27.145MHz transmitter operational description of Morphibian The transmitter send out 27.105MHz ~27.185MHz signal of high frequency to control the cat move which supply voltage is 9.0volts with battery. Please consult with added block diagram and schematic. When the user pulls the two trigger to up and down (schematic presents with S2~S5), the IC U1 high voltage enters into GND. these signal is processed by IC and sent out through Q1.X1, L1, C1 makes up of oscillator, which generated base oscillatory signal .The signal of R, L, F and B come by L5, C3, L4, C4, C5 and fixed 27.145MHz of high frequency, it is sent out. D1 LED acts as a power ñon indicator. All tuning and verifications are performed by the manufacturer and there are no adjustment which can be made by the user. No external ground is required or used with this transmitter.

1234 A B C D 4 321 D C B A Title NumberRevisionSize A4 Date:11-May-2007Sheet of File:D:\data\KG\G794\LAYOUT\G794TXSCH27MHZ.DdbDrawn By: Q2 2SC2712 Q1 2SC1815 R6 510R R3 150R R2 180K R8 390R R1 10K D1 C5 18PF C4 27PF C3 100PF C2 100PF C10 56PF C1 15PF C11 0.1UF C9 100UF C8 0.02UF C6 0.02UF BA1 9V L1 2.2UH L2 3.3UH L4 5.6UH 1 2 3 4 5 6 78 9 10 11 12 13 14 U1CS5201 ANT X1 27.145MHZ Z1A 3.3V S1 R4120K S5SW S2SW S3SW S4SW LEFT FOSC OSC1 OSC0 PC VDD SOSC TURBO FWD BACK GND TEST RIGHT C12 24PF R7 100R C7 0.01UF L5 2.2UH PDF created with pdfFactory Pro trial version www.pdffactory.com
