QDMH10MULTI-CODE JUKE BOX

DREAMUS COMPANY

Click to zoom

Application Details

Equipment Class: JBP - Part 15 Class B Computing Device Peripheral
Date of Grant: Nov 16, 2004
Application Purpose: Original Equipment
Date of Application: Nov 16, 2004
Equipment Note: MULTI-CODE JUKE BOX
Company: DREAMUS COMPANY
Country: South Korea

Documents & Files

Select a file to view

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Users Manual

37 Main System Using the buttons 36 If the product is not responding, check if the HOLD switchis OFF. If the HOLD switch is set, the following messageis displayed in the product. Connect the Remote Control and Earphones to the product.Press the button to turn the power on.See the initializing screen. [Note] Getting up and running The playback standby screen is displayed.Use the button to playback a music file. Use the buttons while playing to playback another music file. Use the buttons to control volume.Press the button again to pause the playback. Press the button to end the playback. The playback standby screen is displayed. Press and hold the button to turn the power off.Press and hold the button to open the function selectionscreen.Use the buttons in the function selection screen to select a desired function. Press the button to confirm the selection and run the selected function.If there are too many saved files, the time that the Playback Standby Display appears may bea bit delayed. [Note] Item Description Turns the power on when the power is off. Plays a music file in the playback standby screen.Pauses the play while playing a music file.Press and hold the button to turn the power off when the power is on.Stops Playback.Stop current recording in record mode.Changes the repeat mode while in playback standby or playing.Press and hold the button to open the functions screen.Starts recording in the recording standby screen.Pauses the recording during a recording.Press and hold the button while in playback standby or playing to open the EQ Setting mode. Changes EQ/SRS in the EQ Setting mode.Press the button twice during playback for the section repeat function. Please see Page 57 for details. Opens the Navigation screen during playback.Press and hold the button while in playback standby or playing to open the Menu screen. Increases volume while in playback standby, playing, or listening to radio.Decreases volume while in playback standby, playing, or listening to radio.Plays the previous title, when in playback.Press and hold the button while playing to fast rewind.Press the button and then hold it to the previous folder in playback standby display or while playing. Select the previous channel when listening to radio.Plays the next title when playing.Press and hold the button while playing to fast forward.Press the button and then hold it to the next folder in playback standby display or while playing. Select the next channel when listening to radio. Each button on the player may have multiple functions based onthe mode the player is on (Recording, playback, etc.) 39 38 Remote Control Item Description Turns the power on when the power is off. Plays a music file in the playback standby screen.Pauses the play while playing a music file.Press and hold the button to turn the power off when the power is on.Plays the previous title when playing.Press and hold the button while playing to fast rewind.Press the button and then hold it to the previous folder in playback standby display or while playing. Select the previous channel when listening to radio.Plays the next title when playing.Press and hold the button while playing to fast forward.Press the button and then hold it to the next folder in playback standby display or while playing. Select the next channel when listening to radio.Increases volume while in playback standby, playing, or listening to radio.Decreases volume while in playback standby, playing, or listening to radio. Use the buttons to control volume. Press the button again to pause the playback. Press the button to end the playback. The playback standby screen isdisplayed.Press and hold the buttons while playing to fast forward or fast rewindthe title.Press the or button twice and hold it to return to the previous folder orforward to the next folder. Please see Page 53 for the details on the music file search. Press the button while playing to change the Repeat mode. Please see Page 53 for more information about Repeat modes. ID3 Tag information is displayed during the playback. Only MP3, OGG, WMA, and ASF, IRM files are supported. If a music file is damaged, the damaged section is skipped. If the file is seriously damaged, the file is skipped. The playback standby screen follows theinitialization screen when the power is turnedon. Basic playback information, including thenumber of folders and music files, isdisplayed.Start playing with the button. Use thebuttons while playing to play another title. [Note] Playing Music Playing music files 41 40 Listening to the FM radio Press and hold the button to display the menu of player models. Listening to the FM radio Press the buttons in the radio screen to change frequency by 0.1MHz. Keep pressing the button until the desired channel is found. Manual Search Searching for a FM radio frequency Press and hold the buttons to searchfor an available channel automatically.Hold the button until the desired channelis scanned. Auto Scan KOREA STEREO 87.5 108 FM Tunner CH 02 TOTAL 13CHs Preset OFF Searching 95.8 95.8 Use the buttons to select the Radio icon then press the button toopen the radio screen.Press the buttons to select a channel.Press and hold the buttons to search forchannels automatically. When a frequency isfound, the radio will stay on that station until or is pressed again. Press the button to switch between Stereo / Mono. In areas where the signal is weak, some channels may be unavailable, or receptionmay be poor. [Note] The AUTO SCAN and AUTO MEMORY functions do not work while Preset is ON. In manual search, using the buttons changes the frequency by 0.1MHz in Korea /U.S.A/Japan, and 0.05 MHz in Europe. Press the button in the radio screen toset the Preset ON.Press the buttons to select the next / previous channel. Use thebuttons again until the desired channel is selected. [Note] Preset Function 43 42 Use the button in the radio screen to set the Preset OFF.Use the buttons to select the desiredchannel then press the button t…

Text truncated - open the document above for the full version.

Users Manual

45 44 Press and hold the button to open the functions menu. Recording Recording Use the buttons to select the Record iconthen press the button to open the recordstandby screen. Press the button in the record standby screen to open the Record Setting screen. Press and hold the buttons in the Record Setting screen to select the Source item. Settingthe Source option will change Bit rate, InputVolume, and Output Volume accordingly. The option (Bitrate/Input Volume/Output Volume) value for each source for the recording is saved. It is also possible to change the preset options for each Source option for recording. Source Types LINE IN: Analog signal from an external device INT. MIC: Voice using the internal microphoneEXT. MIC: Voice using an external microphone TUNER: Record FM radio Bitrate Quality of the recording. (40~320Kbps, ). Input Volume(0~20) Volume of the recording. High Input Volume increases the volume of the recording file. But can also cause distortion in the recording. Output Volume(0~40) The product supports monitoring of the recording sound. This option changes the monitoring volume and does not affect the recording file. [Note] Use the buttons to select an option and use the buttons to change the Bit rate, Input Volume, or Output Volume. Press the buttonto return to the Recording Standby display from the Record Setting display. Volume control is not available while recordingFor best results, experiment with various volume settings and microphone distances in each setting you record in. [Note] Press the button to start the MP3 recording. 20 46 47 Press the button in recording standby mode to play the recorded file Playing the recorded file The recorded file is saved in the following location, depending on the Source. LINE IN : RECORD\AUDIO\AUDIOXXX.MP3 TUNER: RECORD\AUDIO\TUNERXXX.MP3INT/EXT MIC : RECORD\VOICE\VOICEXXX.MP3 Press the button to pause the playback. To resume playback, press the button again. [Note] Press the button to finish the recording. The recording standby screen isdisplayed. Press the button again in standby mode to record into a new file.Press the button while recording to pause the recording. Resuming therecording will not create a new file.The recording will automatically stop in the following conditions: - Not enough space is available for the recording.- Recorded MP3 file is over 200MB in size.- Over 5 hours have been recorded - Insufficient battery [Note] Connect the product to a PC using the USB cable. An icon is displayed inthe PC tray if connection is successful. Please see Page 24 for details.Click Start -> Programs -> Accessories -> Windows Explorer.Use Windows Explorer to create a folder named TEXT in the H300drive.Store .txt files to the TEXT folder. Store txt files to the TEXT folder Any text can be entered into a text file, including useful features such as booksections or addresses and phone numbers. Using the text function 49 48 Only Wan-Sung type Korean text files are supported. To use a Jo-Hap type Korean text file, please convert it to a Wan-Sung type before using it. [Note] Press the button to exit the text function. The maximum number of characters that can be displayed in the screen is: English: 26 characters per line, 10 lines. Text is not displayed in the LCD remote controller (sold separately).The text reading feature is supported while playing an MP3 file.Press the REC button while reading text to switch to the music mode (Hot key.) [Note] Press and hold the button in playbackstandby mode or in the radio screen to openthe function menu. Viewing text Use the buttons to select the Text iconthen press the button to open the Textscreen. Check the tree structured file listing.Use the buttons to select the desiredfolder or file and press the button to select.See the text file displayed in the LCD. Normal Browsing Text Browsing Press the buttons to browse to the Previous/Next line whilereading a text file.Press the buttons to browse to the Previous/Next page while reading a text file. Press the button to go to a desired location while reading a text fileUse the buttons to select adesired location. Press the buttons to select a desired numberPress the button to go to the new location. GO TO Browsing The numbers are in Kbyte unit. [Note] THIS DEVICE COMPLIES WITH PART 15 OF THE FCC RULES. OPERATION IS SUBJECT TO THE FOLLOWING TWO CONDITIONS: (1) THIS DEVICE MAY NOT CAUSE HARMFUL INTERFERENCE, AND (2) THIS DEVICE MUST ACCEPT ANY INTERFERENCE RECEIVED, INCLUDING INTERFERENCE THAT MAY CAUSE UNDESIRED OPERATION. NOTE: THE MANUFACTURER IS NOT RESPONSIBLE FOR ANY RADIO OR TV INTERFERENCE CAUSED BY UNAUTHORIZED MODIFICATIONS TO THIS EQUIPMENT. SUCH MODIFICATIONS COULD VOID THE USER'S AUTHORITY TO OPERATE THE EQUIPMENT. NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: - Reorient or relocate the receiving antenna. - Increase the separation between the equipment and receiver. -Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. -Consult the dealer or an experienced radio/TV technician for help

ID Label/Location Info

MULTI-CODEC JUKE BOX MODEL : H10 FCC ID : QDMH10

Test Report

EMI TEST REPORT Emission of electromagnetic disturbance Test Report No. : ERI-FCC04-0055 Equipment : Multi-Codec Jukebox(MP3 Player) Name of basic model : H10 Family model : Refer to page 4 Family ID : QDMH10 Manufacturer : AV CHASEWAY MFG.FTY. Applicant : ReignCom Limited. Tested date : 2004. 11. 2 Issued date : 2004. 11. 15 Test results : PASS Test Standards : FCC Part 15 Subpart B (Class B) /Digital devices & peripherals Test Procedure and Items: - AC Power line Conducted emissions measurement : ANSI C63.4-1992 - Radiated emissions measurement : ANSI C63.4-1992 Tested by: YOUNG-SIK, KIM Approved by: SANG-KYU, LEE The results in this report apply only to the sample tested. This test report shall not be reproduced except in full, without the written approval of ERI Laboratory. EMC RESEARCH INSTITUTE EMC Research Institute CONTENTS 1. CLIENT INFORMATION 2. LABORATORY INFORMATION 3. EQUIPMENT UNDER TEST INFORMATION(EUT) 3.1 Identification of the EUT 3.2 Additional information about the EUT 3.3 Peripheral equipment 4. CONTINUOUS DISTURBANCE VOLTAGE, MAIN TERMINAL 4.1 Operating environment 4.2 Test set-up and test procedures 4.3 Operation Conditions 4.4 Test instrument 4.5 Test results (Test mode: Up & download mode) 5. RADIATED DISTURBANCE: 30MHz – 1000MHz 5.1 Operating environment 5.2 Test set-up 5.3 Test conditions 5.4 Test instrument 5.5 Test results (Test mode: Up & Download mode) 5.6 Test results (Test mode: Play & Record mode) 5.7 Test results (Test mode: FM Tuner mode) APPENDIX (None) EMC Research Institute 1. CLIENT INFORMATION The EUT has been tested by request of : Company : ReignCom Limited. Address : 8F Posgen VentureTower, 1586-7 Seocho-dong, Seocho-gu, Seoul, Korea Name of contact : H.J. Mun Telephone : +82-2-3019-1723 Facsimile : +82-2-3019-1746 2. LABORATORY INFORMATION The 10m full-anechoic chamber and/or EMC facilities are used for these testing. These facilities were accredited by KOLAS, EK, MIC of Korea and FCC of USA. Address ELECTROMAGNETIC RESEARCH INSTITUTE. 66-6, JEIL-RI, YANGJI-MYUN, YOUNGIN-CITY, KYUNGGI-DO, KOREA Telephone No. : +82-31-336-1186~7 Facsimile No. : +82-31-336-1184 Registered No. KOLAS : 111 EK : J MIC : KR0030 FCC Filing No. : 302567 3. EQUIPMENT UNDER TEST INFORMATION(EUT) 3.1 Identification of the EUT Type of equipment : Multi-Codec Jukebox(MP3 Player) Model name : H10 Brand name : - Manufacturer : AV CHASEWAY MFG.FTY. Address : Langang Village, Chongguang Town, Baoan District, Shenzhen City, Guangdong, China Telephone : +86-755-708-4671 Facsimile : +86-755-708-5490 Country of origin : CHINA Rating : 120V, 60Hz EMC Research Institute 3.2 Additional information about the EUT Class B, Family Models List: Basic Model Variant Model Differential point Memory size, LCD H101 LCD, Memory size 4GB, Color LCD H101A LCD, Memory size 4GB, Color LCD H103 LCD, Memory size 5GB, Color LCD H103A LCD, Memory size 4GB, Color LCD H105 LCD, Memory size 6GB, Color LCD H105A LCD, Memory size 6GB, Color LCD H107 LCD, Memory size 8GB, Color LCD H107A LCD, Memory size 8GB, Color LCD H101B LCD, Memory size 4GB, Mono LCD H101C LCD, Memory size 4GB, Mono LCD H103B LCD, Memory size 5GB, Mono LCD H103C LCD, Memory size 5GB, Mono LCD H105B LCD, Memory size 6GB, Mono LCD H105C LCD, Memory size 6GB, Mono LCD H107B LCD, Memory size 8GB, Mono LCD H10 (5GB) H107C LCD, Memory size 8GB, Mono LCD 3.3 Peripheral equipment Defined as equipment needed for correct operation of the EUT. Description Model No. Serial No. Manufacture AC/DC adaptor SEA60NZ-16.0X 03502395C SANKEN ELECTRIC CO., LTD. Notebook computer P5010 464307211682 FUJITSU LIMITED AC/DC adaptor SW10-S050-10 - Dongguan Qiaozi Santai Co., Ltd. Mouse - - - Earphone /controller - - - Cradle - - - Printer DeskJet 930C CN13V1B1SZ HP Keyboard SDM4510UH 4M1030902 Samsung EMC Research Institute 4. CONTINUOUS DISTURBANCE VOLTAGE, MAIN TERMINAL : Frequency range 0.15 MHz to 30 MHz 4.1 Operating environment Temperature : 22.0 Relative Humidity : 34.0 % 4.2 Test set-up and test procedures The mains terminal disturbance voltage was measured with the equipment under test(EUT) in a shield room. The EUT was connected to an artificial mains network(LISN) placed on the floor. The EUT was placed on non-metallic table 0.4m above the metallic, grounded floor. The distance to other metallic surface was at least 0.8m. Amplitude measurements were performed with a quasi-peak detector and an average detector. 4.3 Operation Conditions Up & Download mode 4.4 Test instrument Instrument Model No Serial No. Makers Next cal.date Used Test receiver ESCS30 830986-015 R&S 2005. 04. 08 ESH3-Z5 100029 R&S 2004. 11. 11 L.I.S.N. ESH3-Z5 831887/018 R&S 2005. 03. 19 Shield room 8 6 3.3m/H - - - AC Main Cradle EUT Notebook computer AC/DC adaptor Printer Keyboard LISN LISN AC/DC adaptor Mouse Earphone /controller EMC Research Institute 4.5 Test results (Up & Download mode) Date of test: Nov 02, 2004. An overview sweep performed with peak detector & average detector are included in the report as test reports. Frequency Tested LISN Meter Range Freq. Reading Limits Margin QP AV QP AV QP AV [MHz] [MHz] [dBuV] [dBuV] [dBuV] 0.156 N 50.2 44.4 65.7 55.7 15.5 11.3 0.276 N 41.5 40.1 60.9 50.9 19.4 10.8 0.15-30 0.390 N 39.9 37.4 58.0 48.0 18.1 10.6 0.507 N 40.6 38.2 56.0 46.0 15.4 7.8 0.585 N 40.1 38.0 56.0 46.0 15.9 8.0 1.398 N 41.7 39.5 56.0 46.0 14.3 6.5 2.916 N 41.7 37.8 56.0 46.0 14.3 8.2 2.991 N 42.9 37.5 56.0 46.0 13.1 8.5 3.030 N 41.6 37.7 56.0 46.0 14.4 8.3 7.800 N 26.6 12.8 60.0 46.0 33.4 33.2 * <5 : mean less than 5dB * Other frequency keep over 20dB margin. EMC Research Institute [Live line] EMC Research Institute [Neutral line] EMC Research Institute 5. RADIATED DISTURBANCE : 30MHz – 1000MHz 5.1 Operating environment Temperature : 22.0 Relative Humidity : 34.0 % 5.2 Test set-up The frequency range investigated was 30 MHz to 1000 MHz. All readings are quasi-peak unless stated otherwise. The half-wave dipole antenna was tuned to the frequency found during Preliminary …

Text truncated - open the document above for the full version.
