QEASUVPLANE27DRV-SUV&PLANE

1 2 34 ABCD 4 3 2 1 D CBA LUNG CHEONG TITLEFUNCTION DWG NO DZXX-XXXXXX-XX DESIGN DRAWING APPROVED SHEET 1 OF 1 ANTENNA LED SPRC205 9V BATTERY OSC FORWARD BACKWARD SHOOT RIGHT LEFT 27.145MHZ BLOCK DIAGRAM OF E936 TX FILTER ENCODER E936 TX TRUCK-PLANE HZD HZD

Operation Description for DRV - SUV & Plane (27 MHz Transmitter) The transmitter of DRV- SUV & Plane is powered by a 9V battery and operated at channel 27.145MHz. There are two control sticks in front of the unit. When the joystick is pushed up or down once, it will transmit a radio frequency for receiver to go forward or backward. When the joystick is pushed left or right once, it will transmit a radio frequency for receiver go left or right. Referring to the transmitter circuit design, the circuit description is listed below: - X1 and associate circuit act as Oscillator. - U1 and associate circuit act as encoder. - L3, L4 and associate circuit act as filter.

1 2 34 ABCD 4 3 2 1 D CBA LUNG CHEONG TITLEFUNCTION DWG NO DZXX-XXXXXX-XX DESIGN DRAWING APPROVED SHEET 1 OF 1 VDD 1 DI0 2 OSCI 3 OSCO 4 RFO 5 VSS 6 DOUT 7 DI1 8 DI2 9 ROSC 10 DI3 11 DI4 12 U1SPRC205 R1100 R21K R3 200K R422 R5 2.2M R61K R71K R81K R91K R101K K1 K2 K3 K4 K5 X1 27.145MHZ LED C2104 C330p C4CAP C5104 C947P C1030P C11104 C647p C739p C830p L110uH L22.2uH L32.2uH L46.8uH C1220u D1 4.3V ANT BATT9V SW112F20 CNCAP E936 TX TRUCK-PLANE HZD HZD

TEST REPORT Report No. : AF009397-001 Date : 2005 May 10 For and on behalf of CMA Testing and Certification Laboratories Authorized Signature : Page 1 of 11 Danny Chui EMC Engineer - EL. Division FCC ID : QEASUVPLANE27 This document shall not be reproduced either in full or in part except with written approval by the Authorized Representative of CMA Testing. Room 1302, Yan Hing Centre, 9-13 Wong Chuk Yeung St.., Fo Tan, Shatin, Hong Kong. Tel: (852) 2698 8198 Fax: (852) 2695 4177 E-mail: [email protected] Web Site: http://www.cmatcl.com Application No. : LF207060(4) Applicant : Kid Galaxy Inc. One Sundial Ave, Suite 310 Manchester, NH 03103, U.S.A. Sample Description : One(1) submitted sample stated to be DRV - SUV & Plane of Model No. 10210 Rating : 1 x 9V size battery No. of submitted sample : Two (2) piece(s)*** Date Received : Test Period : Test Requested : Test Method : Test Result : Conclusion : 2005 April 21 2005 April 21 – 2005 May 03 FCC Part 15 Certification FCC Rules and Regulations Part 15 – July 2004 ANSI C63.4 – 2003 See attached sheet(s) from page 2 to 11. The submitted sample was found to comply with requirement of FCC Part 15 Subpart C. TEST REPORT Report No. : AF009397-001 Date : 2005 May 10 Page 2 of 11 FCC ID : QEASUVPLANE27 This document shall not be reproduced either in full or in part except with written approval by the Authorized Representative of CMA Testing. Room 1302, Yan Hing Centre, 9-13 Wong Chuk Yeung St.., Fo Tan, Shatin, Hong Kong. Tel: (852) 2698 8198 Fax: (852) 2695 4177 E-mail: [email protected] Web Site: http://www.cmatcl.com Table of Contents 1 General Information ..................................................................................................................... 3 1.1 General Description ............................................................................................................... 3 1.2 Location of the test site.......................................................................................................... 4 1.3 List of measuring equipment ................................................................................................. 5 2 Description of the radiated emission test ..................................................................................... 6 2.1 Test Procedure ....................................................................................................................... 6 2.2 Test Result ............................................................................................................................. 6 2.3 Radiated Emission Measurement Data.................................................................................. 7 3 Description of the Line-conducted Test .......................................................................................8 3.1 Test Procedure ....................................................................................................................... 8 3.2 Test Result ............................................................................................................................. 8 3.3 Graph and Table of Conducted Emission Measurement Data .............................................. 8 4 Photograph ................................................................................................................................... 9 4.1 Photographs of the Test Setup for Radiated Emission and Conduction Emission ................ 9 4.2 Photographs of the External and Internal Configurations of the EUT .................................. 9 5 Supplementary document ............................................................................................................ 10 5.1 Bandwidth............................................................................................................................ 10 5.2 Duty Cycle ............................................................................................................................ 10 6 Appendices ................................................................................................................................. 11 TEST REPORT Report No. : AF009397-001 Date : 2005 May 10 Page 3 of 11 FCC ID : QEASUVPLANE27 This document shall not be reproduced either in full or in part except with written approval by the Authorized Representative of CMA Testing. Room 1302, Yan Hing Centre, 9-13 Wong Chuk Yeung St.., Fo Tan, Shatin, Hong Kong. Tel: (852) 2698 8198 Fax: (852) 2695 4177 E-mail: [email protected] Web Site: http://www.cmatcl.com 1 General Information 1.1 General Description The equipment under test (EUT) is a transmitter for DRV – SUV & Plane. Operating at 27.145MHz which is controlled by a crystal. The EUT is powered by 9V battery. There are two control stick in front of EUT. When it switched on and push the stick once, it can transmit difference radio signal for receiver go difference direction. The brief circuit description is listed as follows : - X1 and associated circuit act as oscillator. - U1 and associated circuit act as encoder . - L3, L4 and associated circuit act as filter. TEST REPORT Report No. : AF009397-001 Date : 2005 May 10 Page 4 of 11 FCC ID : QEASUVPLANE27 This document shall not be reproduced either in full or in part except with written approval by the Authorized Representative of CMA Testing. Room 1302, Yan Hing Centre, 9-13 Wong Chuk Yeung St.., Fo Tan, Shatin, Hong Kong. Tel: (852) 2698 8198 Fax: (852) 2695 4177 E-mail: [email protected] Web Site: http://www.cmatcl.com 1.2 Location of the test site Radiated emissions measurements are investigated and taken pursuant to the procedures of ANSI C63.4 – 2003. A Semi-Anechoic Chamber Testing Site is set up for investigation and located at : Ground Floor, Yan Hing Centre, 9 – 13 Wong Chuk Yeung Street, Fo Tan, Shatin, New Territories, Hong Kong. Conducted emissions measurements are investigated and also taken pursuant to the procedures of ANSI C63.4 – 2003. A shielded room is locate…

Text truncated - open the document above for the full version.

CMA Testing and Certification Laboratories Job No.: WF-EL-EMC-15 Edition 3 2005 Mar 29 Page of Bandwidth Plot Bandwidth 1

CMA Testing and Certification Laboratories Job No.: WF-EL-EMC-15 Edition 3 2005 Mar 29 Page of Duty Cycle Duty Cycle 1 Duty Cycle 2 CMA Testing and Certification Laboratories Job No.: WF-EL-EMC-15 Edition 3 2005 Mar 29 Page of Duty Cycle 3
