CUE, spol. s r.o. Na Dolinách 6 147 00 Praha 4 Czech Republic phone: +420 241 433 555 fax: +420 241 432 446 www.cuesystem.com e-mail: [email protected] User Manual rfbaseCUE Version 02 User Manual rfbaseCUE UM011_02, 06.11.2002 Copyright © CUE, spol. s r.o. Praha, Czech Republic 1990 - 2002. All rights reserved. Specifications are subject to change without prior notice. Caution Changes or modifications to this unit not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. Note This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: • Reorient or relocate the receiving antenna. • Increase the separation between the equipment and receiver. • Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. • Consult the dealer or an experienced radio/TV technician for help. User Manual rfbaseCUE www.cuesystem.com Page 3 of 16 Table of Contents 1. Introduction....................................................................................................................................... 4 1.1. Overview.............................................................................................................................................. 4 1.2. Models ................................................................................................................................................. 4 1.3. Features .............................................................................................................................................. 4 2. Mounting the Base Unit ................................................................................................................... 5 3. Front and Rear Panels Description ................................................................................................ 6 3.1. CUEwire Connection ........................................................................................................................... 6 3.2. Host Computer Connection ................................................................................................................. 7 3.3. Indicators ............................................................................................................................................. 8 3.4. Antennas ............................................................................................................................................. 8 3.5. Fuse..................................................................................................................................................... 8 4. Service Mode .................................................................................................................................... 9 4.1. Overview.............................................................................................................................................. 9 4.2. How to Check Firmware Version ......................................................................................................... 9 4.3. Starting Service Mode ......................................................................................................................... 9 4.4. Upgrading the Firmware .....................................................................................................................10 4.5. Modifying Address of Wireless Control Panel .....................................................................................11 5. Troubleshooting ............................................................................................................................. 12 5.1. The POWER Indicator does not Light.................................................................................................12 5.2. The Short Operating Range................................................................................................................12 6. Specifications ................................................................................................................................. 13 7. Mechanical Drawings..................................................................................................................... 14 User Manual rfbaseCUE www.cuesystem.com Page 4 of 16 1. Introduction 1.1. Overview.................................................................... The rfbaseCUE is a unit that serves as an interface between wireless RF control panels and the RS-485 bus. Main functions • Receives data from wireless RF control panels and transfers them via CUEwire (RS-485) to the control units (Assistant or Assistant-S). • Receives data from CUEwire (RS-485) and transfers them via RF to wireless RF control panels. • Stores data when the wireless RF control panels are not active or out of range and transfers them when the connection is newly established. 1.2. Models ....................................................................... Model Product code Description rfbaseCUE CS0171-4 RF base unit, 433.92 MHz rfbaseCUE CS0171-8 RF base unit, 869.85 MHz rfbaseCUE CS0171-9 RF base unit, 914.5 MHz 1.3. Features..................................................................... The main features of the base unit are • PC…

Text truncated - open the document above for the full version.

CUE spol. s r.o. Na Dolinách 6 147 00 Praha 4 Czech Republic phone: +420 241 433 555 fax: +420 241 432 446 www.cuesystem.com e-mail: [email protected] Zapsána v obchodním rejstříku Krajského obchodního soudu v Praze, v oddílu C, vložka 4534 Entered into Commercial register of the Direct Commercial Court in Prague, section C,attachment 4534 Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 U.S.A. date/datum: 02.12.2002 CONFIDENTIALITY REQUEST Gentlemen: This letter is to comply with Section 0.457(d)(2)(i) pertaining to confidential material. Cue s.r.o. would like the following documents regarding this submission for FCC ID: QHXCS0171-9 to be kept confidential. 1. Document "schematics rfbaseCUE.pdf" 2. Document "operation description rfbaseCUE.pdf" 3. Document "block diagram rfbaseCUE.pdf" The above material contains trade secrets or technical data, which would customarily be guarded from competitors. We do not want these documents to be accessible to the general public. Sincerely, Karel Cvrk.

CS0171 rfbaseCUE, front wiew CS0171 rfbaseCUE, rear view

CS0171 rfbaseCUE ID label Equipment ID label is placed on rear panel of the metal case: Detail of ID label (actual size 42x30mm):

CS0171 rfbaseCUE, top side of PCB CS0171 rfbaseCUE, rear view

EMC Test Report No.: 02-042 FCC ID: QHXCS0171-9 The test report shall not be reproduced except in full without the written approval of the testing laboratory. ECL-EMC-TR-02-042-V01.00 Page 2 of 33 Manufacturer:CUE spol. s r.o. Na Dolinách 147 00 Praha 4 Czech Republic Test Location:Lucent Technologies Network Systems GmbH European Compliance Laboratory (ECL) Thurn-und-Taxis-Strasse 10 D-90411 Nürnberg Germany Tel.: +49 911 526 1422 Fax: +49 911 526 2391 General: The purpose of this report is to show compliance to the FCC regulations for unlicensed devices operating under section 15.249 of the Code of Federal Regulations title 47. This report informs about the results of the EMC tests, it only refers to the equipment under test. No part of this report may be reproduced in any form, without written permission. EMC Test Report No.: 02-042 FCC ID: QHXCS0171-9 The test report shall not be reproduced except in full without the written approval of the testing laboratory. ECL-EMC-TR-02-042-V01.00 Page 3 of 33 Table of contents 1TEST RESULTS SUMMERY.........................................................................................................4 2CS0171 RFBASECUE..................................................................................................................5 3DESCRIPTION OF EMC TEST CENTRE.......................................................................................7 3.1REGISTRATIONS.......................................................................................................................7 3.2SEMI ANECHOIC CHAMBER (SAC) WITH MAXIMUM 10M MEASUREMENT DISTANCE...............................8 3.3FULLY ANECHOIC CHAMBER (FAC) WITH MAXIMUM 5M MEASUREMENT DISTANCE................................8 3.4SHIELDED TEST CABINS.............................................................................................................9 3.5INSTRUMENT ROOM................................................................................................................10 3.6MEASUREMENT UNCERTAINTY.................................................................................................11 3.7GROUND PLAN.......................................................................................................................12 4ANTENNA REQUIREMENT........................................................................................................13 4.1REGULATION.........................................................................................................................13 4.2RESULT................................................................................................................................13 5RADIATED EMISSIONS TEST....................................................................................................14 5.1REGULATION.........................................................................................................................14 5.2RADIATED EMISSIONS TEST, 9 KHZ TO 10 GHZ..........................................................................15 5.2.1TEST EQUIPMENT USED:...................................................................................................15 5.2.2TEST PROCEDURES.........................................................................................................15 5.2.3CALCULATION OF FIELD STRENGTH LIMITS..........................................................................16 5.2.4CALCULATION OF AVERAGE CORRECTION FACTOR...............................................................16 5.2.5FIELD STRENGTH CALCULATION........................................................................................16 5.2.6TEST RESULTS...............................................................................................................18 6CONDUCTED EMISSIONS TESTS.............................................................................................23 6.1REGULATION.........................................................................................................................23 6.2TEST EQUIPMENT...................................................................................................................23 6.3TEST PROCEDURES................................................................................................................23 6.4TEST RESULTS......................................................................................................................24 7CALIBRATION LIST...................................................................................................................28 8ACCREDITATION CERTIFICATE...............................................................................................32 9LIST OF ANNEXES....................................................................................................................33 EMC Test Report No.: 02-042 FCC ID: QHXCS0171-9 The test report shall not be reproduced except in full without the written approval of the testing laboratory. ECL-EMC-TR-02-042-V01.00 Page 4 of 33 1 Test Results Summery Summary of Test Results CS0171 RFBASECUE RequirementCFR SectionReport SectionTest Result Antenna requirement15.2034Pass Conducted emissions15.2076Pass Field Strength Limits (Fundamental and Harmonics)15.2495Pass Radiated Spurious Emissions15.209, 15.2495Pass The client has made the determination that EUT Condition, Characterization, and Mode of Operation are representative of production units, and meet the requirements of the specifications referenced herein. Consistent with industry practice, measurement and test equipment not directly involved in obtaining measurement results but having an impact on measurements (such as cable loss, antenna factors, etc.) are factored into the “Correction Factor” documented in certain test results. Instrumentation employed for testing meets tolerances consistent with known Industry Standards and Regulations. The measurements contained in this report were made in ac…
