Theory of Operation Description of Circuit Operation (1) Baseband : The smartphone is using the TI solution with two ARM processor for PDA & GSM code called Perseus . Perseus can control LCD displayer, USB, Keypad, UART, IRDA, SDRAM, Flash(16-64Mbytes), Enhance Audio Codec with 44.1kHz. And it support 32kHz crystal for Big/Deep sleep function for Power consumption. It also include a DSP called Nausica (Omega) with ADC, Battery/charging manager, SIM and RF/BB interface function. (2) Memery: ARM9 will copy the flash to SDRAM to run the Stinger code(PDA) and GSM code in SDRAM during the power/on to the stinger operating system. In the same time, the DPLL clock will rise to 108Mhz. (3) Audio Codec The Perseus build in the Audio Codec function. It also support the I2C control interface for Enhance stereo audio D/A converter and Although the sampling rate can reach to 8khz but this sampling rate is not enough for MP3 player. Thus, the U401 TVL320DAC converter can enhance it to 44.1kHz. The audio can separate as earphone, speaker, and receiver path. Audio can change path by plugging in the earphone jack or

Compal Communications, Inc. 7 th FL, No. 319, Sec. 4, Pa-Teh Rd, Taipei, Taiwan. Federal Communications Commission Date: October 25, 2002 Authorization and Evaluation Division Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MD 21046 Re: Request for Confidentiality In reference to the application under FCC ID: QQX-AR11 and pursuant to Sections 0.457(d)(1)(ii) and 0.459 of the Commission's Rules, the Applicant hereby requests confidential treatment of the accompanying information as outlined below: 1. Technical Specification 2. Schematic 3. Part list 4. Tune-up Procedure 5. Theory of Operation of the subject application The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the Applicant and provide unjustified benefits to its competitors. The Applicant understands that pursuant to Rule 0.457(d)(1)(ii), disclosure of this Application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely, Soros Huang Project Leader Compal Communications, Inc. Compal Communications, Inc.

From: Thu Chan Sent: Wednesday, December 04, 2002 5:48 PM To: Mike Kuo Cc: Helen Zhao; Michael Heckrotte; Scott Wang; Steve Cheng; Thu Chan Subject: FW: Compal Communications, Inc., FCC ID:QQX-AR11, AN02T2429 Follow Up Flag: Follow up Flag Status: Flagged Dear Mike, Please review all the answers below. Thank you. Best Regards, Thu Notice_content ------------- Notice #2: Part 24 Portion: Question #1: Please provide emission designator and provide test data plot to justify the necessary bandwidth. _ 240KGXW. Please see "99%BW" plot. Question #2: EUT is positioned vertically but the EIRP readings demonstrated when the receiving antenna is at horizontal polarization emits the higher power. Please explain. _ Actually, we did test the EUT on all different X, Y, & Z positions, and found that the maximum reading was coming from Z-Rear lay-down position. That’s why the receiving antenna was picking the maximum power on horizontal polarity. Please see attached "Fundamental Circuit Switched X-Y-Z Positions" data for more detail. Question #3: There are two mode of operation were tested, one is packet data and the other one is circuit switch. Please clearly explain the test condition and procedures used during the tests and also provide the any additional support equipment used to establish the communication. _ Because EUT can use only one channel to upload the data to server for GPRS level 8, also it’s considering same as generic GSM protocol. So, GPRS test has been intentionally bypassed. Question #4: The max. conducted output power measured during SAR tests is 29.2dBm but the highest EIRP is 28.4dBm. Please provide a spectrum plots to show the max. conducted output power used during EIRP measurements. _ We measured the maximum RF conducted output power was 29.5dBm @ low channel, and the EIRP was 28.4dBm which the antenna gain ~0dBi. Please see attached "RF conducted output power L-M-H" plot for your reference. Best Regards Mike Kuo The items indicated above must be submitted before processing can continue on the above referenced application. Failure to provide the requested information within 60 days of the original e-mail date may result in application dismissal and forfeiture of the filing fee. Also, please note that partial responses increase processing time and should not be submitted. Any questions about the content of this correspondence should be directed to the e-mail address listed below the name of the sender.

PROPOSED FCC ID LABEL AND LOCATION Compal Communications Inc. This device complies with Part 24 of the FCC Rules. FCC ID: QQX-AR11 FCC ID LABEL LOCATION

System Validation - D1800V2 S/N: 294 (Antenna input power: 250 mW) SAM-1; Flat Probe: ET3DV6 - SN1578; ConvF(5.50,5.50,5.50); Crest factor: 1.0 Head 1800 MHz: σ = 1.35 mho/m ε r = 39.5 ρ = 1.00 g/cm 3 Cube 5x5x7: Peak: 16.9 mW/g, SAR (1g): 9.17 mW/g, SAR (10g): 4.82 mW/g, (Worst-case extrapolation) Penetration depth: 8.4 (8.0, 9.3) [mm] Powerdrift: 0.01 dB Ambient Temperature (degree C): 22.0 Liquid Temperature (degree C): 20.5 SAR Tot [mW/g] 1.00E+0 3.00E+0 5.01E+0 7.01E+0 9.01E+0 11/14/02 COMPLIANCE CERTIFICATION SERVICES System Validation - D1800V2 S/N: 294 (Antenna input power: 250 mW) SAM-1; Probe: ET3DV6 - SN1578; ConvF(5.50,5.50,5.50); Crest factor: 1.0 Head 1800 MHz: σ = 1.35 mho/m ε r = 39.5 ρ = 1.00 g/cm 3 : , , () Penetration depth: 8.5 (8.0, 9.4) [mm] Ambient Temperature (degree C): 22.0 Liquid Temperature (degree C): 20.5 11/14/02 COMPLIANCE CERTIFICATION SERVICES 0 2 4 6 8 10 12 14 16 18 0102030405060708090100110 SAR tot [mW/g] [mm]

REPORT NO: 02T1648-2 DATE: November 15, 2002 FCC ID: QQX-AR11 COMPLIANCE CERTIFICATION SERVICES Page: 18 of 25 This report shall not be reproduced except in full, without the written approval of CCS. This document may be altered or revised by Compliance Certification Services personnel only, and shall be noted in the revision section of the document. 8.4. EUT SETUP PHOTOS Left Hand - Touch Position Left Hand - Tilt Position REPORT NO: 02T1648-2 DATE: November 15, 2002 FCC ID: QQX-AR11 COMPLIANCE CERTIFICATION SERVICES Page: 19 of 25 This report shall not be reproduced except in full, without the written approval of CCS. This document may be altered or revised by Compliance Certification Services personnel only, and shall be noted in the revision section of the document. Right Hand - Touch Position Right Hand - Tilt Position REPORT NO: 02T1648-2 DATE: November 15, 2002 FCC ID: QQX-AR11 COMPLIANCE CERTIFICATION SERVICES Page: 20 of 25 This report shall not be reproduced except in full, without the written approval of CCS. This document may be altered or revised by Compliance Certification Services personnel only, and shall be noted in the revision section of the document. Flat - Body Configuration Note(s): 2. Separation distance of 1.5 cm between the back of the EUTand flat phantom 3. The Ear-microphone wire connected to the phone to simulate hands-free operation in a body-worn configuration.

in accordance with the requirements of FCC Report and Order: ET Docket 93-62, and OET Bulletin 65 Supplement C for Windows   Powered Smartphone MODEL: AR11 FCC ID: QQX-AR11 November 15, 2002 REPORT NO: 02T1648-2 Prepared for Compal Communications, Inc. 7 th Fl., No. 319, Sec. 4 Pa-Teh Road Taipei, Taiwan, R. O. C. Prepared by COMPLIANCE CERTIFICATION SERVICES 561F MONTEREY ROAD, MORGAN HILL, CA 95037, USA TEL: (408) 463-0885 REPORT NO: 02T1648-2 DATE: November 15, 2002 FCC ID: QQX-AR11 COMPLIANCE CERTIFICATION SERVICES Page: 2 of 25 This report shall not be reproduced except in full, without the written approval of CCS. This document may be altered or revised by Compliance Certification Services personnel only, and shall be noted in the revision section of the document. CERTIFICATE OF COMPLIANCE (SAR EVALUATION) DATES OF TEST: November 14 ~ 15, 2002 REPORT NO: 02T1648-2 APPLICANT: Compal Communications, Inc. 7 th Fl., No. 319, Section 4, Pa-Teh Road Taipei, Taiwan, R.O.C. MODEL: AR11 FCC ID: QQX-AR11 DEVICE CATEGORY: PORTABLE DEVICES EXPOSURE CATEGORY: GENERAL POPULATION/UNCONTROLLED EXPOSURE Test Sample is a: Production unit Modulation type: GSM+GPRS Operating Mode: Maximum continuous output Tx Frequency: 1850.2 ~ 1909.8 MHz Max. Conducted O/P Power: 29.2 dBm (1850.2 MHz) Max. SAR (1g): 1.36 W/Kg (at 1909.8 MHz; Right head, tilted position) 0.246 W/Kg (at 1850.2 MHz; body-worn position) Application Type: Certification FCC Rule Part(s): 24 (E) This wireless portable device has been shown to be capable of compliance for localized specific absorption rate (SAR) for uncontrolled environment/general population exposure limits specified in ANSI/IEEE Std. C95.1-1992 and had been tested in accordance with the measurement procedures specified in FCC OET 65 Supplement C (released on 6/29/2001 see Test Report). I attest to the accuracy of data. All measurements reported herein were performed by me or were made under my supervision and are correct to the best of my knowledge and belief. I assume full responsibility for the completeness of these measurements and vouch for the qualifications of all persons taking them. Steve Cheng EMC Engineering Manager REPORT NO: 02T1648-2 DATE: November 15, 2002 FCC ID: QQX-AR11 COMPLIANCE CERTIFICATION SERVICES Page: 3 of 25 This report shall not be reproduced except in full, without the written approval of CCS. This document may be altered or revised by Compliance Certification Services personnel only, and shall be noted in the revision section of the document. TABLE OF CONTENT 1. EUT DESCRIPTION .................................................................................................... 4 2. REQUIREMENTS FOR COMPLIANCE TESTING DEFINED BY THE FCC ...................... 5 3. DOSIMETRIC ASSESSMENT SETUP .......................................................................... 5 3.1. MEASUREMENT SYSTEM DIAGRAM ........................................................................................................6 3.2. SYSTEM COMPONENTS ............................................................................................................................7 4. EVALUATION PROCEDURE ...................................................................................... 9 5. MEASUREMENT UNCERTAINTY .............................................................................. 12 6. EXPOSURE LIMIT .................................................................................................... 13 7. EUT ARRANGEMENT .............................................................................................. 14 8. MEASUREMENT RESULTS ...................................................................................... 15 8.1. SYSTEM VALIDATION ..............................................................................................................................15 8.2. TEST LIQUID CONFIRMATION.................................................................................................................16 8.3. EUT TUNE-UP PROCEDURE....................................................................................................................17 8.4. EUT SETUP PHOTOS ...............................................................................................................................18 8.5. SAR MEASUREMENT RESULTS..............................................................................................................21 9. EUT PHOTOS .......................................................................................................... 22 10. EQUIPMENTS LIST & CALIBRATION INFORMATION ............................................... 23 11. REFERENCES ......................................................................................................... 24 12. ATTACHMANTS ...................................................................................................... 25 REPORT NO: 02T1648-2 DATE: November 15, 2002 FCC ID: QQX-AR11 COMPLIANCE CERTIFICATION SERVICES Page: 4 of 25 This report shall not be reproduced except in full, without the written approval of CCS. This document may be altered or revised by Compliance Certification Services personnel only, and shall be noted in the revision section of the document. 1. EUT DESCRIPTION APPLICANT: Compal Communications, Inc. 7 th Fl., No. 319, Section 4, Pa-Teh Road Taipei, Taiwan, R.O.C. MODEL: AR11 FCC ID: QQX-AR11 DEVICE CATEGORY: PORTABLE DEVICES EXPOSURE CATEGORY: GENERAL POPULATION/UNCONTROLLED EXPOSURE Test Sample is a: Production unit Modulation type: GSM+GPRS Operating Mode: Maximum continuous output Tx Frequency: 1850.2 ~ 1909.8 MHz Max. Conducted O/P Power: 29.2 dBm (1850.2 MHz) Max. SAR (1g): 1.36 W/Kg (at 1909.8 MHz; Right head, tilted position) 0.246 W/Kg (at 1850.2 MHz; body-worn position) Application Type: Certification FCC Rule Part(s): 24 (E) Antenna Type: Monopole Dimensions: Length = 20.7 mm Diameter = 9.4 mm Battery option: Only one model with EUT 1 Spe…

Text truncated - open the document above for the full version.

Compal (Model: AR11), Frequency: 1850.2 MHz (Left head - Touch) Frequency: 1900 MHz; Crest factor: 8.0 Medium: Head 1900 MHz: σ = 1.35 mho/m ε r = 40.5 ρ = 1.00 g/cm 3 SAM-1 Phantom; Left Hand Section; Position: (91°,60°) Probe: ET3DV6 - SN1578; ConvF(5.50,5.50,5.50); SAR:Cube 5x5x7: Peak: 1.09 mW/g, SAR (1g): 0.641 mW/g, SAR (10g): 0.373 mW/g, (Worst-case extrapolation) Penetration depth: 10.3 (9.5, 11.4) [mm]; Powerdrift: -0.03 dB Coarse: Dx = 15.0, Dy = 15.0, Dz = 10.0 Ambient Temperature (degree C): 22.0 Liquid Temperature (degree C): 20.5 SAR Tot [mW/g] 6.83E-2 2.05E-1 3.42E-1 4.78E-1 6.15E-1 11/14/02 COMPLIANCE CERTIFICATION SERVICES Compal (Model: AR11 ), Frequency: 1880.0 MHz (Left head - Touch) Frequency: 1900 MHz; Crest factor: 8.0 Medium: Head 1900 MHz: σ = 1.35 mho/m ε r = 40.5 ρ = 1.00 g/cm 3 SAM-1 Phantom; Left Hand Section; Position: (91°,60°) Probe: ET3DV6 - SN1578; ConvF(5.50,5.50,5.50); SAR:Cube 5x5x7: Peak: 1.17 mW/g, SAR (1g): 0.692 mW/g, SAR (10g): 0.402 mW/g, (Worst-case extrapolation) Penetration depth: 10.1 (9.4, 11.0) [mm]; Powerdrift: 0.01 dB Coarse: Dx = 15.0, Dy = 15.0, Dz = 10.0 Ambient Temperature (degree C): 22.0 Liquid Temperature (degree C): 20.5 SAR Tot [mW/g] 7.43E-2 2.23E-1 3.72E-1 5.20E-1 6.69E-1 11/14/02 COMPLIANCE CERTIFICATION SERVICES Compal (Model: AR11 ), Frequency: 1909.8 MHz (Left head - Touch) Frequency: 1900 MHz; Crest factor: 8.0 Medium: Head 1900 MHz: σ = 1.35 mho/m ε r = 40.5 ρ = 1.00 g/cm 3 SAM-1 Phantom; Left Hand Section; Position: (91°,60°) Probe: ET3DV6 - SN1578; ConvF(5.50,5.50,5.50); SAR:Cube 5x5x7: Peak: 1.27 mW/g, SAR (1g): 0.734 mW/g, SAR (10g): 0.419 mW/g, (Worst-case extrapolation) Penetration depth: 9.7 (9.0, 10.6) [mm]; Powerdrift: 0.05 dB Coarse: Dx = 15.0, Dy = 15.0, Dz = 10.0 Ambient Temperature (degree C): 22.0 Liquid Temperature (degree C): 20.5 SAR Tot [mW/g] 7.96E-2 2.39E-1 3.98E-1 5.57E-1 7.16E-1 11/14/02 COMPLIANCE CERTIFICATION SERVICES Compal (Model: AR11 ), Frequency: 1909.8 MHz (Left head - Touch) Frequency: 1900 MHz; Crest factor: 8.0 Medium: Head 1900 MHz: σ = 1.35 mho/m ε r = 40.5 ρ = 1.00 g/cm 3 SAM-1 Phantom; Section; Position: Probe: ET3DV6 - SN1578; ConvF(5.50,5.50,5.50); SAR:: , , () Penetration depth: 9.5 (8.9, 10.4) [mm]; Z-Axis: Dx = 0.0, Dy = 0.0, Dz = 2.0 Ambient Temperature (degree C): 22.0 Liquid Temperature (degree C): 20.5 11/14/02 COMPLIANCE CERTIFICATION SERVICES 0.0 0.2 0.4 0.6 0.8 1.0 1.2 1.4 0102030405060708090 SAR tot [mW/g] [mm] Compal (Model: AR11 ), Frequency: 1850.2 MHz (Left head - Tilt) Frequency: 1900 MHz; Crest factor: 8.0 Medium: Head 1900 MHz: σ = 1.35 mho/m ε r = 40.5 ρ = 1.00 g/cm 3 SAM-1 Phantom; Left Hand Section; Position: (106°,60°) Probe: ET3DV6 - SN1578; ConvF(5.50,5.50,5.50); SAR:Cube 5x5x7: Peak: 1.78 mW/g, SAR (1g): 1.04 mW/g, SAR (10g): 0.590 mW/g, (Worst-case extrapolation) Penetration depth: 10.0 (9.4, 10.9) [mm]; Powerdrift: 0.08 dB Coarse: Dx = 15.0, Dy = 15.0, Dz = 10.0 Ambient Temperature (degree C): 22.0 Liquid Temperature (degree C): 20.5 SAR Tot [mW/g] 1.13E-1 3.40E-1 5.67E-1 7.94E-1 1.02E+0 11/14/02 COMPLIANCE CERTIFICATION SERVICES Compal (Model: AR11 ), Frequency: 1880.0 MHz (Left head - Tilt) Frequency: 1900 MHz; Crest factor: 8.0 Medium: Head 1900 MHz: σ = 1.35 mho/m ε r = 40.5 ρ = 1.00 g/cm 3 SAM-1 Phantom; Left Hand Section; Position: (106°,60°) Probe: ET3DV6 - SN1578; ConvF(5.50,5.50,5.50); SAR:Cube 5x5x7: Peak: 1.95 mW/g, SAR (1g): 1.13 mW/g, SAR (10g): 0.633 mW/g, (Worst-case extrapolation) Penetration depth: 9.7 (9.2, 10.6) [mm]; Powerdrift: -0.02 dB Coarse: Dx = 15.0, Dy = 15.0, Dz = 10.0 Ambient Temperature (degree C): 22.0 Liquid Temperature (degree C): 20.5 SAR Tot [mW/g] 1.22E-1 3.65E-1 6.08E-1 8.51E-1 1.09E+0 11/14/02 COMPLIANCE CERTIFICATION SERVICES Compal (Model: AR11 ), Frequency: 1909.8 MHz (Left head - Tilt) Frequency: 1900 MHz; Crest factor: 8.0 Medium: Head 1900 MHz: σ = 1.35 mho/m ε r = 40.5 ρ = 1.00 g/cm 3 SAM-1 Phantom; Left Hand Section; Position: (106°,60°) Probe: ET3DV6 - SN1578; ConvF(5.50,5.50,5.50); SAR:Cube 5x5x7: Peak: 2.05 mW/g, SAR (1g): 1.16 mW/g, SAR (10g): 0.643 mW/g, (Worst-case extrapolation) Penetration depth: 9.4 (8.8, 10.4) [mm]; Powerdrift: -0.00 dB Coarse: Dx = 15.0, Dy = 15.0, Dz = 10.0 Ambient Temperature (degree C): 22.0 Liquid Temperature (degree C): 20.5 SAR Tot [mW/g] 1.24E-1 3.73E-1 6.22E-1 8.71E-1 1.12E+0 11/14/02 COMPLIANCE CERTIFICATION SERVICES Compal (Model: AR11 ), Frequency: 1909.8 MHz (Left head - Tilt) Frequency: 1900 MHz; Crest factor: 8.0 Medium: Head 1900 MHz: σ = 1.35 mho/m ε r = 40.5 ρ = 1.00 g/cm 3 SAM-1 Phantom; Section; Position: Probe: ET3DV6 - SN1578; ConvF(5.50,5.50,5.50); SAR:: , , () Penetration depth: 9.3 (8.8, 10.2) [mm]; Z-Axis: Dx = 0.0, Dy = 0.0, Dz = 2.0 Ambient Temperature (degree C): 22.0 Liquid Temperature (degree C): 20.5 11/14/02 COMPLIANCE CERTIFICATION SERVICES 0.0 0.2 0.4 0.6 0.8 1.0 1.2 1.4 1.6 1.8 2.0 2.2 0102030405060708090 SAR tot [mW/g] [mm] Compal (Model: AR11 ), Frequency: 1850.2 MHz (Right head - Touch) Frequency: 1900 MHz; Crest factor: 8.0 Medium: Head 1900 MHz: σ = 1.35 mho/m ε r = 40.5 ρ = 1.00 g/cm 3 SAM-1 Phantom; Righ Hand Section; Position: (91°,300°) Probe: ET3DV6 - SN1578; ConvF(5.50,5.50,5.50); SAR:Cube 5x5x7: Peak: 1.37 mW/g, SAR (1g): 0.787 mW/g, SAR (10g): 0.443 mW/g, (Worst-case extrapolation) Penetration depth: 9.9 (9.2, 10.9) [mm]; Powerdrift: -0.02 dB Coarse: Dx = 15.0, Dy = 15.0, Dz = 10.0 Ambient Temperature (degree C): 22.0 Liquid Temperature (degree C): 20.4 SAR Tot [mW/g] 8.31E-2 2.49E-1 4.16E-1 5.82E-1 7.48E-1 11/14/02 COMPLIANCE CERTIFICATION SERVICES Compal (Model: AR11 ), Frequency: 1880.2 MHz (Right head - Touch) Frequency: 1900 MHz; Crest factor: 8.0 Medium: Head 1900 MHz: σ = 1.35 mho/m ε r = 40.5 ρ = 1.00 g/cm 3 SAM-1 Phantom; Righ Hand Section; Position: (91°,300°) Probe: ET3DV6 - SN1578; ConvF(5.50,5.50,5.50); SAR:Cube 5x5x7: Peak: 1.51 mW/g, SAR (1g): 0.868 mW/g, SAR (10g): 0.486 mW/g, (Worst-case extrapolation) Penetration dept…

Text truncated - open the document above for the full version.

FCC CFR47 CERTIFICATION PART 24E TEST REPORT FOR GSM/GPRS CLASS 8 PCS SMARTPHONE MODEL: AR11 FCC ID: QQX-AR11 REPORT NUMBER: 02T1648-1 ISSUE DATE: NOVEMBER 25, 2002 Prepared for COMPAL COMMUNICATIONS, INC. 7 TH FL, NO. 319, SEC. 4 PA-THE ROAD, TAIPEI, TAIWAN Prepared by COMPLIANCE CERTIFICATION SERVICES 561F MONTEREY ROAD, ROUTE 2 MORGAN HILL, CA 95037, USA TEL: (408) 463-0885 FAX: (408) 463-0888 REPORT NO: 02T1648-1 DATE: NOVEMBER 25, 2002 EUT: SMARTPHONE FCC ID: QQX-AR11 Page 2 of 45 COMPLIANCE CERTIFICATION SERVICES DOCUMENT NO: CCSUP4031A 561F MONTEREY ROAD, MORGAN HILL, CA 95037 USA TEL: (408) 463-0885 FAX: (408) 463-0888 This report shall not be reproduced except in full, without the written approval of CCS. This document may be altered or revised by Compliance Certification Services personnel only, and shall be noted in the revision section of the document. TABLE OF CONTENT 1. TEST RESULT CERTIFICATION..........................................................................................3 2. EUT DESCRIPTION................................................................................................................4 3. FACILITIES, LABORATORY AND ACCREDITATION.......................................................4 3.1. FACILITIES..........................................................................................................................4 3.2. LABORATORY ACCREDITATION............................................................................................4 3.3. LIST OF ACCREDITATIONS....................................................................................................5 4. CALIBRATION, METHODOLOGY AND UNCERTAINTY...................................................6 4.1. EQUIPMENT CALIBRATION...................................................................................................6 4.2. TEST METHODOLOGY..........................................................................................................6 4.3. MEASUREMENT UNCERTAINTY.............................................................................................6 4.4. TEST AND MEASUREMENT EQUIPMENT.................................................................................7 5. APPLICABLE RULES.............................................................................................................8 5.1. RF POWER OUTPUT §2.1046............................................................................................8 5.2. MODULATION CHARACTERISTICS §2.1047...................................................................8 5.3. OCCUPIED BANDWIDTH §2.1049....................................................................................8 5.4. SPURIOUS EMISSIONS AT ANTENNA TERMINALS §2.1051.........................................9 5.5. FIELD STRENGTH OF SPURIOUS RADIATION §2.1053..................................................9 5.6. FREQUENCY STABILITY §2.1055....................................................................................9 5.7. FREQUENCY RANGE TO BE INVESTIGATED §2.1057.................................................10 6. TEST SETUP, PROCEDURE AND RESULT........................................................................11 6.1. SECTION 2.1046: RF POWER OUTPUT...........................................................................11 6.2. OCCUPIED BANDWIDTH...............................................................................................14 6.3. SPURIOUS EMISSION AT ANTENNA TERMINAL........................................................16 6.4. FIELD STRENGTH OF SPURIOUS RADIATION.............................................................23 6.5. FREQUENCY STABILITY...............................................................................................27 6.6. RADIATED EMISSION....................................................................................................30 6.7. POWER LINE CONDUCTED EMISSION.........................................................................33 7. APENDIX...............................................................................................................................39 7.1. EXTERNAL & INTERNAL PHOTOS...............................................................................39 REPORT NO: 02T1648-1 DATE: NOVEMBER 25, 2002 EUT: SMARTPHONE FCC ID: QQX-AR11 Page 3 of 45 COMPLIANCE CERTIFICATION SERVICES DOCUMENT NO: CCSUP4031A 561F MONTEREY ROAD, MORGAN HILL, CA 95037 USA TEL: (408) 463-0885 FAX: (408) 463-0888 This report shall not be reproduced except in full, without the written approval of CCS. This document may be altered or revised by Compliance Certification Services personnel only, and shall be noted in the revision se…
