SPORTON International Inc. No. 52, Hwa Ya 1st Rd., Kwei-Shan Hsiang, TaoYuan Hsien, Taiwan, R.O.C. Ph: 886-3-327-3456 / FAX: 886-3-327-0973 / www.sporton.com.tw Report Format Version: 01 FCC RADIO TEST REPORT Applicant’s company Z-Com, Inc. Applicant Address 7F-2, No. 9. Prosperity RD.I Science-Based Industrial, Park Hsinchu, 300 Taiwan FCC ID M4Y-XN620V04 Manufacturer’s company Z-Com, Inc. Manufacturer Address 7F-2, No. 9. Prosperity RD.I Science-Based Industrial, Park Hsinchu, 300 Taiwan Product Name Draft 802.11n Wireless Mini-PCI Card Brand Name ZCOM Model Name XN-620 Test Rule 47 CFR FCC Part 15 Subpart C § 15.247 Test Freq. Range 2400 ~ 2483.5MHz Received Date Jun. 06, 2007 Final Test Date Jun. 21, 2007 Submission Type Original Equipment Statement Test result included is only for the Draft n part of the product. The test result in this report refers exclusively to the presented test model / sample. Without written approval of SPORTON International Inc., the test report shall not be reproduced except in full. The measurements and test results shown in this test report were made in accordance with the procedures and found in compliance with the limit given in ANSI C63.4-2003 and 47 CFR FCC Part 15 Subpart C. The test equipment used to perform the test is calibrated and traceable to NML/ROC. Report No.: FR760609-AA Report Format Version: 01 Page No. : ii of ii FCC ID: M4Y-XN620V04 Issued Date : Jun. 28, 2007 Table of Contents 1. CERTIFICATE OF COMPLIANCE ......................................................................................................................... 1 2. SUMMARY OF THE TEST RESULT .......................................................................................................................... 2 3. GENERAL INFORMATION .................................................................................................................................. 3 3.1. Product Details..................................................................
Report No.: FR760609 FCC ID: M4Y-XN620V04 Page No. : 1 of 8 Appendix B. Test Photos Report No.: FR760609 FCC ID: M4Y-XN620V04 Page No. : 2 of 8 1. Photographs of Conducted Emissions Test Configuration FRONT VIEW REAR VIEW Report No.: FR760609 FCC ID: M4Y-XN620V04 Page No. : 3 of 8 FRONT VIEW Report No.: FR760609 FCC ID: M4Y-XN620V04 Page No. : 4 of 8 2. Photographs of Radiated Emissions Test Configuration 9kHz ~30MHz FRONT VIEW REAR VIEW Report No.: FR760609 FCC ID: M4Y-XN620V04 Page No. : 5 of 8 30MHz~1GHz FRONT VIEW REAR VIEW Report No.: FR760609 FCC ID: M4Y-XN620V04 Page No. : 6 of 8 FRONT VIEW Report No.: FR760609 FCC ID: M4Y-XN620V04 Page No. : 7 of 8 Above 1GHz FRONT VIEW REAR VIEW Report No.: FR760609 FCC ID: M4Y-XN620V04 Page No. : 8 of 8 FRONT VIEW
FCC Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one of the following measures: - Reorient or relocate the receiving antenna. - Increase the separation between the equipment and receiver. - Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. - Consult the dealer or an experienced radio/TV technician for help. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. This device and its antenna(s) must not be co-located or operation in conjunction with any other antenna or transmitter. IEEE 802.11b or 802.11g operation of this product in the U.S.A. is firmware-limited to channels 1 through 11. CAUTION: To comply with FCC RF exposure compliance requirements, a separation distance of at least 20 cm must be maintained between the antenna of this device and all persons. This Transmitter must not be co-located or operating in conjunction with any other antenna or transmitter This device is intended only for OEM integrators under the following conditions: The antenna must be installed such that 20 cm is mai...
DATE 10th of May 2007 Nemko Canada Inc 303 River Road Ottawa, Ontario, Canada K1V 1H2 Attn: Director of Certification Authority to Act as Agent On our behalf, I appoint Nemko Comlab A/S, Gåsevikveien 8, Kjeller, Norway , to act as our agent in the preparation of this application for equipment certification. I certify that submitted documents properly describe the device or system for which equipment certification is sought. I also certify that each unit manufactured, imported or marketed, as defined in the Federal Communications Commission’s regulations will have affixed to it a label identical to that submitted for approval with this application. For instances where our authorized agent signs the application for certification on our behalf, I acknowledge that all responsibility for complying with the terms and conditions for certification, as specified by Nemko Canada Inc, still resides with Jotron AS, Kirkestien 1, PO Box 54, 3280 Tjodalyng, Norway. Dated this 10th of May 20 07 Agency agreement expiration date: 10 th May 2008 By: Eirik Storjordet Signature Printed Title: Certification Manager On behalf of : Jotron AS Telephone: +47 33139714
Tjodalyng: 06.07.2007 RE: CONFIDENTIALITY REQUEST FOR: FCC ID: RA9RA-7203 To whom it may concern: This letter serves as an official request for confidentiality under FCC rule section 0.459. We have requested that the following documents: Technical Manual, Maintenance and Repair Manual, Schematic Description, RA7203 blockdiagram.pdf document, RA7203 brief description.pdf document and Internal Photos required to be submitted with this application, to be withheld from public view. These documents are company property and must never get into the possession of Jotron AS competition. The sale and marketing of this equipment is limited to ground –to-air projects and the equipment is sold directly to these customers. The equipment is not available for our competitors to study. Sincerely, Eirik Storjordet Certification Manager [email protected] Tel. +47 33139714 Fax. +47 33126780 Attn: Reviewing Engineer Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 USA
Nemko AS, Gaustadalléen 30, P.O.Box 73 Blindern, NO-0314 Oslo Norway T +47 22 96 03 30 F +47 22 96 05 50 Enterprise number NO974404532 Visiting address: Nemko Comlab, Gåsevikveien 8, P.O.Box 96, NO-2027 Kjeller Norway T +47 64 84 57 00 F +47 64 84 57 05 Test report no. : 71006/8 Item tested : RA-7203 Type of equipment : VHF Receiver FCC ID : RA9RA-7203 Client : Jotron AS FCC Part 15, subpart B (VHF receiver) 09 July 2007 Authorized by : ........................... ................... Egil Hauger Technical Verificator TEST REPORT FCC part 15B Project no.: 71006/8 Nemko Comlab, N-2027 Kjeller Page 2 (29) CONTENTS 1 GENERAL INFORMATION ............................................................................................................... 3 1.1 Testhouse Info ................................................................................................................................... 3 1.2 Client Information............................................................................................................................... 3 1.3 Manufacturer ( if other than client) ..................................................................................................... 3 2 TEST INFORMATION ....................................................................................................................... 4 2.1 Tested Item........................................................................................................................................ 4 2.2 Test Environment............................................................................................................................... 5 2.3 Test Period ........................................................................................................................................ 5 2.4 Test Engineer(s) ................................................................................................................................ 5 2.5 Test Equipment............................
FCC Part 15B Project no.: 71006/8 Page 1 of 1 Nemko Comlab, N-2007 Kjeller TEST SET-UP PHOTOS Conducted emission 150kHz – 30MHz , AC/DC mains Test set-up for Radiated emission 50 ohm termination
RA - 7203 123456 7 8 9 101112 1 DISPLAY 2 FbA (Function button A) 3 RS (Rotary switch) 4 SQUELCH LED 5 REMOTE LED 6 FRONT CONNECTOR 7 FbB (Function button B) 8 FbC (Function button C) 9 ON/OFF 10 ALARM LED11 STANDBY LED12 LOUDSPEAKER VHF Receiver RA - 7203 Front RJ45 connector Front Connector, RJ45 Name PIN Purpose SEL 1 TDO 2 Headset 3 RS232 4 RS232 Tx RS232 5 RS232 Rx TMS 6 +12VDC 7 +12 VDC to external equipment (10mA) GND 8 Common ground RA - 7203 Technical data, 1 of 4 Standards ; ICAO annex 10, EN300 676(AM, AM-MSK), EN301 841(VDL2 – Physical layer) Environmental: Temperature range -20 ° C to +55 ° C (operating) - 40 ° C to +70 ° C (storage) Humidity 90% @+40 ° C (non condensing) Shock Transport: IEC-721-3-2, Class 2M3 Vibration Transport: IEC-68-2-32, Class 2M3. IEC-68-2-6 EMC EN 301 489 – part 22 Weight: 1.7 kg Dimension: 71mm (14TE)(W) * 230mm(D) * 128mm (H) RA - 7203 Frequency response: 300-3400 Hz 350-2500 Hz Data ports: RS232, RS485, 100/10BaseT Protocol: (SNMP v.2) Simple Network Management RS232/RS485 Jotron proprietary BITE monitoring: VSWR, Voltages, Currents, Levels, Lock detect, Temperature, Out put power, Reflected power, a.o. Supply voltage: AC 115/230VAC +15/-10% / 50-60Hz Supply voltage, DC 21.6 - 31.2VDC negative ground MTBF: >10 years / unit MTTR: <30 minutes at lowest replaceable unit Technical data, 2 of 4 RA - 7203 Technical data, 3 of 4 Receiver AM 25kHz AM 8.33kHz Sensitivity analogue @1 μ V / 30% pd: 10dSINAD(CCITT) Adjacent channel rejection: >70dB >60dB Intermodulation (3 signal): >70 dBc IF bandwidth: +/- 11kHz +/-2.8kHz Image and IF frequency response: >110 dB Squelch operation: Adjustable 107dBm, 30dB S/N + carrier override Activation time <20ms Hysteresis <3dB Audio AGC: 30%-90%, <1dB variation Noise blanker: IF: Selectable ON/OFF Signal / Noise: >45dB on any output @100 μ V, 30% RA - 7203 Technical data, 4 of 4 AGC range: -107dBm to +5dBm AGC attach time: <50ms AGC decay time: <200ms Inband squelch signal: Configurable tones: 150-...
| # | Rule Parts | Frequency Range | Power Output |
|---|---|---|---|
| 1 | 15C | 2.40 GHz - 2.48 GHz | 2.00 mW |
