QDMH340multi-code juke box

THIS DEVICE COMPLIES WITH PART 15 OF THE FCC RULES. OPERATION IS SUBJECT TO THE FOLLOWING TWO CONDITIONS: (1) THIS DEVICE MAY NOT CAUSE HARMFUL INTERFERENCE, AND (2) THIS DEVICE MUST ACCEPT ANY INTERFERENCE RECEIVED, INCLUDING INTERFERENCE THAT MAY CAUSE UNDESIRED OPERATION. NOTE: THE MANUFACTURER IS NOT RESPONSIBLE FOR ANY RADIO OR TV INTERFERENCE CAUSED BY UNAUTHORIZED MODIFICATIONS TO THIS EQUIPMENT. SUCH MODIFICATIONS COULD VOID THE USER'S AUTHORITY TO OPERATE THE EQUIPMENT. NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: - Reorient or relocate the receiving antenna. - Increase the separation between the equipment and receiver. -Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. -Consult the dealer or an experienced radio/TV technician for help

CPU MCF5249 ADAPTOR CHARGER BATTERY LCD CHARGE SWITCHING DC/DC : 3.3VDC/DC : 1.8V EEPROM 5V ADAPTOR IN SYSTEM BUS ADC 16M FLASH 256M SDRAM CODEC KEY TRANCIVER HDD USB 30MHz USB OUT CODEC OUT H-340 BLOCKDIAGRAM 11.2896MHz EEPROM

<FRONT SIDE OF EUT> <REAR SIDE OF EUT> <FRONT SIDE OF PROP> <REAR SIDE OF PROP>

MULTI-CODEC JUKE BOX MODEL : H340 FCC ID : QDMH340 SERIAL NO. : Manufactured by iRiver

<INNER SIDE OF EUT> <FRONT SIDE OF MAIN BOARD> <REAR SIDE OF MAIN BOARD> <FRONT SIDE OF HDD> <REAR SIDE OF HDD> < FRONT SIDE OF BATTERY> < REAR SIDE OF BATTERY>

EMI TEST REPORT Emission of electromagnetic disturbance Test Report No. : ERI-FCC04-0032 Equipment : PORTABLE STORAGE DEVICE & MULTI-CODEC JUKE BOX Name of basic model : H340 Family model : H320, H330, H360 Manufacturer : AV CHASEWAY MFG.FTY. Applicant : ReignCom Limited. Tested date : 2004. 4. 28 – 5. 11 Issued date : 2004. 5. 12 Test results : PASS Test Standards : FCC Part 15 Subpart B (Class B) /Digital devices & peripherals Test Procedure and Items: - AC Power line Conducted emissions measurement : ANSI C63.4-1992 - Radiated emissions measurement : ANSI C63.4-1992 Tested by: GWEON, HUR Approved by: SANG-KYU, LEE The results in this report apply only to the sample tested. This test report shall not be reproduced except in full, without the written approval of ERI Laboratory. EMC RESEARCH INSTITUTE EMC RESEARCH INSTITUTE File No. ERI-FCC04-0032 Page 2 of 11 E R I, 66-6, Jeil-Ri, Yangji-Myun, Yongin-City, Kyunggi-Do, Korea Tel: +82-31-336-1186~7 Fax: +82-31-336-1184 CONTENTS 1. CLIENT INFORMATION 2. LABORATORY INFORMATION 3. EQUIPMENT UNDER TEST INFORMATION(EUT) 3.1 Identification of the EUT 3.2 Additional information about the EUT 3.3 Peripheral equipment 4. CONTINUOUS DISTURBANCE VOLTAGE, MAIN TERMINAL 4.1 Operating environment 4.2 Test set-up and test procedures 4.3 Operation Conditions 4.4 Test instrument 4.5 Test results (Test mode: Up & Download mode) 5. RADIATED DISTURBANCE : 30MHz – 1000MHz 5.1 Operating environment 5.2 Test set-up 5.3 Test conditions 5.4 Test instrument 5.5 Test results (Test mode: Up & Download mode) 5.6 Test results (Test mode: Play mode) 5.7 Test results (Test mode: Recode mode) 5.8 Test results (Test mode : FM Tuner) APPENDIX (None) EMC RESEARCH INSTITUTE File No. ERI-FCC04-0032 Page 3 of 11 E R I, 66-6, Jeil-Ri, Yangji-Myun, Yongin-City, Kyunggi-Do, Korea Tel: +82-31-336-1186~7 Fax: +82-31-336-1184 1. CLIENT INFORMATION The EUT has been tested by request of : Company : ReignCom Limited. Address : 8F Posgen VentureTower, 1586-7 Seocho-dong, Seocho-gu, Seoul, Korea Name of contact : H.J. Mun Telephone : +82-2-3019-1723 Facsimile : +82-2-3019-1746 2. LABORATORY INFORMATION The 10m full-anechoic chamber and/or EMC facilities are used for these testing. These facilities were accredited by KOLAS, EK, MIC of Korea and FCC of USA. Address ELECTROMAGNETIC RESEARCH INSTITUTE. 66-6, JEIL-RI, YANGJI-MYUN, YOUNGIN-CITY, KYUNGGI-DO, KOREA Telephone No. : +82-31-336-1186~7 Facsimile No. : +82-31-336-1184 Registered No. KOLAS : 111 EK : J MIC : KR0030 FCC Filing No. : 302567 3. EQUIPMENT UNDER TEST INFORMATION(EUT) 3.1 Identification of the EUT Type of equipment : PORTABLE STORAGE DEVICE & MULTI-CODEC JUKE BOX Model name : H340 Brand name : - Manufacturer : AV CHASEWAY MFG.FTY. Address : Langang Village, Chongguang Town, Baoan District, Shenzhen City, Guangdong, China Telephone : +86-755-708-4671 Facsimile : +86-755-708-5490 Country of origin : CHINA Rating : 120V, 60Hz EMC RESEARCH INSTITUTE File No. ERI-FCC04-0032 Page 4 of 11 E R I, 66-6, Jeil-Ri, Yangji-Myun, Yongin-City, Kyunggi-Do, Korea Tel: +82-31-336-1186~7 Fax: +82-31-336-1184 3.2 Additional information about the EUT Class B, Family Models List: Basic Model Variant Model Differential point Memory size H320 HDD size 20GB H330 HDD size 30GB H340 (40GB) H360 HDD size 60GB 3.3 Peripheral equipment Defined as equipment needed for correct operation of the EUT. Description Model No. Serial No. Manufacture NOTEBOOK P5010 464307211682 FUJITSU LIMITED KEYBOARD SDM4510UH 4M030902 SAMSUNG EARPHONE - - iRIVER ADAPTOR CA01007-0750 03502395C SANKEN ELECTRIC CO., LTD. MOUSE MOSXUB - - STAND H340 - AV CHASEWAY MFG.FTY. ADAPTOR SW10-S050-10 - - REMOTE - - iRIVER EMC RESEARCH INSTITUTE File No. ERI-FCC04-0032 Page 5 of 11 E R I, 66-6, Jeil-Ri, Yangji-Myun, Yongin-City, Kyunggi-Do, Korea Tel: +82-31-336-1186~7 Fax: +82-31-336-1184 4. CONTINUOUS DISTURBANCE VOLTAGE, MAIN TERMINAL : Frequency range 0.15 MHz to 30 MHz 4.1 Operating environment Temperature : 20.0 °C Relative Humidity : 36.0 % 4.2 Test set-up and test procedures The mains terminal disturbance voltage was measured with the equipment under test(EUT) in a shield room. The EUT was connected to an artificial mains network(LISN) placed on the floor. The EUT was placed on non-metallic table 0.4m above the metallic, grounded floor. The distance to other metallic surface was at least 0.8m. Amplitude measurements were performed with a quasi-peak detector and an average detector. 4.3 Operation Conditions Up & download mode, play mode, recording mode, tuner mode 4.4 Test instrument Instrument Model No Serial No. Makers Next cal.date Used Test receiver ESCS30 100020 R&S 2005. 3. 25 x ESH3-Z5 827246/008 R&S 2005. 3. 19 x L.I.S.N. ESH3-Z5 831887/018 R&S 2005. 3. 19 x Shield room 8 × 6 × 3.3m/H - - - x AC Main NOTEBOOK STAND ADAPTOR REMOTE KEYBOARD EUT MOUSE EARPHONE ADAPTOR LISN LISN EMC RESEARCH INSTITUTE File No. ERI-FCC04-0032 Page 6 of 11 E R I, 66-6, Jeil-Ri, Yangji-Myun, Yongin-City, Kyunggi-Do, Korea Tel: +82-31-336-1186~7 Fax: +82-31-336-1184 4.5 Test results (Up & download mode) Date of test: Apr 29, 2004. An overview sweep performed with peak detector & average detector are included in the report as test reports. Frequency Tested LISN Meter Range Freq. Reading Limits Margin QP AV QP AV QP AV [MHz] [MHz] [dBuV] [dBuV] [dBuV] 0.201H 54.939.0 63.5 53.5 8.6 14.5 0.213N 52.640.9 63.1 53.1 10.5 12.2 0.15-30 0.234N 50.439.4 62.3 52.3 11.9 12.9 0.465N 43.737.9 56.5 46.5 12.8 8.6 0.774N 38.737.9 56.0 46.0 17.3 8.1 0.825H 40.729.7 56.0 46.0 15.3 16.3 2.799N 39.528.1 56.0 46.0 16.5 17.9 2.925H 39.527.5 56.0 46.0 16.5 18.5 3.030N 37.023.9 56.0 46.0 19.0 22.1 22.580H 45.241.7 60.0 50.0 14.8 8.3 * <5 : mean less than 5dB * Other frequency keep over 20dB margin. EMC RESEARCH INSTITUTE File No. ERI-FCC04-0032 Page 7 of 11 E R I, 66-6, Jeil-Ri, Yangji-Myun, Yongin-City, Kyunggi-Do, Korea Tel: +82-31-336-1186~7 Fax: +82-31-336-1184 [Live line] [Neutral line] EMC RESEARCH INSTITUTE File No. E…

Text truncated - open the document above for the full version.

<FRONT PHOTO OF RAIDIATED DISTURBANCE > <REAR PHOTO OF RADIATED DISTURBANCE > <FRONT PHOTO OF CONTINUOUS DISTURBANCE VOLTAGE > <SIDE PHOTO OF CONTINUOUS DISTURBANCE VOLTAGE >
