QDMIGP100MP3 PLAYER

Model iMP-350 Model iGP-100 http://www.iRiverAmerica.com Instruction Manual PORTABLE STORAGE DEVICE & MULTI - CODEC JUKE BOX Model iGP-100 Thank you for your purchase. Please read this manual carefully before using your new player. http://www.iRiverAmerica.com THIS DEVICE COMPLIES WITH PART 15 OF THE FCC RULES.OPERATION IS SUBJECT TO THE FOLLOWING TWO CONDITIONS:(1) THIS DEVICE MAY NOT CAUSE HARMFUL INTERFERENCE, AND(2) THIS DEVICE MUST ACCEPT ANY INTERFERENCE, RECEIVED, INCLUDING INTERFERENCE THAT MAY CAUSE UNDESIREDOPERATION. NOTE : This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. Theselimits are designed to provide reasonable protection against harmfulinterference in a residential installation.This equipment generates, uses and can radiate radio frequencyenergy and, if not installed and used in accordance with theinstructions, may cause harmful interference to radio communications.However, there is no guarantee that interference will not occur in aparticular installation. If this equipment does cause harmfulinterference to radio or television reception, which can be determinedby turning the equipment off and on, the user is encouraged to try tocorrect the interference by one or more of the following measures : - Reorient or relocate the receiving antenna.- Increase the separation between the equipment and receiver.- Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. - Consult the dealer or an experienced radio/TV technician for help.NOTE : THE MANUFACTURER IS NOT RESPONSIBLE FOR ANY RADIO OR TV INTERFERENCE CAUSED BY UNAUTHORIZEDMODIFICATIONS TO THIS EQUIPMENT. SUCH MODIFICATIONSCOULD VOID THE USER'S AUTHORITY TO OPERATE THEEQUIPMENT. 1 Portable Storage Device iGP-100 can be used as a storage device (1.5 GB media). USB 2.0 is supported iGP-100 supports USB 2.0 with maximum transfer speed of 480 Mbit/Sec aswell as USB 1.1. Multi-Codec Player Supports MP3, WMA, ASF, and OGG formats as a Multi-Codec player. The iGP-100 also supports 44.1 KHz, 32~500Kbps based OGG files. Firmware Upgrade Provides the latest updated features via firmware upgrade. Graphic LCD supporting Multiple Languages iGP-100 comes with a graphic LCD which can support multiple languages,including: English, French, Spanish, German, Italian, other alphabet-orientedfonts, Korean, Japanese (Katakana, Hiragana, Kanji), Chinese (Traditional,Simplified) and others. A total of 38 languages are supported. FM Tuner Auto scanning and station memory functions make it easy for you to enjoylistening to the FM Radio. Supports 6 Equalizer Patterns. Normal, Rock, Jazz, Classic, Ultra Bass, User EQ This player supports 3D Surround Sound developed by SRS Lab.The player can recognize up to 1000 folders and 5000 files.Graphic User Interface Menu Support iRiver Limited does not assume any responsibility for errors or omissions in this document or make any commitment to update the information containedherein. iRiver is a registered trademark of iRiver Limited in the Republic ofKorea and/or other countries and is used under license.All other brand and product names are trademarks of their respectivecompanies or organization.All other product names may be trademarks of the companies with whichthey are associated. 1999~2003 iRiver Limited, All rights reserved. Microsoft Windows Media and the Windows logo are trademarks or registered trademarks of Microsoft Corporation in the United States and /or other countries. The information, artwork, text, video, audio, pictures, softwareand other intellectual property are protected by copyright andinternational laws.You may not reproduce, distribute, publicly perform, publiclydisplay, modify or create derivative works of the intellectualproperty, unless authorized by the appropriate copyrightowner(s). iRiver does not encourage any of our customers touse copy-righted Intellectual property illegally by using thisproduct. URL : http://www.iRiverAmerica.comProvides information on our company, products, and customer support information. Download the latest Software and Firmware UpgradesRegister your iRiver product online so that our Customer Service is enabled to provide support as efficiently as possible. Contents described in this manual may be changed with out notice. 2 3 FRONT VIEWSIDE VIEW 4 5 1. Locating the Controls Front View, Side View.......................................................Side View..........................................................................LCD Window..................................................................... 2. Getting started Using AC POWER ADAPTER..........................................Software Installation..........................................................Connecting the iGP to the Host PC..................................Installing the iGP Device Driver........................................Using as a Portable Storage Device.................................Disconnecting the iGP from the Host PC..........................Listening to Music.............................................................Basic Operation................................................................ 3. Useful Features Playback Mode.................................................................Navigation.........................................................................Operating the FM Tuner....................................................Playback Mode.................................................................EQ/SRS............................................................................Menu.................................................................................Using WINAMP Playlist.....................................................Firmware Upgrade............................................................ 4. Additional Information References................................................................…

Text truncated - open the document above for the full version.

–

EMI TEST REPORT Emission of electromagnetic disturbance Test Report No. : ERI-FCC03-0059 Equipment : MP3 Player Name of basic model : iGP-100 Family model : None Manufacturer : AV CHASEWAY MFG.FTY. Applicant : iRiver CO., LTD. Tested date : 2003. 9. 22 – 9. 23 Issued date : 2003. 9. 24 Test results : PASS Test Standards : FCC Part 15 Subpart B (Class B) /digital devices & peripherals Test Procedure and Items: - AC Power line Conducted emissions measurement : ANSI C63.4-1992 - Radiated emissions measurement : ANSI C63.4-1992 Tested by: GWEON, HUR Approved by: UK-CHO, RIM The results in this report apply only to the sample tested. This test report shall not be reproduced except in full, without the written approval of ERI Laboratory. ELECTROMAGNETIC RESEARCH INSTITUTE CONTENTS 1. CLIENT INFORMATION 2. LABORATORY INFORMATION 3. EQUIPMENT UNDER TEST INFORMATION(EUT) 3.1 Identification of the EUT 3.2 Additional information about the EUT 3.3 Peripheral equipment 4. CONTINUOUS DISTURBANCE VOLTAGE, MAIN TERMINAL 4.1 Operating environment 4.2 Test set-up and test procedures 4.3 Operation Conditions 4.4 Test instrument 4.5 Test results 5. RADIATED DISTURBANCE : 30MHz – 1000MHz 5.1 Operating environment 5.2 Test set-up 5.3 Test conditions 5.4 Test instrument 5.5 Test results(Test mode: Up & download mode) 5.6 Test results(Test mode: Play mode) 5.7 Test results(Test mode : FM Tuner) APPENDIX (None) ELECTROMAGNETIC RESEARCH INSTITUTE 1. CLIENT INFORMATION The EUT has been tested by request of : Company : iRiver CO., LTD. Address : 8F Posgen VentureTower, 1586-7 Seocho-dong, Seocho-gu, Seoul, Korea Name of contact : H.J. Mun Telephone : +82-2-3019-1723 Facsimile : +82-2-3019-1746 2. LABORATORY INFORMATION The 10m full-anechoic chamber and/or EMC facilities are used for these testing. These facilities were accredited by KOLAS, EK, MIC of Korea and FCC of USA. Address ELECTROMAGNETIC RESEARCH INSTITUTE. 66-6, JEIL-RI, YANGJI-MYUN, YOUNGIN-CITY, KYUNGGI-DO, KOREA Telephone No. : +82-31-336-1186~7 Facsimile No. : +82-31-336-1184 Registered No. KOLAS : 111 EK : J MIC : KR0030 FCC Filing No. : 302567 3. EQUIPMENT UNDER TEST INFORMATION(EUT) 3.1 Identification of the EUT Type of equipment : MP3 Player Model name : iGP-100 Brand name : - Manufacturer : AV CHASEWAY MFG.FTY. Address : Langang Village, Chongguang Town, Baoan District, Shenzhen City, Guangdong, China Telephone : +86-755-708-4671 Facsimile : +86-755-708-5490 Country of origin : CHINA Rating : 120V, 60Hz ELECTROMAGNETIC RESEARCH INSTITUTE 3.2 Additional information about the EUT Class B, Family Models List: None 3.3 Peripheral equipment Defined as equipment needed for correct operation of the EUT. Description Model No. Serial No. Manufacture AC/DC adaptor SEA60N2-16.0 03502395C SANKEN ELECTRIC CO., LTD. Note PC FPC02015C 464307211682 FUJITSU AC/DC adaptor - - - Earphone - - - Keyboard SDL2500 07035593 SAMSUNG Electronics Co., Ltd. ELECTROMAGNETIC RESEARCH INSTITUTE 4. CONTINUOUS DISTURBANCE VOLTAGE, MAIN TERMINAL : Frequency range 0.15 MHz to 30 MHz 4.1 Operating environment Temperature : 22.0 Relative Humidity : 52.0 % 4.2 Test set-up and test procedures The mains terminal disturbance voltage was measured with the equipment under test(EUT) in a shield room. The EUT was connected to an artificial mains network(LISN) placed on the floor. The EUT was placed on non-metallic table 0.4m above the metallic, grounded floor. The distance to other metallic surface was at least 0.8m. Amplitude measurements were performed with a quasi-peak detector and an average detector. 4.3 Operation Conditions Up & download mode, play mode 4.4 Test instrument Instrument Model No Serial No. Makers Next cal.date Used Test receiver ESCS30 100021 R&S 2004. 1. 24 ESH3-Z5 827246/008 R&S 2004. 3. 19 L.I.S.N. ESH3-Z5 831887/018 R&S 2004. 3. 19 Shield room 8 6 3.3m/H - - - AC Main LISN EUT NOTE PC LISN Earphone AC/DC adaptor AC/DC adaptor Keyboard ELECTROMAGNETIC RESEARCH INSTITUTE 4.5 Test results Date of test: Sep 22, 2003. An overview sweep performed with peak detector & average detector are included in the report as test reports. Frequency Tested LISN Meter Range Freq. Reading Limits Margin QP AV QP AV QP AV [MHz] [MHz] [dBuV] [dBuV] [dBuV] 0.195 N 45.3 37.7 63.8 53.8 18.5 16.1 0.417 V 40.3 37.1 57.9 47.9 17.6 10.8 0.15-30 0.636 V 41.6 27.9 56.0 46.0 14.4 18.1 1.887 V 34.1 25.3 56.0 46.0 21.9 20.7 2.499 V 37.8 37.1 56.0 46.0 18.2 8.9 3.950 V 36.8 35.4 56.0 46.0 19.2 10.6 * <5 : mean less than 5dB * Other frequency keep over 20dB margin. ELECTROMAGNETIC RESEARCH INSTITUTE [Hot line] [Neutral line] ELECTROMAGNETIC RESEARCH INSTITUTE 5. RADIATED DISTURBANCE : 30MHz – 1000MHz 5.1 Operating environment Temperature : 23.0 Relative Humidity : 48.0 % 5.2 Test set-up The frequency range investigated was 30 MHz to 1000 MHz. All readings are quasi-peak unless stated otherwise. The half-wave dipole antenna was tuned to the frequency found during Preliminary radiated measurements. The EUT, support equipment and Interconnecting cables were re-configured to the set-up to the producing the Maximum emission for the frequency and were placed on top of a 0.8 meter High non-metallic 1 X 1.5 meter table. The EUT, support equipment, and interconnecting cables were re-arranged and manipulated to maximize each EME emission. The turntable containing the system was rotated the antenna height was varied 1 to 4 meters and stopped at the azimuth or height producing the maximum emission. And this device(EUT) was tested in 3 orthogonal planes. The antenna measured both horizontal and vertical polarization. <General test set-up for radiated emissions> 5.3 Operation Conditions Up & download mode, play mode ELECTROMAGNETIC RESEARCH INSTITUTE 5.4 Test instrument Instrument Model No. Serial No. Makers Next cal.date Used Test receiver ESCS30 100021 R&S 2004. 1. 24 ESH3-Z5 827246/008 R&S 2004. 3. 19 L.I.S.N. ESH3-Z5 831887/018 R&S 2004. 3. 19 5.5 Test results(Test mode: Up & download mode) Date of test: Sep 23, 20…
