QH5TM200LICENSED BROADCAST STATION MODULATOR

TM200BroadcastModulator  OPERATING MANUAL TM-200 Issue 1.02 November 2005 Page 1 of 64 TABLE OF CONTENTS 1.0 SAFEGUARDS................................................................................................................................... 2 General Safeguards........................................................................................................................... 2 Safety and First Aid............................................................................................................................ 3 2.0 WARRANTY...................................................................................................................................... 4 3.0 DESCRIPTION AND SPECIFICATIONS................................................................................................... 5 General Description........................................................................................................................... 5 Standard Features.............................................................................................................................. 5 Available Options............................................................................................................................... 6 Block Diagram.................................................................................................................................... 7 Specifications..................................................................................................................................... 9 Signal Conditioning Module............................................................................................................ 11 4.0 INSTALLATION................................................................................................................................ 12 Building Recommendations............................................................................................................ 12 Heating and Cooling Requirements............................................................................................... 12 Electrical Service Recommendations............................................................................................ 13 Antenna and Tower Recommendations......................................................................................... 14 Shelter Security................................................................................................................................ 15 Unpacking and Inspection.............................................................................................................. 16 Location and Function of Controls and Connectors.................................................................... 17 5.0 OPERATING PROCEDURE................................................................................................................ 19 Preliminary Hook-up........................................................................................................................ 19 Setup of Output Level and Channel Selection.............................................................................. 20 Setup of Video Input Connection and Adjustment....................................................................... 21 Setup of Baseband Audio Input Connection and Adjustment.................................................... 22 Setup of 4.5 MHz Sub-Carrier Audio Input Connection and Adjustment................................... 23 Setup of IF Pre-Correction on Signal Conditioning PCB............................................................. 24 Setup of Sync Level on Signal Conditioning PCB........................................................................ 25 Automatic Shut Down...................................................................................................................... 26 Transmitter Hookup......................................................................................................................... 27 6.0 PROBLEM TROUBLESHOOTING GUIDE............................................................................................. 28 7.0 BILL OF MATERIALS, SCHEMATICS, AND PCB OVERLAYS................................................................ 29 Agile Logic Board Bill of Materials................................................................................................. 29 Agile Output Amplifier Bill of Materials......................................................................................... 34 Audio Video Modulator Board Bill of Materials............................................................................. 37 Signal Conditioning Bill of Materials.............................................................................................. 46 Digital Up converter Bill of Materials............................................................................................. 50 750 MHz Down Converter Bill of Materials.................................................................................... 56 Power Supply Bill of Materials........................................................................................................ 61 TM-200 Issue 1.02 November 2005 Page 2 of 64 1.0 SAFEGUARDS  General Safeguards  This section is written as a general guide for those having previous knowledge and experience with these kinds of equipment.  It is not intended to contain a complete statementofallsafetyprecautions,whichshouldbeobservedbypersonnelusingthisor otherelectronicequipment.  To reduce the risk of fire or electric shock, do not expose this equipment to rain or moisture.Donotopenthecabinet.Referservicingtoqualifiedpersonnel.  1. READINSTRUCTIONSAllsafety,installation,andoperatinginstructionsshouldbe readbeforetheequipmentisoperated.  2. RETAININSTRU…

Text truncated - open the document above for the full version.

Technalogix – the company that can! January 30, 2007 Attestation Statement: TM-200 Tests were conducted on production models of the equipment on location at Technalogix: #4, 8021 Edgar Industrial Place Red Deer, Alberta Canada T4P 3R3 403.347.5400 ph 403.347.7444 fx All tests were carried out on representative channels in the VHF and UHF bands in accordance with FCC Part 73 and Part 74 and Industry Canada BESP-100 and BETS-4. The results in the submitted documentation show that the equipment meets or exceeds the required specifications. Should you have any questions, please do not hesitate to contact Technalogix: Bob Gullon President and CEO [email protected] Aaron Sivacoe, P.ENG Technical Director [email protected] #4 – 8021 Edgar Ind. Place, Red Deer, AB T4P 3R3 Ph: (403) 347-5400 [email protected] Fax: (403) 347-7444 www.technalogix.ca

Technalogix – the company that can! February 12, 2007 Cover Letter: TM-200 This report is in support of an application by Technalogix Ltd. for certification of transmitting equipment used for VHF and UHF television systems (54-806 MHz). Specifically, Technalogix is requesting certification of the Technalogix TM-200 frequency agile television modulator. The TM-200 accepts standard video and audio and supplies a +15 dBm peak video signal in addition to 10% aural power on any of the VHF (2 through 13) and UHF (14 through 69) channels. All tests were carried out on representative channels in the VHF and UHF bands in accordance with FCC Part 73 and Part 74. The results in the attached documentation show that the equipment meets or exceeds the required specifications. The emission designators based on FCC Part 74 transmitters are 5M75C3F (for visual) and 250KF3E (for aural). Should you have any questions, please do not hesitate to contact Technalogix: Bob Gullon President and CEO [email protected] Aaron Sivacoe, P.ENG Technical Director [email protected] #4 – 8021 Edgar Ind. Place, Red Deer, AB T4P 3R3 Ph: (403) 347-5400 [email protected] Fax: (403) 347-7444 www.technalogix.ca

Technalogix – the company that can! EXTERNAL CONSTRUCTION Front View: #4 – 8021 Edgar Ind. Place, Red Deer, AB T4P 3R3 Ph: (403) 347-5400 [email protected] Fax: (403) 347-7444 www.technalogix.ca Technalogix – the company that can! Back View:

Technalogix – the company that can! ID Label: #4 – 8021 Edgar Ind. Place, Red Deer, AB T4P 3R3 Ph: (403) 347-5400 [email protected] Fax: (403) 347-7444 www.technalogix.ca TECHNALOGIX LTD. Made in Red Deer, AB Canada FCC ID:QH5TM200 I.C. :3803A-TM200 Model No:TM-200 Serial No: Actual Size: 2" x 3 1/4" Technalogix – the company that can! ID Label Location: TECHNALOGIX LTD. Made in Red Deer, AB Canada FCC ID:QH5TM200 I.C. :3803A-TM200 Model No:TM-200 Serial No:

Technalogix – the company that can! TM-200 CONSTRUCTION PHOTOGRAPHS Internal View: #4 – 8021 Edgar Ind. Place, Red Deer, AB T4P 3R3 Ph: (403) 347-5400 [email protected] Fax: (403) 347-7444 www.technalogix.ca Technalogix – the company that can! Internal view of Upconverter and Downconverter PCB: Solder Side of Main Audio Video Modulator PCB: Technalogix – the company that can! Top Layer of IF Precorrection PCB: Bottom Layer of IF Precorrection PCB:

Technalogix – the company that can! January 30, 2007 To Whom it May Concern, This letter certifies that there was no measurable cabinet radiation from the TM-200, even at 0.5 meters. Measurements were conducted as per Industry Canada BETS-4, section 6.6 and FCC Part 74.736. All measurements were well below 60dBc including those of harmonics and all other spurious emissions. Aaron Sivacoe, P.ENG Technical Director [email protected] Bob Gullon President and CEO [email protected] Best regards, Aaron Sivacoe #4 – 8021 Edgar Ind. Place, Red Deer, AB T4P 3R3 Ph: (403) 347-5400 [email protected] Fax: (403) 347-7444 www.technalogix.ca

TM-200 Issue 1.02 November 2005 Page 26 of 61 7.0 BILL OF MATERIALS, SCHEMATICS, AND PCB OVERLAYS Agile Logic Board Bill of Materials Last Revision: 09.12.00 Component Reference Quantity Identification Modifier Package C1 1 22pF CAP250D C10 1 0.47uF CAP100RP C11 1 10 uF CAP100RP C12 1 22 uF CAP100RP C13 1 22 uF CAP100RP C14 1 22 uF CAP100RP C15 1 22 uF CAP100RP C16 1 0.01uF CAP250D C17 1 0.01uF CAP250D C18 1 47 uF CAP100RP C19 1 47 uF CAP100RP C2 1 22pF CAP250D C20 1 CAP100RP C21 1 0.01uF CAP250D C22 1 0.01uF CAP250D C23 1 0.01uF CAP250D C24 1 0.01uF CAP250D C3 1 22 uF CAP100RP C4 1 10 uF CAP100RP C5 1 0.47uF CAP100RP C6 1 0.47uF CAP100RP C7 1 0.01uF CAP250D C8 1 0.01uF CAP250D C9 1 470 uF CAP197R D1 1 RED T1 LED T1-W/HLD D2 1 T1 W/HLD LED D3 1 RED T1 LED T1-W/HLD DS1 1 8 POS DPS8W JP1 1 4 POS HEADER JP-DUAL4 JP2 1 8 POS HEADER JP-DUAL8 JP3 1 JP-DUAL4 JP4 1 3PIN JP3IL JP5 1 3PIN JP3IL JP6 1 3PIN JP3IL JP7 1 3 POS JP3IL JP8 1 3 IL JP3IL TM-200 Issue 1.02 November 2005 Page 27 of 61 L1 1 6 T COIL 60 L2 1 6 T COIL 60 L3 1 6 T COIL 60 L4 1 6 T COIL 60 L5 1 6 T COIL 60 P1 1 4 PIN SMB P10 1 10 POS DIPIL10 P11 1 4 PIN SMB P12 1 8 POS CONNIL8 P2 1 RT ANG F FCONN P3 1 12 POS CONN IL12 P4 1 12 POS CONN IL12 P5 1 ON DISPLAY BDS CONN IL19 P6 1 12 POS CONN IL12 P7 1 12 POS CONN IL12 P8 1 4 PIN SMB P9 1 10 PIN CONN10IL Q1 1 2222 TRANS2222 Q2 1 2907 TO18C QP1 1 4-2222A DIP14C R1 1 10 Mohm RES1-8 R10 1 1 kOhm RES1-8 R11 1 5 kOhm POT1 R12 1 10 Kohm RES1-8 R13 1 10 Kohm RES1-8 R14 1 1 kOhm RES1-8 R15 1 6.8 kOhm RES1-8 R16 1 1 kOhm RES1-8 R17 1 500 Ohm POT1 R18 1 10 Kohm RES1-8 R19 1 5.6 kOhm RES1-8 R2 1 4.7 Ohm RES1-8 R20 1 10 Kohm RES1-8 R21 1 91 Ohm RES1-8 R22 1 10 Ohm RES1-8 R23 1 5 kOhm POT1 R3 1 5 kOhm POT1 R4 1 10 Kohm RES1-8 R5 1 1 kOhm RES1-8 R6 1 68 kOhm RES1-8 R7 1 68 kOhm RES1-8 R8 1 68 kOhm RES1-8 R9 1 4.7 Ohm RES1-8 RP1 1 10 Kohm DIPIL11 RP2 1 10 Kohm DIPIL11 RP3 1 10 Kohm DIPIL11 RP4 1 150 Ohm DIP IL8 TM-200 Issue 1.02 November 2005 Page 28 of 61 RP5 1 150 Ohm DIP IL8 SW1 1 PADDLE SW1 SW2 1 PADDLE SW1 SW3 1 ROCKER SW1 SW4 1 ROCKER SW1 U1 1 MC74HC165 DIP16C U2 1 IC34064 REGTO92 U3 1 68705C8 DIP40C U4 1 74H04 DIP14C U5 1 74H04 DIP14C U6 1 MC14499 DIP18C U7 1 DS232 DIP16C U8 1 X2402 DIP8C Y1 1 4MHz XTAL TM-200 Issue 1.02 November 2005 Page 31 of 61 Agile Output Amplifier Bill of Materials Last Revision: 09.12.00 Component Reference Quantity Identification Modifier Package C1 1 0.1uF 1206 C2 1 0.1uF 1206 C3 1 2.7 pF 1206 C4 1 3-10pF VCAP CGKG27 C5 1 3-10pF VCAP CGKG27 C6 1 3-10pF VCAP CGKG27 C7 1 2.7 pF 1206 E1 1 E-COAX E2 1 12 V EPAD E3 1 E-COAX E5 1 GND EPAD I1 1 1206 L1 1 IND400 L2 1 10 nH 1210 L3 1 12 nH 1210 L4 1 12 nH 1210 L5 1 10 nH 1210 P1 1 FCONN-S U1 1 AMP6342 TM-200 Issue 1.02 November 2005 Page 34 of 61 Audio Video Modulator Board Bill of Materials Last Revision: 09.12.00 Component Reference Quantity Identification Modifier Package C1 1 0.1uF SMD1206 C10 1 0.1uF SMD1206 C100 1 4.7uF CAP100RP C101 1 100pF SMD1206 C102 1 47uF CAP100RP C103 1 0.1uF SMD1206 C104 1 470pF SMD1206 C105 1 0.1uF SMD1206 C106 1 470uF CAP200RP C107 1 0.1uF SMD1206 C108 1 470uF CAP200RP C109 1 0.0027uF SMD1206 C11 1 0.1uF SMD1206 C110 1 0.1uF SMD1206 C111 1 NI SMD1206 C112 1 470uF CAP200RP C113 1 0.1uF SMD1206 C114 1 0.1uF SMD1206 C115 1 0.1uF SMD1206 C116 1 0.1uF SMD1206 C117 1 0.01uF SMD1206 C118 1 18pF SMD1206 C119 1 NI SMD1206 C12 1 0.01uF SMD1206 C120 1 0.1uF SMD1206 C121 1 470uF CAP200RP C122 1 0.01uF SMD1206 C123 1 470uF CAP200RP C124 1 10pF SMD1206 C125 1 27pF SMD1206 C126 1 82pF SMD1206 C127 1 0.001uF SMD1206 C128 1 0.01uF SMD1206 C129 1 0.01uF SMD1206 C13 1 0.1uF SMD1206 C130 1 0.1uF SMD1206 C131 1 NI SMD1206 C132 1 0.1uF SMD1206 C133 1 0.01uF SMD1206 C134 1 0.01uF SMD1206 TM-200 Issue 1.02 November 2005 Page 35 of 61 C135 1 0.1uF SMD1206 C136 1 0.1uF SMD1206 C137 1 0.01uF SMD1206 C138 1 0.1uF SMD1206 C139 1 0.01uF SMD1206 C14 1 0.001uF SMD1206 C140 1 0.01uF SMD1206 C141 1 0.01uF SMD1206 C142 1 0.1uF SMD1206 C143 1 12pF SMD1206 C144 1 12pF SMD1206 C145 1 3-10pF CGKG27 C146 1 12pF SMD1206 C147 1 12pF SMD1206 C148 1 0.1uF SMD1206 C149 1 0.01uF SMD1206 C15 1 0.01uF SMD1206 C150 1 0.1uF SMD1206 C151 1 27pF SMD1206 C152 1 56pF SMD1206 C153 1 27pF SMD1206 C154 1 0.01uF SMD1206 C155 1 0.01uF SMD1206 C156 1 0.01uF SMD1206 C16 1 0.1uF SMD1206 C17 1 22pF SMD1206 C18 1 56pF SMD1206 C19 1 10pF SMD1206 C2 1 0.1uF SMD1206 C20 1 0.001uF SMD1206 C21 1 0.47uF SMD1206 C22 1 22pF SMD1206 C23 1 22pF SMD1206 C24 1 4.5-20pF CGKG27 C25 1 0.01uF SMD1206 C26 1 0.001uF SMD1206 C27 1 22pF SMD1206 C28 1 4.7uF CAP100RP C29 1 100pF SMD1206 C3 1 4.7uF CAP100RP C30 1 0.01uF SMD1206 C31 1 0.1uF SMD1206 C32 1 0.001uF SMD1206 C33 1 0.01uF SMD1206 C34 1 68pF SMD1206 C35 1 100pF SMD1206 C36 1 100pF SMD1206 C37 1 68pF SMD1206 TM-200 Issue 1.02 November 2005 Page 36 of 61 C38 1 470uF CAP200RP C39 1 0.01uF SMD1206 C4 1 0.1uF SMD1206 C40 1 0.01uF SMD1206 C41 1 0.1uF SMD1206 C42 1 0.01uF SMD1206 C43 1 0.01uF SMD1206 C44 1 0.1uF SMD1206 C45 1 470uF 25V CAP200RP C46 1 1000uF CAP300RP C5 1 4.7uF CAP100RP C6 1 0.1uF SMD1206 C7 1 0.001uF SMD1206 C8 1 470uF CAP200RP C9 1 47pF SMD1206 D1 1 5236 SOT23 D10 1 3800 SOT23 D100 1 2800 SOT23 D101 1 2800 SOT23 D11 1 3800 SOT23 D2 1 2800 SOT23 D3 1 2800 SOT23 D6 1 MMBV105GL SOT23 D7 1 10 V SOT23 D8 1 4.7V SOT23 D9 1 3800 SOT23 F1 1 SIP5L F100 1 FILTER2219 F101 1 SF28S J1 1 NI SMD1206 JP1 1 NI SMD1206 JP2 1 0 SMD1206 JP3 1 NI SMD1206 JP4 1 NI SMD1206 JP5 1 0 SMD1206 L1 1 10.5 T,26GA COIL L100 1 12.5T 22GA COIL L101 1 0.47uH SMD1812 L102 1 0.47uH SMD1812 L103 1 12.5T 22GA COIL-S L104 1 12.5T 22GA COIL-S L105 1 0.47uH SMD1812 L106 1 0.47uH SMD1812 L107 1 0.47uH SMD1812 L15 1 0.47uH IND400 L2 1 0.33uH SMD1812 L3 1 0.33uH SMD1812 L4 1 0.33uH SMD1812 TM-200 Issue 1.02 November 2005 Page 37 of 61 L5 1 0.47uH SMD1812 MX100 1 MIXER P1 1 FCONN-S P100 1 FCONN-S P101 1 RTARCA P102 1 RTARCA P103 1 FCONN-S P2 1 CONN10IL P7 1 CONHDR6 P8 1 CONHDR6 Q1 1 2369 SOT23 Q100 1 2222 SOT23 Q101 1 2907 SOT23 Q102 1 2222 SOT23 Q103 1 2…

Text truncated - open the document above for the full version.

TM-200 Issue 1.02 November 2005 Page 26 of 61 7.0 BILL OF MATERIALS, SCHEMATICS, AND PCB OVERLAYS Agile Logic Board Bill of Materials Last Revision: 09.12.00 Component Reference Quantity Identification Modifier Package C1 1 22pF CAP250D C10 1 0.47uF CAP100RP C11 1 10 uF CAP100RP C12 1 22 uF CAP100RP C13 1 22 uF CAP100RP C14 1 22 uF CAP100RP C15 1 22 uF CAP100RP C16 1 0.01uF CAP250D C17 1 0.01uF CAP250D C18 1 47 uF CAP100RP C19 1 47 uF CAP100RP C2 1 22pF CAP250D C20 1 CAP100RP C21 1 0.01uF CAP250D C22 1 0.01uF CAP250D C23 1 0.01uF CAP250D C24 1 0.01uF CAP250D C3 1 22 uF CAP100RP C4 1 10 uF CAP100RP C5 1 0.47uF CAP100RP C6 1 0.47uF CAP100RP C7 1 0.01uF CAP250D C8 1 0.01uF CAP250D C9 1 470 uF CAP197R D1 1 RED T1 LED T1-W/HLD D2 1 T1 W/HLD LED D3 1 RED T1 LED T1-W/HLD DS1 1 8 POS DPS8W JP1 1 4 POS HEADER JP-DUAL4 JP2 1 8 POS HEADER JP-DUAL8 JP3 1 JP-DUAL4 JP4 1 3PIN JP3IL JP5 1 3PIN JP3IL JP6 1 3PIN JP3IL JP7 1 3 POS JP3IL JP8 1 3 IL JP3IL TM-200 Issue 1.02 November 2005 Page 27 of 61 L1 1 6 T COIL 60 L2 1 6 T COIL 60 L3 1 6 T COIL 60 L4 1 6 T COIL 60 L5 1 6 T COIL 60 P1 1 4 PIN SMB P10 1 10 POS DIPIL10 P11 1 4 PIN SMB P12 1 8 POS CONNIL8 P2 1 RT ANG F FCONN P3 1 12 POS CONN IL12 P4 1 12 POS CONN IL12 P5 1 ON DISPLAY BDS CONN IL19 P6 1 12 POS CONN IL12 P7 1 12 POS CONN IL12 P8 1 4 PIN SMB P9 1 10 PIN CONN10IL Q1 1 2222 TRANS2222 Q2 1 2907 TO18C QP1 1 4-2222A DIP14C R1 1 10 Mohm RES1-8 R10 1 1 kOhm RES1-8 R11 1 5 kOhm POT1 R12 1 10 Kohm RES1-8 R13 1 10 Kohm RES1-8 R14 1 1 kOhm RES1-8 R15 1 6.8 kOhm RES1-8 R16 1 1 kOhm RES1-8 R17 1 500 Ohm POT1 R18 1 10 Kohm RES1-8 R19 1 5.6 kOhm RES1-8 R2 1 4.7 Ohm RES1-8 R20 1 10 Kohm RES1-8 R21 1 91 Ohm RES1-8 R22 1 10 Ohm RES1-8 R23 1 5 kOhm POT1 R3 1 5 kOhm POT1 R4 1 10 Kohm RES1-8 R5 1 1 kOhm RES1-8 R6 1 68 kOhm RES1-8 R7 1 68 kOhm RES1-8 R8 1 68 kOhm RES1-8 R9 1 4.7 Ohm RES1-8 RP1 1 10 Kohm DIPIL11 RP2 1 10 Kohm DIPIL11 RP3 1 10 Kohm DIPIL11 RP4 1 150 Ohm DIP IL8 TM-200 Issue 1.02 November 2005 Page 28 of 61 RP5 1 150 Ohm DIP IL8 SW1 1 PADDLE SW1 SW2 1 PADDLE SW1 SW3 1 ROCKER SW1 SW4 1 ROCKER SW1 U1 1 MC74HC165 DIP16C U2 1 IC34064 REGTO92 U3 1 68705C8 DIP40C U4 1 74H04 DIP14C U5 1 74H04 DIP14C U6 1 MC14499 DIP18C U7 1 DS232 DIP16C U8 1 X2402 DIP8C Y1 1 4MHz XTAL TM-200 Issue 1.02 November 2005 Page 31 of 61 Agile Output Amplifier Bill of Materials Last Revision: 09.12.00 Component Reference Quantity Identification Modifier Package C1 1 0.1uF 1206 C2 1 0.1uF 1206 C3 1 2.7 pF 1206 C4 1 3-10pF VCAP CGKG27 C5 1 3-10pF VCAP CGKG27 C6 1 3-10pF VCAP CGKG27 C7 1 2.7 pF 1206 E1 1 E-COAX E2 1 12 V EPAD E3 1 E-COAX E5 1 GND EPAD I1 1 1206 L1 1 IND400 L2 1 10 nH 1210 L3 1 12 nH 1210 L4 1 12 nH 1210 L5 1 10 nH 1210 P1 1 FCONN-S U1 1 AMP6342 TM-200 Issue 1.02 November 2005 Page 34 of 61 Audio Video Modulator Board Bill of Materials Last Revision: 09.12.00 Component Reference Quantity Identification Modifier Package C1 1 0.1uF SMD1206 C10 1 0.1uF SMD1206 C100 1 4.7uF CAP100RP C101 1 100pF SMD1206 C102 1 47uF CAP100RP C103 1 0.1uF SMD1206 C104 1 470pF SMD1206 C105 1 0.1uF SMD1206 C106 1 470uF CAP200RP C107 1 0.1uF SMD1206 C108 1 470uF CAP200RP C109 1 0.0027uF SMD1206 C11 1 0.1uF SMD1206 C110 1 0.1uF SMD1206 C111 1 NI SMD1206 C112 1 470uF CAP200RP C113 1 0.1uF SMD1206 C114 1 0.1uF SMD1206 C115 1 0.1uF SMD1206 C116 1 0.1uF SMD1206 C117 1 0.01uF SMD1206 C118 1 18pF SMD1206 C119 1 NI SMD1206 C12 1 0.01uF SMD1206 C120 1 0.1uF SMD1206 C121 1 470uF CAP200RP C122 1 0.01uF SMD1206 C123 1 470uF CAP200RP C124 1 10pF SMD1206 C125 1 27pF SMD1206 C126 1 82pF SMD1206 C127 1 0.001uF SMD1206 C128 1 0.01uF SMD1206 C129 1 0.01uF SMD1206 C13 1 0.1uF SMD1206 C130 1 0.1uF SMD1206 C131 1 NI SMD1206 C132 1 0.1uF SMD1206 C133 1 0.01uF SMD1206 C134 1 0.01uF SMD1206 TM-200 Issue 1.02 November 2005 Page 35 of 61 C135 1 0.1uF SMD1206 C136 1 0.1uF SMD1206 C137 1 0.01uF SMD1206 C138 1 0.1uF SMD1206 C139 1 0.01uF SMD1206 C14 1 0.001uF SMD1206 C140 1 0.01uF SMD1206 C141 1 0.01uF SMD1206 C142 1 0.1uF SMD1206 C143 1 12pF SMD1206 C144 1 12pF SMD1206 C145 1 3-10pF CGKG27 C146 1 12pF SMD1206 C147 1 12pF SMD1206 C148 1 0.1uF SMD1206 C149 1 0.01uF SMD1206 C15 1 0.01uF SMD1206 C150 1 0.1uF SMD1206 C151 1 27pF SMD1206 C152 1 56pF SMD1206 C153 1 27pF SMD1206 C154 1 0.01uF SMD1206 C155 1 0.01uF SMD1206 C156 1 0.01uF SMD1206 C16 1 0.1uF SMD1206 C17 1 22pF SMD1206 C18 1 56pF SMD1206 C19 1 10pF SMD1206 C2 1 0.1uF SMD1206 C20 1 0.001uF SMD1206 C21 1 0.47uF SMD1206 C22 1 22pF SMD1206 C23 1 22pF SMD1206 C24 1 4.5-20pF CGKG27 C25 1 0.01uF SMD1206 C26 1 0.001uF SMD1206 C27 1 22pF SMD1206 C28 1 4.7uF CAP100RP C29 1 100pF SMD1206 C3 1 4.7uF CAP100RP C30 1 0.01uF SMD1206 C31 1 0.1uF SMD1206 C32 1 0.001uF SMD1206 C33 1 0.01uF SMD1206 C34 1 68pF SMD1206 C35 1 100pF SMD1206 C36 1 100pF SMD1206 C37 1 68pF SMD1206 TM-200 Issue 1.02 November 2005 Page 36 of 61 C38 1 470uF CAP200RP C39 1 0.01uF SMD1206 C4 1 0.1uF SMD1206 C40 1 0.01uF SMD1206 C41 1 0.1uF SMD1206 C42 1 0.01uF SMD1206 C43 1 0.01uF SMD1206 C44 1 0.1uF SMD1206 C45 1 470uF 25V CAP200RP C46 1 1000uF CAP300RP C5 1 4.7uF CAP100RP C6 1 0.1uF SMD1206 C7 1 0.001uF SMD1206 C8 1 470uF CAP200RP C9 1 47pF SMD1206 D1 1 5236 SOT23 D10 1 3800 SOT23 D100 1 2800 SOT23 D101 1 2800 SOT23 D11 1 3800 SOT23 D2 1 2800 SOT23 D3 1 2800 SOT23 D6 1 MMBV105GL SOT23 D7 1 10 V SOT23 D8 1 4.7V SOT23 D9 1 3800 SOT23 F1 1 SIP5L F100 1 FILTER2219 F101 1 SF28S J1 1 NI SMD1206 JP1 1 NI SMD1206 JP2 1 0 SMD1206 JP3 1 NI SMD1206 JP4 1 NI SMD1206 JP5 1 0 SMD1206 L1 1 10.5 T,26GA COIL L100 1 12.5T 22GA COIL L101 1 0.47uH SMD1812 L102 1 0.47uH SMD1812 L103 1 12.5T 22GA COIL-S L104 1 12.5T 22GA COIL-S L105 1 0.47uH SMD1812 L106 1 0.47uH SMD1812 L107 1 0.47uH SMD1812 L15 1 0.47uH IND400 L2 1 0.33uH SMD1812 L3 1 0.33uH SMD1812 L4 1 0.33uH SMD1812 TM-200 Issue 1.02 November 2005 Page 37 of 61 L5 1 0.47uH SMD1812 MX100 1 MIXER P1 1 FCONN-S P100 1 FCONN-S P101 1 RTARCA P102 1 RTARCA P103 1 FCONN-S P2 1 CONN10IL P7 1 CONHDR6 P8 1 CONHDR6 Q1 1 2369 SOT23 Q100 1 2222 SOT23 Q101 1 2907 SOT23 Q102 1 2222 SOT23 Q103 1 2…

Text truncated - open the document above for the full version.

1 1 3 3 EEPROM MEMORY STORAGE MUTE SPARES/DEMOD (360 MOD)VIDEO MODULATION VIDEO OUT MODULATOR INPUT VIDEO IN 370/370T VIDEO GAIN (360.361.362 360 VIDEO MOD ADJ 361/2 ALR LEVEL 360 VIDEO MODULATION NOTES: ON M/N UNITS W411808 DISPLAY BD. ONLY 1. CUT THE ETCH CONNECTING PINS 6&9 ON TOP OF P5 ON TOP OF BOARD 2. CUT THE ETCH CONNECTING PINS 7&11 ON P5 ON BOTTOM OF BOARD 3. CONNECT PINS 1&6 OF P5 W/INSULATED WIRE ON BOTTOM OF BOARD 4. CONNECT PINS 2&7 OF P5 W/INSULATED WIRE ON BOTTOM OF BOARD -20dB RF MONITOR 90-F MONITOR IN 360 BAR GRAPH DISPLAY (370 MOD) T CHANNEL (370 MOD) VHF/UHF TO JP2 P5-4 TO P6.2 DEDOM INTERFACE +12V N/C 360 TEXT OVERLAY OPTION5K/370 500R/360 100K/361-2 (360/370) (361/2) TDO RDI RSTX RSRX LDO LDI LD +12V TEST NORM INPUT CH OUTPUT CH INPUT MODE INPUT LD +30V +12V (362.SW3 3 W/R17) +5V +5V (DEMOD) W/R23 CW/R23 RSTX RSRX 25 KHz 12.5KHz +12V TO RP RJ11 +5V MUTE -12V REF DATA LDO 12.5KHz OUT PLL EN CLOCK 25KHz +12V +5V -12V +24V +12V IN PLL EN DATA CLOCK LD OFF OUT LVL OUT LVL PROCESSOR INPUT TO UP CONV. TO OUTPUT CONV. W/R17 C20 PLLI EN PLLO EN PLL EN DATA IO CLK PWR SBSEL LED1 LED0 SPR41 SPR51 SPR61 VIN VRST DATA IO CLK +5V N/C OUT LVL OMIT FOR DEMOD FP OUTPUT LEVEL ADJ TO JP5.2 TO JP5.3 TO P4.2 RSRX TO P4.1 RSTX C5045.6 REAR PANEL RJ11/RS232 INPUT +25V P/S LED +30V +12V -12V FROM P/S VIDEO TEXT OVERLAY P1 P2 P3 P4P5 P6 P7 P8 JP3 P1 P2 P3 P4P5 P6 P7 P8 U8 1 2 3 4 5 6 7 89 10 11 12 13 14 15 16 U11 QP1 12 10 5 3 13 14 9 8 6 7 2 1 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 P5 1 2 3 4 5 6 7 89 10 11 12 13 14 15 16 JP2 RP5 RP4 1 2 3 4 5 6 7 8 910 11 12 13 14 15 16 17 18 U9 1 2 3 4 5 6 7 89 10 11 12 13 14 15 16 U7 NOT RESET NOT IRQ NOT VPR SW1UP SW1DWN SW0UP SW0DWN PA3 PA2 S/L SHREG DATAIO CLK DSPEN VRST PLLIEN PLLOEN PLLEN PWR GNDISTHR OFF AIR SPR6I SPR5I SPR4I LED0 LED1 SBSEL RDI TDO LD0 LDI LD PD 5 MUTE1 VIN TCAP OSC 2 OSC 1 Vdd U6 S1 S2 S3 5V 1 9 8 6 7 3 2 5 4 RP3 + C8 IN COM OUT U3 + C7 5V Y1 C4C3 1 2 3 4 5 6 9 10 RP2 RP1 5V 5V C2 L1 + C9 +5V Q1 Q2 +12V JP4 + C12 + C13 + C14 + C1 + C11 + C10 + C6 + C5 5V D4 LOCK LED P7 P4 P3 P6 U2F U2E U2D U2C U2B U2A U1F U1E U1D U1C U1B U1A P10 R3 +5V D3 D2 R171 P1 J1 L3 +5V + C181 +12V JPR P111 P9 R111 R14 10k 40% + C200 J2 CON + C191 + C161 +5V SW4 12V JP6 P100 P200 J101 P12 POWER ON LED C22C21 L4 +5V L5 C23C24 +12V U4 U5 +5V+5V P1 P2 P3 P4P5 P6 P7 P8 JP1 R11 R2 R18 R19 R20 R16 R9 R8 R7R6 R4 R121 R13 R10 R5 R21 R1 R15 R221 32 11 9 1 1 4 3 2 1 3 21 98 4 11 5 13 10 3 9 1 1 12 11 5 4 3 7 6 5 4 3 2 1 10 9 8 7 6 5 4 2 1 1 7 6 5 11 32 31 4 3 2 4 1 3 1 3 2 3 3 1 35 12 13 14 1 1 13 10 1 1 2 37 36 34 22 21 6 7 4 5 21 22 9 8 12 19 1 37 19 18 17 16 15 14 13 12 21 22 23 24 25 26 27 28 29 30 31 32 33 34 35 36 11 10 9 8 7 6 5 4 2 1 1 111 1 1 1 1 Technalogix Ltd. #4, 8021 Edgar Industrial Place Red Deer, Alberta, Canada T4P 3R3 Agile Logic C Date: 09/11/00Page: 1 of 1 RevID 1 1 2 2 3 3 4 4 5 5 6 6 7 7 8 8 9 9 10 10 AA BB CC DD EE FF GG L3 C4C5 L5L2 C6 L4 C3 P1 OUTPUT E3 -20dB TEST 19 5 2 + U1 C7 E2 +24V E1 INPUT L1 C2C1 R1 Technalogix Ltd. #4, 8021 Edgar Industrial Place Red Deer, Alberta, Canada T4P 3R3 Agile Output Amplifier Board H Date: 09/11/00Page: 1 of 1 RevID 1 1 2 2 3 3 4 4 5 5 6 6 7 7 AA BB CC DD EE FF GG HH II JJ AUDIO/INPUT FROM LOGIC BOARD P8 TO LOGIC BOARD P11 VIDEO OUT P103 P2:4 P2:3P2:1 L2 L200 P1 P2 P3 P4P5 P6 P7 P8 U11 3 8 1 65 7 2 4 U100 P101 P1 P2P3 P4 GROUP DELAY F100 P1P2P3P4 P5P6P7P8 U102 P1P2P3P4P5P6P7P8 P9 P10P11P12P13P14P15P16 U101 P1 P2 P3 P4 P5 P6 P7 P8 P9P10 P11 P12 P13 P14 P15 P16 P17 P18 U10 L15 +12V C47 D1 C4 C2 5 6 4 7 + U1:B + C3 P2:5 TB1 P2:6 C6 + C5 +12V + C8 3 2 8 1 + U1:A C9 C7 J1 STEREO + C46 +12V C13 C21 C25 C22 C23 C24 Y1 JP5 JP4 JP2 JP1 JP3 C27 C26 +12V D8 C28 D7 +12VA C11 D2 D3 C10 3 28 4 1 + U103:A +12V P2:9 C12 R15 C14 D6 L1 C15 +12V C16 + C38 Q3 C17 C18 C115 D101 D100 C116 5 6 8 4 7 + U103:B +12V P2:10 C117 R125 TP100 Q102 +12V C113 + C112 Q103 Q101 Q104 C114 R120 +12V +12V + C45 Q106 C118 +12V C129 + C106 C107 C109 + C108 C111 +12V C110 +12V Q100 P100P102 + C100 + C102 C130 C101 C105 C104 C103 +12V C29 C30 C32 C31 P8:1 P8:2 P2:7 +12V C41 C40 C39 D11 D9 D10 C43 P2:8 L5 C42 P1 +12V + C44 + C156 P2:2 P7:5 TP1 C33 C20 Q2 C19 L3L4 TP2 C35 C34 C36C37 C123 L100 C124 C128 C125 C126 y100 Q107 C127 C122 12V C120 Q5 + C121 R130 MX2 1 2 3 45 6 7 8 TP1 C119 C131 C132 Q6 C133 L101 C136 C134 C135 12V F101 5 1 C142 C139 12V C137 C140C141 C138 Q7 L102 C143 C145 L103L104 C146 C144 C147 C148 Q4 C149 L105 C150 C154 C155 12V C151C152 C153 L106L107 R5 R4 R2 R1R23 R10 R8R9 R3 R12 R7 R11 R24R26 R25 R13 R18 R27 R29 R28 R14 R17 R16 R19 R20 R21 R22 R123 R126 R124 R118 R115R114 R116 R119 R117 R121 R122 R134 R133 R127 R107 R106 R105 R113 R112 R104 R111 R110 R109 R108 R100 R101R102 R103 R37R36R35 R32 R33 R34 R31 R38R39 R40 R30 R42 R135 R136 R137 R140 R138 R139 R132 R131 R129 R128 R141 R142 R143 R147 R144 R145 R146 R148 R150 R151 R152 R149 R159 R156R155 R158 R153R154 R157 R160 R161 R162 R163 R164 R166 R165 R170 R167 R168 R169 Technalogix Ltd. #4, 8021 Edgar Industrial Place Red Deer, Alberta, Canada T4P 3R3 Audio Video Modulator Board E Date: 09/11/00Page: 1 of 1 RevID 1 1 2 2 3 3 4 4 5 5 6 6 7 7 8 8 9 9 10 10 AA BB CC DD EE FF GG IF IN LOCK DETECT TO MPU C300C301 C21 + C303 +12V +12V D3 D2 D1 C5 C2 C1 P1 L1 C4 +12V +12V L5 C3 C12 C11 ENABLE IN J6 CLOCK IN J5 DATA IN J4 250 KHZ REF FROM ON CONVERTER J3 J2 C129 C128 C38 + 1 4 2 3 U102 C126 C125 L103 C124 L102 C123 L101 C122 C121 L100 + U101 + C116A C141 L107 C135 C136 C139 C140 L109 C137 C138 L108 C131 C132C133 + C134 D102 12V D101 C104 C110 12V D100 + C103 C101C102 C108 C107 C106 C105 D103 12V C109 C115 C116 C117 C119 C120 12V C118 C111 C112 C113 C114 L104 C130 IF OUT P2 942 MHZ C208 C205 +12V C210 C209C207 C206 + 1 4 2 3 U200 C204 C201 C15 L6 C14 + 1 4 2 3 U2 IF MIXER MIX 1LO FIL 200 P1 P2 P3 P4 P5 P6 P7 P8 P9 P10P11 P12 P13 P14 P15 P16 P17 P18 P19 P20 M145200 U100 VCD1 U6 R4 R5 R2 R3 R1 R15 R1900 R6 R14 R16 R1800 R17 R120 R116 R119 R109 R101 R106 R105 R104 R103 R102 R108 R111…

Text truncated - open the document above for the full version.

TM-200 TEST REPORT S/N: K6349 Prepared by: Aaron Sivacoe, P.ENG Rainier Kong Date: January 30, 2007 2 Contents Contents____________________________________________________________________2 Test Equipment______________________________________________________________3 Performance Specifications____________________________________________________4 Visual Power Output Rating___________________________________________________4 Visual Power Adjustment Capability____________________________________________5 Aural Power Output Rating___________________________________________________6 Carrier Frequency Tolerance__________________________________________________8 Visual Frequency Response__________________________________________________11 Intermodulation Distortion___________________________________________________14 Spurious Emissions_________________________________________________________16 Modulation_______________________________________________________________18 K Pulse to Bar (Kpb) Rating__________________________________________________19 2T Pulse K (K2T) Rating____________________________________________________20 Chrominance-Luminance Gain Inequality_______________________________________21 Chrominance-Luminance Delay Inequality______________________________________22 Differential Gain Distortion__________________________________________________23 Differential Phase Distortion_________________________________________________24 Group Delay Response______________________________________________________25 Horizontal Timing__________________________________________________________26 Audio Amplitude Frequency Response_________________________________________27 3 Test Equipment Equipment Manufacturer Model Number Serial Number Test Signal Generator Tektronix TSG95 B025497 Test Signal Generator Tektronix 1910 B022706 Spectrum Analyzer Advantest R3162 110301419 Spectrum Analyzer Tektronix 2710 B021677 Waveform Analyzer/Monitor Tektronix VM700A B020283 Radiation Meter Narda Network Analyzer Agilent 8753ET US39170436 Frequency Counter HP 5343A 2428A01747 Audio Generator HP 209A 1045A06481 Noise and Distortion Meter HP 3…

Text truncated - open the document above for the full version.
