Bluetooth Mini Speaker(NFC) Model: AF-MCB12 Brand: My Music FCC ID: QIFAF-MCB12 Main Function: 1. Bluetooth music playing function 2. MIC function for hands-free talking(distance:30-50cm) Operate Instructions (Note: The device, called AF-MCB12, pair Code: 0000) „ Bluetooth function and MIC function for hands-free talking (Let us take mobile phone for example) a. Making switch to Bluetooth, after 3 seconds, hear the Beep twice, then Bluetooth indicator will flash quickly and it means that it has entered Bluetooth pairing status. b. Starting up the Bluetooth function of mobile phone to search for Bluetooth device. When the mobile finds the Bluetooth device(AF-MCB12), select it and it will be prompted for a password (Note: some mobile phone can be connected directly without entering pairing code, and if the mobile phone had already been paired before, it is also unnecessary to enter pairing code), enter “0000” number, press “Yes” to connect the Bluetooth device (AF-MCB12). c. The mobile phone will show the sign of success after it connects to Bluetooth. d. Set up the play mode to Bluetooth output of your device and play music. Music volume can be increased or decreased by adjusting the volume of phone. e. During you listening music, if there somebody call you, the music will be interrupted automatically. Anwser the calling and you can talk and hear clearly from the speaker directly, instead of from mobile phone. The effective distance between the bluetooth speaker and your mouth is 30-50cm. f. After hung up, it will turn into playing music program automatically. „ Plug mini 5P USB cable into the Line in/5Vsocket, the signal light keeps on when charging, after fully charged the signal light turn off.(The signal light keeps off when the speaker turn off) „ Body can be separated from Base stands, can be rotate with 360 degrees when they are combined. „ Low power Warning When the battery is running low, it will beep every 30 seconds. Please recharge it in time to protect battery. NFC Function NFC can be used for Bluetooth pairing: NFC offers a low-speed connection with extremely simple setup, and can be used to bootstrap more capable wireless connections. It also makes the pairing process easy with NFC -- a simple tap of your Mobile to the speaker gets the tunes flowing. When you get the speaker and a mobile phone with NFC equipment together, they sense each other through NFC and switch your sound to stereo. You need to touch the loudspeaker of NFC mobile, and it will begin to play music immediately. „ Product Specification: 1. SNR: ≥95±2dB 2. Speakers: D36mm(20HZ-20KHZ) 3. Lithium polymer battery input: 400MHA (DC5V) 4. Dimension: D72.26* H104.8 (MM), single weight: 136g 5. Material： ABS case+Metal Net-cover 6,Charging time: 2.5-3 hours playing time: 4-6 hours IMPORTANT REGULATORY INFORMATION This device complies with Part 15 of the FCC Rules: Operation is subject to the following two conditions: 1. This device may not cause harmful interference and 2. This device must accept any interference that is received, including any interference that may cause undesired operation. WARNING: Changes or modifications to this unit not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment.

Dec.12, 2012 Federal Communication Commission Authorization and Evaluation Division FCC ID: QIFAF-MCB12 Re: Confidentiality Request Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, the applicant hereby requests confidential treatment of information applied this application as outlined below: 1: Block Diagram 2: Circuit Diagram 3: Operational Description 4: Parts List The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the applicant and provide unjustified benefits to its competitors. The Applicant understands that pursuant to Rules 0.457, disclosure of this Application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely, My Music Group Limited Contact Person: Smile Zhang

PHOTOGRAPHS OF THE EUT TOP VIEW OF EUT BOTTOM VIEW OF EUT FRONT VIEW OF EUT BACK VIEW OF EUT LEFT VIEW OF EUT RIGHT VIEW OF EUT

FCC Label Location Bluetooth Mini Speaker(NFC) Brand: My Music Model: AF-MCB12 FCC ID:QIFAF-MCB12

OPEN VIEW OF EUT-1 OPEN VIEW OF EUT-2 INTERNAL VIEW OF EUT-1 INTERNAL VIEW OF EUT-2 NFC Label INTERNAL VIEW OF EUT-3 INTERNAL VIEW OF EUT-4 BT Antenna INTERNAL VIEW OF EUT-5

Report No.: AGC06F121001-3F2 Page 1 of 54 FCC Test Report Report No.: AGC06F121001‐3F2 FCC ID : QIFAF‐MCB12 PRODUCT DESIGNATION : Bluetooth Mini Speaker(NFC) BRAND NAME : My Music MODEL NAME : AF‐MCB12 CLIENT : My Music Group Limited DATE OF ISSUE : Dec.10,2012 STANDARD(S) : FCC Part 15 Rules REPORT VERSION : V1.0 Attestation of Global Compliance (Shenzhen) Co., Ltd. CAUTION: This report shall not be reproduced except in full without the written permission of the test laboratory and shall not be quoted out of context. Report No.: AGC06F121001-3F2 Page 2 of 54 VERIFICATION OF COMPLIANCE Applicant My Music Group Limited Room No.7063, Building East, Cheng shi TianDi Plaza, Jia Bin Road, Luo Hu District, Shenzhen, Guangdong, China, 518001 Manufacturer Affluent International Co., Ltd 3F, No. 10, Yituan Road, Bantian Town, Shenzhen, Guangdong, China,518129 Product Designation Bluetooth Mini Speaker(NFC) Brand Name My Music Test Model AF-MCB12 FCC ID QIFAF-MCB12 Report Number AGC06F121001-3F2 Date of Test Dec.04,2012 to Dec.10,2012 WE HEREBY CERTIFY THAT: The above equipment was tested by Attestation of Global Compliance Co., Ltd. The test data, data evaluation, test procedures, and equipment configurations shown in this report were made in accordance with the procedures given in ANSI C63.4 (2003) and the energy emitted by the sample EUT tested as described in this report is in compliance with radiated emission limits of FCC Rules Part 15.247. Tested By: Jane Wu Dec.10,2012 Reviewed By: Forrest Lei Dec.10,2012 Approved By: Solger Zhang Dec.10,2012 Report No.: AGC06F121001-3F2 Page 3 of 54 TABLE OF CONTENTS 1. GENERAL INFORMATION .................................................................................................................................................... 5 1.1 PRODUCT DESCRIPTION .............................................................................................................................................. 5 1.2 TABLE OF CARRIER FREQUENCYS .......................................................................................................................... 5 1.3 RECEIVER INPUT BANDWIDTH ................................................................................................................................... 6 1.4 EXAMPLE OF A HOPPING SEQUENCY IN DATA MODE ........................................................................................ 7 1.5 EQUALLY AVERAGE USE OF FREQUENCIES AND BEHAVIOUR ....................................................................... 7 1.6 RELATED SUBMITTAL(S) / GRANT (S) ...................................................................................................................... 7 1.7 TEST METHODOLOGY ................................................................................................................................................... 7 1.8 MEASUREMENT UNCERTAINTY ................................................................................................................................. 7 1.9 TEST FACILITY ................................................................................................................................................................. 8 1.10 SPECIAL ACCESSORIES ............................................................................................................................................ 8 1.11 EQUIPMENT MODIFICATIONS ................................................................................................................................... 8 2. SYSTEM TEST CONFIGURATION ...................................................................................................................................... 9 2.1 CONFIGURATION OF TESTED SYSTEM .................................................................................................................... 9 2.2 EQUIPMENT USED IN EUT SYSTEM .......................................................................................................................... 9 3. SUMMARY OF TEST RESULTS ......................................................................................................................................... 10 4. DESCRIPTION OF TEST MODES ..................................................................................................................................... 10 5. PEAK OUTPUT POWER ..................................................................................................................................................... 11 5.1 MEASUREMENT PROCEDURE .................................................................................................................................. 11 5.2 TEST SET-UP (BLOCK DIAGRAM OF CONFIGURATION) ................................................................................... 11 5.3 MEASUREMENT EQUIPMENT USED ........................................................................................................................ 12 5.4 LIMITS AND MEASUREMENT RESULT .................................................................................................................... 12 6. 20 DB BANDWIDTH ............................................................................................................................................................. 14 6.1 MEASUREMENT PROCEDURE .................................................................................................................................. 14 6.2 TEST SET-UP (BLOCK DIAGRAM OF CONFIGURATION) ................................................................................... 14 6.3 MEASUREMENT EQUIPMENT USED ........................................................................................................................ 14 6.4 LIMITS AND MEASUREMENT RESULTS .................................................................................................................. 14 7. CONDUCTED SPURIOUS EMISSION .....................................…
