle 2441.00 0.05 ±0.1 1.04 2.06e-4 1 High 2480.00 1.70 ±0.1 1.51 3.01e-4 1

Dongguan Nore Testing Center Co., Ltd. Report No.: NTC1505010F-1 FCC ID: QCD-TS-4006 Page 2 of 32 Table of Contents 1. GENERAL INFORMATION ................................................................................................ 4 1.1 P RODUCT D ESCRIPTION FOR E QUIPMENT UNDER T EST .................................................................... 4 1.2 R ELATED S UBMITTAL ( S ) / G RANT ( S ) ................................................................................................ 4 1.3 T EST M ETHODOLOGY ....................................................................................................................... 5 1.4 E QUIPMENT M ODIFICATIONS ............................................................................................................ 5 1.5 S UPPORT D EVICE ............................................................................................................................ 5 1.6 T EST F ACILITY AND L OCATION .......................................................................................................... 6 1.7 S UMMARY OF T EST R ESULTS ........................................................................................................... 6 2. SYSTEM TEST CONFIGURATION.................................................................................... 7 2.1 EUT C ONFIGURATION ...................................................................................................................... 7 2.2 S PECIAL A CCESSORIES .................................................................................................................... 7 2.3 D ESCRIPTION OF TEST MODES ......................................................................................................... 7 2.4 EUT E XERCISE ................................................................................................................................7 3. CONDUCTED EMISSIONS TEST ...................................................................................... 8 3.1 T EST SET-UP (B LOCK D IAGRAM OF C ONFIGURATION )..................................................................... 8 3.2 T EST C ONDITION ............................................................................................................................. 8 3.3 M EASUREMENT R ESULTS ................................................................................................................. 8 4. MAX. CONDUCTED OUTPUT POWER........................................................................... 11 4.1 M EASUREMENT P ROCEDURE ......................................................................................................... 11 4.2 T EST SET-UP (B LOCK D IAGRAM OF C ONFIGURATION )................................................................... 11 4.3 M EASUREMENT R ESULTS ............................................................................................................... 12 5. 6DB & 20DB BANDWIDTH .............................................................................................. 14 5.1 M EASUREMENT P ROCEDURE ......................................................................................................... 14 5.2 T EST SET-UP (B LOCK D IAGRAM OF C ONFIGURATION )................................................................... 14 5.3 M EASUREMENT R ESULTS ............................................................................................................... 14 6. POWER SPECTRAL DENSITY ....................................................................................... 18 6.1 M EASUREMENT P ROCEDURE ......................................................................................................... 18 6.2 T EST SET-UP (B LOCK D IAGRAM OF C ONFIGURATION )................................................................... 18 6.3 M EASUREMENT R ESULTS ............................................................................................................... 18 7. BAND EDGE AND CONDUCTED SPURIOUS EMISSIONS ........................................... 21 7.1 R EQUIREMENT AND M EASUREMENT P ROCEDURE ........................................................................... 21 7.2 T EST SET-UP (B LOCK D IAGRAM OF C ONFIGURATION )................................................................... 21 7.3 M EASUREMENT R ESULTS ............................................................................................................... 21 Dongguan Nore Testing Center Co., Ltd. Report No.: NTC1505010F-1 FCC ID: QCD-TS-4006 Page 3 of 32 8. RADIATED SPURIOUS EMISSIONS AND RESTRICTED BANDS ................................ 26 8.1 T EST SET-UP (B LOCK D IAGRAM OF C ONFIGURATION )................................................................... 26 8.2 M EASUREMENT P ROCEDURE ......................................................................................................... 27 8.3 L IMIT .............................................................................................................................................. 28 8.4 M EASUREMENT R ESULTS ..................................................................................................... 29 9. ANTENNA APPLICATION ............................................................................................... 31 9.1 A NTENNA REQUIREMENT ................................................................................................................ 31 9.2 M EASUREMENT R ESULTS ............................................................................................................... 31 10. TEST EQUIPMENT LIST................................................................................................ 32 Dongguan Nore Testing Center Co., Ltd. Report No.: NTC1505010F-1 FCC ID: QCD-TS-4006 Page 4 of 32 1. GENERAL INFORMATION 1.1 Product Description for Equipment under Test Item BT2.1+EDR BLE(V4.0) Frequency 2402-2480MHz 2402-2480MHz Modulation GFSK, π/4-DQ…

Text truncated - open the document above for the full version.

Dongguan Nore Testing Center Co., Ltd. Report No.: NTC1505010F/-1 FCC ID: QCD-TS-4006 Conducted Emission Dongguan Nore Testing Center Co., Ltd. Report No.: NTC1505010F/-1 FCC ID: QCD-TS-4006 Radiated Emission
