Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.
CONFIDENTIALITY REQUEST FOR FCCID:QQ2-GAOFDM900Q Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 Gentlemen: This letter is to comply with Section 0.457(d)(2)(i) pertaining to confidential material. WaveIP Ltd. would like the following documents regarding this submission for FCC ID: QQ2-GAOFDM900Q to be kept confidential. 1. Pages 1 of 5 of document GA OFDM 900Q_Radio_Scheme 2. Pages 1 of document GA OFDM 900Q_Clock_Tree 3. Pages 1 of document GA OFDM 900Q_Power_Tree. 4. Pages 1 to 41 of document GA OFDM 900Q_user_guide. The above material contains trade secrets or technical data, which would customarily be guarded from competitors. We do not want these documents to be accessible to the general public. Sincerely, Company Name: WaveIP Ltd. Technical Contact: Michael Dayan Phone: 972-4-9937333 ext. 121 Fax: 972-4-9592614 Email: [email protected] Address: 1 Tavor Building P.O.B 335 Yokneam 20692, Israel 1/1
Internal External Picture for GAOFDM900Q FCC ID: QQ2-GAOFDM900Q Subject: Internal & External pictures for GigAccess 900Q FCC ID:QQ2- GAOFDM900Q 1/4 Internal External Picture for GAOFDM900Q 2/4
Lable ARTWORK FCCID:QQ2-GAOFDM900Q LOCATION OF LABLE ON TEST ITEM 1/1
Internal External Picture for GAOFDM900Q 3/4 Internal External Picture for GAOFDM900Q 4/4
Subject: Operational Description FCCID GAofdm900 1/3 2/3 3/3
Antenna Information GA OFDM 900Q 1/7 Antenna Information GA OFDM 900Q Antenna Type-MTI-262002 Back Side Antenna Type-MTI-262002 Front Side 2/7 Antenna Information GA OFDM 900Q Antenna Type-MA-1S91-T2 Back Side Antenna Type-MA-1S91-T2 Front Side 3/7 Antenna Information GA OFDM 900Q Antenna Type-MTI-262001 Back Side Antenna Type-MTI-262001 Front Side 4/7 Antenna Information GA OFDM 900Q Antenna Type-MTI-263006 Back Side Antenna Type-MTI-263006 Front Side 5/7 Antenna Information GA OFDM 900Q Antenna Type-Omni HG908U 6/7 Antenna Information GA OFDM 900Q Antenna Type-Omni HG908U 7/7
FCC ID: QQ2-GAOFDM900Q Subject: Environmental evaluation and Exposure limit according to FCC CFR 47 §15.247(b)(5) and §1.1307, §1.1310 Limit for power density for general population /uncontrolled exposure is 0.603 mW/cm² (for 905MHz) The Power density: P (mW/cm²)= P T /4π R² where P T is the maximum transmitted power, which is equal to the transmitter output power 26.22 dBm plus the maximum antenna gain 12.5 dBi, the maximum equivalent isotropically radiated power EIRP is: P R = P T + antenna gain = 27.75 dBm + 12.5dBi = 40.25 dBm = 10.59W Hence, according to 15.247(b)(4) the maximum transmitted power shall be reduced below the limit stated in 15.247(b)(3) by: Power Limit Correction factor = (maximum antenna gain dBi - 6 dB) dB In our case the transmitted power shall be reduced below: Power Limit Correction factor = 12.5 dBi - 6 dBi = 6.5 dB P Limit1 = P Limit - Power Limit Correction factor = 30 dBm – 6.5 dB = 23.5 dBm Power Reduction factor = P T – P Limit1 = 27.75 dBm – 23.5 dBm = 4.24 dB P T1 = P T – Power Reduction factor = 27.75 dBm – 4.24 dB = 23.5 dBm Corrected radiated P R = 23.5 dBm + 12.5dBi = 36 dBm = 4 W The minimum safe distance “R” where RF exposure does not exceed FCC permitted limit is 17.5 cm. R=sqrt (P R / 0.603 mW/cm² *4π)= sqrt (4000/7.58)= 22.97 cm The actual Safety distance shall be Not less than 30 cm 1/1
Ga-ofdm-900Q WaveIP EMI Test Report EMC/30020FC05116 1 /124 REV ∆ Description Sheet Effected Date Drawn Checked A 01.09.05 D.Lanuel S.Cohen EMC Laboratory Manufactured by WaveIP Ltd. EMC Test Report According FCC Part 15 Requirements SEP 2005 Function/Title Name Signatur e Date Prepared b Test Engineer D.Lanuel 01.09.05 Checked by Test Engineer D.Lanuel 01.09.05 Approved by EMC Lab. Manager S.Cohen 01.09.05 Ga-ofdm-900Q WaveIP EMI Test Report EMC/30020FC05116 2/124 Table of Contents Para Page 1 GENERAL INFORMATION........................................................................................................... 3 2 TEST SUMMARY AND SIGNATURES........................................................................................... 4 3 EUT DESCRIPTION..................................................................................................................... 5 4 OCCUPIED BANDWIDTH FOR DSSS SYSTEM ACCORDING TO 15.247(A) (2)........................... 6 5 MAXIMUM PEAK OUTPUT POWER TEST ACCORDING 15.247(B) (3)........................................ 8 6 OUT OF BAND CONDUCTED EMISSION TEST ACCORDING T0 15.247(C)............................... 11 7 RADIATED EMISSION IN RESTRICTED BANDS TEST ACCORDING 15.247(C), 15.205 AND 15.209 ........................................................................................................................................... 13 8 PEAK POWER SPECTRAL DENSITY OF DSSS ACCORDING 15.247D........................................ 19 9 UNINTENTIONAL RADIATED EMISSION TEST ACCORDING TO 15.109.................................. 21 10 CONDUCTED EMISSION TEST ACCORDING TO 15.207.15.107........................................... 23 11 PLOTS................................................................................................................................... 26 12 CORRECTION FACTORS..................................................................................................... 122 13 ABBREVIATIONS AND ACRONYMS.................................................................................... 124 Ga-ofdm-900Q WaveIP EMI Test Report EMC/30020FC05116 3/124 1 GENERAL Information a. Description of equipment under test Equipment Under Test: Ga-ofdm-900Q FCCID: QQ2-GAOFDM900Q Manufacturer: WaveIP. Serial Numbers: 00-50C21CCD86 Mode of Operation: TX MODE Operating frequency: 902-928MHZ Year of Manufacture: 2005 b. Applicant Information: Applicant: WaveIP Ltd. Applicant Address TAVOR Building YOKNEAM Telephone: +972-4-9937333 FAX: +972-4-9592614 The testing was observed by: Yoram Singer Following applicant's personnel: Yoram Singer c. Test Performance: Date of reception for testing: 25.08.05 Dates of testing 25.08.05 Test Laboratory Location TADIRAN EMC LAB, Hashoftim 26 Holon 58102 ISRAEL Tel: 972-3-5574476 Fax: 972-3- 5575320 Applicable EMC Specification: Federal Communication Commission (FCC), Code of Federal Regulations 47, FCC Docket 89-103, Part 15: Radio Frequency Devices, Sections 15.109, 15.209 & 15.207, 15.205, 15.247. Ga-ofdm-900Q WaveIP EMI Test Report EMC/30020FC05116 4 /124 2 Test Summary and Signatures. TADIRAN EMC Laboratory has completed testing of E.U.T in accordance with the requirements of the FCC 15.247 The E.U.T was found to comply with the requirements of the FCC Part 15.247 Regulations given below Test Description Specificatio n Referenc e Date of Testing Test Report Paragraph Compliance PASS/FAIL Occupied 6db bandwidth 15.247 (a) (2) 25/08/05 4 PASS Max peak output power 15.247 (b) (3) 25/08/05 5 PASS Out of band Conducted emission 15.247 (c) 25/08/05 6 PASS Spurious emission radiated In Restricted band 15.209 15.205(a ,c) 25/08/05 7 PASS Peak power spectral density 15.247 (d) 25/08/05 8 PASS Unintentional radiated emission 15.109 25/08/05 9 PASS Conducted emission 15.207 25/08/05 10 pass a. Test performed by: Mr. D. Lanuel Test Engineer b. Test Report prepared by: Mr. D. Lanuel Test Engineer c. Test Report Approved by: Mr. Samuel Cohen EMC Lab. Manager Ga-ofdm-900Q WaveIP EMI Test Report EMC/30020FC05116 5 /124 3 EUT Description a. General Model Number(s): Ga-ofdm-900Q Brief Description (Purpose of Device): GigAccess TM 900Q is WaveIP’s wireless point-to-point and point-to-multipoint broadband communication system. The basic subsystem is composed of a single sector, which consists of an AU (Access Unit) and up to 128 SUs (Subscriber Units). Each sector is a stand-alone communication network operating on a star topology with a gateway to the WAN, which allows two-way communication between the SUs and the WAN via the AU. A Sector may be divided into sub sectors, which are consecutive to the SUs within the sector. b. E.U.T Test Configuration EUT test configuration is shown in figure bellow AC Power Source EUT Laptop Antenn Adapter a c. n description (1) Transmit 30dbm-905MHz (2) Transmit 30dbm-915MHz (3) Transmit 30dbm-925MHz (4) Standby (5) Transmitter Power Source Adapter 220VAC/12VDC E.U.T Mode of Operatio Ga-ofdm-900Q WaveIP EMI Test Report EMC/30020FC05116 6 /124 4 Occupied Bandwidth for DSSS System According to 15.247(a) (2) E.U.T: Ga-ofdm-900Q S/N: 0050C21CCD86 Test Method: ANSI 63.4 Date: 25/08/05 Relative Humidity: 26% Ambient Temperature: 22c Air Pressure: 1047hpa Testing Engineer: D.Lanuel Date 01/09/05 a. Test Results Summary & Conclusions The E.U.T was found in compliance with OCCUPIED BANDWIDTH b. Limits of bandwidth The test unit shall meet the limits of Table 4.b Table 4.b Limits For Bandwidth Operating Frequency (MHz) Minimum allowed bandwidth 902 - 928 ≥500KHz for 6dbc c. Test Results Table 4.c Bandwidth Test Result Frequency (MHz) Min Bandwidth (MHz) Bandwidth Max Limit(KHz) Plot Results PASS/ FAIL 905 6.37 Plot-1 PASS 915 6.22 Plot-2 PASS 925 5.93 ≥500KHz Plot-3 PASS d. Test Instrumentation and Equipment Table 4.d Test Instrumentation and Equipment Item Model Manufacturer Next Date Calibration Spectrum Analyzer 8593E HP 31/01/06 Broadband Antenna BTA-L FRANKONIA 10.04.06 20db attenuator 2525-200 ATM …
Text truncated - open the document above for the full version.
SET UP PICTURE FOR GAOFDM900Q FCC ID: QQ2-GAOFDM900Q- Subject: SETUP PICTURES for GigAccess 900Q FCC ID:QQ2-GAOFDM900Q Radiated emission up to 30MHz Setup 1/3 SET UP PICTURE FOR GAOFDM900Q Radiated emission 30MHz – 1GHz Setup 2/3 SET UP PICTURE FOR GAOFDM900Q Radiated emission 1GHz – 18GHz Setup 3/3
| # | Rule Parts | Frequency Range | Power Output |
|---|---|---|---|
| 1 | 15C | 905 MHz - 925 MHz | 596.00 mW |

Point-to-Point & Point-to-Multipoint broadband wireless bridge
Equipment Class
DTS - Digital Transmission System
Point-to-Point & Point-to-Multipoint broadband wireless bridge
Equipment Class
TNB - Licensed Non-Broadcast Station Transmitter
Point-to-Point & Point-to-Multipoint broadband wireless bridge
Equipment Class
DTS - Digital Transmission System
Outdoor Transmitter Unit
Equipment Class
TNB - Licensed Non-Broadcast Station Transmitter
Indoor Transmitter Unit
Equipment Class
TNB - Licensed Non-Broadcast Station Transmitter
