QWHUL1-THigh-Performance UHF Wireless In-Ear Monitoring System

Quick Start Guide UL 1000G2 High-Performance UHF Wireless In-Ear Monitoring System V 1.0 2UL 1000G2 Terminals marked with this symbol carry electrical current of suffi cient magnitude to constitute risk of electric shock. Use only high-quality professional speaker cables with 1/4" TS or twist-locking plugs pre-installed. All other installation or modifi cation should be performed only by qualifi ed personnel. This symbol, wherever it appears, alerts you to the presence of uninsulated dangerous voltage inside the enclosure - voltage that may be suffi cient to constitute a risk of shock. This symbol, wherever it appears, alerts you to important operating and maintenance instructions in the accompanying literature. Please read the manual. Caution To reduce the risk of electric shock, do not remove the top cover (or the rear section). No user serviceable parts inside. Refer servicing to qualifi ed personnel. Caution To reduce the risk of fi re or electric shock, do not expose this appliance to rain and moisture. The apparatus shall not be exposed to dripping or splashing liquids and no objects fi lled with liquids, such as vases, shall be placed on the apparatus. Caution These service instructions are for use by qualifi ed service personnel only. To reduce the risk of electric shock do not perform any servicing other than that contained in the operation instructions. Repairs have to be performed by qualifi ed service personnel. 1. Read these instructions. 2. Keep these instructions. 3. Heed all warnings. 4. Follow all instructions. 5. Do not use this apparatus near water. 6. Clean only with dry cloth. 7. Do not block any ventilation openings. Install in accordance with the manufacturer’s instructions. 8. Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus (including amplifi ers) that produce heat. 9. Do not defeat the safety purpose of the polarized or grounding-type plug. A polarized plug has two blades with one wider than the other. A grounding-type plug has two blades and a third grounding prong. The wide blade or the third prong are provided for your safety. If the provided plug does not fi t into your outlet, consult an electrician for replacement of the obsolete outlet. 10. Protect the power cord from being walked on or pinched particularly at plugs, convenience receptacles, and the point where they exit from the apparatus. 11. Use only attachments/accessories specifi ed by the manufacturer. 12. Use only with the cart, stand, tripod, bracket, or table specifi ed by the manufacturer, or sold with the apparatus. When a cart is used, use caution when moving the cart/apparatus combination to avoid injury from tip-over. 13. Unplug this apparatus during lightning storms or when unused for long periods of time. 14. Refer all servicing to qualifi ed service personnel. Servicing is required when the apparatus has been damaged in any way, such as power supply cord or plug is damaged, liquid has been spilled or objects have fallen into the apparatus, the apparatus has been exposed to rain or moisture, does not operate normally, or has been dropped. 15. The apparatus shall be connected to a MAINS socket outlet with a protective earthing connection. 16. Where the MAINS plug or an appliance coupler is used as the disconnect device, the disconnect device shall remain readily operable. 17. Correct disposal of this product: This symbol indicates that this product must not be disposed of with household waste, according to the WEEE Directive (2012/19/EU) and your national law. This product should be taken to a collection center licensed for the recycling of waste electrical and electronic equipment (EEE). The mishandling of this type of waste could have a possible negative impact on the environment and human health due to potentially hazardous substances that are generally associated with EEE. At the same time, your cooperation in the correct disposal of this product will contribute to the effi cient use of natural resources. For more information about where you can take your waste equipment for recycling, please contact your local city offi ce, or your household waste collection service. 18. Do not install in a confi ned space, such as a book case or similar unit. 19. Do not place naked fl ame sources, such as lighted candles, on the apparatus. 20. Please keep the environmental aspects of battery disposal in mind. Batteries must be disposed-of at a battery collection point. 21. This apparatus may be used in tropical and moderate climates up to 45°C. 22. WARNING To prevent possible hearing damage, do not listen at high volume levels for long periods. As a guide to setting the volume level, check that you can still hear your own voice, when speaking normally while listening with the headphones. 23. WARNING • • As with all small batteries, the batteries used with this product should be kept away from small children who still put things in their mouths. If they are swallowed, promptly call your local poison control center. • • Always purchase the correct size and grade of battery most suitable for intended use. • • Replace all batteries of a set at the same time. • • Clean the battery contacts, and also those of the device prior to battery installation. • • Ensure the batteries are installed correctly with the regard to polarity (+ and -). • • Always remove battery if consumed or if product is to be left unused for a long time. • • Replacement of a battery with an incorrect type can defeat a safeguard. Replace only with the same or equivalent type. • • Risk of fi re or explosion if the battery is replaced by an incorrect type. • • Batteries (battery pack or batteries installed) shall not be exposed to excessive heat such as sunshine, fi re or the like. • • Disposal of a battery into fi re or a hot oven, or mechanically crushing or cutting of a battery can result in an explosion. • • Leaving a battery in an extremely high temperature surrounding environment can …

Text truncated - open the document above for the full version.

Music Tribe Commercial MY Sdn. Bhd. Declaration of Authorization We Name: Music Tribe Commercial MY Sdn. Bhd. Address: 1-17-02, Suntech @ Penang Cybercity, LinTang Mayang Pasir 3, City: Bayan Baru, Pulau Pinang Country: Malaysia Declare that: Name Representative of agent: Ms. Rose Liu Agent Company name: BTL Inc. Address: No.3 Jinshagang 1 st Road, Shixia, Dalang Town City: Dong Guan Country: China is authorized to apply for Certification and signing related documents of the following product(s), including 731 form(s): Product description: High-Performance UHF Wireless In-Ear Monitoring System Type designation: UL 1000G2 Trademark: Behringer FCC ID: QWHUL1-T on our behalf. Date: 2022-11-18 City: Bayan Baru, Pulau Pinang Name: Kane Xin Function: Innovation Compliance Leader Signature: -----------------------------------------

Rev 11/20/07 Music Tribe Commercial MY Sdn. Bhd. Federal Communications Commission Authorization and Evaluation Division Confidentiality Request regarding application for certification of FCC ID: (QWHUL1-T). Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, we hereby request confidential treatment of information accompanying this application as outlined below: Exhibit Type File Name Schematics, Block Diagram, Operational Description, 4. Schematics 5. Block Diagram 6. Operatinal Description The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Section 0.457 of the Rules, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. It is our understanding that all measurement test reports, FCC ID label format and correspondence during the certification review process cannot be granted as confidential documents and this information will be available for public review once the grant of equipment authorization is issued. (signature) Kane Xin

Model Declaration Letter We, the undersigning company Company Name: Music Tribe Commercial MY Sdn. Bhd. Address: 1-17-02, Suntech @ Penang Cybercity, LinTang Mayang Pasir 3, Bayan Baru, Pulau Pinang, Malaysia Hereby confirm that the following products: Product description: High-Performance UHF Wireless In-Ear Monitoring System Type designation: UL 1000G2 Trademark: Behringer That The difference as below: UL 1000G2-T (UHF Wireless Transmitter), UL 1000G2-R (UHF Wireless Belt-Pack Receiver) UL 1000G2 is a bundle of Transmitter and Receiver. UL 1000G2-R is receiver which will be sold separately, it's same receiver with the one in UL 1000G2. Date: 2022-11-18 Name: Kane Xin Telephone: +86-15818554545 E-mail: [email protected] Signature:

Page 1 of 4 Report No.: STS2210066 APPENDIX-PHOTOGRAPHS OF EUT CONSTRUCTIONAL DETAILS Model: UL 1000G2 Photo 1 Photo 2 Page 2 of 4 Report No.: STS2210066 Photo 3 Photo 4 Page 3 of 4 Report No.: STS2210066 Photo 5 Photo 6 Antenna Page 4 of 4 Report No.: STS2210066 Photo 7

ARTW_BE_0404-AAA_UL-1000G2_LAB-Bottom1-3x2.25in _TMS6ARTW_BE_0404-AAA_UL-1000G2_LAB-Bottom2-3x2.25in _TMS6 PRINTING DATA CAN ICES – 3 ( B )/ NMB – 3 ( B ) MADE IN CHINA Model : UL 1000G 2 Manufacturer : Mu sic Tr ib e C o mme r c i al MY S dn . Bh d . MADE IN CHINA This equipment complies with Par t 15 of the FCC Rules. Operation is subject to the following t wo ( 2 ) conditions: ( 1 ) this device may not cause harmful inter ference, and ( 2 ) this device must accept any inter ference received, including inter ference that may cause undesired operation. Music Tribe Brands DK A / S Gammel Strand 44 DK – 1202 København K, Denmark Music Tribe Brands UK Ltd. 6 Lloyds Avenue Unit 4CL London EC3N 3A X United Kingdom FCC ID : QWHUL1 – T High-Performance UHF Wireless In-Ear Monitoring System OVERVIEW NOT FOR PRINT, ONLY FOR ORIENTATION! For Print Dat a 1) Only use the l atest Adobe Acrobat Reader when opening Print Dat a for v erification. 2) Do not edit/alte r t he Print Dat a. I f c hanges are required (clearance, e tc .), the Print Dat a must be returned to Music Tribe for r evision. 3) Disto rte d or corrupte d Print Dat a (or t hose with questio nable quality) should be returned to Music Tribe i mmediately. 4) Please always consult Music Tribe for any additio nal c oncerns. 关于打印 数据 1）只能使用最新的Adobe Acrobat Reader软件来打开打印数据进行验证。 2）请勿编辑/ 修改打 印数据。 如果需要更改（清除等），则必须将打印数据返回给Music Tribe进行修 订。 3）失真或损坏的打印数据（或质量有问题的）应立即退还给Music Tribe。 4）如果有任何其他疑问，请随时咨询Music Tribe。 SCALE 1:2 PLACE LABEL ON THE BOTTOM HB00-04345-000 C. Cortez X TMS6 2022/07/18 - Updated FCC ID - Document update to TMS6 OLD ARTWORK NO: ART-TMP-00989 0404-AAA UL 1000G2 (P0EST) LABEL SPECIFICATION Siz e: 3in x 2.25in COR. RAD 0.08in Color: Pan tone Process Bla ck C Material: Plastic Dim ens ion Tolerance: ±0.015in (0.381mm) Note: Label must be UL969 compliant Model : UL 1000G 2 Manufacturer : Mu sic Tr ib e C o mme r c i al MY S dn . Bh d .

Page 1 of 5 Report No.: STS2210066 APPENDIX-PHOTOGRAPHS OF EUT CONSTRUCTIONAL DETAILS Model: UL 1000G2 Photo 1 Photo 2 Page 2 of 5 Report No.: STS2210066 Photo 3 Photo 4 Page 3 of 5 Report No.: STS2210066 Photo 5 Photo 6 Page 4 of 5 Report No.: STS2210066 Photo 7 Photo 8 Page 5 of 5 Report No.: STS2210066 Photo 9 Photo 10

Any reproduction of this document must be done in full. No single part of this document may be reproduced without permission from STS, all test data presented in this report is only applicable to presented test sample. Shenzhen STS Test Services Co., Ltd. A 1/F, Building B, Zhuoke Science Park, No.190 Chongqing Road, HepingShequ, Fuyong Sub-District, Bao’an District, Shenzhen, Guang Dong, China TEL: +86-755 3688 6288 FAX: +86-755 3688 6277 E-mail:[email protected] RADIO TEST REPORT Report No: STS2210066H01 Issued for Music Tribe Commercial MY Sdn. Bhd. 1-17-02, Suntech @ Penang Cybercity, LinTang Mayang Pasir 3, Bayan Baru, Pulau Pinang, Malaysia Product Name: High-Performance UHF Wireless In-Ear Monitoring System Brand Name: Behringer Model Name: UL 1000G2 Series Model: N/A FCC ID: QWHUL1-T Test Standard: FCC 47CFR §2.1091 S T L A B S Page 2 of 9 Report No.: STS2210066H01 Test Report Certification Applicant’s Name ................. : Music Tribe Commercial MY Sdn. Bhd. Address ................................. : 1-17-02, Suntech @ Penang Cybercity, LinTang Mayang Pasir 3, Bayan Baru, Pulau Pinang, Malaysia Manufacturer's Name .......... : Music Tribe Commercial MY Sdn. Bhd. Address ................................. : 1-17-02, Suntech @ Penang Cybercity, LinTang Mayang Pasir 3, Bayan Baru, Pulau Pinang, Malaysia Product Description Product Name ........................ : High-Performance UHF Wireless In-Ear Monitoring System Brand Name ......................... : Behringer Model Name .......................... : ... : UL 1000G2 Series Model .......................... : N/A Standards ............................. : FCC 47CFR §2.1091 447498 D04 Interim General RF Exposure Guidance v01 This report shall not be reproduced except in full, without the written approval of STS, this document only be altered or revised by STS, personal only, and shall be noted in the revision of the document. Date of Test ........................................... : Date of receipt of test item ..................... : 19 Oct. 2022 Date (s) of performance of tests ............. : 19 Oct. 2022 ~ 11 Nov. 2022 Date of Issue .......................................... : 11 Nov. 2022 Test Result.............................................. : Pass Testing Engineer : (Chris Chen) Technical Manager : (Sean she) Authorized Signatory : (Bovey Yang) Page 3 of 9 Report No.: STS2210066H01 TABLE OF CONTENTS 1. GENERAL INFORMATION 5 1.1 GENERAL DESCRIPTION OF THE EUT 5 1.2 TEST FACTORY 5 2. FCC 47CFR §2.1091 REQUIREMENT 6 2.1 TEST STANDARDS 6 2.2 LIMIT 6 2.3 TEST RESULT 9 Page 4 of 9 Report No.: STS2210066H01 Revision History Rev. Issue Date Report No. Effect Page Contents 00 11 Nov. 2022 STS2210066H01 ALL Initial Issue Page 5 of 9 Report No.: STS2210066H01 1. GENERAL INFORMATION 1.1 GENERAL DESCRIPTION OF THE EUT Product Name High-Performance UHF Wireless In-Ear Monitoring System Brand Name Behringer Model Name UL 1000G2 Series Model N/A Model Difference UL 1000G2-T（UHF Wireless Transmitter) UL 1000G2-R (UHF Wireless Belt-Pack Receiver) UL 1000G2 is a bundle of Transmitter and Receiver. UL 1000G2-R is receiver which will be sold separately, it's same receiver with the one in UL 1000G2. Product Description The EUT is High-Performance UHF Wireless In-Ear Monitoring System Operation Frequency: 584 - 608 MHz Modulation Type: FM Antenna gain: Omni Directional Antenna Designation: Transmitter: -0.25dBi Receiver: 0.5dBi Rating Transmitter: DC 12V, 500mA Receiver: DC 3V Adapter Input: 100~240V~50/60HZ 0.5A Output:12.0V, 0.6A, 7.2W Hardware Version Transmitter: V1.2 Receiver: V1 Software Version V1.1 1.2 TEST FACTORY SHENZHEN STS TEST SERVICES CO., LTD Add. : A 1/F, Building B, Zhuoke Science Park, No.190 Chongqing Road, HepingShequ, Fuyong Sub-District, Bao’an District, Shenzhen, Guang Dong, China FCC test Firm Registration Number: 625569 IC test Firm Registration Number: 12108A A2LA Certificate No.: 4338.01 Page 6 of 9 Report No.: STS2210066H01 2. FCC 47CFR §2.1091 REQUIREMENT 2.1 TEST STANDARDS Follow the maximum permissible exposure (MPE) limits specified in 447498 D04 Interim General Radio Frequency Exposure Guidelines v01. The gain of the antenna used in the product was extracted from the supplied antenna data sheet and the maximum total power input to the antenna was also measured. Calculate the distance from the product to the MPE limit by the formula. 2.2 LIMIT For single RF sources (i.e., any single fixed RF source, mobile device, or portable device, as defined in paragraph (b)(2) of this section): A single RF source is exempt if: (A) The available maximum time-averaged power is no more than 1 mW, regardless of separation distance. This exemption may not be used in conjunction with other exemption criteria other than those in paragraph (b)(3)(ii)(A) of Part 1.1307. Medical implant devices may only use this exemption and that in paragraph (b)(3)(ii)(A); (B) Or the available maximum time-averaged power or effective radiated power (ERP), whichever is greater, is less than or equal to the threshold Pth (mW) described in the following formula. This method shall only be used at separation distances (cm) from 0.5 centimeters to 40 centimeters and at frequencies from 0.3 GHz to 6 GHz (inclusive). Pth is given by: Page 7 of 9 Report No.: STS2210066H01 (C) Or using below table and the minimum separation distance (R in meters) from the body of a nearby person for the frequency (f in MHz) at which the source operates, the ERP (watts) is no more than the calculated value prescribed for that frequency. For the exemption in Table 1 to apply, R must be at least λ/2π, where λ is the free-space operating wavelength in meters. If the ERP of a single RF source is not easily obtained, then the available maximum time-averaged power may be used in lieu of ERP if the physical dimensions of the radiating structure(s) do not exceed the electrical length of λ/4 or if the antenna gain is less than that of a half-wave dipole (1.64 linear value). RF Source f…

Text truncated - open the document above for the full version.

Any reproduction of this document must be done in full. No single part of this document may be reproduced without permission from STS, All Test Data Presented in this report is only applicable to presented Test sample. Shenzhen STS Test Services Co., Ltd. A 1/F, Building B, Zhuoke Science Park, No.190 Chongqing Road, HepingShequ, Fuyong Sub-District, Bao’an District, Shenzhen, Guang Dong, China TEL: +86-755 3688 6288 FAX: +86-755 3688 6277 E-mail:[email protected] FCC TEST REPORT Report No: STS2210066W01 Issued for Music Tribe Commercial MY Sdn. Bhd. 1-17-02, Suntech @ Penang Cybercity, LinTang Mayang Pasir 3, Bayan Baru, Pulau Pinang, Malaysia Product Name: High-Performance UHF Wireless In-Ear Monitoring System Brand: Behringer Model Number: UL 1000G2 Series Model(s): N/A FCC ID: QWHUL1-T Test Standard: FCC Part 15.236 S T L A B S Page 2 of 34 Report No.: STS2210066W01 TEST RESULT CERTIFICATION Applicant’s Name ................. : Music Tribe Commercial MY Sdn. Bhd. Address .................................. : 1-17-02, Suntech @ Penang Cybercity, LinTang Mayang Pasir 3, Bayan Baru, Pulau Pinang, Malaysia Manufacturer's Name ........... : Music Tribe Commercial MY Sdn. Bhd. Address .................................. : 1-17-02, Suntech @ Penang Cybercity, LinTang Mayang Pasir 3, Bayan Baru, Pulau Pinang, Malaysia Product Description Product Name ........................ : High-Performance UHF Wireless In-Ear Monitoring System Brand ................................... : Behringer Model Number ....................... : UL 1000G2 Series Model(s) ...................... : N/A Test Standards ..................... : FCC Part 15.236 Test Procedure ....................... : ANSI C63.10-2013 This device described above has been tested by STS, the test results show that the equipment under test (EUT) is in compliance with the FCC requirements. And it is applicable only to the tested sample identified in the report. This report shall not be reproduced except in full, without the written approval of STS, this document only be altered or revised by STS, personal only, and shall be noted in the revision of the document. Date of Test .............................................. : Date of receipt of test item ....................... : 19 Oct. 2022 Date of performance of tests .................... : 19 Oct. 2022 ~ 11 Nov. 2022 Date of Issue ............................................ : 11 Nov. 2022 Test Result ................................................ : Pass Testing Engineer : (Chris Chen) Technical Manager : (Sean she) Authorized Signatory : (Bovey Yang) Page 3 of 34 Report No.: STS2210066W01 Table of Contents Page 1. SUMMARY OF TEST RESULTS 5 1.1 TEST FACTORY 6 1.2 MEASUREMENT UNCERTAINTY 6 2. GENERAL INFORMATION 7 2.1 GENERAL DESCRIPTION OF THE EUT 7 2.2 DESCRIPTION OF THE TEST MODES 9 2.3 BLOCK DIAGRAM SHOWING THE CONFIGURATION OF SYSTEM TESTED 9 2.4 DESCRIPTION OF NECESSARY ACCESSORIES AND SUPPORT UNITS 10 2.5 TEST EQUIPMENT 11 3. PART 15.236 REQUIREMENTS 12 3.1 RADIATED SPURIOUS EMISSION 12 3.2 EMISSION MASK 12 3.3 FREQUENCY STABILITY VS. TEMPERATURE & VOLTAGE 24 3.4 OCCUPIED BANDWIDTH 28 3.5 RADIATED POWER 31 PHOTOS OF TEST SETUP 34 Page 4 of 34 Report No.: STS2210066W01 Revision History Rev. Issue Date Report NO. Effect Page Contents 00 11 Nov. 2022 STS2210066W01 ALL Initial Issue Page 5 of 34 Report No.: STS2210066W01 1. SUMMARY OF TEST RESULTS Test procedures according to the technical standards: The EUT has been tested according to FCC CFR 47: Part 15.236: Operation of wireless microphones in the bands 54-72 MHz, 76-88 MHz, 174-216 MHz, 470-608 MHz and 614-698 MHz. Emission Standard Item Limit Result FCC 15.236(g) Radiated Spurious Emission Refer to 300 422-1 V1.4.2 (8.4) PASS FCC 15.236(d)(1) EIRP ≤50 mW PASS FCC 15.215 Occupied Bandwidth -- PASS FCC 15.236(f)(3) Frequency tolerance ±0.005% PASS FCC 15.236(g) Necessary Bandwidth (Mask) Refer to 300 422-1 V1.4.2 (8.3) PASS NOTE: (1) “N/A” denotes test is not applicable in this Test Report. Page 6 of 34 Report No.: STS2210066W01 1.1 TEST FACTORY SHENZHEN STS TEST SERVICES CO., LTD Add. : A 1/F, Building B, Zhuoke Science Park, No.190 Chongqing Road, HepingShequ, Fuyong Sub-District, Bao’an District, Shenzhen, Guang Dong, China FCC test Firm Registration Number: 625569 IC test Firm Registration Number: 12108A A2LA Certificate No.: 4338.01 1.2 MEASUREMENT UNCERTAINTY The reported uncertainty of measurement y ± U, where expended uncertainty U is based on a standard uncertainty multiplied by a coverage factor of k=2, providing a level of confidence of approximately 95 %. No. Item Uncertainty 1 RF output power, conducted ±0.68dB 2 Unwanted Emissions, conducted ±2.988dB 3 All emissions, radiated 9K-30MHz ±2.84dB 4 All emissions, radiated 30M-1GHz ±4.39dB 5 All emissions, radiated 1G-6GHz ±5.10dB 6 All emissions, radiated>6G ±5.48dB 7 Conducted Emission (9KHz-150KHz) ±2.79dB 8 Conducted Emission (150KHz-30MHz) ±2.80dB Page 7 of 34 Report No.: STS2210066W01 2. GENERAL INFORMATION 2.1 GENERAL DESCRIPTION OF THE EUT Product Name: High-Performance UHF Wireless In-Ear Monitoring System Brand Name: Behringer Model Name: UL 1000G2 Series Model : N/A Model Difference description: UL 1000G2-T（UHF Wireless Transmitter) UL 1000G2-R (UHF Wireless Belt-Pack Receiver) UL 1000G2 is a bundle of Transmitter and Receiver. UL 1000G2-R is receiver which will be sold separately, it's same receiver with the one in UL 1000G2. Emission Bandwidth: 42.968KHz Rating: Transmitter: DC 12V, 500mA Receiver: DC 3V Adapter: Input: 100~240V~50/60HZ 0.5A Output:12.0V, 0.6A, 7.2W Operation Frequency Range 584 - 608 MHz Antenna Type Omni Directional Antenna Gain Transmitter: -0.25dBi Receiver: 0.5dBi Maximum Transmitter Power: 0.03656W(1.563dBm) Modulation mode / type: FM Frequency Tolerance: 0.0002% Temperature Range: -20°C-50°C Test frequency list: Please refer to the Note 4. Software version number: V1.1 Hardware version number: Transmitter: V1.2 Receiver: V1 Connecting I/O Port(…

Text truncated - open the document above for the full version.

Unit11， 12/F, BLK B Veristrong ind. Ctr, 34-36 Au Pui Wan Street, Fo Tan Shatin, N.T. HK Tel: 852 2345 0215 Fax: 852 27978191 Email: [email protected] No.:AN04201 CUSTOMER’S NAME : CUSTOMER’S MODEL NO . : CUSTOMER’S PART NO. : PRODUCT NAME : OUR MODEL NO. : NO. 1 2 3 4 Please fax back this brefile page with authorized signature and company chop as customer’s approval on samples,Thanks! Specification of Product 3 G-RA0B13200418-JM028 Product Drawing Capability Test Report Company Chop 1 Pages 1 Bondale Electronics Ltd. 1 Rubber Antenna This Specification is Composed of Under Listed (Samples be attached) Website: www.bondale.com COVER OF SPECIFICATION Certificate Of Conformance ROHS 7 Items Customer Sign Customer Unit11， 12/F, BLK B Veristrong ind. Ctr, 34-36 Au Pui Wan Street, Fo Tan Shatin, N.T. HK Tel: 852 2345 0215 Fax: 852 27978191 Email: [email protected] TO: DATE: File NO.: AN04201 Customer Part No. : Bondale Part No. : Description : Rubber Antenna We, Bondale Electronics ltd. assured that the above mentioned item G-RA0B13200418-JM028 is fully comply with the EU directive 2011/65/EU, (EU)2015/863 and packaging directive 94/62/EC and that its content of hazardous substances is below the values as listed: ROHS critical values: *Cadmium(Cd)under 100 ppm Generallyunder 1,000 ppm Products that contain Copper alloy components under 40,000 ppm Product that contain Steel alloy components under 3,500 ppm Product that contain aluminum alloy components under 4,000 ppm *Mercury (Hg)under 1,000 ppm *Hexavalent Chormium (Cr6+)under 1,000 ppm *PBBsunder 1,000 ppm *PBDEsunder 1,000 ppm *DEHPunder 1,000 ppm *BBPunder 1,000 ppm *DBPunder 1,000 ppm *DIBPunder 1,000 ppm Packaging directive 94/62/EC critical values: *Packaging (Pb + Cd +Hg +Cr6+ ) under 100 ppm Expemted below: If the above mentioned item is reprocessed by customer, we wouldn’t promise and assure the content of hazardous substances of the product item. On behalf of Bondale Electronics Ltd. ROHS green chop and GPMS spokesman sign Yours sincerely, Bondale Electronics Ltd. CERTIFICATE OF CONFORMANCE ROHS Be Exempted*Lead (Pb) 2021-05-28 Website: www.bondale.com ---GREEN PRODUCT MANAGEMENT SYSTEM (GPMS)--- G-RA0B13200418-JM028 PROJECTION BNC-P CONNECTOR 5 9 5 Notes: 1.The color of the rubber hosing is black 2.Connector: BNC-P, black chrome plated on the surface 3.Operating frequency:595±15 Mhz 4.On the surface of antenna connector is pasted a sticker which is black background with 595MHz white font VER. Lu Dong Linear dimension Undeclared dimension deviation No tolerance indicated This position for a sticker,White words printed on the sticker Customer : Specication No.: AN04201 Model No.: G-RA0B13200418-JM028 1, Application The antenna specified in this specification is applicable for the radio-communication 2, Dimensions As per Drawing No. G-RA0B13200418-JM028 attached. 3, Materials As specified in drawing No. G-RA0B13200418-JM028 4, Electrical Characteristics i) Resonate Frequency : 595±15MHz. ii) Impedance : 50 ohm Nominal iii) Radiation Pattern : Omni Directional iv) Polarization : Vertical v) Standing Wave Ratio (S.W.R) : 2.0 or less at Resonate point vi) Insulation resistance : 500 M ohm at DC 500V 5, Mechanical characteristics: The strength of fixing between sleeve and stud shall withstand the following stresses Vertical Direction: 2.0 kg Rotating Direction: 2.0 kgf.cm 6, Others: Any modification of this specification has to be agreed by us RUBBER ANTENNA SPECIFICATION Prepared By:Checked By:Approval: Specification NO.:AN04201 Model NO.: G-RA0B13200418-JM028 Capability Test Report

Page 1 of 1 FCC ID: QWHUL1-T Setup photo Model Number: UL 1000G2
