DATE Equipment Autorisation Division Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 FCC ID: QF9-ZEKLER412 Product Name: ZEKLER 412DB & ZEKLER 412 RDB Request for Confidentiality Pursuant to Sections 0.457(d) and 0.459 of the commissions rules, we hereby request that the following documents be held confidential: (List here the documents for which you are seeking confidentiality – for example ...) • Schematics • Block diagram • Operational Description • Component list These materials contain trade secrets and proprietary information and are not customarily released to the public. The public disclosure of this information might be harmful to the company and provide unjustified benefits to our competitors. Dated this 22 th Day of May 20 20 By: Fredrik Eriksson Signature Printed Title: R&D Manager On behalf of : Hellberg Safety AB Telephone: +46703849400

External Photos FCC ID: QF9-ZEKLER412 Zekler DB External Photos FCC ID: QF9-ZEKLER412 Zekler DB External Photos FCC ID: QF9-ZEKLER412 Zekler RDB External Photos FCC ID: QF9-ZEKLER412 Zekler RDB

Author: Fredrik Eriksson Document No: RnD_Spec_000XX Revision: 1 1 Zekler DB & RDB marking P ro ducts: Zekler DB, Zekler DBH, Zekler RDB & Zekler RDBH Label position:

Zekler BT LD Headband Zekler BT LD Helmet Zekler BT Combi Headband Zekler BT Combi Helmet

Internal Photos FCC ID: QF9-ZEKLER412 Internal Photos FCC ID: QF9-ZEKLER412

FCC ID: QF9-ZEKLER412 SAR Exclusion Justification Test exclusion thresholds for 100 MHz to 6 GHz at test separation distances ≤ 50 mm Guidance document reference: 447498 D01 General RF Exposure Guidance v05r02, page 11, paragraph 4.3.1(1). The 1-g and 10-g SAR test exclusion thresholds for 100 MHz to 6 GHz at test separation distances ≤ 50 mm are determined by: [(max. power of channel, including tune-up tolerance, mW)/(min. test separation distance, mm)] * [√f(GHz)] ≤ 3.0 for 1-g SAR and ≤ 7.5 for 10-g extremity SAR, where • f(GHz) is the RF channel transmit frequency in GHz • Power and distance are rounded to the nearest mW and mm before calculation • The result is rounded to one decimal place for comparison • 3.0 and 7.5 are referred to as the numeric thresholds in the step 2 below The test exclusions are applicable only when the minimum test separation distance is ≤ 50 mm and for transmission frequencies between 100 MHz and 6 GHz. When the minimum test separation distance is < 5 mm, a distance of 5 mm according to 5) in section 4.1 is applied to determine SAR test exclusion. SAR test exclusion analysis: Max. power of channel:0.83mW Min. separation distance:5mm Max. frequency:2.44GHz [(Pwr/Dist)*√Freq.] = 0.3 The result of the above SAR threshold calculation demonstrates that the result is less than the 1-g numeric threshold of 3 and the 10-g numeric threshold of 7.5. Conclusion: The above analysis shows that the evaluated device qualifies for exemption from SAR testing. Signed: , Technical Manager 6/18/2020

Report No. 397015-01-R01 Template version: C Nemko Norway Nemko AS, Instituttveien 6, P.O. Box 96 Kjeller, 2027 Kjeller, Norway TEL +47 22 96 03 30 FAX +47 22 96 05 50 EMAIL [email protected] ENTERPRISE NUMBER NO974404532 nemko.com/no Test Report Product Headset with Bluetooth Classic and FM receiver Name and address of the applicant Hellberg Safety AS Stakebergsvägen 2 SE-44361 Stenkullen, Sweden Name and address of the manufacturer Hellberg Safety AS Stakebergsvägen 2 SE-44361 Stenkullen, Sweden Model 412RDB, 412RDBH, 412DB, 412DBH Rating 3.0V DC (2x AA cells) Trademark Zekler Serial number See clause 1.1 Additional information Bluetooth Basic Rate and EDR, FM Receiver Tested according to FCC Part 15.247 Frequency Hopping Transmitters / Digital Transmission Systems Industry Canada RSS-247, Issue 2 Digital Transmission Systems (DTSs), Frequency Hopping Systems (FHSs) and Licence-Exempt Local Area Network (LE-LAN) Devices Order number 397015 Tested in period 2020-05-06 to 2020-05-08 Issue date 2020-06-24 Name and address of the testing laboratory Instituttveien 6 Kjeller, Norway www.nemko.com CAB Number: FCC: NO0001 ISED: NO0470 TEL: +47 22 96 03 30 FAX: +47 22 96 05 50 An accredited technical test executed under the Norwegian accreditation scheme Prepared by [Frode Sveinsen] Approved by [G.Suhanthakumar] This report shall not be reproduced except in full without the written approval of Nemko. Opinions and interpretations expressed within this report are not part of the current accreditation. This report was originally distributed electronically with digital signatures. For more information contact Nemko. TEST REPORT FCC Part 15.247 Report no.: 397015-01-R01 FCC ID: QF9-ZEKLER412 IC: 5808A-ZEKLER412 Nemko Norway, Instituttveien 6, Kjeller, Norway Page 2 (61) CONTENTS 1 INFORMATION ......................................................................................................................... 3 1.1 Test Item .................................................................................................................................... 3 1.2 Normal test condition ................................................................................................................. 4 1.3 Test Engineer(s) ........................................................................................................................ 4 1.4 Antenna Requirement ................................................................................................................ 4 1.5 Worst-Case Configuration and Mode ......................................................................................... 4 1.6 Comments ................................................................................................................................. 4 2 TEST REPORT SUMMARY ...................................................................................................... 5 2.1 General ...................................................................................................................................... 5 2.2 Test Summary ........................................................................................................................... 6 3 TEST RESULTS ........................................................................................................................ 7 3.1 Power Line Conducted Emissions ............................................................................................. 7 3.2 Channel Separation and 20dB Bandwidth ................................................................................. 8 3.3 Occupancy Time ...................................................................................................................... 14 3.4 Occupied Bandwidth (99% BW) and Hopping Bandwidth ........................................................ 20 3.5 Peak Power Output .................................................................................................................. 26 3.6 Conducted Emissions at Antenna Connector .......................................................................... 32 3.7 Restricted Bands of operation.................................................................................................. 41 3.8 Radiated Emissions, Band Edge ............................................................................................. 42 3.9 Radiated Emission, 30 – 1000 MHz ......................................................................................... 46 3.10 Radiated Emissions, 1 - 26 GHz .............................................................................................. 48 4 Measurement Uncertainty ..................................................................................................... 59 5 LIST OF TEST EQUIPMENT................................................................................................... 60 6 BLOCK DIAGRAM .................................................................................................................. 61 6.1 Power Line Conducted Emission ............................................................................................. 61 6.2 Test Site Radiated Emission .................................................................................................... 61 TEST REPORT FCC Part 15.247 Report no.: 397015-01-R01 FCC ID: QF9-ZEKLER412 IC: 5808A-ZEKLER412 Nemko Norway, Instituttveien 6, Kjeller, Norway Page 3 (61) 1 INFORMATION 1.1 Test Item Name Zekler Model/version 412RDB, 412RDBH, 412DB, 412DBH FCC ID QF9-ZEKLER412 ISED ID 5808A-ZEKLER412 Serial number Conducted Sample: 3970150002 Radiated Sample: 3970150003 Hardware identity and/or version 49002-801-K, 48001-801-K Software identity and/or version 1.01 Frequency Range 2402 – 2480 MHz Number of Channels 79 Operating Modes Bluetooth FHSS Type of Modulation GFSK, π/4-DQPSK, 8-DPSK Rated Output Power 0.83 mW Type of Power Supply Primary or Secondary Batteries (2x AA Alkaline or NiMH cells) Antenn…
