ETL Inc. 584 Sangwhal-ri, Kanam-myon, Yoju-kun, Kyounggi-do, 469-885, Korea 5 of 16 FCC ID : QGNTGUD-03A Report No:E03.0204.FCC.060N Date of Test : February 4, 2003 TAB Global Co., Ltd. USB DRIVE Model : TGUD-03A 2.1 Equipment Description The Equipment Under Test (EUT) is the USB DRIVE from TAB Global Co., Ltd. Please refer to Users manual 2.2 General Specification l Chassis Type : Plastic Cover l List of Each OSC. Or X-Tal. Freq. (>=1MHz) : X-TAL – 12.0MHz l Chipset Brand & Part No. : 0238MF59H01-11 – GL814, K9K1G08UOM YCBO – SAMSUNG l Number of Layers : Main board – 6Layers l USB DRIVE Specifications : USB DRIVE 16MB – 2000MB l Interface : USB compatible with USB 1.1 spec l Capacity MB : 16 / 32 / 64 / 128 / 256 / 512 / 1024 / 2000 l Data Retention : Up to 10 years l Data Access Rate : 4MB / sec (read), 800KB / sec (write) l Power supply : USB BUS-Powered (4.5V ~ 5.5V) l OS Support : Windows 98 / SE / Me / 2000 / XP Mac OS 9, 10X, Linux 2.4
