Operation Description The receiver of TRUCK car is powered by 4*1.5V AA battery. When it received either one of Forward, Backward, Left Turn and Right Turn signal from the transmitter, it will move forward, backward, turn left or right accordingly. Refer to the receiver circuit design, the circuit description is listed as below :
 C8 and associate components are acted as RF receiver.
 U1 and associate components are acted as control signal decoder.
 Q1 ~ Q12 and associate components are acted as motor driving.

E004TRUCK.sch-1 - Tue Apr 19 14:22:10 2005

TEST REPORT Report No. : AF009154-001 Date : 2005 April 29 For and on behalf of CMA Testing and Certification Laboratories Authorized Signature : Page 1 of 11 Danny Chui EMC Engineer - EL. Division FCC ID : QEATRUCKATV9L This document shall not be reproduced either in full or in part except with written approval by the Authorized Representative of CMA Testing. Room 1302, Yan Hing Centre, 9-13 Wong Chuk Yeung St.., Fo Tan, Shatin, Hong Kong. Tel: (852) 2698 8198 Fax: (852) 2695 4177 E-mail: [email protected] Web Site: http://www.cmatcl.com Application No. : LF205025(3) Applicant : Kid Galaxy Inc. One Sundial Ave, Suite 310 Manchester, NH 03103, U.S.A. Sample Description : One(1) submitted sample stated to be DRV - Truck & ATV of Model No. 10117 Rating : 4 x 1.5V AA size batteries No. of submitted sample : Two (2) piece(s)*** Date Received : Test Period : Test Requested : Test Method : Test Result : Conclusion : 2005 April 18 2005 April 18 – 2005 April 27 FCC Part 15 Certification FCC Rules and Regulations Part 15 – July 2004 ANSI C63.4 – 2003 See attached sheet(s) from page 2 to 11. The submitted sample was found to comply with requirement of FCC Part 15 Subpart B. TEST REPORT Report No. : AF009154-001 Date : 2005 April 29 Page 2 of 11 FCC ID : QEATRUCKATV9L This document shall not be reproduced either in full or in part except with written approval by the Authorized Representative of CMA Testing. Room 1302, Yan Hing Centre, 9-13 Wong Chuk Yeung St.., Fo Tan, Shatin, Hong Kong. Tel: (852) 2698 8198 Fax: (852) 2695 4177 E-mail: [email protected] Web Site: http://www.cmatcl.com Table of Contents 1 General Information ..................................................................................................................... 3 1.1 General Description ............................................................................................................... 3 1.2 Location of the test site.......................................................................................................... 4 1.3 List of measuring equipment ................................................................................................. 5 2 Description of the radiated emission test ..................................................................................... 6 2.1 Test Procedure ....................................................................................................................... 6 2.2 Test Result ............................................................................................................................. 6 2.3 Radiated Emission Measurement Data.................................................................................. 7 3 Description of the Line-conducted Test .......................................................................................8 3.1 Test Procedure ....................................................................................................................... 8 3.2 Test Result ............................................................................................................................. 8 3.3 Graph and Table of Conducted Emission Measurement Data .............................................. 8 4 Photograph ................................................................................................................................... 9 4.1 Photographs of the Test Setup for Radiated Emission and Conduction Emission ................ 9 4.2 Photographs of the External and Internal Configurations of the EUT .................................. 9 5 Supplementary document ............................................................................................................ 10 5.1 Bandwidth............................................................................................................................ 10 5.2 Duty Cycle ........................................................................................................................... 10 6 Appendices .................................................................................................................................. 11 TEST REPORT Report No. : AF009154-001 Date : 2005 April 29 Page 3 of 11 FCC ID : QEATRUCKATV9L This document shall not be reproduced either in full or in part except with written approval by the Authorized Representative of CMA Testing. Room 1302, Yan Hing Centre, 9-13 Wong Chuk Yeung St.., Fo Tan, Shatin, Hong Kong. Tel: (852) 2698 8198 Fax: (852) 2695 4177 E-mail: [email protected] Web Site: http://www.cmatcl.com 1 General Information 1.1 General Description The equipment under test (EUT) is a superregenerative receiver for DRV – Truck & ATV operating at 49.860MHz which is controlled by a LRC circuit. The EUT is powered by 4 x 1.5V AA size batteries. When it received either one of forward, backward, left turn and right turn signal from the transmitter, it will move forward, backward, left turn and right turn accordingly. The brief circuit description is listed as follows : - C8 and associated circuit act as RF receiver. - U1 and associated circuit act as control signal decoder. - Q1 – Q12 and associated circuit act as motor driving. TEST REPORT Report No. : AF009154-001 Date : 2005 April 29 Page 4 of 11 FCC ID : QEATRUCKATV9L This document shall not be reproduced either in full or in part except with written approval by the Authorized Representative of CMA Testing. Room 1302, Yan Hing Centre, 9-13 Wong Chuk Yeung St.., Fo Tan, Shatin, Hong Kong. Tel: (852) 2698 8198 Fax: (852) 2695 4177 E-mail: [email protected] Web Site: http://www.cmatcl.com 1.2 Location of the test site Radiated emissions measurements are investigated and taken pursuant to the procedures of ANSI C63.4 – 2003. A Semi-Anechoic Chamber Testing Site is set up for investigation and located at : Ground Floor, Yan Hing Centre, 9 – 13 Wong Chuk Yeung Street, Fo Tan, Shatin, New Territories, Hong Kong. Conducted emissions measurements are investigated and also…
