QOQ-917ACBluetooth Low Energy (LE), and Wi-Fi 802.11b/g/n/ax wireless radio module

Silicon Laboratories Finland Oy Alberga Business Park, Bertel Jungin aukio 3 FI-02600 Espoo, Finland www.silabs.com | +358 9 435 5060 Attestation Statements Federal Communications Commission (Authorization and Evaluation Division) 7435 Oakland Mills Road, Columbia, MD 21046, USA TUV SUD BABT UNLIMITED (A Certification Body of TÜV SÜD) Attn: To Whom it May Concern / Application Examiner / Review Engineer / Officer in Charge Re: 1] Attestation Statements Part 2.911(d)(5)(i) Request for FCC ID: QOQ-917AC Re: 2] Attestation Statements Part 2.911(d)(5)(ii) Request for FCC ID: QOQ-917AC Dear Madam or Sir, We, Silicon Laboratories Finland Oy, a corporation branch and subsidiary of USA-based Silicon Laboratories Inc., validly organized and existing under the laws of Finland, having its principal place of business at Alberga Business Park, Bertel Jungin aukio 3, 02600 Espoo, Finland, in relation to our Bluetooth Low Energy (LE) and Wi-Fi 802.11b/g/n/ax wireless radio modules having brand name of SILICON LABS and model names of SiW917Y1GA and SiW917Y1GN, and coming with FCC ID: QOQ-917AC hereby certify that 1] the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules and 2] as of the date of the filing of the application, the applicant is not identified on the Covered List as an entity producing “covered” equipment. Should there be any query regarding this letter with our Attestation Statements, please do not hesitate to contact the undersigned. Thank you for your attention to this matter. Place and date of issue (of this letter): Espoo, September 16, 2024 Authorized Signatory: Enrico Taddeo Job Title: Senior Certifications Lead eMail: [email protected]

Silicon Laboratories Finland Oy Alberga Business Park, Bertel Jungin aukio 3 FI -02600 Espoo, Finland www.silabs.com | +358 9 435 5060 Attestation Statements / Agent Federal Communications Commission (Authorization and Evaluation Division) 7435 Oakland Mills Road, Columbia, MD 21046, USA Attn: To Whom it May Concern / Application Examiner / Review Engineer / Officer in Charge Re: Attestation Statements Part 2.911(d)(7) in relation to request for FCC ID: QOQ-917AC Dear Madam or Sir, We, Silicon Laboratories Finland Oy, a corporation branch and subsidiary of USA-based Silicon Laboratories Inc., validly organized and existing under the laws of Finland, having its principal place of business at Alberga Business Park, Bertel Jungin aukio 3, 02600 Espoo, Finland, as the Applicants with Grantee ID of QOQ and FRN of 0007782659, hereby declare to have authorized Silicon Laboratories Inc., having address of 400 W. Cesar Chavez St., Austin, TX 78701, to act as our designated U.S. Agent for service of process for the above referenced FCC ID, and we accept to maintain an agent for no less than one year after the grantee has terminated all marketing and importation or the conclusion of any Commission-related proceeding involving the equipment. Silicon Laboratories Inc., having Grantee ID of 2ADB9 and FRN of 0023977978, accepts the responsibility to act as designated U.S. Agent for service of process, and accepts to provide an agent for no less than one year after the grantee has terminated all marketing and importation or the conclusion of any Commission-related proceeding involving the equipment. Should there be any query regarding this letter with our Attestation Statement, please do not hesitate to contact the undersigned. Thank you for your attention to this matter. Place: Espoo Date: September 17, 2024 _____________________________________________ Authorized Signatory: Enrico Taddeo (on behalf of the Applicant) Job Title: Senior Certifications Lead eMail: [email protected] Place: Austin, Texas Date: September 17, 2024 _____________________________________________ Authorized Signatory: Efrén Garcia (on behalf of the Agent) Job Title: Senior Legal Counsel, Legal eMail: [email protected]

Silicon Laboratories Finland Oy Alberga Business Park, Bertel Jungin aukio 3 FI-02600 Espoo, Finland www.silabs.com | +358 9 435 5060 Cover Letter for Confidentiality Federal Communications Commission (Authorization and Evaluation Division) 7435 Oakland Mills Road, Columbia, MD 21046 Attn: To Whom it May Concern / Application Examiner / Review Engineer / Officer in Charge Re: Permanent (Long-Term) Confidentiality Request for FCC ID: QOQ-917AC Dear Madam or Sir, We, Silicon Laboratories Finland Oy, a corporation branch and subsidiary of USA-based Silicon Laboratories Inc., validly organized and existing under the laws of Finland, having its principal place of business at Alberga Business Park, Bertel Jungin aukio 3, 02600 Espoo, Finland, pursuant to Sections 0.457 and 0.459 of the Commission’s Rules (CFR 47), hereby request the permanent confidential treatment of the information accompanying our application, as outlined below: Block Diagram, Operational Description, Bill of Materials/Parts List, Schematics, PCB Assembly/Layout The above-mentioned design material relates to the FCC application for equipment authorization in connection with our Bluetooth Low Energy (LE) and Wi-Fi 802.11b/g/n/ax wireless radio modules having brand name of SILICON LABS and model names of SiW917Y1GA and SiW917Y1GN, and coming with FCC ID: QOQ-917AC. The above-mentioned design material contains trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to our business and provide unjustified benefits to our competitors. We understand that pursuant to Rule 0.457, disclosure of the application and all other accompanying documentation shall not be made before the date of the related Grant release. Should there be any query regarding this letter with our request to withhold our confidential design files from public review, please do not hesitate to contact the undersigned. Thank you for your attention to this matter. Place and date of issue (of this letter): Espoo, September 16, 2024 Authorized Signatory: Enrico Taddeo Job Title: Senior Certifications Lead eMail: [email protected]

Silicon Laboratories Finland Oy Alberga Business Park, Bertel Jungin aukio 3 FI-02600 Espoo, Finland www.silabs.com | +358 9 435 5060 Modular Approval Request Letter Federal Communications Commission (Authorization and Evaluation Division) 7435 Oakland Mills Road, Columbia, MD 21046 Attn: To Whom it May Concern / Application Examiner / Review Engineer / Officer in Charge Re: Request for FCC Modular Approval, FCC ID: QOQ-917AC Dear Madam or Sir, We, Silicon Laboratories Finland Oy, a corporation branch and subsidiary of USA-based Silicon Laboratories Inc., validly organized and existing under the laws of Finland, having its principal place of business at Alberga Business Park, Bertel Jungin aukio 3, 02600 Espoo, Finland, hereby request a single-modular approval for the radio equipment referenced above. The self-contained radiofrequency transmitter device, a Bluetooth Low Energy (LE) and Wi-Fi 6 802.11b/g/n/ax wireless module, meets all the requirements for the single-modular approval in accordance with 47 CFR § 15.212 (a) (1) (i) through (viii), as detailed below: 1] The radio portion of the module comes with its own RF shielding. 2] The module has buffered modulation/data inputs to ensure that it complies with Part 15 requirements under conditions of excessive data rates or over-modulation. 3] The module is fully internally regulated, except for the last stage PA. The user manual indicates the host supply voltage range to use, within which the RF compliance to the FCC requirements is demonstrated and ensured. Further to that, the firmware implements a mechanism to prevent transmissions when supply voltage is outside of the intended range. 4] The module comes in a variant with a permanently attached antenna, or in a variant that employs a unique antenna connector, in which case it is marketed to operate only with specific external antenna(s). 5] The module has demonstrated compliance in a stand-alone configuration. 6] The module is equipped with a permanently affixed label displaying its FCC identification. 7] The module does comply with any and all specific rules and operating requirements that are ordinarily applicable to the complete transmitter, including the provision of all the instructions and conditions for maintaining compliance, as detailed in the user manual with integration guidance by the grantee. 8] The module does comply with any and all applicable RF exposure requirements in its final configuration. Should there be any query regarding this request, please do not hesitate to contact the undersigned. Thank you for your attention to this matter. Place and date of issue (of this letter): Espoo, September 16, 2024 Authorized Signatory: Enrico Taddeo Job Title: Senior Certifications Lead eMail: [email protected]

SiW917Y1GA YYWWTTTTTT S i W x 9 1 7 Y 1 x x x G A B x M o d e l : S i W 9 1 7 Y 1 G A F C C I D : Q O Q - 9 1 7 A C I C : 5 1 2 3 A - 9 1 7 A C K C I D : R - R - B G T - 9 1 7 A C C M I I T I D : 2 0 2 4 X X X X X X ( X ) 203-JN1379 R S i W x 9 1 7 Y 1 x x x G A B x M o d e l : S i W 9 1 7 Y 1 G A F C C I D : Q O Q - 9 1 7 A C I C : 5 1 2 3 A - 9 1 7 A C K C I D : R - R - B G T - 9 1 7 A C C M I I T I D : 2 0 2 4 X X X X X X ( X ) YYWWTTTTTT 203-JN1379 R YYWWTTTTTT S i W x 9 1 7 Y 1 x x x G N B x M o d e l : S i W 9 1 7 Y 1 G N F C C I D : Q O Q - 9 1 7 A C I C : 5 1 2 3 A - 9 1 7 A C K C I D : R - R - B G T - 9 1 7 A C C M I I T I D : 2 0 2 4 X X X X X X ( X ) 203-JN1379 R S i W x 9 1 7 Y 1 x x x G N B x M o d e l : S i W 9 1 7 Y 1 G N F C C I D : Q O Q - 9 1 7 A C I C : 5 1 2 3 A - 9 1 7 A C K C I D : R - R - B G T - 9 1 7 A C C M I I T I D : 2 0 2 4 X X X X X X ( X ) YYWWTTTTTT 203-JN1379 R SiW917Y1GN

S i W x 9 1 7 Y 1 x x x G N B x M o d e l : S i W 9 1 7 Y 1 G N F C C I D : Q O Q - 9 1 7 A C I C : 5 1 2 3 A - 9 1 7 A C R YYWWTTTTTT 203-JN1379 YYWWTTTTTT S i W x 9 1 7 Y 1 x x x G A B x M o d e l : S i W 9 1 7 Y 1 G A F C C I D : Q O Q - 9 1 7 A C I C : 5 1 2 3 A - 9 1 7 A C R 203-JN1379

TÜV SÜD is a trading name of TUV SUD Ltd Registered in Scotland at East Kilbride, Glasgow G75 0QF, United Kingdom Registered number: SC215164 TUV SUD Ltd is a TÜV SÜD Group Company Phone: +44 (0) 1489 558100 Fax: +44 (0) 1489 558101 www.tuvsud.com/en TÜV SÜD Octagon House Concorde Way Fareham Hampshire PO15 5RL United Kingdom TÜV SÜD SIGNATURE NAME JOB TITLE RESPONSIBLE FOR ISSUE DATE Steve Marshall Senior Engineer Authorised Signatory 22 August 2024 Signatures in this approval box have checked this document in line with the requirements of TÜV SÜD document control rules. FCC Accreditation 294497/UK2010 Octagon House, Fareham Test Laboratory EXECUTIVE SUMMARY The wireless devices described within this report are compliant with the exemption criteria related to human exposure to electromagnetic fields laid out in FCC CFR Title 47 Part 1.1307. RF Exposure Exemption Report Silicon Laboratories Finland Oy Main Model: SiW917Y1GA Series Model: SiW917Y1GN In accordance with FCC CFR 47 Pt 1.1307 Prepared for: Silicon Laboratories Finland Oy Bertel Jungin Aukio 3 Alberga Business Park 02600 Espoo Finland COMMERCIAL-IN-CONFIDENCE FCC ID: QOQ-917AC Document 75960833-09 Issue: 01 DISCLAIMER AND COPYRIGHT This non-binding report has been prepared by TÜV SÜD with all reasonable skill and care. The document is confidential to the potential Client and TÜV SÜD. No part of this document may be reproduced without the prior written approval of TÜV SÜD. © 2024 TÜV SÜD. This report relates only to the actual item/items tested. ACCREDITATION Our UKAS Accreditation does not cover opinions and interpretations and any expressed are outside the scope of our UKAS Accreditation. Results of tests not covered by our UKAS Accreditation Schedule are marked NUA (Not UKAS Accredited). Document 75960833-09 Issue: 01 COMMERCIAL-IN-CONFIDENCE COMMERCIAL-IN-CONFIDENCE Page 1 of 9 Contents 1 Report Summary .........................................................................................................................2 1.1 Report Modification Record ...........................................................................................................2 1.2 Introduction ....................................................................................................................................2 1.3 Brief Summary of Results .............................................................................................................3 1.4 Application Form ...........................................................................................................................4 1.5 Product Information .......................................................................................................................6 2 Assessment Details ....................................................................................................................7 2.1 Single RF Source options for determination of exemption............................................................7 2.2 Individual Antenna Port Exposure Results ....................................................................................8 Document 75960833-09 Issue: 01 COMMERCIAL-IN-CONFIDENCE COMMERCIAL-IN-CONFIDENCE Page 2 of 9 1 Report Summary 1.1 Report Modification Record Alterations and additions to this report will be issued to the holders of each copy in the form of a complete document. Issue Description of Change Date of Issue 1 First Issue 22-August-2024 Table 1 1.2 Introduction Applicant Silicon Laboratories Finland Oy Manufacturer Silicon Laboratories Finland Oy Model Number(s) Main Model SiW917Y1GA Series Model: SiW917Y1GN Hardware Version(s) 1.0 Software Version(s) Stack’s “Connectivity Firmware” version 2.10.1.2.0.4 (WLAN) Stack’s “Connectivity Firmware” version 2.12.1.0.0.1 (BLE) Specification/Issue/Date FCC 47 CFR Part 1.1307: 2022 Order Number Date PTP ~ 6000530772 08-March-2024 Related Document(s) • KDB 447498 D04 v01 • FCC 47 CFR Part 2.1091: 2023 (Mobile Mode) • FCC 47 CFR Part 2.1093: 2023 (Portable Mode) Document 75960833-09 Issue: 01 COMMERCIAL-IN-CONFIDENCE COMMERCIAL-IN-CONFIDENCE Page 3 of 9 1.3 Brief Summary of Results The wireless devices described within this report are compliant with the exemption criteria related to human exposure to electromagnetic fields laid out in FCC CFR Title 47 Part 1.1307. The calculations shown in this report were made in accordance with the procedures specified in the applied test specification(s). The report has two test tables for the device in a “Mobile Mode” at distances greater than 20 cm and “Portable Mode” at distances lower than 20 cm. Portable mode calculations have been performed to FCC 1.1307(b)(3)(i)(B) Option B (SAR Based Exemption). Mobile mode calculations have been performed to FCC 1.1307(b)(3)(i)(C) ‘Option C’ (MPE Based Exemption). Document 75960833-09 Issue: 01 COMMERCIAL-IN-CONFIDENCE COMMERCIAL-IN-CONFIDENCE Page 4 of 9 1.4 Application Form Equipment Description Technical Description: (Please provide a brief description of the intended use of the equipment) Bluetooth Low Energy (LE), and Wi-Fi 802.11b/g/n/ax wireless radio module Manufacturer: Silicon Laboratories Finland Oy Model: Main Model: SiW917Y1GA (with integral antenna) Series Model: SiW917Y1GN (with no integral antenna but RF pin) Part Number: Not Applicable If more than one frequency band is supported, please confirm which combinations of bands are capable of Simultaneous Transmit. Frequency Band 1: 2.4 GHz WLAN Antenna Model 1: Integral Antenna Antenna length 1: 1.4 cm Antenna Model 2: ANT-2.4-CW-CT-SMA-RPS by TE Connectivity Antenna length 2: 14.2 cm Bottom frequency: 2412 MHz Middle frequency: 2437 MHz Top frequency: 2462 MHz Maximum power (input to the antenna including a tolerance): 20.69 dBm Antenna gain 1 (or maximum gain allowed): 2.26 dBi Antenna gain 2 (or maximum gain allowed): 2.80 dBi Or Field Strength Measurement: dBμA/M Measurement Distance: cm Separation distance from antenna to the user/bysta…

Text truncated - open the document above for the full version.

TÜV SÜD is a trading name of TUV SUD Ltd Registered in Scotland at East Kilbride, Glasgow G75 0QF, United Kingdom Registered number: SC215164 TUV SUD Ltd is a TÜV SÜD Group Company Phone: +44 (0) 1489 558100 Fax: +44 (0) 1489 558101 www.tuvsud.com/en TÜV SÜD Octagon House Concorde Way Fareham Hampshire PO15 5RL United Kingdom TÜV SÜD SIGNATURE NAME JOB TITLE RESPONSIBLE FOR ISSUE DATE Steve Marshall Senior Engineer Authorised Signatory 04 September 2024 Signatures in this approval box have checked this document in line with the requirements of TÜV SÜD document control rules. ENGINEERING STATEMENT The measurements shown in this report were made in accordance with the procedures described on test pages. All reported testing was carried out on a sample equipment to demonstrate limited compliance with FCC 47 CFR Part 15C, ISED RSS-247 and ISED RSS-GEN. The sample tested was found to comply with the requirements defined in the applied rules. RESPONSIBLE FOR NAME DATE SIGNATURE Testing Thomas Biddlecombe 04 September 2024 Ahmad Javid 04 September 2024 George Williams 04 September 2024 FCC Accreditation 492497/UK2010 Octagon House, Fareham Test Laboratory ISED Accreditation 12669A Octagon House, Fareham Test Laboratory EXECUTIVE SUMMARY A sample of this product was tested and found to be compliant with FCC 47 CFR Part 15C: 2022, ISED RSS-247: Issue 3 (08- 2023) and ISED RSS-GEN: Issue 5 (04-2018) + A2 (02-2021) for the tests detailed in section 1.3. FCC and ISED Test Report Silicon Laboratories Finland Oy Main Model: SiW917Y1GA Series Model: SiW917Y1GN In accordance with FCC 47 CFR Part 15C, ISED RSS-247 and ISED RSS-GEN (2.4 GHz WLAN) Prepared for: Silicon Laboratories Finland Oy Bertel Jungin Aukio 3 Alberga Business Park 02600 Espoo Finland FCC ID: QOQ-917AC IC: 5123A-917AC COMMERCIAL-IN-CONFIDENCE Document 75960833-04 Issue 01 DISCLAIMER AND COPYRIGHT This non-binding report has been prepared by TÜV SÜD with all reasonable skill and care. The document is confidential to the potential Client and TÜV SÜD. No part of this document may be reproduced without the prior written approval of TÜV SÜD. © 2024 TÜV SÜD. This report relates only to the actual item/items tested. ACCREDITATION Our UKAS Accreditation does not cover opinions and interpretations and any expressed are outside the scope of our UKAS Accreditation. Results of tests not covered by our UKAS Accreditation Schedule are marked NUA (Not UKAS Accredited). Results of tests covered by our Flexible UKAS Accreditation Schedule are marked FS (Flexible Scope). Document 75960833-04 Issue 01 COMMERCIAL-IN-CONFIDENCE COMMERCIAL-IN-CONFIDENCE Page 1 of 187 Contents 1 Report Summary .........................................................................................................................2 1.1 Report Modification Record ...........................................................................................................2 1.2 Introduction ....................................................................................................................................2 1.3 Brief Summary of Results .............................................................................................................3 1.4 Application Form ...........................................................................................................................5 1.5 Product Information .......................................................................................................................8 1.6 Deviations from the Standard ........................................................................................................8 1.7 EUT Modification Record ..............................................................................................................8 1.8 Test Location .................................................................................................................................9 2 Test Details ............................................................................................................................... 10 2.1 Emission Bandwidth ................................................................................................................... 10 2.2 Maximum Conducted Output Power .......................................................................................... 28 2.3 Power Spectral Density .............................................................................................................. 35 2.4 Spurious Radiated Emissions .................................................................................................... 42 2.5 Restricted Band Edges............................................................................................................. 154 2.6 Authorised Band Edges ........................................................................................................... 169 3 Photographs ........................................................................................................................... 184 3.1 Test Setup Photographs .......................................................................................................... 184 4 Measurement Uncertainty ..................................................................................................... 187 ANNEX A Maximum Conducted Output Power at Extreme Voltages ....................................................... A.1 Document 75960833-04 Issue 01 COMMERCIAL-IN-CONFIDENCE COMMERCIAL-IN-CONFIDENCE Page 2 of 187 1 Report Summary 1.1 Report Modification Record Alterations and additions to this report will be issued to the holders of each copy in the form of a complete document. Issue Description of Change Date of Issue 1 First Issue 04-September-2024 Table 1 1.2 Introduction Applicant Silicon Laboratories Finland Oy Manufacturer Silicon Laboratories Finland Oy Model Number(s) Main Model SiW917Y1GA Series Model: SiW917Y1GN Serial Number(s) WLAN MAC address: ec:f6:4c…

Text truncated - open the document above for the full version.

Document 75960833-04 Issue 01 COMMERCIAL-IN-CONFIDENCE COMMERCIAL-IN-CONFIDENCE Page 69 of 187 Figure 76 - CH6_802.11g_6Mbps_X, 2437 MHz, 30 MHz to 1 GHz, Vertical (Peak) Figure 77 - CH6_802.11g_6Mbps_X, 2437 MHz, 1 GHz to 26 GHz, Vertical Document 75960833-04 Issue 01 COMMERCIAL-IN-CONFIDENCE COMMERCIAL-IN-CONFIDENCE Page 70 of 187 Frequency (MHz) Level (dBμV/m) Limit (dBμV/m) Margin (dB) Detector Angle (°) Height (cm) Polarisation * Table 55 - CH6_802.11g_6Mbps_Y, 2437 MHz, 30 MHz to 26 GHz *No emissions found within 10 dB of the limit. Figure 78 - CH6_802.11g_6Mbps_Y, 2437 MHz, 30 MHz to 1 GHz, Horizontal (Peak) Figure 79 - CH6_802.11g_6Mbps_Y, 2437 MHz, 1 GHz to 26 GHz, Horizontal Document 75960833-04 Issue 01 COMMERCIAL-IN-CONFIDENCE COMMERCIAL-IN-CONFIDENCE Page 71 of 187 Figure 80 - CH6_802.11g_6Mbps_Y, 2437 MHz, 30 MHz to 1 GHz, Vertical (Peak) Figure 81 - CH6_802.11g_6Mbps_Y, 2437 MHz, 1 GHz to 26 GHz, Vertical Document 75960833-04 Issue 01 COMMERCIAL-IN-CONFIDENCE COMMERCIAL-IN-CONFIDENCE Page 72 of 187 Frequency (MHz) Level Limit Margin (dB) Detector Unit Angle (°) Height (cm) Polarisation * Table 56 - CH6_802.11g_6Mbps_Z, 2437 MHz, 30 MHz to 26 GHz *No emissions found within 10 dB of the limit. Figure 82 - CH6_802.11g_6Mbps_Z, 2437 MHz, 30 MHz to 1 GHz, Horizontal (Peak) Figure 83 - CH6_802.11g_6Mbps_Z, 2437 MHz, 1 GHz to 26 GHz, Horizontal Document 75960833-04 Issue 01 COMMERCIAL-IN-CONFIDENCE COMMERCIAL-IN-CONFIDENCE Page 73 of 187 Figure 84 - CH6_802.11g_6Mbps_Z, 2437 MHz, 30 MHz to 1 GHz, Vertical (Peak) Figure 85 - CH6_802.11g_6Mbps_Z, 2437 MHz, 1 GHz to 26 GHz, Vertical Document 75960833-04 Issue 01 COMMERCIAL-IN-CONFIDENCE COMMERCIAL-IN-CONFIDENCE Page 74 of 187 Frequency (MHz) Level Limit Margin (dB) Detector Unit Angle (°) Height (cm) Polarisation * Table 57 - CH11_802.11g_6Mbps_X, 2462 MHz, 30 MHz to 26 GHz *No emissions found within 10 dB of the limit. Figure 86 - CH11_802.11g_6Mbps_X, 2462 MHz, 30 MHz to 1 GHz, Horizontal (Peak) Figure 87 - CH11_802.11g_6Mbps_X, 2462 MHz, 1 GHz to 26 GHz, Horizontal Document 75960833-04 Issue 01 COMMERCIAL-IN-CONFIDENCE COMMERCIAL-IN-CONFIDENCE Page 75 of 187 Figure 88 - CH11_802.11g_6Mbps_X, 2462 MHz, 30 MHz to 1 GHz, Vertical (Peak) Figure 89 - CH11_802.11g_6Mbps_X, 2462 MHz, 1 GHz to 26 GHz, Vertical Document 75960833-04 Issue 01 COMMERCIAL-IN-CONFIDENCE COMMERCIAL-IN-CONFIDENCE Page 76 of 187 Frequency (MHz) Level Limit Margin (dB) Detector Unit Angle (°) Height (cm) Polarisation * Table 58 - CH11_802.11g_6Mbps_Y, 2462 MHz, 30 MHz to 26 GHz *No emissions found within 10 dB of the limit. Figure 90 - CH11_802.11g_6Mbps_Y, 2462 MHz, 30 MHz to 1 GHz, Horizontal (Peak) Figure 91 - CH11_802.11g_6Mbps_Y, 2462 MHz, 1 GHz to 26 GHz, Horizontal Document 75960833-04 Issue 01 COMMERCIAL-IN-CONFIDENCE COMMERCIAL-IN-CONFIDENCE Page 77 of 187 Figure 92 - CH11_802.11g_6Mbps_Y, 2462 MHz, 30 MHz to 1 GHz, Vertical (Peak) Figure 93 - CH11_802.11g_6Mbps_Y, 2462 MHz, 1 GHz to 26 GHz, Vertical Document 75960833-04 Issue 01 COMMERCIAL-IN-CONFIDENCE COMMERCIAL-IN-CONFIDENCE Page 78 of 187 Frequency (MHz) Level Limit Margin (dB) Detector Unit Angle (°) Height (cm) Polarisation * Table 59 - CH11_802.11g_6Mbps_Z, 2462 MHz, 30 MHz to 26 GHz *No emissions found within 10 dB of the limit. Figure 94 - CH11_802.11g_6Mbps_Z, 2462 MHz, 30 MHz to 1 GHz, Horizontal (Peak) Figure 95 - CH11_802.11g_6Mbps_Z, 2462 MHz, 1 GHz to 26 GHz, Horizontal Document 75960833-04 Issue 01 COMMERCIAL-IN-CONFIDENCE COMMERCIAL-IN-CONFIDENCE Page 79 of 187 Figure 96 - CH11_802.11g_6Mbps_Z, 2462 MHz, 30 MHz to 1 GHz, Vertical (Peak) Figure 97 - CH11_802.11g_6Mbps_Z, 2462 MHz, 1 GHz to 26 GHz, Vertical Document 75960833-04 Issue 01 COMMERCIAL-IN-CONFIDENCE COMMERCIAL-IN-CONFIDENCE Page 80 of 187 Frequency (MHz) Level (dBμV/m) Limit (dBμV/m) Margin (dB) Detector Angle (°) Height (cm) Polarisation * Table 60 - CH1_HE20_MCS0_X, 2412 MHz, 30 MHz to 26 GHz *No emissions found within 10 dB of the limit. Figure 98 - CH1_HE20_MCS0_X, 2412 MHz, 30 MHz to 1 GHz, Horizontal (Peak) Figure 99 - CH1_HE20_MCS0_X, 2412 MHz, 1 GHz to 26 GHz, Horizontal Document 75960833-04 Issue 01 COMMERCIAL-IN-CONFIDENCE COMMERCIAL-IN-CONFIDENCE Page 81 of 187 Figure 100 - CH1_HE20_MCS0_X, 2412 MHz, 30 MHz to 1 GHz, Vertical (Peak) Figure 101 - CH1_HE20_MCS0_X, 2412 MHz, 1 GHz to 26 GHz, Vertical Document 75960833-04 Issue 01 COMMERCIAL-IN-CONFIDENCE COMMERCIAL-IN-CONFIDENCE Page 82 of 187 Frequency (MHz) Level (dBμV/m) Limit (dBμV/m) Margin (dB) Detector Angle (°) Height (cm) Polarisation * Table 61 - CH1_HE20_MCS0_Y, 2412 MHz, 30 MHz to 26 GHz *No emissions found within 10 dB of the limit. Figure 102 - CH1_HE20_MCS0_Y, 2412 MHz, 30 MHz to 1 GHz, Horizontal (Peak) Figure 103 - CH1_HE20_MCS0_Y, 2412 MHz, 1 GHz to 26 GHz, Horizontal Document 75960833-04 Issue 01 COMMERCIAL-IN-CONFIDENCE COMMERCIAL-IN-CONFIDENCE Page 83 of 187 Figure 104 - CH1_HE20_MCS0_Y, 2412 MHz, 30 MHz to 1 GHz, Vertical (Peak) Figure 105 - CH1_HE20_MCS0_Y, 2412 MHz, 1 GHz to 26 GHz, Vertical Document 75960833-04 Issue 01 COMMERCIAL-IN-CONFIDENCE COMMERCIAL-IN-CONFIDENCE Page 84 of 187 Frequency (MHz) Level Limit Margin (dB) Detector Unit Angle (°) Height (cm) Polarisation * Table 62 - CH1_HE20_MCS0_Z, 2412 MHz, 30 MHz to 26 GHz *No emissions found within 10 dB of the limit. Figure 106 - CH1_HE20_MCS0_Z, 2412 MHz, 30 MHz to 1 GHz, Horizontal (Peak) Figure 107 - CH1_HE20_MCS0_Z, 2412 MHz, 1 GHz to 26 GHz, Horizontal Document 75960833-04 Issue 01 COMMERCIAL-IN-CONFIDENCE COMMERCIAL-IN-CONFIDENCE Page 85 of 187 Figure 108 - CH1_HE20_MCS0_Z, 2412 MHz, 30 MHz to 1 GHz, Vertical (Peak) Figure 109 - CH1_HE20_MCS0_Z, 2412 MHz, 1 GHz to 26 GHz, Vertical Document 75960833-04 Issue 01 COMMERCIAL-IN-CONFIDENCE COMMERCIAL-IN-CONFIDENCE Page 86 of 187 Frequency (MHz) Level (dBμV/m) Limit (dBμV/m) Margin (dB) Detector Angle (°) Height (cm) Polarisation * Table 63 - CH6_HE20_MCS0_X, 2437 MHz, 30 MHz to 26 GHz *No emissions found within 10 dB of the limit. Figure …

Text truncated - open the document above for the full version.

Document 75960833-04 Issue 01 COMMERCIAL-IN-CONFIDENCE COMMERCIAL-IN-CONFIDENCE Page 110 of 187 Frequency (MHz) Level Limit Margin (dB) Detector Unit Angle (°) Height (cm) Polarisation * Table 75 - CH11_802.11b_1Mbps_X, 2462 MHz, 30 MHz to 26 GHz *No emissions found within 10 dB of the limit. Figure 158 - CH11_802.11b_1Mbps_X, 2462 MHz, 30 MHz to 1 GHz, Horizontal (Peak) Figure 159 - CH11_802.11b_1Mbps_X, 2462 MHz, 1 GHz to 26 GHz, Horizontal Document 75960833-04 Issue 01 COMMERCIAL-IN-CONFIDENCE COMMERCIAL-IN-CONFIDENCE Page 111 of 187 Figure 160 - CH11_802.11b_1Mbps_X, 2462 MHz, 30 MHz to 1 GHz, Vertical (Peak) Figure 161 - CH11_802.11b_1Mbps_X, 2462 MHz, 1 GHz to 26 GHz, Vertical Document 75960833-04 Issue 01 COMMERCIAL-IN-CONFIDENCE COMMERCIAL-IN-CONFIDENCE Page 112 of 187 Frequency (MHz) Level Limit Margin (dB) Detector Unit Angle (°) Height (cm) Polarisation * Table 76 - CH11_802.11b_1Mbps_Y, 2462 MHz, 30 MHz to 26 GHz *No emissions found within 10 dB of the limit. Figure 162 - CH11_802.11b_1Mbps_Y, 2462 MHz, 30 MHz to 1 GHz, Horizontal (Peak) Figure 163 - CH11_802.11b_1Mbps_Y, 2462 MHz, 1 GHz to 26 GHz, Horizontal Document 75960833-04 Issue 01 COMMERCIAL-IN-CONFIDENCE COMMERCIAL-IN-CONFIDENCE Page 113 of 187 Figure 164 - CH11_802.11b_1Mbps_Y, 2462 MHz, 30 MHz to 1 GHz, Vertical (Peak) Figure 165 - CH11_802.11b_1Mbps_Y, 2462 MHz, 1 GHz to 26 GHz, Vertical Document 75960833-04 Issue 01 COMMERCIAL-IN-CONFIDENCE COMMERCIAL-IN-CONFIDENCE Page 114 of 187 Frequency (MHz) Level Limit Margin (dB) Detector Unit Angle (°) Height (cm) Polarisation * Table 77 - CH11_802.11b_1Mbps_Z, 2462 MHz, 30 MHz to 26 GHz *No emissions found within 10 dB of the limit. Figure 166 - CH11_802.11b_1Mbps_Z, 2462 MHz, 30 MHz to 1 GHz, Horizontal (Peak) Figure 167 - CH11_802.11b_1Mbps_Z, 2462 MHz, 1 GHz to 26 GHz, Ho…
