Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.
SMM-112 Instruction Manual PROFESSIONAL WIRELESS MICROPHONE Please read before using this unit. “ The Singing Machine is a registered trademark of The Singing Machine Co., Inc. 0678 Contents 1. Headset Wireless Microphone x 1 2. Microphone Receiver x 1 3. Microphone Transmitter x 1 Congratulations on your purchase of a Singing Machine Wireless Microphone. We at the Singing Machine know that it will provide you and your friends with endless hours of entertainment. Inside you will find instructions on how to use and maintain this unit. Microphone Transmitter Details Settings The switch on the transmitter of your Singing Machine Wireless Microphone has three settings: 1.ON - The switch is set to ON position. The microphone will function. The red indicator light is on. The microphone will use battery power. 2.STANDBY - The switch is set to STANDBY position. The microphone will not function. The red indicator light is on. The microphone will use battery power. NOTE: The purpose of this setting is to maintain a connection between the microphone and the receiver when moving around the area in which it is being used. 3.OFF - The switch is set to OFF position. The microphone will not function. The red indicator light is off. The microphone will not use battery power. Important Note: When the microphone transmitter switch is set to OFF, noise may be generated from the karaoke machine. Please make sure to reduce both the MASTER VOLUME and MIC VOLUME to the low level OR switch off the receiver before turning off your microphone. 1 123 Instructions for Use 1.Insert one (1) active DC 9-Volt battery into the slot located at the bottom of the transmitter. 2.Insert one (1) active DC 9-Volt battery into the slot located in the back of the receiver. 3.Plug the ∆3.5mm microphone cord into the transmitter input jack. 4.Hold the transmitter on the belt by attached clip. 5.Properly wear the wireless headset microphone and adjust the mic head by its flexible cord to appropriate position. 6.Set the switch on the transmitter to the STANDBY position. 7.Plug the receiver into the Microphone Input Jack of your Singing Machine karaoke machine. 8.Set the switch on your Singing Machine karaoke machine to the ON position. 9.Adjust the Master Volume and Mic Volume Controls of your Singing Machine to a comfortable level. 10.Set the switch on the receiver to the ON position. 11.Set the switch on the transmitter to the top ON position. Your Singing Machine Wireless Microphone set is now ready for use! Maintenance !To ensure long battery life, please make sure that both the Receiver and the Transmitter are set to the OFF position when not in use. To be absolutely certain, we advise you to remove the 9-Volt batteries from both the Receiver and the Transmitter when they are not in use. !Please remove the Receiver from the Microphone Input Jack of your Singing Machine karaoke machine when not in use. This will reduce the possibility of damage to the Receiver. 2 3 1.PROBLEM: The Transmitter indicator light is on, but there is no sound when I sing. a)Is the Transmitter switch set to ON? b)Is the Singing Machine karaoke machine correctly plugged in and switched on? c)Are the Microphone Volume and Master Volume controls of your Singing Machine set to a high enough level? d)Does the Receiver contain one (1) 9-volt battery, is it properly connected to your Singing Machine, and is it turned on? 2.PROBLEM: The Receiver indicator light is on, but there is no sound when I sing. a)Is the Receiver properly connected to the Singing Machine? b)Is the Transmitter switch set to ON? c)Does the Transmitter contain one (1) 9-volt battery? d)Is the Singing Machine karaoke machine correctly plugged in and switched on? e)Are the Microphone Volume and Master Volume controls of the Singing Machine karaoke machine set to a high enough level? 3.PROBLEM: The Singing Machine karaoke machine I am using is switched on, but there is no sound when I sing. a)Is the Transmitter switch set to ON? b)Does the Transmitter contain one (1) 9-volt battery? c)Are the Microphone Volume and Master Volume controls of your Singing Machine set to a high enough level? d)Does the Receiver contain one (1) 9-volt battery, is it properly connected to your Singing Machine, and is it turned on? Troubleshooting Troubleshooting CAUTION: Two of same microphones should not be used in same location unless with one wireless and one wired microphone. Please call Customer Service at (866) 670-6888 if the Troubleshooting Guide information does not correct your problem. Servicing of a Singing Machine by an unauthorized repair facility will void your warranty. The Singing Machine cannot guarantee future repairs on machines that have been tampered with by unauthorized personnel. 4 NOTE: THE MANUFACTURER IS NOT RESPONSIBLE FOR ANY RADIO OR TV INTERFERENCE CAUSED BY UNAUTHORIZED MODIFICATIONS TO THIS EQUIPMENT. SUCH MODIFICATIONS COULD VOID THE USER AUTHORITY TO OPERATE THE EQUIPMENT. PRINTED IN CHINA The Singing Machine Company, Inc. 6601 Lyons Road, Bldg. A7, Coconut Creek, FL33073-9902, USA. TEL: (954) 596-1000 FAX: (954) 596-2000 VISIT OUR WEBSITE www.singingmachine.com
107t-blk.sch-1 - Mon Dec 08 22:49:15 2003 PDF created with FinePrint pdfFactory trial version http://www.fineprint.com
Technical Description Transmitter High frequency carrier wave is generated by the radio frequency oscillator (crystal 171.905MHz). The carrier wave will be then amplified by frequency amplifier and power amplifier (amplifier the signal by the KS8803BD) before modulation. The modulator mixes the voice signal (i.e.KS8803BD) into the carrier wave and then will be transmitted outside through antenna.
序 号 Part No 使 用 位 置 ADDRESS TAG 使用数量 Qty(pcs) 备 注 Remarks 1IC KS8803BDKS8803BD 集成块IC1011 29018H TRANSISTOR9018H三极管Q103 Q1042 39013 TRANSISTOR9013三极管Q1021 49014 TRANSISTOR9014三极管Q1011 52SC3778 TRANSISTOR2SC3778 三极管Q1051 61N4148 DIODE二极管1N4148D101 D1022 7LED 3mm (RED)3mm灯仔D1031 8CRYSTAL T174.5M(B)晶振T175.00M(B)X1011 9560 RES 1/8W 560欧电阻R118 R1242 101K RES 1/8W1K欧电阻R1061 113.3K RES 1/8W3.3K欧电阻R1171 124.7K RES 1/8W4.7K欧电阻R103 R113 R119 R1214 1310K RES 1/8W10K欧电阻R104 R1232 1412K RES 1/8W12K欧电阻R1221 1515K RES 1/8W15K欧电阻R1092 1627K RES 1/8W27K欧电阻R1151 1733K RES 1/8W33K欧电阻R1011 1839K RES 1/8W39K欧电阻R1071 1947K RES 1/8W47K欧电阻R120 1 20390K RES 1/8W390K欧电阻R1021 213PF C.CAP(NPO)3PF电容C1281 2215PF C.CAP(NPO)15FP电容C112 C125 C129 C1324 2318PF C.CAP(NPO)18PF电容C1271 2422PF C.CAP(NPO)22PF电容C105 C106 C1133 2530PF C.CAP(NPO)30PF电容C1171 2639PF C.CAP(NPO)39PF电容C1211 2747PF C.CAP(NPO)47PF电容C1301 2850PF C.CAP(NPO)50PF电容C114 C1232 29102 C.CAP1000PF电容C88 C118 C124 C126 C131 C133 C134 C1388 30222 C.CAP2200PF电容C1021 31103 C.CAP10000PF电容C108 C110 C119 C120 C1375 32104 C.CAP0.1uF电容C111 C1152 331UF/10V E.CAP 4x7mm1uF电解C1351 344.7UF/10V E.CAP 4x7mm4.7uF电解C101 C103 C1093 35100UF/10V E.CAP 5x7mm100uF电解C107 C1362 363x3T5x0.7mm FM COIL高频线圈L103 L105 L1063 37FT33-25-F1 FM COIL可调电感L101 L1042 386KL-341RO COIL中周T1011 392.2uH CHKOE COIL2.2uH线圈L107 L1082 405mm JUMPER WIRE5mm跳线J2 J3 L107 L1084 第1页 SMM-112 VHF无线咪元件表(171.902MHz) (SMM-112 VHF Cordless Mic TX Part list)(发射) 元 件 名 称 Part Name 序 号 Part No 使 用 位 置 ADDRESS TAG 使用数量 Qty(pcs) 备 注 Remarks 4115mm JUMPER WIRE15mm跳线J41 42SLIDE SW(SK23D04-G5 ) 开关SW1011 43PCB 72x53x1.6mm机板1 443.5mm HEAD PHONE JACK 3.5mm耳机插座JK11 45 STRAND WIRE UL1007 线仔 AWG26 4+25+4mm(BLACK) L=4+25+4mm1 46UL TUBE I.D 2x0.5x10mmUL胶管2 47MIC( * * * )咪头1 48OUTPUT JACK (ANT)天线插座1 49BATTERY PLATE"+"电池片1 50BATTERY PLATE"-"电池片1 51MACHINE SCREW 螺丝 52 MS/KH 2.5x4mm丝牙/平头2 53 MACHINE SCREW 螺丝 MS/BH2.5x10mm丝牙/大头1 54MACHINE HANDLE ( A ) 金属手柄(A)1 55MACHINE HANDLE ( B )金属手柄(B)1 56MACHINE HANDLE ( C )金属手柄©1 57MACHINE GRILL金属(咪)网1 58MACHINE ADORN (RED) 金属装饰圈(红)1 59BATTERY BRACKET(ABS) 电池盒支架1 60MIC BRACKET(A)(ABS) 咪支架(A)1 61MIC BRACKET(B)(ABS) 咪支架(B)1 62KNOB SLIDE (ABS)推钮1 63ADORN NET 35x40mm装饰网3 64GIFT BOX ( * * * )彩盒1 65CARTON卡通 66POLYBAG 0.2PE-HD PE胶袋1 300x100x0.03mm1 67POLYBAG 0.2PE-HD PE胶袋 130x40x0.03mm1 68POLYBAG 0.2PE-HD PE胶袋 200x70x0.03mm1 69MIC CORD 3MM咪线1 70MICROPHONE JACK咪输出插1 第2页 SMM-112 VHF无线咪元件表(171.905MHz) (SMM-112 VHF Cordless Mic TX Part list)(发射) 元 件 名 称 Part Name 序 号 Part No 使 用 位 置 ADDRESS TAG 使用数量 Qty(pcs) 备 注 Remarks 1IC78L05集成块IC21 2IC CXA1691BM(SONY)集成块IC11 39018H TRANSISTOR三极管9018HQ21 4LED 3mm (RED)灯仔LED11 5FILTER J10.7G陶瓷滤波器CF11 6FILTER L10.7A陶瓷滤波器CF2 CF32 7CRYSTAL R174.5M晶振R171.905MX11 81N4148 DIODE二极管1N4148D4 D32 9150 RES 1/8W 150欧电阻R11 10560 RES 1/8W 560欧电阻R101 111K RES 1/8W1K欧电阻R7 R12 2 122.2K RES 1/8W 2.2K欧电阻R51 133.9K RES 1/8W3.9K欧电阻R81 1410K RES 1/8W10K欧电阻R91 1515K RES 1/8W 15K欧电阻R21 1647K RES 1/8W47K欧电阻R31 17200K RES 1/8W200K欧电阻R131 181PF C.CAP(NPO)1P电容C27 1 1915PF C.CAP(NPO)15P电容C5 C82 2022PF C.CAP(NPO)22P电容C61 2127PF C.CAP(NPO)27P电容C10 C282 2230PF C.CAP(NPO)30P电容C4 C312 2339PF C.CAP(NPO)39P电容C26 C292 24103 C.CAP0.01u电容C3 C7 C11 C16 C18 C32 C337 25104 C.CAP0.1uH电容C1 C15 C19 C234 264.7UF/10V E.CAP 4x7mm4.7u电解C2 C20 2 2710UF/10V E.CAP 4x7mm10u电解C9 C12 C17 C304 28100UF/10V E.CAP 5x7mm100u电解C221 293.5x3T5x0.7mm FM COIL高频线圈L2 L5 L63 301uH COIL1uH电感L1 L7 2 313.3uH COIL3.3uH电感L101 32SLIDE SW.1P2T开关SW11定 33METAL BATT PLATE" +"电池片BT11 34METAL BATT SPRING" -"电池 片1 356.3mm PLUG6.3mm插头JK11 36PCB 38x65x1.6mm FR4机板1 37 STRAND WIRE UL1007 线仔1.OUTPUT TO PCB AWG30 4+30+4mm(RED) L=4+30+4mm2.BATTERY "+" TO PCB2 38 STRAND WIRE UL1007 线仔 AWG28 4+500mm(BLACK) L=4+40+4mmANT1 39 MACHINE SCREW 螺丝 TA/PH2x8mm自攻/小头3 40REAR CAB 后壳1 41FRONT CAB前壳1 42BATTERY DOOR电池门1 43POLYBAG 0.2PE-HD PE胶袋 140x60x0.03mm1 元 件 名 称 Part Name SMM-112 VHF无线咪元件表(171.902MHz) (SMM-112 VHF Cordless Mic TX Part list)(接收)
Report No.: 04.05.1056EF Page: 1 of 20 FCC ID: QNISMM-112-T Authorized Signature: Kent Hsu Laboratory Manager SGS-CSTC Co.,Ltd. This report refers to the General Conditions for Inspection and Testing Services, printed overleaf This report details the results of the testing carried out on one sample. The results contained in this test report do not relate to other samples of the same product and does not permit the use of the SGS PRODUCT CERTIFICATION MARK.. The manufacturer should ensure that all products in series production are in conformity with the product sample detailed in this report. This report may only be reproduced and distributed in full. If the product in this report is used in any configuration other than that detailed in the report, the manufacturer must ensure the new system complies with all relevant standards. Any mention of SGS International Electrical Approvals or testing done by SGS International Electrical Approvals in connection with, distribution or use of the product described in this report must be approved by SGS International Electrical Approvals in writing. The report must not be used by the client to claim product certification, approval, or endorsement by NVLAP, NIST, or any agency of the federal government. All test results in this report can be traceable to National or International Standards. Member of the SGS Group (Société Générale de Surveillance) SGS-CSTC Standards Technical Services Ltd. 1/F., Building No. 1 Building, Agriculture Machinery Materials Co. Wushan Road, Shipai, Tianhe District,Guangzhou, China Telephone: +86 (0) 20 3848 1001 Fax: +86 (0) 20 3848 1006 [email protected] FEDERAL COMMUNICATIONS COMMISSION Registration number: 282399 FCC TEST REPORT Application No. : 04.05.1056EF Applicant : International SMC( HK ) Ltd FCC ID : QNISMM-112-T Fundamental Frequency : 171.905MHz Equipment under Test (EUT): Name : Uni-direction Dynamic VHF Wireless Headset Microphone Model : SMM-112 Standards : FCC PART 90: 1997 (Section 90.265) Date of Receipt : 12 May 2004 Date of Test : 20 May to 25 June 2004 Date of Issue : 05 July 2004 Test Result : PASS * * In the configuration tested, the EUT complied with the standards specified above. FCC ID : QNISMM-112-T Report No.: 04.05.1056EF Page: 2 of 20 SGS-CSTC Standards Technical Services Ltd. 2 Contents Page 1 COVER PAGE.........................................................................................................................................................1 2 CONTENTS .............................................................................................................................................................. 2 3 GENERAL INFORMATION.................................................................................................................................. 3 3.1 CLIENT INFORMATION....................................................................................................................................... 3 3.2 DETAILS OF E.U.T. ............................................................................................................................................ 3 3.3 DESCRIPTION OF SUPPORT UNITS....................................................................................................................... 3 3.4 TEST LOCATION................................................................................................................................................. 3 3.5 OTHER INFORMATION REQUESTED BY THE CUSTOMER...................................................................................... 3 3.6 TEST FACILITY................................................................................................................................................... 4 4 TEST RESULTS....................................................................................................................................................... 5 4.1 TEST INSTRUMENTS........................................................................................................................................... 5 4.2 E.U.T. OPERATION............................................................................................................................................ 5 4.3 TEST PROCEDURE & MEASUREMENT DATA....................................................................................................... 6 4.3.1 Power Output ............................................................................................................................................... 6 4.3.2 Filed Strength of Spurious Radiation ........................................................................................................... 8 4.3.3 OCCUPIED BANDWIDTH........................................................................................................................ 11 4.3.4 Modulation Characteristics: ...................................................................................................................... 13 4.3.5 Frequency Stability.................................................................................................................................... 17 5 PHOTOGRAPHS - TEST SETUP........................................................................................................................ 18 6 PHOTOGRAPHS - EUT CONSTRUCTIONAL DETAILS .........................................................................19-20 FCC ID : QNISMM-112-T Report No.: 04.05.1056EF Page: 3 of 20 SGS-CSTC Standards Technical Services Ltd. 3 General Information 3.1 Client Information Applicant: International SMC( HK ) Ltd Address of Applicant: Suite 1210, Ocean Centre, 5 Canton Road, TST, Kowloon, HongKong. 3.2 Details of E.U.T. Product Name: Uni-direction Dynamic VHF Wireless Headset Microphone ( Transmitter Part) Model: SMM-112 Power Supply: 9Vdc (1 x 6F22 Manganin-Zincic alkaline battery) for Transmitter 3.3 Description of Support Units The EUT was tested as a 171.905…
Text truncated - open the document above for the full version.
| # | Rule Parts | Frequency Range | Power Output | Emission | Tolerance |
|---|---|---|---|---|---|
| 1 | 90.265 | 171.905 MHz - 171.905 MHz | 140.00 µW | 54K0F3E | 3800.0000000000 Hz |

Wireless Handheld Microphone
Equipment Class
TNB - Licensed Non-Broadcast Station Transmitter
Wireless Microphone
Equipment Class
TNF - Licensed Non-Broadcast Transmitter Held to Face
Receiver of Wireless Microphone
Equipment Class
CYY - Communications Receiver used w/Pt 15 Transmitter
Wireless Microphone
Equipment Class
DXX - Part 15 Low Power Communication Device Transmitter
