QKJ91931Wireless Bluetooth Headphones

Man Shun Uinon Electronic Technology (Shenzhen) Co., Ltd. 1-3/F, 23# Shengxin Road, Shengping, Longgang, Shenzhen, Guangdong, China 518172 Tel: +86 755-28935123 Fax: +86 755-28934769 Series Models Description Date: 2020/05/07 To: Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD FCC ID: QKJ91931 Dear Sir/Madam, We, Man Shun Uinon Electronic Technology (Shenzhen) Co., Ltd. Hereby declares the following statement for Federal Communications Commission, PCB board, circuit, structure and internal of these model(s) are the same, Only color and model number is different for these model: Product name:Wireless Bluetooth Headphones Model no.:91931, MG508, MG507, BB2866, BB2867, BB2421, BB2422, BB2423 Sincerely, Name:hongjun Lan Company:Man Shun Uinon Electronic Technology (Shenzhen) Co., Ltd. Address:1-3/F, 23# Shengxin Road, Shengping, Longgang, Shenzhen, Guangdong, China 518172 Phone:+86 755-28935123 Fax:+86 755-28934769 E-Mail:[email protected]

CONFIDENTIALITY REQUEST for Certification Service in USA Federal Communication Commission Equipment Authorization Division, Application Processing Branch 7435 Oakland Mills Road Columbia, MD 21046 Date: May 07, 2020 TO WHOM IT MAY CONCERN Pursuant to Paragraphs §0.457 and 0.459 of the Commission’s Rules (47 C.F.R.) and Section §552(b)(4) of the Freedom of Information Act, we requests confidentiality for the following products: FCC IDModel name QKJ9193191931, MG508, MG507, BB2866, BB2867, BB2421, BB2422, BB2423 For the product stated above, we request that the following information be held confidential; Exhibits Long-Term Confidentiality Short-Term Confidentiality Short-Term Confidentiality Days External Photos Internal Photos Block Diagram Schematics Test Setup Photos User’s Manual Parts List Tune Up Operational Descriptions The long-term confidentiality exhibits contain our trade secrets and proprietary information that could be of benefit to our competitors. The short-term confidentiality on the basis of ensuring that business sensitive information remains confidential until the actual marketing of our new device. If you have any questions, please feel free to contact me at the address shown below. Sincerely, Name:hongjun Lan Company:Man Shun Uinon Electronic Technology (Shenzhen) Co., Ltd. Address:1-3/F, 23# Shengxin Road, Shengping, Longgang, Shenzhen, Guangdong, China 518172 Phone:+86 755-28935123 Fax:+86 755-28934769 E-Mail:[email protected]

Man Shun Uinon Electronic Technology (Shenzhen) Co., Ltd. 1-3/F, 23# Shengxin Road, Shengping, Longgang, Shenzhen, Guangdong, China 518172 Tel: +86 755-28935123 Fax: +86 755-28934769 Federal Communications Commission Authorization and Evaluation Division Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MD 21046 2020-05-08 To whom it may concern: We, the undersigned, hereby authorize Eurofins Product Service GmbH to act on our behalf in all matters relating to applications for equipment authorization FCC ID: QKJ91931 including the signing of all documents related to these matters. Any and all acts carried out by Eurofins Product Service GmbH on our behalf shall have the same effect as acts of our own. We also hereby certify that no party to this application is subject to a denial of benefits, including FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 862. Sincerely, Name:hongjun Lan Company:Man Shun Uinon Electronic Technology (Shenzhen) Co., Ltd. Address:1-3/F, 23# Shengxin Road, Shengping, Longgang, Shenzhen, Guangdong, China 518172 Phone:+86 755-28935123 Fax:+86 755-28934769 E-Mail:[email protected]

FCC ID: QKJ91931

BT antenna

RF Exposure evaluation FCC ID: QKJ91931 1.1.Applicable Standard According to §1.1307(b)(1), systems operating under the provisions of this section shall be operated in a manner that ensures that the public is not exposed to radio frequency energy level in excess of the Commission’s guidelines. According to §1.1310 and §2.1093 RF exposure requirement KDB447498 v06: Mobile and Portable Devices RF Exposure Procedures and Equipment Authorization Policies 1.2.Requirement According to KDB447498 D01 General RF Exposure Guidance v06 Section 4.3.1 Standalone SAR test exclusion considerations: “Unless specifically required by the published RF exposure KDB procedures, standalone 1-g head or body and 10-g extremity SAR evaluation for general population exposure conditions, by measurement or numerical simulation, is not required when the corresponding SAR Test Exclusion Threshold condition, listed below, is satisfied. These test exclusion conditions are based on source-based time-averaged maximum conducted output power of the RF channel requiring evaluation, adjusted for tune-up tolerance, and the minimum test separation distance required for the exposure conditions.22 The minimum test separation distance is determined by the smallest distance from the antenna and radiating structures or outer surface of the device, according to the host form factor, exposure conditions and platform requirements, to any part of the body or extremity of a user or bystander (see 5) of section 4.1). To qualify for SAR test exclusion, the test separation distances applied must be fully explained and justified by the operating configurations and exposure conditions of the transmitter and applicable host platform requirements, typically in the SAR measurement or SAR analysis report, according to the required published RF exposure KDB procedures. When no other RF exposure testing or reporting is required, a statement of justification and compliance must be included in the equipment approval, in lieu of the SAR report, to qualify for the SAR test exclusion. When required, the device specific conditions described in the other published RF exposure KDB procedures must be satisfied before applying these SAR test exclusion provisions; for example, handheld PTT two-way radios, handsets, laptops & tablets etc.23 “ [(max. power of channel, including tune-up tolerance, mW)/ (min. test separation distance, mm)] · [√f (GHz)] ≤ 3.0 for 1-g SAR and ≤ 7.5 for 10-g extremity SAR, where: • f (GHz) is the RF channel transmit frequency in GHz • Power and distance are rounded to the nearest mW and mm before calculation • The result is rounded to one decimal place for comparison • 3.0 and 7.5 are referred to as the numeric thresholds in the step 2 below The test exclusions are applicable only when the minimum test separation distance is ≤ 50 mm and for transmission frequencies between 100 MHz and 6 GHz. When the minimum test separation distance is < 5 mm, a distance of 5 mm according to 5) in section 4.1 is applied to determine SAR test exclusion. 1.3.Manufacturing tolerance GFSK ChannelChannel 00Channel 39Channel 78 Target (dBm)4.04.03.0 Tolerance ±(dB)1.01.01.0 π/4DQPSK ChannelChannel 00Channel 39Channel 78 Target (dBm)4.03.03.0 Tolerance ±(dB)1.01.01.0 8DPSK ChannelChannel 00Channel 39Channel 78 Target (dBm)4.03.03.0 Tolerance ±(dB)1.01.01.0 2. Evaluation Result Evaluation Results RF output power (including tune-up tolerance) Band/Modef (GHz) Antenna Distance (mm) dBmmW SAR Test Exclusion Threshold SAR Test Exclusion BT2.402553.1621.0<3.0Yes 3. Conclusion The measurement results comply with the FCC Limit per 47 CFR 2.1093 for the uncontrolled RF Exposure and SAR Exclusion Threshold per KDB 447498 v06, No SAR is required. .....................End.........................

Shenzhen Global Test Service Co.,Ltd. No.7-101 and 8A-104, Building 7 and 8, DCC Cultural and Creative Garden, No.98, Pingxin North Road, Shangmugu Community, Pinghu Street, Longgang District, Shenzhen, Guangdong FCC PART 15 SUBPART CTEST REPORT FCC PART 15.247 Report Reference No. ..................... : FCC ID. .............................................: GTS20200427007-1-2 QKJ91931 Compiled by ( position+printedname+signature) ... : File administrators Jimmy Wang Supervised by (position+printedname+signature) .... : Test Engineer Aaron Tan Approved by (position+printedname+signature) .... : Manager Jason Hu Date of issue ..................................... : Apr. 28, 2020 Representative Laboratory Name .: Shenzhen Global Test Service Co.,Ltd. Address ............................................ : No.7-101 and 8A-104, Building 7 and 8, DCC Cultural and Creative Garden, No.98, Pingxin North Road, Shangmugu Community, Pinghu Street, Longgang District, Shenzhen, Guangdong Applicant’s name ............................ : Man Shun Uinon Electronic Technology (Shenzhen) Co., Ltd. Address ............................................ : 1-3/F, 23# Shengxin Road, Shengping, Longgang, Shenzhen, Guangdong, China 518172 Test specification ...........................: Standard ........................................... : FCC Part 15.247 TRF Originator .................................. : Shenzhen Global Test Service Co.,Ltd. Master TRF ....................................... : Dated 2014-12 Shenzhen Global Test Service Co.,Ltd. All rights reserved. This publication may be reproduced in whole or in part for non-commercial purposes as long as the Shenzhen Global Test Service Co.,Ltd. is acknowledged as copyright owner and source of the material. Shenzhen Global Test Service Co.,Ltd. takes no responsibility for and will not assume liability for damages resulting from the reader's interpretation of the reproduced material due to its placement and context. Test item description .....................: Wireless Bluetooth Headphones Trade Mark ....................................... : N/A Manufacturer .................................... : Man Shun Uinon Electronic Technology (Shenzhen) Co., Ltd. Model/Type reference....................... : 91931 Listed Models .................................. : MG508, MG507, BB2866, BB2867, BB2421, BB2422, BB2423 Modulation Type ............................... : GFSK,Π/4DQPSK,8DPSK Operation Frequency ........................ : From 2402MHz to 2480MHz Rating ............................................... : DC3.7V from battery Result................................................ : PASS Report No.:GTS20200427007-1-2 Page 2 of 48 T E S T R E P O R T Test Report No. : GTS20200427007-1-2 Apr. 28, 2020 ____________________________________________________________________________________ Date of issue Equipment under Test : Wireless Bluetooth Headphones Model /Type : 91931 Listed Models : MG508, MG507, BB2866, BB2867, BB2421, BB2422, BB2423 Applicant : Man Shun Uinon Electronic Technology (Shenzhen) Co., Ltd. Address : 1-3/F, 23# Shengxin Road, Shengping, Longgang, Shenzhen, Guangdong, China 518172 Manufacturer : Man Shun Uinon Electronic Technology (Shenzhen) Co., Ltd. Address : 1-3/F, 23# Shengxin Road, Shengping, Longgang, Shenzhen, Guangdong, China 518172 Test Result: PASS The test report merely corresponds to the test sample. It is not permitted to copy extracts of these test result without the written permission of the test laboratory. Report No.:GTS20200427007-1-2 Page 3 of 48 Contents 1 T E S T S T A N D A R D S ................................................................. 4 2 S U M M A R Y ............................................................................ 5 2.1 General Remarks 5 2.2 Product Description 5 2.3 Equipment Under Test 5 2.4 Short description of the Equipment under Test (EUT) 5 2.5 EUT operation mode 6 2.6 Block Diagram of Test Setup 6 2.7 Related Submittal(s) / Grant (s) 6 2.8 Modifications 6 3 T E S T E N V I R O N M E N T .............................................................. 7 3.1 Address of the test laboratory 7 3.2 Test Facility 7 3.3 Environmental conditions 7 3.4 Summary of measurement results 8 3.5 Statement of the measurement uncertainty 8 3.6 Equipments Used during the Test 9 4 T E S T C O N D I T I O N S A N D R E S U L T S ........................................... 10 4.1 AC Power Conducted Emission 10 4.2 Radiated Emission 13 4.3 MaximumPeak Output Power 20 4.4 20dB Bandwidth 21 4.5 Frequency Separation 25 4.6 Number of hopping frequency 27 4.7 Time ofOccupancy (Dwell Time) 29 4.8 Out-of-band Emissions 33 4.9 Pseudorandom Frequency Hopping Sequence 41 4.10 Antenna Requirement 42 5 T E S T S E T U P P H O T O S O F T H E E U T ......................................... 43 6 P H O T O S O F T H E E U T ........................................................... 44 Report No.:GTS20200427007-1-2 Page 4 of 48 1 T E S T S T A N D A R D S The tests were performed according to following standards: FCC Rules Part 15.247: Frequency Hopping, Direct Spread Spectrum and Hybrid Systems that are in operation within the bands of 902-928 MHz, 2400-2483.5 MHz, and 5725-5850 MHz. ANSI C63.10-2013:AmericanNationalStandardforTestingUnlicensedWirelessDevices Report No.:GTS20200427007-1-2 Page 5 of 48 2 S U M M A R Y 2.1 General Remarks Date of receipt of test sample : Apr. 21, 2020 Testing commenced on : Apr. 22, 2020 Testing concluded on : Apr. 27, 2020 2.2 Product Description Product Name: Wireless Bluetooth Headphones Model/Type reference: 91931 Power supply: DC3.7V from battery Adapter(Auxiliary testProvided by the laborator) Mode:EP-TA20CBC Input:AC100-240V-50/60Hz，0.5A Output:DC 5V,2A Bluetooth : Supported Type: Bluetooth BR/EDR Modulation: GFSK, π/4DQPSK, 8DPSK Operation frequency: 2402MHz~2480MHz Channel number: 79 Channel separation: 1MHz Antenna type: PCB antenna Antenna gain: 0 dBi 2.3 Equipment Under Test Power supply system ut…
