QUYUW2003AUW2003A

U U W W 2 2 0 0 0 0 3 3 A A Ve r s i o n 1. 0 Dec.2021 © Initio 2021. All right reserved. Copying prohibited This document is confidential 1 S pecification For USB 802.11 ac/a/b/g/n WiFi USB Nano dongle UW2003A R e v. 1. 0 2012-2021 Well Linkage, Co. Ltd. This document contain information that is proprietary to Well Linkage, Co. Ltd Unauthorized reproduction or disclosure of this information in whole or in part is strictly prohibited. Specification are subject to change without notice. U U W W 2 2 0 0 0 0 3 3 A A Ve r s i o n 1. 0 Dec.2021 © Initio 2021. All right reserved. Copying prohibited This document is confidential 2 Overview UW2003A is 802.11 ac/a/b/g/n 2.4G/5G dual band 1T1R USB Nano dongle. It run up to 433Mbps (MCS9) 5G and 150Mbps 2.4G and delivers superior WiFi output up to 16dBm. It use highly integrated SOC chip RTL8811CU. UW2003A have small form factor and high performance design for wireless connection with popular USB interface. It is good choose for high throughput networking and multimedia application. In addition, it not only support WPS for easy connection, but also support security encryption through WPA, WPA2 ..and so on. U U W W 2 2 0 0 0 0 3 3 A A Ve r s i o n 1. 0 Dec.2021 © Initio 2021. All right reserved. Copying prohibited This document is confidential 3 Feature: 1. Dual band 1T1R mode with support of 433Mbps 5G + 150Mbps 2.4G PHY rate 2. I EEE 802.11 a/b/g/n and 802.11ac client 3. T ransmit Beanforming and STBC 4 . Q OS: WFA WMM, WMM PS 5. Security : WFA WPA/WPA2 personal, WAPI, WPS2.0 6. Integrate high efficiency switching regulator 7. Supports 802.11w protected managed frames 8. Support WPS 9. Su pports Wi-Fi Direct 10. A ntenna: IPEX antenna 11. U SB 2.0/1.1 USB-A type Nang dongle 13. S upport Windows XP, Vista, Win 7, Win8, Linux 2.6.x U U W W 2 2 0 0 0 0 3 3 A A Ve r s i o n 1. 0 Dec.2021 © Initio 2021. All right reserved. Copying prohibited This document is confidential 4 Application: Desk-Top/Mini PC/Note-Book Mobile, portable smart device Set-top box/Media player Tablet Blue-ray Disk Property: Main Chip Realtek RTL8811CU WiFi Standard IEEE 802.11 a/b/g/n/ac Frequency 2.4~2.4835GHz 5.15GHx ~5.850GHz USB type 2.0/1.1 Data Rates 11ac: MCS0 ~MCS9 11n: MCS0~MCS7 11a/g: 6~54 Mbps 11b:1~11 Mbps Modulation 802.11ac:OFDM(BPSK, QPSK, 16-QAM, 64-QAM, 256-QAM) 802.11a/n/g:(BPSK, QPSK, 16-QAM, 64-QAM) 802.11b:(DBSK,DQPSK,CCK) TX power 802.11ac HT20: 12+/-1.5dBm@MCS8 802.11ac HT40: 12+/-1.5dBm@MCS9 802.11ac HT80: 12+/-1.5dBm@MCS9 802.11a/g: 12 +/-1.5dBm@54Mbps 802.11gn HT20: 12+/-1.5dBm@MCS7 802.11gn HT40: 12+/-1.5dBm@MCS7 802.11an HT20: 12+/-1.5dBm@MCS7 802.11an HT20: 12+/-1.5dBm@MCS7 U U W W 2 2 0 0 0 0 3 3 A A Ve r s i o n 1. 0 Dec.2021 © Initio 2021. All right reserved. Copying prohibited This document is confidential 5 802.11b: 15+/-1.5dBm@11Mbps RX Sensitivity 802.11ac: -59dBm+/-2dBm @HT20 MCS8 802.11ac: -56dBm+/-2dBm @HT40 MCS9 802.11ac: -51dBm+/-2 dBm @HT80 MCS9 802.11n: -66dBm+/-2dBm @HT20 MCS7 802.11n: -63dBm+/-2dBm @HT40 MCS7 802.11a/g:-67dBm+/-2dBm@54Mbps 802.11b:-73dBm+/-2dBm@11Mbps Power Consumption Idle : 38mA Continue RX: 240mA Continue TX: 355mA Environment Operation Temperature Range -20~60°C Storing Temperature Range -10~70°C Operation Humidity: 5% ~ 90% Storing Humidity: 5% ~ 90% Production Dimension: This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Any changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: -- Reorient or relocate the receiving antenna. -- Increase the separation between the equipment and receiver. -- Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. -- Consult the dealer or an experienced radio/ TV technician for help. Specific Absorption Rate (SAR) information: This Nano dongle meets the government's requirements for exposure to radio waves. The guidelines are based on standards that were developed by independent scientific organizations through periodic and thorough evaluation of scientific studies. The standards include a substantial safety margin designed to assure the safety of all persons regardless of age or health. FCC RF Exposure Information and Statement The SAR limit of USA (FCC) is 1.6 W/kg averaged over one gram of tissue. Device types: UW2003A (FCC ID: QUYUW2003A) has also been tested against this SAR limit. The highest SAR value reported under this standard during product certification for use at when properly worn on the body is 1.23 W/kg This device was tested for typical body-worn operations with the back of the Nano dongle kept 0mm from the body. Body-worn Operation This device was tested for typical body-worn operations. To comply with RF exposure requirements, a minimum separation distance of 0mm must be maintained betweenthe user’s body and the handset, including the antenna. Third-party belt-clips, holsters, and similar accessories used by this device sh…
