QKJ91906Wireless Charger For Apple Watch

Radiation Exposure StatementThis equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with minimum distance of 20 cm between the radiator & your body.

Man Shun Uinon Electronic Technology (Shenzhen) Co., Ltd. 1-3/F, 23# Shengxin Road, Shengping, Longgang, Shenzhen, Guangdong, China 518172 Tel: +86 755-28935123 Fax: +86 755-28934769 Series Models Description Date: 2020/06/02 To: Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD FCC ID: QKJ91906 Dear Sir/Madam, We, Man Shun Uinon Electronic Technology (Shenzhen) Co., Ltd. Hereby declares the following statement for Federal Communications Commission, PCB board, circuit, structure and internal of these model(s) are the same, Only color and model number is different for these model: Product name: Wireless Charger For Apple Watch Model no.: TB883, 91906 Sincerely, Name: hongjun Lan Company: Man Shun Uinon Electronic Technology (Shenzhen) Co., Ltd. Address: 1-3/F, 23# Shengxin Road, Shengping, Longgang, Shenzhen, Guangdong, China 518172 Phone: +86 755-28935123 Fax: +86 755-28934769 E-Mail: [email protected]

CONFIDENTIALITY REQUEST for Certification Service in USA Federal Communication Commission Equipment Authorization Division, Application Processing Branch 7435 Oakland Mills Road Columbia, MD 21046 Date: June 02, 2020 TO WHOM IT MAY CONCERN Pursuant to Paragraphs §0.457 and 0.459 of the Commission’s Rules (47 C.F.R.) and Section §552(b)(4) of the Freedom of Information Act, we requests confidentiality for the following products: FCC ID Model name QKJ91906 TB883, 91906 For the product stated above, we request that the following information be held confidential; Exhibits Long-Term Confidentiality Short-Term Confidentiality Short-Term Confidentiality Days External Photos Internal Photos Block Diagram Schematics Test Setup Photos User’s Manual Parts List Tune Up Operational Descriptions The long-term confidentiality exhibits contain our trade secrets and proprietary information that could be of benefit to our competitors. The short-term confidentiality on the basis of ensuring that business sensitive information remains confidential until the actual marketing of our new device. If you have any questions, please feel free to contact me at the address shown below. Sincerely, Name: hongjun Lan Company: Man Shun Uinon Electronic Technology (Shenzhen) Co., Ltd. Address: 1-3/F, 23# Shengxin Road, Shengping, Longgang, Shenzhen, Guangdong, China 518172 Phone: +86 755-28935123 Fax: +86 755-28934769 E-Mail: [email protected]

Man Shun Uinon Electronic Technology (Shenzhen) Co., Ltd. 1-3/F, 23# Shengxin Road, Shengping, Longgang, Shenzhen, Guangdong, China 518172 Tel: +86 755-28935123 Fax: +86 755-28934769 Federal Communications Commission Authorization and Evaluation Division Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MD 21046 6/4/2020 To whom it may concern: We, the undersigned, hereby authorize Eurofins Product Service GmbH to act on our behalf in all matters relating to applications for equipment authorization FCC ID: QKJ91906 including the signing of all documents related to these matters. Any and all acts carried out by Eurofins Product Service GmbH on our behalf shall have the same effect as acts of our own. We also hereby certify that no party to this application is subject to a denial of benefits, including FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 862. Sincerely, Name: hongjun Lan Company: Man Shun Uinon Electronic Technology (Shenzhen) Co., Ltd. Address: 1-3/F, 23# Shengxin Road, Shengping, Longgang, Shenzhen, Guangdong, China 518172 Phone: +86 755-28935123 Fax: +86 755-28934769 E-Mail: [email protected]

FCC ID: QKJ91906 FCC ID: QKJ91906

FCC ID: QKJ91906

FCC ID: QKJ91906 Antenna

Shenzhen Global Test Service Co.,Ltd. No.7-101 and 8A-104, Building 7 and 8, DCC Cultural and Creative Garden, No.98, Pingxin North Road, Shangmugu Community, Pinghu Street, Longgang District, Shenzhen, Guangdong TEST REPORT Report Reference No. ..................... : FCC ID. ........................................... : GTS20200528006-1-7-2 QKJ91906 Compiled by ( position+printed name+signature) .. : File administrators Jimmy Wang Supervised by ( position+printed name+signature) .. : Test Engineer Aaron Tan Approved by ( position+printed name+signature) .. : Manager Jason Hu Date of issue ..................................... : May 28, 2020 Representative Laboratory Name .: Shenzhen Global Test Service Co., Ltd. Address ............................................ : No.7-101 and 8A-104, Building 7 and 8, DCC Cultural and Creative Garden, No.98, Pingxin North Road, Shangmugu Community, Pinghu Street, Longgang District, Shenzhen, Guangdong Applicant’s name ............................ : Man Shun Uinon Electronic Technology (Shenzhen) Co., Ltd. Address ............................................ : 1-3/F, 23# Shengxin Road, Shengping, Longgang, Shenzhen, Guangdong, China 518172 Test specification ...........................: Standard ........................................... : FCC Rules and Regulations part 2.1091 KDB680106 D01v03 TRF Originator .................................. : Shenzhen Global Test Service Co.,Ltd. Master TRF ....................................... : Dated 2014-12 Shenzhen Global Test Service Co.,Ltd. All rights reserved. This publication may be reproduced in whole or in part for non-commercial purposes as long as the Shenzhen Global Test Service Co.,Ltd. is acknowledged as copyright owner and source of the material. Shenzhen Global Test Service Co.,Ltd. takes no responsibility for and will not assume liability for damages resulting from the reader's interpretation of the reproduced material due to its placement and context. Test item description ..................... : Wireless Charger For Apple Watch Trade Mark ....................................... : Wireless gear Manufacturer .................................... : Man Shun Uinon Electronic Technology (Shenzhen) Co., Ltd. Model/Type reference....................... : TB883 Listed Models .................................. : 91906 Modulation Type ............................... : ASK Operation Frequency ........................ : From 110KHz~205KHz Rating ............................................... : DC 5V/1A Result................................................ : PASS Report No.: GTS20200528006-1-7-2 Page 2 of 11 T E S T R E P O R T Test Report No. : GTS20200528006-1-7-2 May 28, 2020 ____________________________________________________________________________________ Date of issue Equipment under Test : Wireless Charger For Apple Watch Model /Type : TB883 Listed Models : 91906 Applicant : Man Shun Uinon Electronic Technology (Shenzhen) Co., Ltd. Address : 1-3/F, 23# Shengxin Road, Shengping, Longgang, Shenzhen, Guangdong, China 518172 Manufacturer : Man Shun Uinon Electronic Technology (Shenzhen) Co., Ltd. Address : 1-3/F, 23# Shengxin Road, Shengping, Longgang, Shenzhen, Guangdong, China 518172 Test Result: PASS The test report merely corresponds to the test sample. It is not permitted to copy extracts of these test result without the written permission of the test laboratory. Report No.: GTS20200528006-1-7-2 Page 3 of 11 Contents 1 S U M M A R Y ............................................................................. 4 1.1 General Remarks 4 1.2 Product Description 4 1.3 Description of the test mode 4 1.4 Special Accessories 4 1.5 Modifications 4 2 T E S T E N V I R O N M E N T ............................................................... 5 2.1 Address of the test laboratory 5 2.2 Test Facility 5 2.3 Environmental conditions 5 2.4 Summary of measurement results 6 2.5 Statement of the measurement uncertainty 6 2.6 Equipments Used during the Test 6 3 T E ST C O N D I T I O N S A N D R E S U L T S ............................................. 7 3.1 Applicable Standard 7 3.2 Limit 7 3.3 Test Setup 7 3.4 Measurement Procedure 8 1.1. Test Result of E and H field Strength 8 1.2. Equipment Approval Considerations 10 1.3. Conclusion 10 Report No.: GTS20200528006-1-7-2 Page 4 of 11 1 S U M M A R Y 1.1 General Remarks Date of receipt of test sample : May 20, 2020 Testing commenced on : May 21, 2020 Testing concluded on : May 27, 2020 1.2 Product Description Product Name: Wireless Charger For Apple Watch Model/Type reference: TB883 Hardware version: A13 V3 Software version: V1.0 Test samples ID: GTS20200528006-1-7# Power supply: DC 5V from PC Operation frequency: 110KHz - 205KHz Modulation type: ASK Antenna type: Loop coil antenna 1.3 Description of the test mode Equipment under test was operated during the measurement under the following conditions: Charging and communication mode Test Modes: Mode 1 PC + EUT + iWatch (Battery Status: <1%) Record Mode 2 PC + EUT + iWatch (Battery Status: <50%) Pre-tested Mode 3 PC + EUT + iWatch (Battery Status: 100%) Pre-tested Note: All test modes were pre-tested, but we only recorded the worst case in this report. 1.4 Special Accessories Follow auxiliary equipment(s) test with EUT that provided by the manufacturer or laboratory is listed as follow: Description Manufacturer Model Technical Parameters Certificate Provided by PC Lenove ThinkPad E480 Input: 20V,2.25A / 3.25A CE/FCC laboratory Adapter Lenove ADLX65YLC3A Input: 100-240V~1.8A 50-60Hz Output: 20V3.25A/15V3A /9V2A/5V2A CE/FCC laboratory / / / / / / / / / / / / 1.5 Modifications No modifications were implemented to meet testing criteria. Report No.: GTS20200528006-1-7-2 Page 5 of 11 2 T E S T E N V I R O N M E N T 2.1 Address of the test laboratory Shenzhen Global Test Service Co.,Ltd. No.7-101 and 8A-104, Building 7 and 8, DCC Cultural and Creative Garden, No.98, Pingxin North Road, Shangmugu Community, Pinghu Street,…

Text truncated - open the document above for the full version.

Shenzhen Global Test Service Co.,Ltd. No.7-101 and 8A-104, Building 7 and 8, DCC Cultural and Creative Garden, No.98, Pingxin North Road, Shangmugu Community, Pinghu Street, Longgang District, Shenzhen, Guangdong FCC PART 15 SUBPART C TEST REPORT Report Reference No. ..................... : FCC ID. ........................................... : GTS20200528006-1-7 QKJ91906 Compiled by ( position+printed name+signature) .. : File administrators Jimmy Wang Supervised by ( position+printed name+signature) .. : Test Engineer Aaron Tan Approved by ( position+printed name+signature) .. : Manager Jason Hu Date of issue ..................................... : May 28, 2020 Representative Laboratory Name .: Shenzhen Global Test Service Co., Ltd. Address ............................................ : No.7-101 and 8A-104, Building 7 and 8, DCC Cultural and Creative Garden, No.98, Pingxin North Road, Shangmugu Community, Pinghu Street, Longgang District, Shenzhen, Guangdong Applicant’s name ............................ : Man Shun Uinon Electronic Technology (Shenzhen) Co., Ltd. Address ............................................ : 1-3/F, 23# Shengxin Road, Shengping, Longgang, Shenzhen, Guangdong, China 518172 Test specification ...........................: Standard ........................................... : FCC Rules and Regulations Part 15 Subpart C (Section 15.209), ANSI C63.10: 2013 TRF Originator .................................. : Shenzhen Global Test Service Co.,Ltd. Master TRF ....................................... : Dated 2014-12 Shenzhen Global Test Service Co.,Ltd. All rights reserved. This publication may be reproduced in whole or in part for non-commercial purpses as long as the Shenzhen Global Test Service Co.,Ltd. is acknowledged as copyright owner and source of the material. Shenzhen Global Test Service Co.,Ltd. takes no responsibility for and will not assume liability for damages resulting from the reader's interpretation of the reproduced material due to its placement and context. Test item description ..................... : Wireless Charger For Apple Watch Trade Mark ....................................... : Wireless gear Manufacturer .................................... : Man Shun Uinon Electronic Technology (Shenzhen) Co., Ltd. Model/Type reference....................... : TB883 Listed Models .................................. : 91906 Modulation Type ............................... : ASK Operation Frequency ........................ : From 110KHz~205KHz Rating ............................................... : DC 5V/1A Result................................................ : PASS Report No.: GTS20200528006-1-7 Page 2 of 21 T E S T R E P O R T Test Report No. : GTS20200528006-1-7 May 28, 2020 ____________________________________________________________________________________ Date of issue Equipment under Test : Wireless Charger For Apple Watch Model /Type : TB883 Listed Models : 91906 Applicant : Man Shun Uinon Electronic Technology (Shenzhen) Co., Ltd. Address : 1-3/F, 23# Shengxin Road, Shengping, Longgang, Shenzhen, Guangdong, China 518172 Manufacturer : Man Shun Uinon Electronic Technology (Shenzhen) Co., Ltd. Address : 1-3/F, 23# Shengxin Road, Shengping, Longgang, Shenzhen, Guangdong, China 518172 Test Result: PASS The test report merely corresponds to the test sample. It is not permitted to copy extracts of these test result without the written permission of the test laboratory. Report No.: GTS20200528006-1-7 Page 3 of 21 Contents 1 T E S T S T A N D A R D S .................................................................. 4 2 S U M M A R Y ............................................................................. 5 2.1 General Remarks 5 2.2 Product Description 5 2.3 Description of the test mode 5 2.4 Special Accessories 5 2.5 Modifications 5 3 T E S T E N V I R O N M E N T ............................................................... 6 3.1 Address of the test laboratory 6 3.2 Test Facility 6 3.3 Environmental conditions 6 3.4 Summary of measurement results 7 3.5 Statement of the measurement uncertainty 7 3.6 Equipments Used during the Test 7 4 T E S T C O N D I T I O N S A N D R E S U L T S ............................................. 9 4.1 AC Power Conducted Emission 9 4.2 Radiated Emission 12 4.3 Occupied Bandwidth 16 4.4 Antenna Requirement 17 5 T E S T S E T U P P H O T O S O F T H E E U T .......................................... 18 6 PH O T O S O F T H E E U T ............................................................. 19 Report No.: GTS20200528006-1-7 Page 4 of 21 1 T E S T S T A N D A R D S The tests were performed according to following standards: FCC Rules and Regulations Part 15 Subpart C (Section 15.207): Conducted limits. FCC Rules and Regulations Part 15 Subpart C (Section 15.209): Radiated emission limits; general requirements. ANSI C63.10: 2013: American National Standard for Testing Unlicensed Wireless Devices Report No.: GTS20200528006-1-7 Page 5 of 21 2 S U M M A R Y 2.1 General Remarks Date of receipt of test sample : May 20, 2020 Testing commenced on : May 21, 2020 Testing concluded on : May 27, 2020 2.2 Product Description Product Name: Wireless Charger For Apple Watch Model/Type reference: TB883 Hardware version: A13 V3 Software version: V1.0 Test samples ID: GTS20200528006-1-7# Power supply: DC 5V from PC Operation frequency: 110KHz - 205KHz Modulation type: ASK Antenna type: Loop coil antenna 2.3 Description of the test mode Equipment under test was operated during the measurement under the following conditions: Charging and communication mode Test Modes: Mode 1 PC + EUT + iWatch (Battery Status: <1%) Record Mode 2 PC + EUT + iWatch (Battery Status: <50%) Pre-tested Mode 3 PC + EUT + iWatch (Battery Status: 100%) Pre-tested Note: All test modes were pre-tested, but we only recorded the worst case in this report. 2.4 Special Accessories Follow auxiliary equipment(s) test with EUT that provided by the manufacturer or laboratory is liste…

Text truncated - open the document above for the full version.

FCC ID: QKJ91906
