USER GUIDE C O NTEN T S 0 1 0 2 0 3 Gatting StartedTroubleshooting and Other Resources Basics 0 3 Gatting Started What’s in the Box? Components may be changed without notice to improve the performance or quality of the product. Main Body Quick start guide & warranty information USB cable Quick Start Guide: Basic guide to using the EB12. Product Warranty: Please keep this warranty in a safe place in the event your EB12 needs servicing. USB Cable: Connect the USB cable to a PC to charge the product. 0 4 1 2 3 4 5 6 7 Touch EPD Simply touch the screen to start. Press the menu button to display the menu window. Press the home button to display the home screen. Click here to display the previous screen. 567 1 4 3 2 Gatting Started EB12 at a Glance Product appearance, printed and engraved information may vary depending on the model. Menu Button Home Button Previous Button Micro SD Card Slot USB Jack Power Insert a Micro SD card into the device to view the stored files. Connect a USB cable to link with a computer or recharge the device. Press and hold the power button to turn the device on/off. Press and hold briefly for power-saving mode. 0 5 Gatting Started Powering Up & Charging Power on/off 1. Press and hold the [ ] power on/off key to power on. 2. During stand-by mode, Press and hold the [ ] power on/off key to power off. This product has an automatic power saving function to prevent excessive battery consumption. If there is no key operation within the prescribed period [Settings - automati- cally turn off], the device will be automatically powered off. (See page 25) Turning to standby mode Using the reset function 1. Manually switch to standby mode by pressing the [ ] key briefly when the power is on. 2. Return to normal mode by pressing the [ ] key briefly. 1. Should the product stop unexpectedly during operation and keys are no longer responsive, press and hold the [ ] key for 10 seconds to reset the product. When using the reset function, the current time and memory data will not be deleted. Do not use the reset function while the product is in use. Doing so may seriously damage the memory. 0 6 Screen refresh Screen setup Recharging by connecting with the computer Gatting Started 1. Refresh the screen by pressing and holding the [ ] key for more than 2 seconds. Optimize the screen for reading by: 1. Press the [ ] key will brings up a window for environment setup. 2. Set up the desired line spacing, margins, and font. 1. To recharge the device’s battery, simply turn on the computer and connect the device. When an eBook is viewed continuously: up to ?? page views On Standby: Approximately ?? weeks after full recharge Use only the USB cable provided with the device. Unauthorized cables may cause device malfunction. Connect the provided cable to the high-power USB 2.0 port. Connecting the cable to a low-power USB port (keyboard or USB hub without power supply) may not recharge the device. Charging may be interrupted when the computer switches to standby mode. Recharge the device at room temperature. Recharging in excessively hot or cold environments may adversely affect charging rate or capacity. Battery life will gradually shorten after frequent recharges. Recharge time will take ? hours and ?? minutes (when battery is fully discharged and the power is off). Recharging while the device is in use will increase the time necessary to achieve a full charge. Recharge at least 10 minutes before turning the power on when the battery is completely discharged and then reset the device by pressing the [ ] key more than 10 seconds. 0 7 Connecting & Syncing Connecting to a computer 1. Turn on the power of the device and the computer, and then connect the device to the computer. Use only the USB cable provided with the EB12 to ensure safe operation. Connect the computer and the USB cable only after all functions of the EB12 have been stopped. Check that the EB12 is connected to a high-power USB 2.0 port. Connecting to a keyboard or a USB hub without its own power supply may prevent normal operation. Disconnecting from a computer 1. Click the icon displayed in the task bar or desktop of the computer to safely disconnect the EB12. 2. Click [Ok] to ensure the EB12 can be safely removed. Gatting Started 0 8 The icon may be hidden in the task bar depending on the operating system. For example: For Windows XP, click the expand icon to display it on the screen. When using application programs like Windows Explorer or Windows Media Player, it may be unsafe to disconnect the device while using the program. Remove the EB12 only after exiting all applications and programs. Failure to do so may result in the loss of stored data. Copy files & folders to the EB12 Delete files & folders in the EB12 1. To copy a file/folder from the computer, select the file and use the drag & drop method to add the files to the device. Please connect the USB cable properly and use caution when copying or moving files. If the computer or product is powered off or the USB cable is removed while the file/folder is being copied or moved, data may be lost or become seriously damaged. Transmission speed may vary depending on the computer and the OS environment. 1. Select the file/folder to delete, right-click, and select [Delete]. 2. Click [Yes] in the [check file/folder/deletion] window to delete the selected file/folder. Gatting Started 0 9 Brand : SanDisk, T ransc end Insert/remove the SD Card Recommended SD Cards 1. Gently insert and push the Micro SD card in the card slot as shown in the figure below while the product is powered off. 2. Gently press the SD card again to remove it. Insert/remove the SD card when the product is powered off. To avoid damage, do not apply excessive force when inserting the SD card. Do not remove the SD card while in use. Doing so may delete data, damage the EB12 or cause damage to the SD card. Do not repeatedly insert/remove the SD card. Improper handling of the SD card may cause damage to the EB12 or t…
