ULTRALINK ULM100USB High-Performance 2.4 GHz Digital Wireless Microphone with USB Receiver ULM100USB Hook-Up XENYX QX2442USB B115MP3 Laptop ULM100USB Controls ULM100USB Controls 1. POWER /STATUS LED 2.  VOLUME Button (Mute/volume down) 3.  VOLUME Button (Power on/volume up) 4. USB connector 5. Wireless Link Status LED ULM100USB Getting Started 1. Press the  button to power on the ULM100M wireless microphone. 2. Connect the ULM100R wireless receiver to the wireless only USB connector on the wireless enabled device or to a USB port on a computer. The ULM100M will sync to the receiver automatically. 3. Use the  and  buttons on the ULM100M wireless mic to adjust the volume. 4. Press and hold the  button to mute the volume of the ULM100M. 5. Press the  button to un-mute the volume of the ULM100M. 6. Disconnect the ULM100R wireless receiver. The ULM100M wireless microphone will power off when no wireless signal is detected for more than 1 minute. Specification RF output +17 dBm (50 mW) Working range 120 m Maximum (Line of Sight) Dynamic range > 67 dB Frequency response 20 Hz – 14.7 kHz (Wireless Link) (+0 / -0.3 dB) THD+N (%) (Wireless Link) > 65 dB (0.03%) Sampling rate 31.25 kHz Audio coding Pulse-coded modulation (PCM) RF channel 2.4 GHz ISM Band (2417 - 2471 MHz), 19 Channels Latency 9 ms Power supply current 160 mA @ +2.7 VDC, (Microphone) 140 mA @ +3.0 VDC Power supply current 100 mA @ +5 VDC (USB receiver) Dimensions (W x D x H) 1.8 x 1.8 x 9.6" 45 x 45 x 245 mm Weight 0.4 lbs / 0.2 kg (1) (2)(3) (5)(4) Model: ULM100R Type of product: Wireless Microphone Model: ULM100M FEDERAL COMMUNICATIONS COMMISSION COMPLIANCE INFORMATION Responsible Party Name: MUSIC Group Services US Inc. Address: 18912 North Creek Parkway, Suite 200 Bothell, WA 98011, USA Phone/Fax No.: Phone: +1 425 672 0816 Fax: +1 425 673 7647 ULTRALINK ULM100USB complies with the FCC rules as mentioned in the following paragraph: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: t
Reorient or relocate the receiving antenna t
Increase the separation between the equipment and receiver t
Connect the equipment into an outlet on a circuit different from that to which the receiver is connected t
Consult the dealer or an experienced radio/TV technician for help This device complies with Part 15 of the FCC rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Important information: Changes or modifications to the equipment not expressly approved by MUSIC Group can void the user’s authority to use the equipment. Operation in the 2.4 GHz ISM (Industrial, Scientific, Medical) frequency band may be subject to interference from other transmitting equipment operating in this band. In the event of such interference, please verify and reassign the transmitting channels of any potentially interfering transmitting equipment. ULTRALINK ULM100USB LEGAL DISCLAIMER TECHNICAL SPECIFICATIONS AND APPEARANCES ARE SUBJECT TO CHANGE WITHOUT NOTICE AND ACCURACY IS NOT GUARANTEED. BEHRINGER, KLARK TEKNIK, MIDAS, BUGERA, AND TURBOSOUND ARE PART OF THE MUSIC GROUP (MUSIC-GROUP.COM). ALL TRADEMARKS ARE THE PROPERTY OF THEIR RESPECTIVE OWNERS. MUSIC GROUP ACCEPTS NO LIABILITY FOR ANY LOSS WHICH MAY BE SUFFERED BY ANY PERSON WHO RELIES EITHER WHOLLY OR IN PART UPON ANY DESCRIPTION, PHOTOGRAPH OR STATEMENT CONTAINED HEREIN. COLORS AND SPECIFICATIONS MAY VARY FROM ACTUAL PRODUCT. MUSIC GROUP PRODUCTS ARE SOLD THROUGH AUTHORIZED FULLFILLERS AND RESELLERS ONLY. FULLFILLERS AND RESELLERS ARE NOT AGENTS OF MUSIC GROUP AND HAVE ABSOLUTELY NO AUTHORITY TO BIND MUSIC GROUP BY ANY EXPRESS OR IMPLIED UNDERTAKING OR REPRESENTATION. THIS MANUAL IS COPYRIGHTED. NO PART OF THIS MANUAL MAY BE REPRODUCED OR TRANSMITTED IN ANY FORM OR BY ANY MEANS, ELECTRONIC OR MECHANICAL, INCLUDING PHOTOCOPYING AND RECORDING OF ANY KIND, FOR ANY PURPOSE, WITHOUT THE EXPRESS WRITTEN PERMISSION OF MUSIC GROUP IP LTD. ALL RIGHTS RESERVED. © 2013 MUSIC Group IP Ltd. Trident Chambers, Wickhams Cay, P.O. Box 146, Road Town, Tortola, British Virgin Islands LIMITED WARRANTY For the applicable warranty terms and conditions and additional information regarding MUSIC Group’s Limited Warranty, please see complete details online at www.music-group.com/warranty. For USB Receiver: This equipment meets the government's requirements for exposure to radio waves. . For body worn operation, this equipment has been tested and meets the FCC RF exposure guidelines. The highest SAR value for this USB Receiver as reported to the FCC when tested for use at the Body-worn is 0.071 W/kg. This equipment complies with the European Council Recommendation of 12 July 1999 on the Limitation of Exposure of the General Public to Electromagnetic Fields [1999/519/EC]. For Microphone: This equipment should be installed and operated with a minimum distance of 15mm between the radiator and your head.

Neutron Engineering Inc. Project No.: 1209C094 Page 2 of 11

Neutron Engineering Inc. Project No.: 1209C094 Page 3 of 11 Neutron Engineering Inc. Project No.: 1209C094 Page 4 of 11 Neutron Engineering Inc. Project No.: 1209C094 Page 5 of 11 Neutron Engineering Inc. Project No.: 1209C094 Page 6 of 11 Neutron Engineering Inc. Project No.: 1209C094 Page 7 of 11 Neutron Engineering Inc. Project No.: 1209C094 Page 8 of 11 Neutron Engineering Inc. Project No.: 1209C094 Page 9 of 11 Neutron Engineering Inc. Project No.: 1209C094 Page 10 of 11 Neutron Engineering Inc. Project No.: 1209C094 Page 11 of 11

Neutron Engineering Inc. FCC RF EXPOSURE REPORT FCC ID: QWHULM100M Project No. : 1209C094 Equipment : Wireless Microphone Model : ULM100M Applicant : MUSIC Group Macao Commercial Offshore Limited Address : Rua De Pequim, No 202-A Macau Finance Centre 9/J, Macau According: : FCC Guidelines for Human Exposure IEEE C95.1 Neutron Engineering Inc. No.3, Jinshagang 1st Road, ShiXia, Dalang Town, Dong Guan, China. TEL : (0769) 8318-3000 FAX : (0769) 8319-6000 Neutron Engineering Inc. GENERAL CONCULUSION: Table for Filed Antenna: Ant. Brand Model Name Antenna Type Connector Gain (dBi) 1 N/A N/A Printed N/A -2.01 Maximum measured transmitter power: Average Output Power (dBm) Out Power (mW) Limit (mW) 13.82 24.10 29 According to FCC KDB447498, Appendix A, SAR Test Exclusion Thresholds for 100 MHz – 6 GHz and ≤ 50 mm The transmitter Average power is 24.10mW, less than 29mW at 15mm distance. Conclusion: No SAR evaluation required since transmitter power is below FCC threshold

Neutron Engineering Inc. Report No.: NEI-FCCP-1-1209C094 Page 1 of 61 FCC Radio Test Report FCC ID: QWHULM100M This report concerns (check one) : Original Grant Class II Change Issued Date : Nov. 16, 2012 Project No. : 1209C094 Equipment : Wireless Microphone Model Name : ULM100M Applicant : MUSIC Group Macao Commercial Offshore Limited Address : Rua De Pequim, No 202-A Macau Finance Centre 9/J, Macau Tested by: Neutron Engineering Inc. EMC Laboratory Date of Receipt: Sep. 17, 2012 Date of Test: Sep. 17, 2012 ~ Nov. 15, 2012 Testing Engineer : (David Mao) Technical Manager : (Leo Hung) Authorized Signatory : (Steven Lu) Neutron Engineering Inc. No.3,Jinshagang 1st Road, ShiXia, Dalang Town, Dong Guan, China. TEL : (0769) 8318-3000 FAX : (0769) 8319-6000 Neutron Engineering Inc. Report No.: NEI-FCCP-1-1209C094 Page 2 of 61 Declaration Neutron represents to the client that testing is done in accordance with standard procedures as applicable and that test instruments used has been calibrated with the standards traceable to National Measurement Laboratory (NML) of CHINA, or National Institute of Standards and Technology (NIST) of U.S.A. Neutron's reports apply only to the specific samples tested under conditions. It is manufacture’s responsibility to ensure that additional production units of this model are manufactured with the identical electrical and mechanical components. Neutronshall have no liability for any declarations, inferences o r generalizations drawn by the client or others from Neutron issued reports. Neutron’s reports must not be used by the client to claim product endorsement by the authorities or any agency of the Government. This report is the confidential property of the client. As a mutual protection to the clients, the public and Neutron-self, extracts from the test report shall not be reproduced except in full with Neutron’s authorized written approval. Neutron’s laboratory quality assurance procedures are in compliance with the ISO Guide 17025 requirements, and accredited by the conformity assessment authorities listed in this test report. Limitation For the use of the authority's logo is limited unless the Test Standard(s)/Scope(s)/Item(s) mentioned in this test report is (are) included in the conformity assessment authorities acceptance respective. Neutron Engineering Inc. Report No.: NEI-FCCP-1-1209C094 Page 3 of 61 Table of Contents Page 1 . CERTIFICATION 6 2 . SUMMARY OF TEST RESULTS 7 2.1 TEST FACILITY 8 2.2 MEASUREMENT UNCERTAINTY 8 3 . GENERAL INFORMATION 9 3.1 GENERAL DESCRIPTION OF EUT 9 3.2 DESCRIPTION OF TEST MODES 11 3.3 TABLE OF PARAMETERS OF TEXT SOFTWARE SETTING 11 3.4 BLOCK DIGRAM SHOWING THE CONFIGURATION OF SYSTEM TESTED 12 3.5 DESCRIPTION OF SUPPORT UNITS 13 4 . EMC EMISSION TEST 14 4.1 CONDUCTED EMISSION MEASUREMENT 14 4.1.1 POWER LINE CONDUCTED EMISSION LIMITS 14 4.1.2 MEASUREMENT INSTRUMENTS LIST AND SETTING 14 4.1.3 TEST PROCEDURE 15 4.1.4 DEVIATION FROM TEST STANDARD 15 4.1.5 TEST SETUP 15 4.1.6 EUT OPERATING CONDITIONS 15 4.1.7 TEST RESULTS 16 4.2 RADIATED EMISSION MEASUREMENT 17 4.2.1 RADIATED EMISSION LIMITS 17 4.2.2 MEASUREMENT INSTRUMENTS LIST ANS SETTING 18 4.2.3 TEST PROCEDURE 20 4.2.4 DEVIATION FROM TEST STANDARD 20 4.2.5 TEST SETUP 21 4.2.6 EUT OPERATING CONDITIONS 22 4.2.7 TEST RESULTS (BELOW 30MHZ) 23 4.2.8 TEST RESULTS (BETWEEN30 – 1000 MHZ) 24 4.2.9 TEST RESULTS (ABOVE 1000 MHZ) 27 5 . NUMBER OF HOPPING CHANNEL 39 5.1 APPLIED PROCEDURES / LIMIT 39 5.1.1 MEASUREMENT INSTRUMENTS LIST AND SETTING 39 5.1.2 TEST PROCEDURE 39 5.1.3 DEVIATION FROM STANDARD 39 5.1.4 TEST SETUP 39 5.1.5 EUT OPERATION CONDITIONS 39 5.1.6 TEST RESULTS 40 Neutron Engineering Inc. Report No.: NEI-FCCP-1-1209C094 Page 4 of 61 Table of Contents Page 6 . AVERAGE TIME OF OCCUPANCY 41 6.1 APPLIED PROCEDURES / LIMIT 41 6.1.1 MEASUREMENT INSTRUMENTS LIST 41 6.1.2 TEST PROCEDURE 41 6.1.3. TEST SETUP LAYOUT 41 6.1.4. TEST DEVIATION 41 6.1.5. EUT OPERATION DURING TEST 41 6.1.6. TEST RESULTS 42 7 . HOPPING CHANNEL SEPARATION MEASUREMENT 44 7.1 APPLIED PROCEDURES / LIMIT 44 7.1.1 MEASUREMENT INSTRUMENTS LIST AND SETTING 44 7.1.2 TEST PROCEDURE 44 7.1.3 DEVIATION FROM STANDARD 44 7.1.4 TEST SETUP 44 7.1.5 EUT OPERATION CONDITIONS 44 7.1.6 TEST RESULTS 45 8 . BANDWIDTH TEST 47 8.1 APPLIED PROCEDURES / LIMIT 47 8.1.1 MEASUREMENT INSTRUMENTS LIST AND SETTING 47 8.1.2 TEST PROCEDURE 47 8.1.3 DEVIATION FROM STANDARD 47 8.1.4 TEST SETUP 47 8.1.5 EUT OPERATION CONDITIONS 47 8.1.6 TEST RESULTS 48 9 . PEAK OUTPUT POWER TEST 50 9.1 APPLIED PROCEDURES / LIMIT 50 9.1.1 MEASUREMENT INSTRUMENTS LIST AND SETTING 50 9.1.2 TEST PROCEDURE 50 9.1.3 DEVIATION FROM STANDARD 50 9.1.4 TEST SETUP 50 9.1.5 EUT OPERATION CONDITIONS 50 9.1.6 TEST RESULTS 51 10 . ANTENNA CONDUCTED SPURIOUS EMISSION 52 10.1 APPLIED PROCEDURES / LIMIT 52 10.1.1 MEASUREMENT INSTRUMENTS LIST AND SETTING 52 10.1.2 TEST PROCEDURE 52 10.1.3 DEVIATION FROM STANDARD 52 10.1.4 TEST SETUP 52 10.1.5 EUT OPERATION CONDITIONS 52 10.1.6 TEST RESULTS 53 Neutron Engineering Inc. Report No.: NEI-FCCP-1-1209C094 Page 5 of 61 Table of Contents Page 11. EUT TEST PHOTOS 59 Neutron Engineering Inc. Report No.: NEI-FCCP-1-1209C094 Page 6 of 61 1. CERTIFICATION Equipment : Wireless Microphone Brand Name : Model Name : ULM100M Applicant : MUSIC Group Macao Commercial Offshore Limited Date of Test : Sep. 17, 2012 ~ Nov. 15, 2012 Test Item : ENGINEERING SAMPLE Standards : FCC Part15, Subpart C(15.247) / ANSI C63.4 : 2009 FCC Public Notice DA 00-705, March 30, 2000. The above equipment has been tested and found compliance with the requirement of the relative standards by Neutron Engineering Inc. EMC Laboratory. The test data, data evaluation, and equipment configuration contained in our test report (Ref No. NEI-FCCP-1-1209C094) were obtained utilizing the test procedures, test instruments, test sites that has been accredited by the Authority of NVLAP and TAF according to the ISO-17025 quality assessment standard and technical standard(s). Neutro…
