QM3NMPLUSCarrier Current Network Device

NtPLUS User Guide For Windows 98-SE® Windows ME® Windows 2000® Windows XP® 1 Copyright 2002, Main.net Communications Ltd. All rights reserved. All contents of this document are subject to change without notice and do not represent a commitment on the part of Main.net or its subsidiaries. Every effort is made to ensure the accuracy of this information. However due to ongoing product improvements and revisions, Main.net and its subsidiaries cannot guarantee the accuracy of this material, nor can it accept responsibility for errors or omissions. No guaranties of any nature are extended by the information contained in these copyrighted materials. Usage or implementation of any one of the concepts, applications, or ideas described in this document may infringe one or more patents or other intellectual property rights owned by Main.net, its subsidiaries and/or third parties. Procurement of appropriate intellectual property rights and license is solely the responsibility of the system implementer. The software referred to in this document is provided under a Software License Agreement. This document is confidential, and any copying or disclosure of its contents is strictly prohibited, unless prior written consent is obtained from Main.net Communications Ltd. or its subsidiaries. PLUS, Power Line Ultimate System, AmrPLUS, CuPLUS, ExPLUS, NmPLUS, MACPLUS, NtPLUS, PLUServer, PcPLUS, HotPLUS, RcPLUS, RgPLUS, RpPLUS, RuPLUS, TelPLUS, are trademarks of Main.net Communications. Other company, brand, product, and other service names are the trademarks or registered trademarks of their respective holders. P/N: DOC10001 Revision: A00 2 Safety Precautions Read these instructions carefully. 10Unplug this product from the wall outlet before cleaning. Do not use liquid cleaners or aerosol products. Use a damp cloth only. 11Do not use this unit near water. 12Do not place this unit on an unstable cart, stand or table. The unit may fall, causing serious damage to the product. 13Ensure reliable operation of the product and protect it from overheating. The unit is not to be placed near or over a radiator or heat register, or in a built-in installation. 14This product is to be operated from the type of power indicated on the label. 15Do not allow anything to rest on the power cord. Do not locate the unit where people will walk on the power cord. 16Do not use an extension cord with this unit. The extra length will change the impedance characteristics and will degrade performance. 17Never push any objects into the cabinet slots as they may touch dangerous voltage points or short out parts that could result in a fire or electrical shock. Never spill liquids of any type on the product. 18Do not attempt to service this product yourself, as opening and removing covers may expose you to dangerous voltages. Refer all servicing to qualified personnel. 19Unplug this product from the wall outlet and refer it to qualified service personnel under the following conditions: a. When the power cord is damaged or frayed. b. If liquid has been spilled into the unit. c. If the product has been exposed to rain or water. d. If the unit has been dropped or the cabinet has been damaged. CE Marking Warning In a domestic environment, this product may cause interference in which case the user may be required to take adequate measures. This equipment generates nuisance and can radiate radio frequencies energy and, if not installed and used in accordance with the instructions in the user guide, may cause interference to radio communications. 3 FCC Marking Warning The following information needs to be added to our manual. Furthermore every NT unit that is delivered to the US market needs to be issued with this updated manual: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: -- Reorient or relocate the receiving antenna. -- Increase the separation between the equipment and receiver. -- Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. -- Consult the dealer or an experienced radio/TV technician for help. Caution - Any changes or modifications not expressly approved by Main.net could void the user's authority to operate the equipment. 4 Table of Contents 1Introduction.............................................................. 5 1.1How to use this guide....................................... 5 1.2System Requirements...................................... 5 1.3NtPLUS Accessories......................................... 5 1.4The NtPLUS Communication.......................... 6 1.4.1 USB or Ethernet Socket Verification.......... 6 2Ethernet Cable Installation....................................... 7 3USB Cable Installation............................................. 9 3.1Windows 98-SE/Windows ME......................... 9 3.1.1Installation................................................. 9 3.1.2Installation Verification............................ 18 3.1.3Network Configuration Parameters........... 19 3.2Windows 2000................................................ 20 3.2.1Installation............................................... 20 3.2.2USB Communication Verification............ 27 3.2.3Network Parameters Configuration........... 28 3.3Windows XP.....................…

Text truncated - open the document above for the full version.

Power utility Backbone SD Professional Workstation 6000 PRO NmPLUS CuPLUS RpPLUS NtPLUS USB NtPLUS 10BastT NtPLUS 10BaseT USB Access units In-Home units Management & control units Internet Main.net's Power Line Ultimate System (PLUS) has a unique concept that provides a highly cost-effective telecommunication solution for high-speed transmissions over low and medium voltage power lines. It is a multi-service platform that enables power utilities and telecom operators to utilize their communication backbone and electric grid infrastructure to offer their end users a wide range of high-speed telecommunication services through any electrical outlet. By using PLUS, power utilities provide 24-hours, always-on high speed Internet connection from any electrical outlet in their customers' home, as well as home networking and other services. The PLUS system can easily be integrated into any communications infrastructure (e.g. SDH/ATM/IP). It consists of three types of sub-categories: 1. Access units (PLUS backbone) - installed by the power utility along the street's power lines. 2. In-home units - installed by the end users at their home or office ('Plug & Play'). 3. Network Management and Control - installed at the utility's regional control center. In-home units NtPLUS - the NtPLUS (Network Termination) is modem that provides Internet connection between the electrical outlet and the PC (or any other peripheral). The units come with a standard connector to the PC (USB and 10BaseT) Several units can be plugged in to create a home network. Electrical Requirements Input Voltage80 – 265 VAC Input Frequency48 – 63 Hz Interface PC or peripheral 10BaseT, USB Packaging Material ABS+PC (Polycarbonate) UL 94-VO Dimensions Height - 54.8mm (2.16 ”) Width – 170mm (6.7 ”) Height – 222mm (8.74 “) Weight NtPLUS - 0.8 Kg Filters & Analog F.E Power Supply Power Line Modem Communication Processor Ethernet Interface USB Interface
