QVNBTSUPER2PBluetooth Handsfree Car Kit

1 User Guide Supertooth II Universal Bluetooth Handsfree Kit with DSP Contents ____________________________________________________________ Product Overview . . . . . . . . . . . . . . . . . . . . . . . . . . .1 Switching On/Off. . . . . . . . . . . . . . . . . . . . . . . . . . . .2 Charging . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2 Installation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2 Pairing to a Mobile Phone . . . . . . . . . . . . . . . . . . . . . . .3 Indicator Status. . . . . . . . . . . . . . . . . . . . . . . . . . . . .4 Hands-free Profile . . . . . . . . . . . . . . . . . . . . . . . . . . .4 SuperTooth II Operations. . . . . . . . . . . . . . . . . . . . . .4 Button Functions Matrix . . . . . . . . . . . . . . . . . . . . . .5 Headset Profile. . . . . . . . . . . . . . . . . . . . . . . . . .6 SuperTooth II Operations. . . . . . . . . . . . . . . . . . . . . .6 Button Functions Matrix . . . . . . . . . . . . . . . . . . . . . .7 SuperTooth II is equipped with Bluetooth and Digital Signal Processor which allow wireless communications on devices such as cellular phones. This is designed to be a totally portable wireless handsfree kit which will enable the user to communicate freely without holding the phone. This will work on any Bluetooth cellular phones available provided that they respect the Bluetooth protocol. 1 Swivel Arm 2 Reject Button 3 Headphone Jack 4 Speaker 5 Charger Input 6 Accept / End Button 7 Microphone 8 Bluetooth Indicator 9 Charge Indicator 10 Volume Control A. PRODUCT OVERVIEW 2 Note: The Swivel Arm[1] can be adjusted to 0º , 55º and 210º orientations. Power on: Flip up the Swivel Arm [1] from 0º to 55º to 210º positions. The Bluetooth indicator[8] will glow (blue blink). This indicates that the kit is ready (standby mode). Note: At first use, the user has to pair SuperTooth II with his phone (refer to Section E PAIRING TO A MOBILE PHONE.) Power off: Flip down the Swivel Arm to 0º position. The Bluetooth Indicator will become red then turns off after a second. 1. Plug the battery charger connector into the Charger Input [5] of SuperTooth II. 2. Plug the other end of the charger into the electrical outlet. Fixing of Clip Fix the metal clip of SuperTooth II on the sun visor. Sun visor Attach the magnetic back of SuperTooth II to the fixed metal clip. The SuperTooth must be placed wherein its microphone will be directed to the mouth of the user. The position of the SuperTooth II can vary according to the position of the sun visor. The Swivel Arm(1) can be adjusted to 0º, 55º and 210 º orientations. B. SWITCHING ON/OFF C. CHARGING D. INSTALLATION 3 Pairing will create a link or connection between the two Bluetooth devices, the SuperTooth II and your phone. 1. Bring the mobile phone at about 20cm from the SuperTooth II. 2. The SuperTooth II is initially off; Turn it on by flipping up the Swivel Arm[1] to 55º position. The Bluetooth Indicator[8] will glow (blue blink). 3. Simultaneously press the Reject Button[2] and Accept/End Button[6] for about 5 seconds. A distinctive tone will be heard and the Bluetooth Indicator LED will change from blinking blue to alternate blinking red and blue. The SuperTooth II is now in Pairing Mode. 4. While the kit is at pairing mode, access the Bluetooth menu of your phone. (Kindly refer to your phone’s manual.) Turn on its Bluetooth function then execute a Bluetooth search so that it will be able to search and find your SuperTooth II. 5. When the phone displays the list of the Bluetooth devices it found, select the name of this kit (SuperTooth II). 6. When the phone asks for the passcode, enter 0000. Pairing is successful if the alternating red/blue lights of Bluetooth Indicator changes to plain blinking blue. Note : Normally, the phone would also show briefly on its display if it’s already paired and connected to the SuperTooth II or if pairing with it failed. Important Note: Some phones do not connect directly after entering 0000. To connect, you need to short press the Accept / End Button[6]. Or, (In your phone) Go back to Bluetooth> Paired devices> highlight the name of this kit (SuperTooth II) > press Options > then press Connect). If pairing has been successful, the SuperTooth II is now ready to use. E. PAIRING TO A MOBILE PHONE (not possible while charging the SuperTooth II) 4 STATUS Bluetooth Indicator [8] Charge Indicator [9] Pairing Mode Alternate Blinking - Red / Blue Standby mode Blinking Blue On Call Steady Blue Low Batt Blinking Red Charging Alternate Red / Green Fully Charged Steady Green Ringing Fast Blinking Blue Supertooth II OPERATIONS Make a Call (Normal dial): Dial the number using your phone. Normally, audio will be on the SuperTooth II. Note: With some phones like Siemens S55; Panasonic X70, audio is always on the phone during an outgoing call. You will need to short press Accept / End Button[6] to transfer the audio to your kit. Make a Call (Voice dial): 1. First, you have to access the voice dialing function of your phone, turn it on and record for a voice tag. (Kindly refer to the procedure in your phone’s manual.) Note: Voice dialing entries must be stored in the phone’s memory, not on the SIM card! When done, execute voice dialing in your kit by proceeding with the instructions. 2. Execute Voice dial: Short press Accept/ End Button[6]. 3. A beep/short tone will then be heard on the SuperTooth II prompting the user to say the voice tag of a contact to call. 4. Say the voice tag. The voice will be played back to you (audio on kit) then the phone will dial the number automatically. Make a Call (Redial): Long press the Accept/ End Button[6]. Audio will be on the SuperTooth II. End a Call (2 options for Hands-free Profile): Short press the Accept/ End Button[6] or short press Reject Button[2]. F. Indicator Status G. HANDS-FREE PROFILE 5 Answer a Call: When the phone receives a call, ring tone will be on the SuperTooth II alone, or both on the SuperTooth II and on …

Text truncated - open the document above for the full version.

November 22, 2005 Federal Communications Commission Authorization and Evaluation Division FCC ID: QVNBTSUPER2P Confidentiality Request Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, the Applicant hereby requests confidential treatment of information accompanying this Application as outlined below: 1.Schematics 2.Block Diagram 3.Operational Description The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the Applicant and provide unjustified benefits to its competitors. The Applicant understands that pursuant to Rule 0.457, disclosure of this Application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely, Michel Marchant / President Euro Communication Equipments SAS

Report No EF/2005/B0023 ID: QVNBTSUPER2P Issue Date: Dec. 13, 2005 The results shown in this test report refer only to the sample(s) tested unless otherwise stated. This test report cannot be reproduced, except in full, without prior written permission of the Company. SGS Taiwan Ltd. No. 134, Wu Kung Rd., Wuku Industrial Zone, Taipei Country, Taiwan. / 台北縣五股工業區五工路134號 台灣檢驗科技股份有限公司 t (886-2) 2299-3939 f (886-2) 2298-2698 www.sgs.com.tw APPENDIX 2 EXTERNAL PHOTOGRPHS OF EUT Report No EF/2005/B0023 ID: QVNBTSUPER2P Issue Date: Dec. 13, 2005 The results shown in this test report refer only to the sample(s) tested unless otherwise stated. This test report cannot be reproduced, except in full, without prior written permission of the Company. SGS Taiwan Ltd. No. 134, Wu Kung Rd., Wuku Industrial Zone, Taipei Country, Taiwan. / 台北縣五股工業區五工路134號 台灣檢驗科技股份有限公司 t (886-2) 2299-3939 f (886-2) 2298-2698 www.sgs.com.tw All View of EUT Front View of EUT Report No EF/2005/B0023 ID: QVNBTSUPER2P Issue Date: Dec. 13, 2005 The results shown in this test report refer only to the sample(s) tested unless otherwise stated. This test report cannot be reproduced, except in full, without prior written permission of the Company. SGS Taiwan Ltd. No. 134, Wu Kung Rd., Wuku Industrial Zone, Taipei Country, Taiwan. / 台北縣五股工業區五工路134號 台灣檢驗科技股份有限公司 t (886-2) 2299-3939 f (886-2) 2298-2698 www.sgs.com.tw Back View of EUT Right View of EUT Report No EF/2005/B0023 ID: QVNBTSUPER2P Issue Date: Dec. 13, 2005 The results shown in this test report refer only to the sample(s) tested unless otherwise stated. This test report cannot be reproduced, except in full, without prior written permission of the Company. SGS Taiwan Ltd. No. 134, Wu Kung Rd., Wuku Industrial Zone, Taipei Country, Taiwan. / 台北縣五股工業區五工路134號 台灣檢驗科技股份有限公司 t (886-2) 2299-3939 f (886-2) 2298-2698 www.sgs.com.tw Top View of EUT

FCC ID LABEL FORMAT AND LOCATION Applicant: Shanghai Flaircomm Technologies. FCC ID: QVNBTSUPER2P

Report No EF/2005/B0023 ID: QVNBTSUPER2P Issue Date: Dec. 13, 2005 The results shown in this test report refer only to the sample(s) tested unless otherwise stated. This test report cannot be reproduced, except in full, without prior written permission of the Company. SGS Taiwan Ltd. No. 134, Wu Kung Rd., Wuku Industrial Zone, Taipei Country, Taiwan. / 台北縣五股工業區五工路134號 台灣檢驗科技股份有限公司 t (886-2) 2299-3939 f (886-2) 2298-2698 www.sgs.com.tw APPENDIX 3 INTERNAL PHOTOGRPHS OF EUT Report No EF/2005/B0023 ID: QVNBTSUPER2P Issue Date: Dec. 13, 2005 The results shown in this test report refer only to the sample(s) tested unless otherwise stated. This test report cannot be reproduced, except in full, without prior written permission of the Company. SGS Taiwan Ltd. No. 134, Wu Kung Rd., Wuku Industrial Zone, Taipei Country, Taiwan. / 台北縣五股工業區五工路134號 台灣檢驗科技股份有限公司 t (886-2) 2299-3939 f (886-2) 2298-2698 www.sgs.com.tw Open View of EUT Report No EF/2005/B0023 ID: QVNBTSUPER2P Issue Date: Dec. 13, 2005 The results shown in this test report refer only to the sample(s) tested unless otherwise stated. This test report cannot be reproduced, except in full, without prior written permission of the Company. SGS Taiwan Ltd. No. 134, Wu Kung Rd., Wuku Industrial Zone, Taipei Country, Taiwan. / 台北縣五股工業區五工路134號 台灣檢驗科技股份有限公司 t (886-2) 2299-3939 f (886-2) 2298-2698 www.sgs.com.tw Internal of EUT – 1 Internal of EUT – 2 Report No EF/2005/B0023 ID: QVNBTSUPER2P Issue Date: Dec. 13, 2005 The results shown in this test report refer only to the sample(s) tested unless otherwise stated. This test report cannot be reproduced, except in full, without prior written permission of the Company. SGS Taiwan Ltd. No. 134, Wu Kung Rd., Wuku Industrial Zone, Taipei Country, Taiwan. / 台北縣五股工業區五工路134號 台灣檢驗科技股份有限公司 t (886-2) 2299-3939 f (886-2) 2298-2698 www.sgs.com.tw Internal of EUT – 3 Internal of EUT – 4 Report No EF/2005/B0023 ID: QVNBTSUPER2P Issue Date: Dec. 13, 2005 The results shown in this test report refer only to the sample(s) tested unless otherwise stated. This test report cannot be reproduced, except in full, without prior written permission of the Company. SGS Taiwan Ltd. No. 134, Wu Kung Rd., Wuku Industrial Zone, Taipei Country, Taiwan. / 台北縣五股工業區五工路134號 台灣檢驗科技股份有限公司 t (886-2) 2299-3939 f (886-2) 2298-2698 www.sgs.com.tw Internal of EUT – 5

Technical description of the BTSUPER2P Hansdfree kit The BTSUPER2P unit is a Bluetooth ™ compatible Class 2 device, which receives and transmits in the frequency range of 2.402-2.480GHz. It is a spread spectrum (frequency hopping) headset; 79 channels, 1MHz Bandwidth, frequency hops at 1600 hops/second per the Bluetooth standard. The unit communicates with other Bluetooth devices using a time division duplex scheme that alternates transmission and receive functions, and thus uses the same antenna to transmit and receive at different times. The unit contains Philips single chip radio with 3V and 1.8V voltage regulation circuit, battery protection and charging circuit. A common antenna is used to send and receive RF signals. The Noise and echo canceling DSP is used to achieve noise and echo reduction on the received and transmitted audio signal. Battery charging is done with an over-charge and protection circuit to charge a rechargeable battery. The handsfree kit can communicate with other Bluetooth ™ products that support the Headset and Handsfree Profile. Refer to the users manual for basic functions of this unit. BTSUPER2P Specification: • Full Duplex. • Bluetooth version 1.2 • Support handsfree and headset profile. • Compatible to any Bluetooth cellphone. • Talk Time: 15 hrs. • Standby Time: up to 600 hrs. • Built-in noise canceling microphone. • Adjustable volume control. • Internal Digital Signal Processor DSP for noise cancellation and echo suppression. • Light indicators: Power, Pairing, Charging, Low Battery, Full-Charge. • Charging time: 1 1/2 hours • Strong 50mm speaker. • ON-OFF Switch. • Size: 150 x 60 x 25mm. • Weight : 130g.

Report No EF/2005/B0023 ID: QVNBTSUPER2P Issue Date: Dec. 22, 2005 Page: 1 of 54 The results shown in this test report refer only to the sample(s) tested unless otherwise stated. This test report cannot be reproduced, except in full, without prior written permission of the Company. SGS Taiwan Ltd. No. 134, Wu Kung Rd., Wuku Industrial Zone, Taipei Country, Taiwan. / 台北縣五股工業區五工路134號 台灣檢驗科技股份有限公司 t (886-2) 2299-3939 f (886-2) 2298-2698 www.sgs.com.tw ELECTROMAGNETIC EMISSIONS COMPLIANCE REPORT INTENTIONAL RADIATOR CERTIFICATION TO FCC PART 15 SUBPART C REQUIREMENT OF Product Name: SUPERTOOTH 2 Brand Name: Freetop Model Name: BTSUPER2P FCC ID: QVNBTSUPER2P Report No.: EF/2005/B0023 Issue Date: Dec. 13, 2005 FCC Rule Part: §15.247 Prepared for: Euro Communication Equipements SAS Route de Foix 11500 Nebias, Quillan, France Prepared by: SGS Taiwan Ltd. No. 134, Wu Kung Rd., Wuku Industrial Zone, Taipei County, Taiwan. Note: This report shall not be reproduced except in full, without the written approval of SGS Taiwan Ltd. This document may be altered or revised by SGS Taiwan Ltd. personnel only, and shall be noted in the revision section of the document. Report No EF/2005/B0023 ID: QVNBTSUPER2P Issue Date: Dec. 22, 2005 Page: 2 The results shown in this test report refer only to the sample(s) tested unless otherwise stated. This test report cannot be reproduced, except in full, without prior written permission of the Company. SGS Taiwan Ltd. No. 134, Wu Kung Rd., Wuku Industrial Zone, Taipei Country, Taiwan. / 台北縣五股工業區五工路134號 台灣檢驗科技股份有限公司 t (886-2) 2299-3939 f (886-2) 2298-2698 www.sgs.com.tw VERIFICATION OF COMPLIANCE Applicant: Euro Communication Equipements SAS Route de Foix 11500 Nebias, Quillan, France Equipment Under Test: SUPERTOOTH 2 Brand Name: Freetop FCC ID Number: QVNBTSUPER2P Model No.: BTSUPER2P Model Difference: N/A File Number: EF/2005/B0023 Date of test: Nov. 25, 2005 ~ Dec. 09, 2005 Date of EUT Received: Nov. 24, 2005 We hereby certify that: The above equipment was tested by SGS Taiwan Ltd. The test data, data evaluation, test proce- dures, and equipment configurations shown in this report were made in accordance with the procedures given in ANSI C63.4 (2003) and the energy emitted by the sample EUT tested as described in this report is in compliance with conducted and radiated emission limits of FCC Rules Part 15.247 The test results of this report relate only to the tested sample identified in this report. Test By: Date Dec. 13, 2005 Henk Huang Prepared By: Date Dec. 13, 2005 Eva Kao Approved By: Date Dec. 13, 2005 Vincent Su Report No EF/2005/B0023 ID: QVNBTSUPER2P Issue Date: Dec. 22, 2005 Page: 3 The results shown in this test report refer only to the sample(s) tested unless otherwise stated. This test report cannot be reproduced, except in full, without prior written permission of the Company. SGS Taiwan Ltd. No. 134, Wu Kung Rd., Wuku Industrial Zone, Taipei Country, Taiwan. / 台北縣五股工業區五工路134號 台灣檢驗科技股份有限公司 t (886-2) 2299-3939 f (886-2) 2298-2698 www.sgs.com.tw Version Version No. Date 00 Dec. 13, 2005 01 Dec. 22, 2005 Report No EF/2005/B0023 ID: QVNBTSUPER2P Issue Date: Dec. 22, 2005 Page: 4 The results shown in this test report refer only to the sample(s) tested unless otherwise stated. This test report cannot be reproduced, except in full, without prior written permission of the Company. SGS Taiwan Ltd. No. 134, Wu Kung Rd., Wuku Industrial Zone, Taipei Country, Taiwan. / 台北縣五股工業區五工路134號 台灣檢驗科技股份有限公司 t (886-2) 2299-3939 f (886-2) 2298-2698 www.sgs.com.tw Table of Contents 1. GENERAL INFORMATION .........................................................................................................7 1.1. Product Description ............................................................................................................................7 1.2. Related Submittal(s) / Grant (s) ..........................................................................................................7 1.3. Test Methodology ...............................................................................................................................7 1.4. Test Facility.........................................................................................................................................7 1.5. Special Accessories .............................................................................................................................7 1.6. Equipment Modifications....................................................................................................................7 2. SYSTEM TEST CONFIGURATION ............................................................................................8 2.1. EUT Configuration .............................................................................................................................8 2.2. EUT Exercise ......................................................................................................................................8 2.3. Test Procedure.....................................................................................................................................8 2.4. Configuration of Tested System..........................................................................................................9 3. SUMMARY OF TEST RESULTS ...............................................................................................10 4. DESCRIPTION OF TEST MODES ............................................................................................10 5. CONDUCTED EMISSION TEST................................................................................................11 5.1. Standard Applicable ..........................................................................................................................11 5.2. EUT Setup.........................................................................................................................................11 5.3. Mea…

Text truncated - open the document above for the full version.
