QT2T08YOUNGHandheld Transmitter

YOUNG Electronics Corp. #396-18, CHEONG CHEON-DONG, BUPYEONG-GU, INCHEON, Korea TEL : +82-32-505-5347 FAX : 82-32-505-5349 Federal Communications Commission Authorization and Evaluation Division FCC ID : QT2T08YOUNG Confidentiality Request Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, the Applicant hereby requests confidential treatment of information accompanying this Application as outlined below: Schematics Block Diagram The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the Applicant and provide unjustified benefits to its competitors. The Applicant understands that pursuant to Rule 0.457, disclosure of this Application and all accompanying documentation will not be made before the data of the Grant for this application. Sincerely, JAE BEOM-JOO/Senior Engineer LG Electronics Inc. TEL : +82-32-505-5347 FAX : +82-54-505-5349

FCC ID : QT2T08YOUNG POWER OF ATTORNEY To whom it may concern: We the undersigned YOUNG Electronics Corp. hereby authorize ESTECH Co., Ltd.(EST) of Korea to act on our behalf in all matters relating to all processes required in the FCC Part 15C approval and any communication needed with the national authority. Any and all acts carried out by EST on our behalf shall have the same effects as acts of our own. If you have any questions regarding the authorization, please don’t hesitate to contact us. Sincerely yours, Sign JAE BEOM-JOO/Senior Engineer LG Electronics Inc. TEL : +82-32-505-5347 FAX : +82-54-505-5349

American Telecommunications Certification Body Inc. 6731 Whittier Ave, McLean, VA 22101 January 20, 2006 RE: Young Electronics Corp. FCC ID: QT2T06YOUNG After a review of the submitted information for FCC, I have a few comments on the above referenced Application. 1) FCC 2 Parts Statement given in 15.19(a)(3) should be placed on the device, or if the device is smaller than 8 x 10 cm, this statement may be placed in the manual instead. Please correct. 2) Schematics and 731 form show 300 MHz. Block Diagram and test report shows 310 MHz. Users manual shows 3 models (300, 310, and 318 MHz). This application will only cover the model tested and shown in the application. However currently information in this application is not consistent. Please correct exhibits as appropriate for consistency. Please note that the users manual may show multiple models if applicable. 3) Please explain the limit at 620 MHz. This should be 55.3 dBuV/m from my calculations. 4) Please explain the detector used for < 1 GHz. Was this peak, QP, or average. What were the RBW and VBW settings? 5) Please explain compliance to the FCC 5 second rule for manually activated transmitter. What is the holdover TX time after the button is released? Timothy R. Johnson Examining Engineer mailto: [email protected] The items indicated above must be submitted before processing can continue on the above referenced application. Failure to provide the requested information may result in application termination. Correspondence should be considered part of the permanent submission and may be viewed from the Internet after a Grant of Equipment Authorization is issued. Please do not respond to this correspondence using the email reply button. In order for your response to be processed expeditiously, you must submit your documents through the AmericanTCB.com website. Also, please note that partial responses increase processing time and should not be submitted. Any questions about the content of this correspondence should be directed to the sender.

American Telecommunications Certification Body Inc. 6731 Whittier Ave, McLean, VA 22101 January 20, 2006 RE: Young Electronics Corp. FCC ID: QT2T06YOUNG After a review of the submitted information for FCC, I have a few comments on the above referenced Application. 1) Where is the 2 part statement of 15.19(a)(3) found. This must be shown either on the device or in the manual. Please correct. 2) Schematics still appear to show components for 300 MHz. A 310 MHz version must be provided. 3) Your response does not appear to explain how the device meets the 5 second holdover/shutoff requirement by the FCC. Please explain compliance to the FCC 5 second rule for manually activated transmitter. When the button is released, how long does the transmitter continue to TX? Timothy R. Johnson Examining Engineer mailto: [email protected] The items indicated above must be submitted before processing can continue on the above referenced application. Failure to provide the requested information may result in application termination. Correspondence should be considered part of the permanent submission and may be viewed from the Internet after a Grant of Equipment Authorization is issued. Please do not respond to this correspondence using the email reply button. In order for your response to be processed expeditiously, you must submit your documents through the AmericanTCB.com website. Also, please note that partial responses increase processing time and should not be submitted. Any questions about the content of this correspondence should be directed to the sender.

Dear Timothy R. Jonson, How are you. I received comments for Young Electronics Corp. I upload revised files(test report,label location,731form) I will explain for test method of radiated emission. 1)Up to 1000Mhz:QP mode(EMI Test Receiver compliance with CISPR 16) 2)above 1000Mhz:AV/Peak mode(case of Peak:RBW:1M VBW:1M case of Average:RBW:1M VBW:10Hz) 3)Radiated limit for 620Mhz revised by 55.3dBuV value. 4)RF Frequency is 310Mhz. 5)Tested when press button compulsorily Have a good nice a weekend. If here have any problem,let me know as soon as possible. thank you, Yang. -----Original Message----- >From: Timothy R. Johnson [mailto:[email protected] ] >Sent: Friday, January 20, 2006 5:00 PM >To: [email protected] >Cc: [email protected] >Subject: Review of Young Electronics Corp., FCC ID: QT2T08YOUNG > >Jin Mo Yang, > >Attached are comments regarding review of this application. Please >provide information as soon as possible. > >Thank You, > > >Timothy R. Johnson >NARTE Certified EMC Engineer >No. EMC-002205-NE > >email: [email protected] >alternate email: [email protected] > > >Attachment Converted: "c:\documents and settings\tim johnson\my documents\atcb folder\eudora\attach\ATCB Comments_012006.pdf" From: =?ks_c_5601-1987?B?vufB+Ljw?= <[email protected]> To: <[email protected]> Subject: FW: Review of Young Electronics Corp., FCC ID: QT2T08YOUNG Page 1 of 1In 1/20/2006Printed for "Timothy R. Johnson" <[email protected]>

Dear Timothy R. Johnson, I uploaded revised files,circuit/manual. I check below items. When the button is released, how long does the transmitter continue to TX? (1)automatically deactivated the transmitter after 1 second of being released. It is very urgent.I didn't receive the grant. ASAP. Thank you, Yang.

1. FRONT 2. REAR

YOUNG Electronics Corp. GARAGE OPEN MODEL : T08 young FCC ID : QT2T08YOUNG

INTERNAL PHOTO 1. MAIN 1.1 Front 1.2 Rear

YOUNG Electronics Corp. FCC ID QT2T08YOUNG -Operational description- The Garage Door Opener Remote Command Unit is designed for general purpose remote control functions. The transmitter/receiver provides ten manually operated pushbutton which send a fixed code upon depression. The transmitter may be paired with various Link receiver modules to accommodate a variety of common periodic remote Control functions. -Setting the address- In order to allow the formation of unique Transmitter/receiver relationships the transmitters address may be selected using internal DIP switches. There is DIP switches at front cover.

Compliance Test Report for FCC Company name Address Telephone Product name Model No. Serial No. Test date Testing location Standard □ Class A■ Class BTest resultN/A □ Class A■ Class BTest resultOK Tested by Reviewed by Abbreviation * Note - This test report is not permitted to copy partly without our permission - This test result is dependent on only equipment to be used - This test result based on a single evaluation of one sample of the above mentioned OK, Pass = Passed, Fail = Failed, N/A = not applicable Young Electronics Corp. #396-18, CHEONG CHEON-DONG, BUPYEONG-GU, INCHEON, KOREA 82-32-505-5347, FAX) 82-32-505-5349 Measurement facility registration number Engineer J.H.Kim Manager Engineer J.M.Yang 94696 (Signature) (Signature) Date of issue ESTECH. Co., Ltd. 97-1 Hoiuk-Ri Majang-Myon, Icheon-city, KyungKi-Do, Korea Test item ■ Conducted Emission ■ Radiated Emission FCC PART 15.231 Subpart C(2005) , ANSI C 63.4 2003 2005-11-29 ~ 2006-01-16 T08 young NONE Young Electronics Corp. KOREA Report Number : ESTF150601-006 , Web : www. estech. co. kr Page 1 of 14 Report NumberESTF150601-006 Manufacturer Country of origin Applicant Product 16-Jan-06 GARAGE OPEN 3 4 5 6 8 8 8 9 10 10 10 11 12 14 Report Number : ESTF150601-006 , Web : www. estech. co. kr Page 2 of 14 6. Measurement of Occupied Bandwidth............................................................... 6.1 Measurement equipment ........................................................................... 6.2 Measurement result ................................................................................. 6.3 Test data ................................................................................................ 4. Measurement condition ................................................................................. 5.3 Test data ................................................................................................ 7. Photographs of test setup ........................................................................... 8. Photogra phs of EUT .................................................................................... 5.2 Environmental conditions ........................................................................ 5. Measurement of radiated emission ............................................................... 5.1 Measurement e quipment ........................................................................... Contents 1. Laboratory Information ................................................................................. 2. Description of EUT ....................................................................................... 3. Test Standards ............................................................................................. 1. Laboratory Information 1.1 General 1.2 Test Lab. Corporation Name : ESTECH Co. Ltd Head Office : Rm 1015, World Venture Center II, 426-5, Gasan-dong, Geumcheon-gu, Seoul, Kor e (Safety & Telecom. Test Lab) EMC Test Lab : 58-1 Osan-Ri, GaNam-Myon, YeoJoo-Gun, KyungKi-Do, Korea 97-1 Hoiuk-Ri Majang-Myon, Icheon-city, KyungKi-Do, Korea 1.3 Official Qualification(s) MIC : Granted Accreditation from Ministry of Information & Communication for EMC, Safety and Telecommunication KOLAS : Accredited Lab By Korea Laboratory Accreditation Schema base on CENELEC requirements FCC : Filed Laboratory at Federal Communications Commission VCCI : Granted Accreditation from Voluntary Control Council for Interference from ITE This EUT (Equipment Under Test) has been shown to be capable of compliance with the applicable technical standards and is tested in accordance with the measurement procedures as indicated in this report. ESTECH Lab attests to accuracy of test data. All measurement reported herein were performed by ESTECH Co., Ltd. ESTECH Lab assume full responsibility for the completeness of these measurements and vouch for the qualifications of all persons taking them. Report Number : ESTF150601-006 , Web : www. estech. co. kr Page 3 of 14 2. Description of EUT 2.1 Summary of Equipment Under Test NONE: Model Number : T08 young Serial Number : Manufacturer : Country of origin : Rating : Receipt Date : EUT Type: RF Remote Control Garage Open Transmitter Output Power : -37dBm Freq. Range: 310MHz Oscillator(s): 310MHZ Report Number : ESTF150601-006 , Web : www. estech. co. kr Page 4 of 14 GARAGE OPEN NONE Young Electronics Corp. KOREA INPUT:9Vdc 2005-11-29 3. Test Standards Test Standard : FCC PART 15 (2005) Test Method : ANSI C 63.4 (2003) This standard sets forth uniform methods of measurement of radio-frequency (RF) signals and noise emitted from both unintentional and intentional emitters of RF energy in the frequency range 9 kHz to 40 GHz. Methods for the measurement of radiated and AC power-line conducted radio noise are covered and may be applied to any such equipment unless otherwise specified by individual equipment requirements. These methods cover measurement of certain decides that deliberately radiate energy, such as intentional emitters, but does not cover licensed transmitters. This standard is not intended for certification/approval of avionic equipment or for industrial, scientific, and medical (ISM) equipment These method apply to the measurement of individual units or systems comprised of multiple units This Standard sets out the regulations under which an intentional, unintentional, or incidental radiator may be operated without an individual license. It also contains the technical specifications, administrative requirements and other conditions relating to the marketing of Part 15 devices. Report Number : ESTF150601-006 , Web : www. estech. co. kr Page 5 of 14 4. Measurement Condition 4.1 EUT Operation. 4.2 Configuration and Peripherals * The EUT was in the following operation mode during all testing * The operational conditions of the EUT was determined by the manufacturer according to the typical use of the EUT with respect to the expected hightest level of em…

Text truncated - open the document above for the full version.

TEST SETUP PHOTO 1. Radiated Emission setup photo (30 ~ 1000 MHz) 1.1. Front 1.2. Rear 2. Radiated Emission setup photo (Above 1000 MHz)
