ETL Inc. #584 Sangwhal-ri, Kanam-myon, Yoju-kun, Kyounggi-do, 469-885, Korea 5 of 17 FCC ID : QTMOR1703 Report No:E03.0621.FCC.365N Issue of Date: June 21, 2003 YURI ELECTRONICS CO., LTD. LCD MONITOR Model : OR1703 2.1 Equipment Description The Equipment Under Test(EUT) is the YURI ELECTRONICS CO., LTD. / LCD MONITOR/ OR1703 Please refer to Users manual 2.2 General Specification l Chassis Type : Plastic & Metal Cover l List of Each OSC. Or X-Tal. Freq. (>=1MHz) : X-TAL – 24.0MHz, 14.31818MHz l Chipset Brand & Part No. : MST9111 – M l Number of Layers : Main board – 4Layers, Inverter board – 4 Layers, Front board – 2 Layers l Screen size : 17” l Display size : 337.92mm (H) X 270.34mm (V) l Screen Coating : Anti-glare & Hard-coating l Pixel Pitch : 0.264mm X 0.264mm l Brightness : 250cd/ l Contrast Scaling : 500:1 l Viewing Angle : 85/85/85/85 (left/right/up/down) l Response Time : Tr = 20ms, Tf = 15ms l RGB Input : Analog RGB 0.7Vp-p l H-Frequency : 30 ~ 61KHz l V-Frequency : 55 ~ 75Hz l Resolution : 1280 X 1024 @60Hz l Panel color : 16.7M Colors l Power : 35W (Normal mode) l Consumption : 5W (Power-Saving mode)
