CellPhone ComLink™ Instructions (Draft) ComLink Enterprises, L.L.C. 10001 Wayzata Boulevard, Suite 210 Minnetonka, MN 55305 952-545-2627/Fax: 952-545-1715 Cellphone ComLink FCC ID: QFDCL-001 This device complies with Part 15 of the FCC rules. Operation is subject to the following two conditions: 1) This device may not cause harmful interference, and, 2) This device must accept any interference received including interference that may cause undesired operation. CAUTION: Changes or modifications not expressly approved by ComLink Enterprises LTD could void the user's authority to operate the equipment. The CellPhone ComLink™ from ComLink Enterprises, L.L.C. is an advanced communications product that lets you enjoy convenient and safe Hands-Free and Wireless use of your cellphone. There is no need to hold the cellphone to your ear and you can keep both hands on the wheel. ComLink EarPiece FCC ID: QFDCL-001 EarPiece Batteries The ComLink EarPiece requires two "button" cells: Type 76 (Silver Oxide) or Type 357 (Silver Oxide) may be used. Insert each battery into the Battery Tray as shown in Figure 2. Insert the Battery Drawer into the ComLink EarPiece. Fig. 2 ComLink Battery Tray Earhook Snap the Earhook Loop onto the Post of the ComLink EarPiece. Reverse the Earhook for the opposite ear. Right EarLeft Ear ComLink Transmitter Transmitter Batteries The ComLink Transmitter requires two "button" cells: Type 76 (Silver Oxide) or Type 357 (Silver Oxide) may be used. Insert each battery into the Battery Tray as shown in the figure 2. Insert the Battery Drawer into the ComLink Transmitter. Connector Cable Plug the Transmitter Connector Cable into the "Audio Port" or "Headset Jack" of your CellPhone. Position the Transmitter on the back of your cellphone to determine the best location for the assembled Transmitter and Cable. Double-Stick Tape Placement Once you have determined the best Transmitter and Connector Cable location for your particular CellPhone, secure the Transmitter to the Back of the Cellphone with the supplied Double Stick Tape. Operation and Battery Life The ComLink Transmitter will turn on automatically when you make a call on your Cellphone. A few seconds after your Cellphone call ends, the ComLink Transmitter will enter "Standby Mode" in order to conserve battery life. The ComLink EarPiece is activated by pressing the oval pushbutton on its case. A few seconds after your Cellphone call ends, the ComLink EarPiece will enter "Standby Mode" in order to conserve battery life. Battery Life ComLink battery consumption is very low. Type 357 batteries will provide approximately 30 to 45 days of service if you use your cell phone between 30 to 60 minutes a day. Volume Control Use the Cellphone Volume Control to adjust the EarPiece sound level; for best sound quality, start with a medium volume setting. PROBLEM SOLVING If you hear no sound from your ComLink 1) Are the correct batteries being used?: Silver-Oxide types 76 or 357 for the Comlink EarPiece and Transmitter. 2) Are the batteries correctly inserted into the Battery Trays? -- See Figure 2. 3) Are the Battery Trays completely inserted into the Transmitter and EarPiece? 4) Is the connector cable plug fully inserted into the Cellphone Audio Port? 5) Is the Cellphone turned on and a call in progress? 6) Is the Cellphone Volume Control set high enough?

FCC ID: QFDCL-001Page 1 of 6 TOP OF UNIT FCC ID: QFDCL-001Page 2 of 6 BOTTOM OF UNIT FCC ID: QFDCL-001Page 3 of 6 END 1 OF UNIT FCC ID: QFDCL-001Page 4 of 6 SIDE 1 OF UNIT FCC ID: QFDCL-001Page 5 of 6 END 2 OF UNIT FCC ID: QFDCL-001Page 6 of 6 SIDE 2 OF UNIT

FCC ID Label: Due to the small size of the EUT, the compliance statement is placed in the user manual. The FCC ID will be placed on the EUT as shown in the photo on the following page. FCC ID: QFDCL-001 LABEL PLACEMENT FCC ID: QFDCL-001 Label Placement

FCC ID: QFDCL-001Page 1 of 5 DISASSEMBLY PHOTO 1 FCC ID: QFDCL-001Page 2 of 5 DISASSEMBLY PHOTO 2 FCC ID: QFDCL-001Page 3 of 5 TRANSMITTER BOARD – TOP FCC ID: QFDCL-001Page 4 of 5 AUDIO BOARD – TOP FCC ID: QFDCL-001Page 5 of 5 TRANSMITTER & AUDIO BOARDS – BOTTOMS The Transmitter Board is a single-sided board. The bottom side is the ground plane of the board. All traces are on the top side.

PRODUCT SERVICE TEST RESULT SUMMARY FCC PART 15 SUBPART C Section 15.235 MANUFACTURER'S NAMEComLink Enterprises, L.L.C. NAME OF EQUIPMENTCellphone ComLink – 49.830 MHz Analog Low Power F.M. Transmitter/Receiver MODEL NUMBER100 MANUFACTURER'S ADDRESS10001 Wayzata Boulevard, Suite 210 Minnetonka MN 55305 TEST REPORT NUMBERNC203061 TEST DATE06 June 2002 According to testing performed at TÜV Product Service Inc, the above-mentioned unit is in compliance with the electromagnetic compatibility requirements defined in FCC Part 15. It is the manufacturer's responsibility to assure that additional production units of this model are manufactured with identical electrical and mechanical characteristics. Any modifications necessary for compliance made during testing on the above mentioned date(s) must be implemented in all production units for compliance to be maintained. TÜV Product Service Inc, as an independent testing laboratory, declares that the equipment tested as specified above conforms to the requirements of FCC Part 15. Date:12 June 2002 Location:Taylors Falls MNJ. C. SausenJ. T. Schneider USATest EngineerChief Engineer Not Transferable FCC ID: QFDCL-001 File No. NC203061, Page 1 of 9 TÜV PRODUCT SERVICE INC19035 Wild Mountain RoadTaylors Falls MN 55084-1758Tel: 651 638 0297Fax: 651 638 0298Rev.No 1.0 PRODUCT SERVICE EMC EMISSION - T E S T R E P O R T Test Report File No.: NC203061 Date of issue: 12 June 2002 Model / Serial No.: 100 / 00001 Product Type: Cellphone ComLink – 49.830 MHz Analog Low Power F.M. Transmitter/Receiver Applicant: ComLink Enterprises, L.L.C. Manufacturer: ComLink Enterprises, L.L.C. License holder: ComLink Enterprises, L.L.C. Address: 10001 Wayzata Boulevard, Suite 210 : Minnetonka MN 55305 Test Result: nn Positiveoo Negative Test Project Number: Reference(s) NC203061 Total pages including Appendices 25 TÜV Product Service Inc is a subcontractor to TÜV Product Service, GmbH according to the principles outlined in ISO/IEC Guide 25 and EN 45001. TÜV Product Service Inc reports apply only to the specific samples tested under stated test conditions. It is the manufacturer's responsibility to assure that additional production units of this model are manufactured with identical electrical and mechanical components. TÜV Product Service Inc shall have no liability for any deductions, inferences or generalizations drawn by the client or others from TÜV Product Service Inc issued reports. This report is the confidential property of the client. As a mutual protection to our clients, the public and ourselves, extracts from the test report shall not be reproduced except in full without our written approval. This report shall not be used by the client to claim product endorsement by NVLAP or any agency of the US government. TÜV Product Service Inc and its professional staff hold government and professional organization certifications and are members of AAMI, ACIL, AEA, ANSI, IEEE, NVLAP, and VCCI File No. NC203061, Page 2 of 9 TÜV PRODUCT SERVICE INC19035 Wild Mountain RoadTaylors Falls MN 55084-1758Tel: 651 638 0297Fax: 651 638 0298Rev.No 1.0 PRODUCT SERVICE D I R E C T O R Y - EMISSIONS Page(s) A)Documentation Test report1 - 10 Directory2 Test Regulations3 Deviation from standard / Summary8 Test-setups (Photos) & Test Site Drawing9 B)Test data Conducted emissions10/150 kHz - 30 MHz4 Radiated emissions10 kHz - 30 MHz5 Radiated emissions30 MHz - 1000 MHz6 C)Appendix A Test Data Sheets and Test Setup Drawing(s) A1 – A5 D)Appendix B Constructional Data Form B1 – B8 E)Appendix C Measurement ProtocolC1 – C3 File No. NC203061, Page 3 of 9 TÜV PRODUCT SERVICE INC19035 Wild Mountain RoadTaylors Falls MN 55084-1758Tel: 651 638 0297Fax: 651 638 0298Rev.No 1.0 PRODUCT SERVICE EMISSIONS TEST REGULATIONS : The emissions tests were performed according to following regulations: -------------------------------------------------------------------------------- o - EN 50081-1 / 1991 o - EN 55011 / 1991o - Group 1o - Group 2 o - Class Ao - Class B o - EN 55013 / 1990 o - EN 55014 / 1987o - Household appliances and similar o - Portable tools o - Semiconductor devices o - EN 55014 / A2:1990 o - EN 55014 / 1993o - Household appliances and similar o - Portable tools o - Semiconductor devices o - EN 55015 / 1987 o - EN 55015 / A1:1990 o - EN 55015 / 1993 o - EN 55022 / 1987o - Class Ao - Class B o - EN 55022 / 1994o - Class Ao - Class B o - BS o - VCCIo - Class Ao - Class B n - FCC Part 15 Subpart C – Section 15.235 o - FCC Part 15 Subpart C Section 15.209 - Radiated o - FCC Part 15 Subpart C Section 15.207 - Conducted o - CISPR 11 (1990) o - Group 1o - Group 2 o - Class Ao - Class B o - CISPR 22 (1993) o - Class Ao - Class B Environmental conditions in the lab: Actual Temperature: 22 °C Relative Humidity: 35 % Atmospheric pressure: 99.2 kPa Power supply system: Battery Sign Explanations: o - not applicable n - applicable File No. NC203061, Page 4 of 9 TÜV PRODUCT SERVICE INC19035 Wild Mountain RoadTaylors Falls MN 55084-1758Tel: 651 638 0297Fax: 651 638 0298Rev.No 1.0 PRODUCT SERVICE Emissions Test Conditions: CONDUCTED EMISSIONS (15.207) The CONDUCTED EMISSIONS (INTERFERENCE VOLTAGE) measurements were performed at the following test location: n - Test not applicable o - Wild River Lab Large Test Site (Open Area Test Site) o - Wild River Lab Small Test Site (Open Area Test Site) o - Oakwood Lab (Open Area Test Site) o - Wild River Lab Screen Room o - New Brighton Lab Shielded Room Test Results: Conducted emissions 450 kHz - 30 MHz The requirements areoo - METoo - NOT MET Minimum margin of compliancedBatMHz Maximum margin of non-compliancedBatMHz Remarks: File No. NC203061, Page 5 of 9 TÜV PRODUCT SERVICE INC19035 Wild Mountain RoadTaylors Falls MN 55084-1758Tel: 651 638 0297Fax: 651 638 0298Rev.No 1.0 PRODUCT SERVICE Emissions Test Conditions: RADIATED EMISSIONS (15.209 - 10 kHz to 30 MHz) The RADIATED EMISSIONS (MAGNETIC FIELD) measurements were performed at the following test location: n - Test not …

Text truncated - open the document above for the full version.

TEST SETUP FOR EMISSIONS TESTING WILD RIVER LAB Small Test Site (STS) EUT 180 27090 0 60 Hz 50 Hz Turntable is 1.2 meters in diameter Enlarged View of Shelter (4 meters square) STS Building Shelter 3 meter antenna 10 meter antenna 30 meter antenna Turntable Control Cable Ground Screen (34 meters long x 12 meters wide) 8 meters FCC ID: QFDCL-001 Radiated Emissions Test Setup Photos
