QDMIDP100Data Play

User Manual Note : This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures : - Reorient or relocate the receiving antenna. - Increase the separation between the equipment and receiver. - Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. - Consult the dealer or an experienced radio/TV technician for help. Front NAVI/ FUNCTION Back VOLUME 1 3 2 Selecting folder and move to upper folder Playing Navigation is the function that allows you to navigate through the files in the CD. Pressing NAVI/FUNCTION button shows you the list of songs and current song playing. NAVIGATION Use NAVI/FUNCTION button to find the song you'd like to listen to. Use button to exit to the upper folder. The next figure shows the status when you move to upper folder. To move the cursor, use the NAVI/FUNCTION button and to enter the Chosen Folder,  click the NAVI/FUNCTION button. Music To move to the Upper folder. NAVI/FUNCTION button To enter the folder The song will be played when you press the NAVI/FUNCTION button. The Main Menu How to use Menu Main Menu general mode display control User EQ timer Sub Menu GENERAL beep resume fade in language load default firmware upgrade CONTROL fast scan fast skip scan speed scroll speed remote mode button auto pause adapter volume sound balance MODE repeat shuffle intro study name User EQ bass boost bass corner freq treble boost treble corner freq DISPLAY back light main lcd contrast remote lcd contrast tag information visualization time TIMER sleep pwr off + + + + GENERAL F.scan F.skip speed scroll BEEP SOUND VOLUME 012 3 4 + + + + GENERAL beep vol resume fade in language + + + + GENERAL F.scan F.skip speed scroll + + + + GENERAL F.scan F.skip speed scroll GENERAL BEEP VOL : Configure beep sound (ON/OFF) with volume level. RESUME : When activated, player resumes playing at the same spot played last after Power OFF. LANGUGE : Song title and ID3 tag information from the CD is dependent on the PC operation system that it is made into. (For example, when the CD is burnt from Japanese Windows, the language setting should be Japanese) LOAD DEFAULT VALUE : Initialize to original factory setting. SOUND FADE IN : When activated, volume steadily increases when you begin playing. It can prevent sudden loudness when you play the song after stopping. Button operation is as below (Select Default Menu) (move to YES) (Select YES : INITIALIZATION) + + + + GENERAL F.scan F.skip speed scroll LOAD DEFAULT ARE YOU SURE? YES NO + + + + GENERAL F.scan F.skip speed scroll BEEP VOLUME 012 3 4 + + + + GENERAL F.scan F.skip speed scroll RESUME OFF ON + + + + GENERAL F.scan F.skip speed scroll SOUND FADE IN OFF ON + + + + F.scan F.skip speed scroll Korean English GENERAL DISPLAY LCD CONTRAST : Adjust LCD contrast of remote control. Using , buttons can adjust LCD contrast. + + + + DISPLAY F.scan F.skip speed scroll LCD CONTRAST 32 While playing, long pressing the play( ) button will turn on the Backlight as you have it set. BACK LIGHT OFF : Backlight is always off. BUTTON ON works as below : 1 : about 3~10 seconds 2 : 10 seconds 3 : 20 seconds ADAPTER ON : 1 : about 3~10 seconds 2 : 10 seconds 3 : 20 seconds 4 : Always OFF ADAPTER ON BACK - LIGHT BUTTON ON 12 124 3 3 VISUALIZATION : Visualizes audio signal at play mode. You can choose between Level Meter and WaveForm. + + + + DISPLAY F.scan F.skip speed scroll VISUALIZATION WAVEFORM LEVEL METER LEVEL METER WAVEFORM + + + + DISPLAY F.scan F.skip speed scroll + + + + TIMER F.scan F.skip speed scroll + + + + TIMER F.scan F.skip speed scroll STOP POWER OFF 1 SLEEP POWER OFF 0 OFF MIN + + + + DISPLAY F.scan F.skip speed scroll OFFON TAG INFORMATION + + + + DISPLAY F.scan F.skip speed scroll REMAIN PLAY TIME INFO NORMAL + + + + DISPLAY F.scan F.skip speed scroll + + + + TIMER F.scan F.skip speed scroll + + + + TIMER F.scan F.skip speed scroll TIMER (Auto Power Off time setting) SLEEP POWER OFF : The power goes off automatically after fixed time. Time range can be set from 0~99 by minutes. STOP POWER OFF : The automatic power off can be made when the player is in STOP mode. Time range can be made from 1~60 minutes. and button can be used for time setting. STOP POWER OFF 1 SLEEP POWER OFF 0 OFF MIN TAG INFORMATION : When ON, tag information is displayed and when OFF, only the file name is displayed + + + + DISPLAY F.scan F.skip speed scroll Setting the tag information to OFF while playing may show the track is playing and the NEXT track with tag information. OFFON TAG INFORMATION TIME : Normal displays elapsed time. Remain displays remaining time. + + + + DISPLAY F.scan F.skip speed scroll With VBR file, the time may not be accurate. REMAIN PLAY TIME INFO NORMAL and button can be used for time setting. When the power goes off, it goes back to Zero setting. CONTROL ADAPTER VOLUME ON: When the Adaptor is connected, the volume always remains at level 35. OFF: No use of Adaptor volume. + + + + CONTROL F.scan F.skip speed scroll ADAPTOR VOLUME OFF35 ON SOUND BALANCE When the lever on the Sound Balance bar is moved to L (Left, 0),the sound output will be in the left earphone. When the lever on the Sound Balance bar is moved to R (Right, 40) the sound output will be in the right earphone. The default va…

Text truncated - open the document above for the full version.

Note : This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures : - Reorient or relocate the receiving antenna. - Increase the separation between the equipment and receiver. - Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. - Consult the dealer or an experienced radio/TV technician for help.

ERI Electromagnetic research institute 66-6, JEIL-RI, YANGJI-MYUN, YOUNGIN-CITY, KYUNGGI-DO, KOREA TEL: 82 31 336 1186 FAX : 82 31 336 1184 homepage : This test report shall not be reproduced except in full, Without the written approval. ReportNo.:ERI-FCC-0116 Page : 1 of 19 EMI TEST REPORT Test report no. : ERI-FCC-0116 Type of equipment : DATA PLAY Model no. : iDP100 Applicant. : ReignCom Co., Ltd. Test standards : FCC Part15 Subpart B (Class B) Test Procedure and Items : - AC Power line Conducted Emissions Measurement : ANSI C63.4-1992 - Radiated Emissions Measurement : ANSI C63.4-1992 Test result : Complied This equipment has been tested to comply with the requirements of FCC Rules and Regulations Part 15 Subpart B Unintentional Radiators. The results in this report apply only to the sample tested. This test report shall not be reproduced except in full, Without the written approval of ERI Laboratory. Date of test: 2002. 5. 1718 Issued date: 2002. 5. 20 Tested by : approved by: GWEON, HUR SANG-KYU, LEE This laboratory is registered by KOLAS, KOREA. This test report have been performed in accordance with Its terms of registration. ERI Electromagnetic research institute 66-6, JEIL-RI, YANGJI-MYUN, YOUNGIN-CITY, KYUNGGI-DO, KOREA TEL: 82 31 336 1186 FAX : 82 31 336 1184 homepage : This test report shall not be reproduced except in full, Without the written approval. ReportNo.:ERI-FCC-0116 Page : 2 of 19 Contents 1. Client Information 2. Laboratory Information 3. Test System Configuration 3.1 Operation Environment 3.2 Measurement Uncertainty 3.3 Sample Calculation 4. Description Of E.U.T. 4.1 Product Description 4.2 Peripherals 4.3 Used Cables 4.4 E.U.T. Test Configuration 4.5 Operating Conditions 5. Test Results 5.1 Conducted Emission 5.1.1 Measurement Procedure 5.1.2 Used Equipments 5.1.3 Measurement Uncertainty 5.1.4 Test Data(Download) 5.1.5 Test Data(Play) 5.1.6 Test Data(Upload) 5.1.7 Result ERI Electromagnetic research institute 66-6, JEIL-RI, YANGJI-MYUN, YOUNGIN-CITY, KYUNGGI-DO, KOREA TEL: 82 31 336 1186 FAX : 82 31 336 1184 homepage : This test report shall not be reproduced except in full, Without the written approval. ReportNo.:ERI-FCC-0116 Page : 3 of 19 5.2 Radiated Emission 5.2.1 Measurement Procedure 5.2.2 Used Equipments 5.2.3 Measurement Uncertainty 5.2.4 Test Data(Download) 5.2.5 Test Data(Play) 5.2.6 Test Data(Upload) 5.2.7 Result 6. Photographs Conducted Emission test Radiated Emission Test EUT(Front, Rear, Inner) 1. Client information Applicant : ReignCom Co., Ltd. Address : 8F Posgen VentureTower, 1586-7 Seocho-dong, Seocho- gu, Seoul, Korea Telephone Number : +81-2-3019-1723 Facsimile Number : +81-2-3019-1746 Contact person : Mun, Hyo Jae Manufacturer : ReignCom Co., Ltd. Address : 8F Posgen VentureTower, 1586-7 Seocho-dong, Seocho-gu, Seoul, Korea Telephone Number : +81-2-3019-1723 Facsimile Number : +81-2-3019-1746 ERI Electromagnetic research institute 66-6, JEIL-RI, YANGJI-MYUN, YOUNGIN-CITY, KYUNGGI-DO, KOREA TEL: 82 31 336 1186 FAX : 82 31 336 1184 homepage : This test report shall not be reproduced except in full, Without the written approval. ReportNo.:ERI-FCC-0116 Page : 4 of 19 2. Laboratory information Address The open area test site and EMC facilities are used for these testing. This facility was accredited by KOLAS, EK of Korea, MIC, FCC. EMC RESEARCH INSTITUTE . 66-6, JEIL-RI, YANGJI-MYUN, YOUNGIN-CITY, KYUNGGI-DO, KOREA Telephone Number : 82- 31- 336- 1186 Facsimile Number : 82- 31- 336 -1184 KOLAS No. : 111 EK : J MIC : KR0030 FCC Filing No. : 302567 ERI Electromagnetic research institute 66-6, JEIL-RI, YANGJI-MYUN, YOUNGIN-CITY, KYUNGGI-DO, KOREA TEL: 82 31 336 1186 FAX : 82 31 336 1184 homepage : This test report shall not be reproduced except in full, Without the written approval. ReportNo.:ERI-FCC-0116 Page : 5 of 19 MAP IC(), TG , 17 (42 ) FA TG TG 3km (ERI) ERI Electromagnetic research institute 66-6, JEIL-RI, YANGJI-MYUN, YOUNGIN-CITY, KYUNGGI-DO, KOREA TEL: 82 31 336 1186 FAX : 82 31 336 1184 homepage : This test report shall not be reproduced except in full, Without the written approval. ReportNo.:ERI-FCC-0116 Page : 6 of 19 3. TEST SYSTEM CONFIGURATION 3.1 Operation Environment Temperature Humidity Pressure 10m Chamber : 20.0C 34 % 1000hPa Shielded room : 22.0C 39 % 998hPa 3.2 Measurement Uncertainty All measurements involve certain levels of uncertainties, specfially in field of EMC. The factors contributing to uncertainties are test receiver, Cable loss, antenna factor calibration, Antenna directivity, antenna factor variation with height, antenna phase center variation, antenna Frequency interpolation, measurement distance variation, site imperfection, mismatch, and system repeatability. Based on NIS 80,81, The measurement uncertainty level with a 95% confidence level were applied. ERI Electromagnetic research institute 66-6, JEIL-RI, YANGJI-MYUN, YOUNGIN-CITY, KYUNGGI-DO, KOREA TEL: 82 31 336 1186 FAX : 82 31 336 1184 homepage : This test report shall not be reproduced except in full, Without the written approval. ReportNo.:ERI-FCC-0116 Page : 7 of 19 3.3 sample calculation Conducted emission The field strength is calculated by adding the LISN factor, cable loss from the measured reading. The sample calculation is as follows : FS = MR + LF + CL MR = Meter Reading LF = LISN Factor CL = Cable Loss If MR is 30dB, LISN Factor 1dB, CL 1dB The result (MR) is 30 + 1 + 1 = 32dBuV radiated emission The field strength is calculated by adding the antenna Factor, cable loss and, Antenna pad subtracting the amplifier gain from the measured reading. The sample calculation is as follows : FS = MR + AF + CL + AT -AG MR = Meter Reading AF = Antenna Factor CL = Cable Loss AT = Antenna Pad AG=Amplifier Gain If MR is 30dB, AF 12dB, CL 5dB, AP 10dB, AG 35dB The result (MR) is 30 + 12 + 5 + 10 –35 = 22dBuV/m ERI Electromagnetic research institute 66-6, JEIL- RI, YANGJI-MYUN, YOUNGIN- CITY, KYUNGGI-DO, KOREA TEL: 82 31 336 1186 FAX : 82 31 336 1184 homepag…
