QD9POWERNET-USBPowerline Telecommunication Modem for USB bus

c • ™ Ž ” Š Ÿ @ p • ž Š ™ n Š › @ u s b @ a ‰ ... – › Š ™ c•™Ž”ŠŸ@p•žŠ™nŠ›

m s t ‰ d Contents This Owner’s Manual, as well as the software described in it, is furnished under license and may be used or copied only in accordance with the terms of the license. The content of this manual is furnished for informational use only, it is subject to change without notice, and it does not represent a commitment on the part of Corinex Global Corp. Corinex Global Corp. assumes no responsibility or liability for any errors or inaccuracies that may appear in this book. It is our policy to enhance our products as new technologies, hardware components, software and firmware become available; therefore, the information contained in this document is subject to change without notice. Some features, functions, and operations described in this manual may not be included and sold in certain countries due to government regulations or marketing policies. The use of the product or its features described in this document may be restricted or regulated by law in some countries. If you are unsure which restrictions or regulations apply, you should consult your regional Corinex office or the authorized reseller. Published by: Corinex Global Corp. 33076 – 1583 Marine Drive West Vancouver, B.C., V7V 1HO Canada Tel: (604) 214 8787 Fax: (604) 214 8788 Corinex is a registered trademark of Corinex Global Corp. Microsoft, MS−DOS, MS, Windows, Windows NT are either registered trademarks or trademarks of Microsoft Corporation in the U.S.A. and/or other countries. 1.1 Overview 1 Corinex PowerNet USB Adapter• Owner‘s Manual All products or company names mentioned herein may be the trademarks of their respective owners. Copyright (c) 2001−2002 by Corinex Global Corp. Source document: Corinex Povernet USB Adapter_Owner's Manual.doc Contents Contents 1 Introduction.................................................................................3 1.1 Overview...................................................................................... 3 1.2 About this Manual....................................................................... 3 2 Installation Guide........................................................................4 2.1 What this Package Contains......................................................... 4 2.2 System Requirements................................................................... 4 2.3 Installing the USB Adapter software............................................ 5 3 User‘s Guide...............................................................................10 3.1 PowerNet Setup Tool User Guide............................................... 10 3.2 Corinex PowerNet USB Adapter................................................. 13 3.3 FAQ .................................................................................... 14 3.4 USB Adapter Specifications........................................................ 15 4 Troubleshooting Guide..............................................................17 1.1 Overview 2 Corinex PowerNet USB Adapter• Owner‘s Manual 1 Introduction 1Introduction 1.1 1 Overview Corinex PowerNet USB Adapter is network interface adapter, using 110/220 powerline as a medium for communication. After successful installation, indoor PowerNet network behaves as traditional LAN for computers. The Corinex PowerNet USB Adapter supports 14 Mbps− network speed. The product keeps network maintenance cost low and eliminates usage barriers while there is no need for additional wiring. The Product is a highly integrated and requires no glue logic or external memory. 1.2 About this Manual This Owner‘s Manual is intended to provide sufficient information to help you understand successfully install the Corinex PowerNet USB Adapter products to meet your networking needs. 1.1 Overview 3 Corinex PowerNet USB Adapter• Owner‘s Manual With the information in this guide, you should be able to: ƒ Analyze your network needs... ƒ Plan the configuration of Corinex PowerNet USB Adapter options... ƒ Install and configure your Corinex PowerNet USB Adapter according to your plan... ƒ Verify and optimize your Corinex PowerNet USB Adapter performance... 2 Installation Guide 2Installation Guide 2 2.1 What this Package Contains When you receive your Corinex PowerNet USB Adapter, check to be sure that your package contains: • Corinex PowerNet USB Adapter • AC cord • USB cable • This manual • Installation CD 2.2 System Requirements • IBM compatible PC with one available USB port (Not hub) • CD−ROM drive • Windows 98/ME/2000/XP operating system 2.1 What this Package Contains 4 Corinex PowerNet USB Adapter• Owner‘s Manual 2 Installation Guide 2.3 Installing the USB Adapter software 1. Insert the installation CD, it should automatically start. Do not connect USB Adapter to PC before step 7! If the installation program does not start automatically, start the application by selecting „My Computer“, usually found on the desktop. Navigate to the CD drive, and double click on the drive. The following screen should be displayed: 2. Click „Yes“ to start installation. The following screen is the welcome screen. Click „Next“ to continue. 2.3 Installing the USB Adapter software 5 Corinex PowerNet USB Adapter• Owner‘s Manual 3. The next screen will ask where PowerNet Setup Tool should be installed. Click „Next“ to continue. 2 Installation Guide 4. This screen will ask where Setup should place the program’s shortcuts. Select Start Menu Folder or simply click „Next“. 2.3 Installing the USB Adapter software 6 Corinex PowerNet USB Adapter• Owner‘s Manual 2 Installation Guide 5. The following screen will appear to inform that Setup is ready to begin installing PowerNet Setup Tool on your computer. Click „Install“. 6. The following screen will appear to inform that the USB driver that is about to be installed does not have a Microsoft signature. Accept this to continue. (this screen varies a little between versions of Windows) 2.3 Installing the USB Adapter software 7 Corinex PowerNet USB Adapter• Owner‘s Manual 2…

Text truncated - open the document above for the full version.

3 User‘s Guide 3User‘s Guide 3.1 3 PowerNet Setup Tool User Guide The PowerNet Setup Tool allows the user to setup a private secure powerline network. Follow the steps on the screen or this guide and your secure network will be setup correctly. • Start the PowerNet Setup Tool from the Start menu by selecting the Powernet folder and select 'PowerNet Setup tool'. • Click 'Next' to start the wizard. • Make sure that your Corinex Powernet USB Adapter is connected to the computer and click 'Next'. Detecting device takes a few seconds. • Now the following screen should be displayed. This is the screen where your network password is selected. Choose a password between 4 and 24 characters, the password is case sensitive so remember exactly how it was typed as it will be needed for the next device being set up. Type your password in the 'Network Password' box and click 'Next'. 3.1 PowerNet Setup Tool User Guide 10 Corine x Powe rNe t USB A d a p t e r • Owne r‘s Manual 3 User‘s Guide • Click 'Next' again to program the Corinex Powernet USB Adapter with the new encryption password. This will take a few seconds. The next screen will look similar to the following screen. The white box will list the MAC addresses of all other installed powerline devices on the network that are programmed with your chosen network password. If no other devices have been programmed, the list will be empty. 3.1 PowerNet Setup Tool User Guide 11 Corine x Powe rNe t USB A d a p t e r • Owne r‘s Manual 3 User‘s Guide • All devices in your network must be programmed with the same network encryption password. Run this utility on all computers with a powerline networking device attached. If you have a powerline device that is not normally connected to a computer, it must first be connected to a computer and set up with a network encryption password. 3.1 PowerNet Setup Tool User Guide 12 Corine x Powe rNe t USB A d a p t e r • Owne r‘s Manual 3 User‘s Guide 3.2 Corinex PowerNet USB Adapter The Corinex PowerNet USB Adapter introduces a new and innovative solution for data communications. This unique technology offers users a wide range of networking options by using digital power line technology enabling 14 Mbps data rate. ƒ Enables users to connect individual PC's into a local area network through a 220V/110V electric power line network ƒ PC file and application sharing ƒ Enables peripheral and printer sharing through a 220V/110V electric power line network ƒ Shared broadband Internet access ƒ Bandwidth for multimedia payloads including voice, data, audio and video ƒ Networked gaming ƒ Eliminates the requirement for special data cable wiring ƒ Cost−effective and reliable solution for data communication in your office and home Example Interconnection of two computers over powerline by Corinex PowerNet USB Adapter: 1. Install Corinex PowerNet USB Adapter on each of two computers (see Installation Guide). 2. 3.2 Corinex PowerNet USB Adapter 13 Corine x Powe rNe t USB A d a p t e r • Owne r‘s Manual For connection enter the properties for this connection and set up IP address manually. For example: 192.168.4.1 mask: 255.255.255.0 and another PC set up 192.168.4.2 mask: 255.255.255.0 3. You can check the connection by simple ping to other side. 3 User‘s Guide 3.3 FAQ 1. Is the Corinex Powernet USB Adapter still working if there is an electricity blackout? And will it resume the transmission automatically after the power come back ? Corinex PowerNet USB Adapter is supplied from PC power supply. When UPS is connected to PC, it will work without any interruption. 2. Once the electricity is on after blackout, is the PowerNet put into operation "automatically"? Yes, we can compare the situation to Ethernet card. When OS Windows starts correctly you don't see any problem. 3. As the transmission range of PowerNet is around 150−200 meters, how does it work when the distance is over say 400 meters? We recommend to measure the line before starting operations. 4. Is there any cross talk or interference issue when using Corinex PowerNet ? Within PC we don't see any interference with any other card and/or system. The OFDM technology reduces influence coming from another device which is connected to power line network. To confirm the above there is a requirement such a device should pass EMC approval. 3.3 FAQ 14 Corine x Powe rNe t USB A d a p t e r • Owne r‘s Manual 5. In case the PCs at the different floors of the same building are connected, can they use the Powernet device for the data transmission ? And how does it work ? Powernet works on the same electric phase − the same physical line. This is the basic condition. If there is the same electric line between the offices and maximum distance is up to 200m, it works fine. 6. What do you mean if you say "Scalable − migration path to 200Mbps and beyond" Next generation of Corinex products, capable of 20Mbps, will still be compatible with current 14Mbps devices. 7. Can you see any impact on the transmission of the signal if the electrocity power (no matter 110V or 220V) is unstable. No. 3 User‘s Guide 8. Can we use Corinex PowerNet USB adapter for both 110/220V Power Network or are there two versions of Corinex PowerNet? We support both 110V and 220V on the same device (PCI, USB, Ethernet). 110V and 220V differ only in the shape of the electric plugs so that they fit into local sockets. 9. Which version of USB do you use? USB v. 1.0/1.1 , full speed 12 Mbps. 3.4 USB Adapter Specifications The following table lists the product specifications for the Corinex PowerNetUSB Adapter. 3.4 USB Adapter Specifications 15 Corine x Powe rNe t USB A d a p t e r • Owne r‘s Manual Homeplug v 1.01 Certified Windows 9x/Me/2000/XP Compatible for PowerNet Setup Tool IEEE 802.3 UL Approved Standard compliance FCC Approved Protocol TCP/IP Port USB (v.1.0/1.1) Speed Up to 14 Mbps Cabling type − Standard AC cable − USB cable LED status Lights Power, Collision, Link, Activity Unit Dimensions 2.36“L x 4.49“W x 1.18“H 60m…
