QEARCGOGO49RRC Soft & Squeezable Vehicle-Tow Truck

TM 16.33”

Block Diagram （ （（（ Rx ） ）））

External photos External photosExternal photos External photos

Label Artwork and Location Label Size: 25mm(W) x 11mm(H)

Internal Photos

RX Technical description Description Function Component Antenna Receive the RF signal ANT Super-regenerative receiver Select the RF signal (49.860MHz) Q1 and associated circuit RF IC Decode the RF signal to Motor Driver U1 Motor Driver Drive the Motor U2 and associated circuit Type of antenna: Integral antenna
