QSS-SD705Inductive Tag Reader Module

V 1.0 Manual sd705 Manual sd705 Page 2 © SKIDATA AG, June 2006 SKIDATA AG Technical Documentation Untersbergstrasse 40 A-5083 Grödig/Salzburg Telephone +43 6246 888-0 Telefax +43 6246 888-7 Internet http://www.skidata.com e-mail [email protected] Copyright © 2006 by SKIDATA AG. All rights reserved. All information in the following document is protected by copyright law. No part of this document may be reproduced without the written consent of SKI- DATA AG. SKIDATA AG reserves the right to make any changes of specification and other information in this document without further notice. Please note During the compilation of this Technical Documentation, great care has been taken to ensure the accuracy of the information contained in it. However, despite our constant effort to ensure the highest degree of accuracy and comprehensiveness possible, the information provided cannot be guaranteed to be absolutely error-free. Trademarks This documentation may contain representations of registered product or service trademarks owned by SKIDATA AG or third parties, as well as references to proprietary know-how protected by copyright laws or other legal provisions. In any case the intel- lectual property rights remain exclusively with their respective owners. Declaration of Conformity The sd705 has been developed, designed and manufactured in accordance with the following EU directive: R&TTE (1999/5/EC) 0408 Version June 2006 Sd705 Manual © SKIDATA AG, June 2006 Page 3 FCC 15.21: IMPORTANT: Any changes to or modifications of de sd705, in- cluding antenna, unless expressly approved by SKIDATA™, may void the user’s authority to operate this device. The final product should contain labelling according to FCC re- quirements. For example: This device complies with Part 15 of the FCC rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause un- desired operation. This device contains FCC ID QSS-SD705. This label will be placed on the final product, clearly visible to all persons exposed to the transmitter. Canada: Operation is subject to the following two conditions: (1) this de- vice may not cause interference, and (2) this device must accept any interference, including interference that may cause undesired operation of the device. Document Management – Version Table Tab. 1: Document Version Table for Installation & Maintenance Instructions Section Document Pages Version Date 1 sd705 4 1.0 2006-06-27 Manual sd705 Page 4 © SKIDATA AG, June 2006 sd705 1 1 sd705 Version 1.0 5 pages Copyright 2006 by SKIDATA AG 1 sd705 1.1 Contents Page 2 © SKIDATA AG, Version 1.0 1.1 Contents 1.1 Contents 2 1.2 General 3 1.3 sd705 4 1.3.1 front view 4 1.3.2 rear view 4 sd705 1 General 1.2 © SKIDATA AG, Version 1.0 Page 3 1.2 General The sd705 is a Radio Transceiver Module (RFID module) which is designed for installation in SKIDATA devices by SKIDATA AG only. The module is not to be sold as an individual product. The sd705 must be connected to the appropriate devices by means of the plug-in connector provided for this purpose. The il- lustrations show the plug-in boards for 5 V DC power supply and the data transfer line, as well as the plug-in parts for the antennas. It is prohibited to use antennas other as the antennas certified to be used with the sd705. 1 sd705 1.3 sd705 Page 4 © SKIDATA AG, Version 1.0 1.3 sd705 1.3.1 front view 1.3.2 rear view Fig. 1: front view sd705 13 Mhz Ant2 13 Mhz Ant1 125 kHz Ant1 Power / Rs232 125 kHz Ant2 Fig. 2: rear view sd705 Power / R S 232 ( 0 V / 5 V )

EMV-Pr ̧fzentrum EMI/EMC-Testcenter Coordinates: ƒussere Fr ̧hlingstrasse 45 ! D-94315 Straubing Telefon (0 94 21) 55 22-0 Telefax (0 94 21) 55 22-99 [email protected] ! http://www.senton.de Senton GmbH ! ƒussere Fr ̧hlingstrasse 45 ! D-94315 Straubing EMCCert DR. RAäEK - Certification Institute - Boelwiese 5 D-91320 Ebermannstadt 14 July 2006 In reference to FCC ID QSS-SD705 Justification for Part 15 Unlicensed Modular Transmitter Approval according to DA 00-1407 1. Own RF Shielding Not complied, but subject to limited modular approval. The Grantee can demonstrate that it will retain control over the final installation of the device, such that compliance of the end product is assured. In such a case, an operating condition on the grant of equipment authorization for the module would state that the module is only approved for use when installed in devices produced by a specific manufacturer, typically the Grantee. 2. Buffered Modulation inputs Complied, no direct modulation input. Modulated signals will be buffered by microcontroller IC12 3. Own power supply regulation Complied, voltage regulated power supply on board, see schematic diagram 4. Antenna requirements Complied, unique antenna coupler employed 5. Test in stand-alone configuration Complied, see test report for details. Cable lengths typical to actual use. 6. Own FCC ID Complied, the exterior label will be ÑContains FCC ID QSS-SD705ì Subject to limited modular approval 7. Not applicable Subject to limited modular approval 8. RF Exposure requirements Not applicable since the unit operates under section 15.225 of the FCC rules. The reference guide contains general installation and operation instructions. MPE evaluation not required Johann Roidt Senton GmbH

Federal Communications Commission 445 12 th Street SW Washington, DC 20554 USA Request for Confidentiality in accordance with CFR 0.457 and 0.459 14 July 2006 EMCCert DR. RAäEK - Certification Institute - Boelwiese 5 D-91320 Ebermannstadt RE: Certification Application FCC ID: QSS-SD705 Please be advised that the following information is to be held confidential on behalf of SKIDATA AG: • Schematics • Parts List • Block Diagram • Technical Description The application contains technical information which SKIDATA AG deems to be trade secrets and proprietary. If made public, the information might be used to the disadvantage of the applicant in the market place. Thank you for your attention to this matter.

Fig. 1: front view sd705 13 Mhz Ant2 13 Mhz Ant1 125 kHz Ant1 Power / Rs232 125 kHz Ant2 Fig. 2: rear view sd705 Power / RS232 (0 V / 5 V)

FCC ID QSS-SD705

Fig. 1: front view sd705 13 Mhz Ant2 13 Mhz Ant1 125 kHz Ant1 Power / Rs232 125 kHz Ant2 Fig. 2: rear view sd705 Power / RS232 (0 V / 5 V)

Senton GmbH Aeussere Fruehlingstrasse 45 D-94315 Straubing Note: The test data of this report is related only to the individual item which has been tested. This report shall not be reproduced except in full extent without the written approval of the testing laboratory. Test Report No. 55426-060354-1 (Edition 1) Page 1 of 124 Pages Straubing, 19 June 2006 T E S T - R E P O R T No. 55426-060354-1 (Edition 1) for sd705 Inductive Tag Reader Module Applicant: SKIDATA AG Test Specifications: FCC Code of Federal Regulations, CFR 47, Part 15, Sections 15.205, 15.207, 15.209 15.215 and 15.225 Industry Canada Radio Standards Specifications RSS-Gen Issue 1, Section 7.2.2 and RSS-210 Issue 6, Sections 2.2, 2.6, A2.6 (Category I Equipment) Senton GmbH Aeussere Fruehlingstrasse 45 D-94315 Straubing Test Report No. 55426-060354-1 (Edition 1) Page 2 of 124 Pages Table of Contents 1 Description of the Equipment Under Test (EUT) ........................................................ 3 2 Administrative Data..................................................................................................... 5 3 Identification of the Test Laboratory ........................................................................... 6 4 Summary .................................................................................................................... 7 5 Operation Mode and Configuration of EUT................................................................. 8 6 Measurement Procedures......................................................................................... 10 6.1 Conducted Output Power ................................................................................... 10 6.2 Bandwidth Measurements .................................................................................. 12 6.3 Pulse Train Measurement .................................................................................. 13 6.4 Conducted AC Powerline Emission .................................................................... 14 6.5 Radiated Emission Measurement 9 kHz to 30 MHz ........................................... 16 6.6 Radiated Emission in Fully or Semi Anechoic Room.......................................... 18 6.7 Radiated Emission at Open Field Test Site........................................................ 20 6.8 Carrier Frequency Stability ................................................................................. 21 7 Photographs Taken During Testing .......................................................................... 23 8 Test Results .............................................................................................................. 51 8.1 Conducted Output Power ................................................................................... 53 8.2 Occupied Bandwidth........................................................................................... 54 8.3 Bandwidth of the Emission ................................................................................. 64 8.4 Designation of Emissions ................................................................................... 68 8.5 Pulse Train Measurement .................................................................................. 69 8.6 Restricted Bands of Operation ........................................................................... 75 8.7 Spectrum Mask................................................................................................... 76 8.8 Conducted Powerline Emission Measurement 150 kHz to 30 MHz................... 78 8.9 Radiated Emission Measurement 9 kHz to 30 MHz .......................................... 81 8.10 Radiated Emission Measurement 30 MHz to 1 GHz ....................................... 106 8.11 Carrier Frequency Stability ............................................................................... 115 8.12 Exposure of Humans to RF Fields.................................................................... 118 9 Referenced Regulations ......................................................................................... 123 10 Charts taken during testing ..................................................................................... 124 Senton GmbH Aeussere Fruehlingstrasse 45 D-94315 Straubing Test Report No. 55426-060354-1 (Edition 1) Page 3 of 124 Pages 1 Description of the Equipment Under Test (EUT) General data of EUT Type designation * : sd705 Parts Ü : and Serial Numbers sd705 (V 2.1): D061600112 Antenna sd611 (V 1.0): 00025 Antenna sd612 (V 1.0): D061100323 Antenna sd647 (V 2.2): D055000252 Antenna sd648 (V 1.3): D055100273 Antenna sd682 (V 1.0): D052100003 Antenna sd697 (V 2.0): D054800052 Antenna sd697 (V 3.0): D060400005 Antenna sd733 (V 2.2): D061700003 Manufacturer: SKIDATA AG Type of equipment: Inductive Tag Reader Module Version: As delivered FCC ID: Additional parts/accessories: * Type designation of the system if EUT consists of more than one part. Ü Type designations of the parts of the system, if applicable. Senton GmbH Aeussere Fruehlingstrasse 45 D-94315 Straubing Test Report No. 55426-060354-1 (Edition 1) Page 4 of 124 Pages Technical data of EUT Application frequency range: 119 - 127 kHz and 13.553 - 13.567 MHz Frequency range: 119 - 127 kHz and 13.556 - 13.567 MHz Operating frequency: 122 kHz and 13.56 MHz Type of modulation: ASK Pulse train: --- Pulse width: --- Number of RF-channels: 2 (122.9 kHz and 13.56 MHz) Channel spacing: Not applicable Designation of emissions á : 10K0A1D Type of antenna: Inductive Loop Coil Size/length of antenna: sd611 (V 1.0): 94 x 143 mm sd612 (V 1.0): ÿ 90 mm sd647 (V 2.2): 40 x 52 mm sd648 (V 1.3): 52 x 70 mm sd682 (V 1.0): 156 x 162 mm sd697 (V 2.0): ÿ 120 mm ß sd697 (V 3.0): ÿ 200 mm sd733 (V 2.2):117 x 135 mm Connection of antenna: detachable not detachable Type of power supply: DC supply Specifications for power supply: nominal voltage: 5.00 V minimum voltage: 4.25 V maximum voltage: 5.75 V á Also known…

Text truncated - open the document above for the full version.

Senton GmbH Aeussere Fruehlingstrasse 45 D-94315 Straubing Test Report No. 55426-060354-1 (Edition 1) Page 36 of 124 Pages Test setup for radiated emission measurement (open field test site) - continued - Senton GmbH Aeussere Fruehlingstrasse 45 D-94315 Straubing Test Report No. 55426-060354-1 (Edition 1) Page 37 of 124 Pages Test setup for radiated emission measurement (open field test site) - continued - Senton GmbH Aeussere Fruehlingstrasse 45 D-94315 Straubing Test Report No. 55426-060354-1 (Edition 1) Page 38 of 124 Pages Test setup for radiated emission measurement (open field test site) - continued - Senton GmbH Aeussere Fruehlingstrasse 45 D-94315 Straubing Test Report No. 55426-060354-1 (Edition 1) Page 39 of 124 Pages Test setup for radiated emission measurement (open field test site) - continued - Senton GmbH Aeussere Fruehlingstrasse 45 D-94315 Straubing Test Report No. 55426-060354-1 (Edition 1) Page 40 of 124 Pages Test setup for radiated emission measurement (open field test site) - continued - Senton GmbH Aeussere Fruehlingstrasse 45 D-94315 Straubing Test Report No. 55426-060354-1 (Edition 1) Page 41 of 124 Pages Test setup for radiated emission measurement (open field test site) - continued - Senton GmbH Aeussere Fruehlingstrasse 45 D-94315 Straubing Test Report No. 55426-060354-1 (Edition 1) Page 42 of 124 Pages Test setup for radiated emission measurement (open field test site) - continued -

Senton GmbH Aeussere Fruehlingstrasse 45 D-94315 Straubing Test Report No. 55426-060354-1 (Edition 1) Page 43 of 124 Pages Test setup for radiated emission measurement (open field test site) - continued - Senton GmbH Aeussere Fruehlingstrasse 45 D-94315 Straubing Test Report No. 55426-060354-1 (Edition 1) Page 44 of 124 Pages Test setup for radiated emission measurement (open field test site) - continued - Senton GmbH Aeussere Fruehlingstrasse 45 D-94315 Straubing Test Report No. 55426-060354-1 (Edition 1) Page 45 of 124 Pages Test setup for radiated emission measurement (open field test site) - continued - Senton GmbH Aeussere Fruehlingstrasse 45 D-94315 Straubing Test Report No. 55426-060354-1 (Edition 1) Page 46 of 124 Pages Test setup for radiated emission measurement (open field test site) - continued - Senton GmbH Aeussere Fruehlingstrasse 45 D-94315 Straubing Test Report No. 55426-060354-1 (Edition 1) Page 47 of 124 Pages Test setup for radiated emission measurement (open field test site) - continued - Senton GmbH Aeussere Fruehlingstrasse 45 D-94315 Straubing Test Report No. 55426-060354-1 (Edition 1) Page 48 of 124 Pages Test setup for radiated emission measurement (open field test site) - continued - Senton GmbH Aeussere Fruehlingstrasse 45 D-94315 Straubing Test Report No. 55426-060354-1 (Edition 1) Page 49 of 124 Pages Test setup for radiated emission measurement (open field test site) - continued - Senton GmbH Aeussere Fruehlingstrasse 45 D-94315 Straubing Test Report No. 55426-060354-1 (Edition 1) Page 50 of 124 Pages Test setup for carrier frequency stability measurement

Senton GmbH Aeussere Fruehlingstrasse 45 D-94315 Straubing Test Report No. 55426-060354-1 (Edition 1) Page 51 of 124 Pages 8 Test Results FCC CFR 47 Parts 2 and 15 Section(s) Test Page Result 2.1046(a) Conducted output power 53 Recorded 2.202(a) Occupied bandwidth 54 Recorded 15.215(c) Bandwidth of the emission 64 Test passed 2.201, 2.202 Class of emission 68 Calculated 15.35(c) Pulse train measurement for pulsed operation 69 Recorded 15.205(a) 15.205(d)(7) Restricted bands of operation 75 áá Test passed 15.207 Conducted AC powerline emission 150 kHz to 30 MHz 78 Test passed 15.225(a)-(d) Spectrum Mask 76 Test passed 15.205(b) 15.209 15.215(b) 15.225(a)(d) Radiated emission 9 kHz to 30 MHz 81 Test passed 15.205(b) 15.209 15.225(d) Radiated emission 30 MHz to 1 GHz 106 Test passed 15.225(e) Carrier frequency stability 115 Test passed áá See "Spectrum Mask" for the 13.36 to 13.41 MHz band. For all other restricted bands see "Radiated Emission". Senton GmbH Aeussere Fruehlingstrasse 45 D-94315 Straubing Test Report No. 55426-060354-1 (Edition 1) Page 52 of 124 Pages IC RSS-Gen Issue 1 Section(s) Test Page Result 4.6 Transmitter output power (conducted) 53 Recorded 4.4.1 Occupied Bandwidth 54 Recorded 3.2(h), 8 Designation of emissions 68 Calculated 4.3 Pulsed operation 69 Recorded 7.2.2 Transmitter AC power lines conducted emissions 150 kHz to 30 MHz 78 Test passed 5.5 Exposure of Humans to RF Fields 118 Exempted from SAR and RF evaluation IC RSS-210 Issue 6 Section(s) Test Page Result 2.2(a) Restricted bands and unwanted emission frequencies 75 ßß Test passed A2.6 Spectrum Mask 76 Test passed 2.2(b)(c), 2.6 A2.6 Unwanted emissions 9 kHz to 30 MHz 81 Test passed 2.2(b)(c), 2.6 A2.6 Unwanted emissions 30 MHz to 1 GHz 106 Test passed A2.6 Carrier frequency stability 115 Test passed ßß See "Spectrum Mask" and "Unwanted emissions". Senton GmbH Aeussere Fruehlingstrasse 45 D-94315 Straubing Test Report No. 55426-060354-1 (Edition 1) Page 53 of 124 Pages 8.1 Conducted Output Power Rules and specifications: CFR 47 Part 2, section 2.1046(a) IC RSS-Gen Issue 1, section 4.6 Guide: CFR 47 Part 2, section 2.1046 / IC RSS-Gen Issue 1 Description: Conducted output power shall be measured at the RF output terminals (e.g. antenna connector if antenna is detachable) when the transmitter is adjusted in accordance with the tune-up procedure, if applicable. The electrical characteristics of the radio frequency load attached to the output terminals when this test is made shall be stated. Measurement procedure: Conducted Output Power (6.1) Comment: Date of test: 23 June 2006 Test site: Unshielded room Test Result: Test passed Antenna gain: dBi ModeFrequenc yPower TypeReadingCorrectionOutput PowerLimitMargin (MHz)(dBm)(dB)(dBm)(dBm)(dB) Polling continiously0.12PEP2.20.02.2 Polling continiously13.56PEP7.810.017.8 Note 1: If applicable, PEP (peak envelope power) and RMS values are measured using a power meter with appropriate sensor. Note 2: If applicable, peak or average values are measured using a spectrum analyzer with resolution and video bandwidth set to: RBW = .........., VBW = .......... Note 3: If transmitting antennas of directional gain greater than 6 dBi are used, the conducted output power limit is reduced by the amount in dB that the directional gain of the antenna exceeds 6 dBi. Senton GmbH Aeussere Fruehlingstrasse 45 D-94315 Straubing Test Report No. 55426-060354-1 (Edition 1) Page 54 of 124 Pages 8.2 Occupied Bandwidth Rules and specifications: CFR 47 Part 2, section 2.202(a) ANSI C63.4, annex H.6 Guide: ANSI C63.4 Description: The occupied bandwidth according to CFR 47 Part 2, section 2.202(a), is measured as the 99% emission bandwidth, i.e. below its lower and above its upper frequency limits, the mean powers radiated are each equal to 0.5% of the total mean power radiated by a given emission. The occupied bandwidth according to ANSI C63.4, annex H.6; is measured as the frequency range defined by the points that are 26 dB down relative to the maximum level of the modulated carrier. The resolution bandwidth of the spectrum analyzer shall be set to a value greater than 5.0% of the allowed bandwidth. If no bandwidth specifications are given, the following guidelines are used: Fundamental frequency Minimum resolution bandwidth 9 kHz to 30 MHz 1 kHz 30 MHz to 1000 MHz 10 kHz 1000 MHz to 40 GHz 100 kHz The video bandwidth shall be at least three times greater than the resolution bandwidth. Measurement procedure: Bandwidth Measurements (6.2) Comment: Date of test: 13 June 2006 Test site: Fully anechoic room, cabin no. 2 Senton GmbH Aeussere Fruehlingstrasse 45 D-94315 Straubing Test Report No. 55426-060354-1 (Edition 1) Page 55 of 124 Pages Occupied Bandwidth (99 %): Ref 87 dBμVAtt 10 dB * A 2 kHz/Center 122.9 kHzSpan 20 kHz * RBW 200 Hz SWT 2.5 s * VBW 1 kHz 1 PK VIEW PRN -10 0 10 20 30 40 50 60 70 80 1 Marker 1 [T1 ] 70.84 dBμ V 122.900000000 kHz OBW 11.440000000 kHz T1 Temp 1 [T1 OBW] 48.77 dBμ V 115.740000000 kHz T2 Temp 2 [T1 OBW] 38.57 dBμ V 127.180000000 kHz Limit1 Limit2 Comment: Skidata 060354: Occupied Bandwidth Date: 13.JUN.2006 19:01:42 Occupied Bandwidth (99 %): 11.44 kHz Senton GmbH Aeussere Fruehlingstrasse 45 D-94315 Straubing Test Report No. 55426-060354-1 (Edition 1) Page 56 of 124 Pages Occupied Bandwidth (-26 dB): Ref 87 dBμVAtt 10 dB * A 2 kHz/Center 122.9 kHzSpan 20 kHz SWT 2.5 s 1 PK VIEW * * RBW 200 Hz VBW 1 kHz * PRN -10 0 10 20 30 40 50 60 70 80 1 Marker 1 [T1 ] 70.84 dBμ V 122.900000000 kHz 2 Marker 2 [T1 ] 44.00 dBμ V 115.380000000 kHz 3 Marker 3 [T1 ] 42.60 dBμ V 125.980000000 kHz D1 44.84 dBμV Limit1 Limit2 Comment: Skidata 060354: Occupied Bandwidth Date: 13.JUN.2006 19:03:37 Occupied Bandwidth (-26 dB): 10.6 kHz Senton GmbH Aeussere Fruehlingstrasse 45 D-94315 Straubing Test Report No. 55426-060354-1 (Edition 1) Page 57 of 124 Pages Occupied Bandwidth (continued) Rules and specifications: IC RSS-Gen Issue 1, section 4.4.1 Guide: IC RSS-Gen Issue 1, section 4.4.1 Descripti…

Text truncated - open the document above for the full version.

Radiated Emission Test 30 MHz - 1 GHz acc. to FCC Part 15 (Fully Anechoic Chamber) Model: sd705 Serial no.: V2.1 Applicant: Skidata AG Test site: Fully anechoic room, cabin no. 2 Tested on: Test distance 3 metres Vertical Polarization Date of test: 06/13/2006 Operator: M. Steindl Test performed: automatically File name: default.emi Detector: Peak Comment: - DC 5 V power supply - with antenna sd611 (V1.0) - reading transponder card continuously (ISO 15693) List of values: Selected by hand 304050701002003004005007001000 MHz 0 5 10 15 20 25 30 35 40 45 50 55 60 dBμV/mLimit1: FCC Part 15 Transducer: VULB 9163 Result: Prescan Project file: 55426-60354 Senton GmbH / Aeussere Fruehlingstrasse 45 / D-94315 Straubing / Germany / Tel. +49 (0)9421 5522-0 / Fax +49 (0)9421 5522-99 Radiated Emission Test 30 MHz - 1 GHz acc. to FCC Part 15 (Fully Anechoic Chamber) Model: sd705 Serial no.: V2.1 Applicant: Skidata AG Test site: Fully anechoic room, cabin no. 2 Tested on: Test distance 3 metres Horizontal Polarization Date of test: 06/13/2006 Operator: M. Steindl Test performed: automatically File name: default.emi Detector: Peak Comment: - DC 5 V power supply - with antenna sd612 (V1.0) - polling continuously without tag List of values: Selected by hand 304050701002003004005007001000 MHz 0 5 10 15 20 25 30 35 40 45 50 55 60 dBμV/mLimit1: FCC Part 15 Transducer: VULB 9163 Result: Prescan Project file: 55426-60354 Senton GmbH / Aeussere Fruehlingstrasse 45 / D-94315 Straubing / Germany / Tel. +49 (0)9421 5522-0 / Fax +49 (0)9421 5522-99 Radiated Emission Test 30 MHz - 1 GHz acc. to FCC Part 15 (Fully Anechoic Chamber) Model: sd705 Serial no.: V2.1 Applicant: Skidata AG Test site: Fully anechoic room, cabin no. 2 Tested on: Test distance 3 metres Vertical Polarization Date of test: 06/13/2006 Operator: M. Steindl Test performed: automatically File name: default.emi Detector: Peak Comment: - DC 5 V power supply - with antenna sd612 (V1.0) - polling continuously without tag List of values: Selected by hand 304050701002003004005007001000 MHz 0 5 10 15 20 25 30 35 40 45 50 55 60 dBμV/mLimit1: FCC Part 15 Transducer: VULB 9163 Result: Prescan Project file: 55426-60354 Senton GmbH / Aeussere Fruehlingstrasse 45 / D-94315 Straubing / Germany / Tel. +49 (0)9421 5522-0 / Fax +49 (0)9421 5522-99 Radiated Emission Test 30 MHz - 1 GHz acc. to FCC Part 15 (Fully Anechoic Chamber) Model: sd705 Serial no.: V2.1 Applicant: Skidata AG Test site: Fully anechoic room, cabin no. 2 Tested on: Test distance 3 metres Horizontal Polarization Date of test: 06/13/2006 Operator: M. Steindl Test performed: automatically File name: default.emi Detector: Peak Comment: - DC 5 V power supply - with antenna sd612 (V1.0) - reading transponder card continuously (ISO 15693) List of values: Selected by hand 304050701002003004005007001000 MHz 0 5 10 15 20 25 30 35 40 45 50 55 60 dBμV/mLimit1: FCC Part 15 Transducer: VULB 9163 Result: Prescan Project file: 55426-60354 Senton GmbH / Aeussere Fruehlingstrasse 45 / D-94315 Straubing / Germany / Tel. +49 (0)9421 5522-0 / Fax +49 (0)9421 5522-99 Radiated Emission Test 30 MHz - 1 GHz acc. to FCC Part 15 (Fully Anechoic Chamber) Model: sd705 Serial no.: V2.1 Applicant: Skidata AG Test site: Fully anechoic room, cabin no. 2 Tested on: Test distance 3 metres Vertical Polarization Date of test: 06/13/2006 Operator: M. Steindl Test performed: automatically File name: default.emi Detector: Peak Comment: - DC 5 V power supply - with antenna sd612 (V1.0) - reading transponder card continuously (ISO 15693) List of values: Selected by hand 304050701002003004005007001000 MHz 0 5 10 15 20 25 30 35 40 45 50 55 60 dBμV/mLimit1: FCC Part 15 Transducer: VULB 9163 Result: Prescan Project file: 55426-60354 Senton GmbH / Aeussere Fruehlingstrasse 45 / D-94315 Straubing / Germany / Tel. +49 (0)9421 5522-0 / Fax +49 (0)9421 5522-99 Radiated Emission Test 30 MHz - 1 GHz acc. to FCC Part 15 (Fully Anechoic Chamber) Model: sd705 Serial no.: V2.1 Applicant: Skidata AG Test site: Fully anechoic room, cabin no. 2 Tested on: Test distance 3 metres Horizontal Polarization Date of test: 06/13/2006 Operator: M. Steindl Test performed: automatically File name: default.emi Detector: Peak Comment: - DC 5 V power supply - with antenna sd647 (V2.2) - polling continuously without tag List of values: Selected by hand 304050701002003004005007001000 MHz 0 5 10 15 20 25 30 35 40 45 50 55 60 dBμV/mLimit1: FCC Part 15 Transducer: VULB 9163 Result: Prescan Project file: 55426-60354 Senton GmbH / Aeussere Fruehlingstrasse 45 / D-94315 Straubing / Germany / Tel. +49 (0)9421 5522-0 / Fax +49 (0)9421 5522-99 Radiated Emission Test 30 MHz - 1 GHz acc. to FCC Part 15 (Fully Anechoic Chamber) Model: sd705 Serial no.: V2.1 Applicant: Skidata AG Test site: Fully anechoic room, cabin no. 2 Tested on: Test distance 3 metres Vertical Polarization Date of test: 06/13/2006 Operator: M. Steindl Test performed: automatically File name: default.emi Detector: Peak Comment: - DC 5 V power supply - with antenna sd647 (V2.2) - polling continuously without tag List of values: Selected by hand 304050701002003004005007001000 MHz 0 5 10 15 20 25 30 35 40 45 50 55 60 dBμV/mLimit1: FCC Part 15 Transducer: VULB 9163 Result: Prescan Project file: 55426-60354 Senton GmbH / Aeussere Fruehlingstrasse 45 / D-94315 Straubing / Germany / Tel. +49 (0)9421 5522-0 / Fax +49 (0)9421 5522-99 Radiated Emission Test 30 MHz - 1 GHz acc. to FCC Part 15 (Fully Anechoic Chamber) Model: sd705 Serial no.: V2.1 Applicant: Skidata AG Test site: Fully anechoic room, cabin no. 2 Tested on: Test distance 3 metres Horizontal Polarization Date of test: 06/13/2006 Operator: M. Steindl Test performed: automatically File name: default.emi Detector: Peak Comment: - DC 5 V power supply - with antenna sd647 (V2.2) - reading transponder card continuously (ISO 15693) List of values: Selected by hand 304050701002003004005007001000 MHz 0 5 10 15 20 25 30 35 40 45 50 55 60 dBμV/mLimit1: FCC Part 15 Transduce…

Text truncated - open the document above for the full version.

Senton GmbH Aeussere Fruehlingstrasse 45 D-94315 Straubing Test Report No. 55426-060354-1 (Edition 1) Page 24 of 124 Pages Test setup for radiated emission measurement 9 kHz ñ 30 MHz Senton GmbH Aeussere Fruehlingstrasse 45 D-94315 Straubing Test Report No. 55426-060354-1 (Edition 1) Page 25 of 124 Pages Test setup for radiated emission measurement 9 kHz ñ 30 MHz - continued - Senton GmbH Aeussere Fruehlingstrasse 45 D-94315 Straubing Test Report No. 55426-060354-1 (Edition 1) Page 26 of 124 Pages Test setup for radiated emission measurement 9 kHz ñ 30 MHz - continued - Senton GmbH Aeussere Fruehlingstrasse 45 D-94315 Straubing Test Report No. 55426-060354-1 (Edition 1) Page 27 of 124 Pages Test setup for radiated emission measurement 9 kHz ñ 30 MHz - continued - Senton GmbH Aeussere Fruehlingstrasse 45 D-94315 Straubing Test Report No. 55426-060354-1 (Edition 1) Page 28 of 124 Pages Test setup for radiated emission measurement 9 kHz ñ 30 MHz - continued - Senton GmbH Aeussere Fruehlingstrasse 45 D-94315 Straubing Test Report No. 55426-060354-1 (Edition 1) Page 29 of 124 Pages Test setup for radiated emission measurement 9 kHz ñ 30 MHz - continued - Senton GmbH Aeussere Fruehlingstrasse 45 D-94315 Straubing Test Report No. 55426-060354-1 (Edition 1) Page 30 of 124 Pages Test setup for radiated emission measurement 9 kHz ñ 30 MHz - continued - Senton GmbH Aeussere Fruehlingstrasse 45 D-94315 Straubing Test Report No. 55426-060354-1 (Edition 1) Page 31 of 124 Pages Test setup for radiated emission measurement (fully anechoic room) Senton GmbH Aeussere Fruehlingstrasse 45 D-94315 Straubing Test Report No. 55426-060354-1 (Edition 1) Page 32 of 124 Pages Test setup for radiated emission measurement (fully anechoic room) - continued - Senton GmbH Aeussere Fruehlingstrasse 45 D-94315 Straubing Test Report No. 55426-060354-1 (Edition 1) Page 33 of 124 Pages Test setup for radiated emission measurement (fully anechoic room) - continued - Senton GmbH Aeussere Fruehlingstrasse 45 D-94315 Straubing Test Report No. 55426-060354-1 (Edition 1) Page 34 of 124 Pages Test setup for radiated emission measurement (fully anechoic room) - continued - Senton GmbH Aeussere Fruehlingstrasse 45 D-94315 Straubing Test Report No. 55426-060354-1 (Edition 1) Page 35 of 124 Pages Test setup for radiated emission measurement (open field test site) Senton GmbH Aeussere Fruehlingstrasse 45 D-94315 Straubing Test Report No. 55426-060354-1 (Edition 1) Page 36 of 124 Pages Test setup for radiated emission measurement (open field test sit…
