QWHXTM1-35UHF Wireless System with Handheld Microphone

Quick Start Guide XTM1-35 VOCAL SET UHF Wireless System with Handheld Microphone and Single-Channel Receiver V 1.0 2XTM1-35 VOCAL SET Terminals marked with this symbol carry electrical current of suffi cient magnitude to constitute risk of electric shock. Use only high-quality professional speaker cables with ¼" TS or twist-locking plugs pre-installed. All other installation or modifi cation should be performed only by qualifi ed personnel. This symbol, wherever it appears, alerts you to the presence of uninsulated dangerous voltage inside the enclosure - voltage that may be suffi cient to constitute a risk of shock. This symbol, wherever it appears, alerts you to important operating and maintenance instructions in the accompanying literature. Please read the manual. Caution To reduce the risk of electric shock, do not remove the top cover (or the rear section). No user serviceable parts inside. Refer servicing to qualifi ed personnel. Caution To reduce the risk of fi re or electric shock, do not expose this appliance to rain and moisture. The apparatus shall not be exposed to dripping or splashing liquids and no objects fi lled with liquids, such as vases, shall be placed on the apparatus. Caution These service instructions are for use by qualifi ed service personnel only. To reduce the risk of electric shock do not perform any servicing other than that contained in the operation instructions. Repairs have to be performed by qualifi ed service personnel. 1. Read these instructions. 2. Keep these instructions. 3. Heed all warnings. 4. Follow all instructions. 5. Do not use this apparatus near water. 6. Clean only with dry cloth. 7. Do not block any ventilation openings. Install in accordance with the manufacturer’s instructions. 8. Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus (including amplifi ers) that produce heat. 9. Do not defeat the safety purpose of the polarized or grounding-type plug. A polarized plug has two blades with one wider than the other. A grounding-type plug has two blades and a third grounding prong. The wide blade or the third prong are provided for your safety. If the provided plug does not fi t into your outlet, consult an electrician for replacement of the obsolete outlet. 10. Protect the power cord from being walked on or pinched particularly at plugs, convenience receptacles, and the point where they exit from the apparatus. 11. Use only attachments/accessories specifi ed by the manufacturer. 12. Use only with the cart, stand, tripod, bracket, or table specifi ed by the manufacturer, or sold with the apparatus. When a cart is used, use caution when moving the cart/apparatus combination to avoid injury from tip-over. 13. Unplug this apparatus during lightning storms or when unused for long periods of time. 14. Refer all servicing to qualifi ed service personnel. Servicing is required when the apparatus has been damaged in any way, such as power supply cord or plug is damaged, liquid has been spilled or objects have fallen into the apparatus, the apparatus has been exposed to rain or moisture, does not operate normally, or has been dropped. 15. The apparatus shall be connected to a MAINS socket outlet with a protective earthing connection. 16. Where the MAINS plug or an appliance coupler is used as the disconnect device, the disconnect device shall remain readily operable. 17. Correct disposal of this product: This symbol indicates that this product must not be disposed of with household waste, according to the WEEE Directive (2012/19/EU) and your national law. This product should be taken to a collection center licensed for the recycling of waste electrical and electronic equipment (EEE). The mishandling of this type of waste could have a possible negative impact on the environment and human health due to potentially hazardous substances that are generally associated with EEE. At the same time, your cooperation in the correct disposal of this product will contribute to the effi cient use of natural resources. For more information about where you can take your waste equipment for recycling, please contact your local city offi ce, or your household waste collection service. 18. Do not install in a confi ned space, such as a book case or similar unit. 19. Do not place naked fl ame sources, such as lighted candles, on the apparatus. 20. Please keep the environmental aspects of battery disposal in mind. Batteries must be disposed-of at a battery collection point. 21. This apparatus may be used in tropical and moderate climates up to 40°C. 22. WARNING • • As with all small batteries, the batteries used with this product should be kept away from small children who still put things in their mouths. If they are swallowed, promptly call your local poison control center. • • Always purchase the correct size and grade of battery most suitable for intended use. • • Replace all batteries of a set at the same time. • • Clean the battery contacts, and also those of the device prior to battery installation. • • Ensure the batteries are installed correctly with the regard to polarity (+ and -). • • Always remove battery if consumed or if product is to be left unused for a long time. • • Replacement of a battery with an incorrect type can defeat a safeguard. Replace only with the same or equivalent type. • • Risk of fi re or explosion if the battery is replaced by an incorrect type. • • Batteries (battery pack or batteries installed) shall not be exposed to excessive heat such as sunshine, fi re or the like. • • Disposal of a battery into fi re or a hot oven, or mechanically crushing or cutting of a battery can result in an explosion. • • Leaving a battery in an extremely high temperature surrounding environment can result in an explosion or the leakage of fl ammable liquid or gas. • • A battery subjected to extremely low air pressure may result in an explosion or the leakage of fl ammable liquid or gas. • • Attention should be …

Text truncated - open the document above for the full version.

Quick Start Guide XTM1-35 DUAL VOCAL SET UHF Wireless System with 2 Handheld Microphones and Dual-Channel Receiver V 1.0 2XTM1-35 DUAL VOCAL SET Terminals marked with this symbol carry electrical current of suffi cient magnitude to constitute risk of electric shock. Use only high-quality professional speaker cables with ¼" TS or twist-locking plugs pre-installed. All other installation or modifi cation should be performed only by qualifi ed personnel. This symbol, wherever it appears, alerts you to the presence of uninsulated dangerous voltage inside the enclosure - voltage that may be suffi cient to constitute a risk of shock. This symbol, wherever it appears, alerts you to important operating and maintenance instructions in the accompanying literature. Please read the manual. Caution To reduce the risk of electric shock, do not remove the top cover (or the rear section). No user serviceable parts inside. Refer servicing to qualifi ed personnel. Caution To reduce the risk of fi re or electric shock, do not expose this appliance to rain and moisture. The apparatus shall not be exposed to dripping or splashing liquids and no objects fi lled with liquids, such as vases, shall be placed on the apparatus. Caution These service instructions are for use by qualifi ed service personnel only. To reduce the risk of electric shock do not perform any servicing other than that contained in the operation instructions. Repairs have to be performed by qualifi ed service personnel. 1. Read these instructions. 2. Keep these instructions. 3. Heed all warnings. 4. Follow all instructions. 5. Do not use this apparatus near water. 6. Clean only with dry cloth. 7. Do not block any ventilation openings. Install in accordance with the manufacturer’s instructions. 8. Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus (including amplifi ers) that produce heat. 9. Do not defeat the safety purpose of the polarized or grounding-type plug. A polarized plug has two blades with one wider than the other. A grounding-type plug has two blades and a third grounding prong. The wide blade or the third prong are provided for your safety. If the provided plug does not fi t into your outlet, consult an electrician for replacement of the obsolete outlet. 10. Protect the power cord from being walked on or pinched particularly at plugs, convenience receptacles, and the point where they exit from the apparatus. 11. Use only attachments/accessories specifi ed by the manufacturer. 12. Use only with the cart, stand, tripod, bracket, or table specifi ed by the manufacturer, or sold with the apparatus. When a cart is used, use caution when moving the cart/apparatus combination to avoid injury from tip-over. 13. Unplug this apparatus during lightning storms or when unused for long periods of time. 14. Refer all servicing to qualifi ed service personnel. Servicing is required when the apparatus has been damaged in any way, such as power supply cord or plug is damaged, liquid has been spilled or objects have fallen into the apparatus, the apparatus has been exposed to rain or moisture, does not operate normally, or has been dropped. 15. The apparatus shall be connected to a MAINS socket outlet with a protective earthing connection. 16. Where the MAINS plug or an appliance coupler is used as the disconnect device, the disconnect device shall remain readily operable. 17. Correct disposal of this product: This symbol indicates that this product must not be disposed of with household waste, according to the WEEE Directive (2012/19/EU) and your national law. This product should be taken to a collection center licensed for the recycling of waste electrical and electronic equipment (EEE). The mishandling of this type of waste could have a possible negative impact on the environment and human health due to potentially hazardous substances that are generally associated with EEE. At the same time, your cooperation in the correct disposal of this product will contribute to the effi cient use of natural resources. For more information about where you can take your waste equipment for recycling, please contact your local city offi ce, or your household waste collection service. 18. Do not install in a confi ned space, such as a book case or similar unit. 19. Do not place naked fl ame sources, such as lighted candles, on the apparatus. 20. Please keep the environmental aspects of battery disposal in mind. Batteries must be disposed-of at a battery collection point. 21. This apparatus may be used in tropical and moderate climates up to 40°C. 22. WARNING • • As with all small batteries, the batteries used with this product should be kept away from small children who still put things in their mouths. If they are swallowed, promptly call your local poison control center. • • Always purchase the correct size and grade of battery most suitable for intended use. • • Replace all batteries of a set at the same time. • • Clean the battery contacts, and also those of the device prior to battery installation. • • Ensure the batteries are installed correctly with the regard to polarity (+ and -). • • Always remove battery if consumed or if product is to be left unused for a long time. • • Replacement of a battery with an incorrect type can defeat a safeguard. Replace only with the same or equivalent type. • • Risk of fi re or explosion if the battery is replaced by an incorrect type. • • Batteries (battery pack or batteries installed) shall not be exposed to excessive heat such as sunshine, fi re or the like. • • Disposal of a battery into fi re or a hot oven, or mechanically crushing or cutting of a battery can result in an explosion. • • Leaving a battery in an extremely high temperature surrounding environment can result in an explosion or the leakage of fl ammable liquid or gas. • • A battery subjected to extremely low air pressure may result in an explosion or the leakage of fl ammable liquid or gas. • • Attention…

Text truncated - open the document above for the full version.

Rev 1/26/2023 Music Tribe Commercial MY Sdn. Bhd. Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 USA Date: 08-21-2023 Ref: Attestation Statements Part 2.911(d)(7) Filing Grantee Code: QWH Applicant FRN: 0022048235 Music Tribe Commercial MY Sdn. Bhd. ;͞the applicant͟Ϳ certifies that͕ as of the date of the filing of the application, Music Tribe Commercial NV Inc. is our designated U.S. agent for service of process for the above referenced FCC ID. Music Tribe Commercial MY Sdn. Bhd. accepts to maintain an agent for no less than one year after the grantee has terminated all marketing and importation or the conclusion of any Commission-related proceeding involving the equipment. Music Tribe Commercial NV Inc. accepts, as of the date of the filing of the application, the obligation of the designated U.S. agent for service of process for the above referenced Grantee Code. Designated U.S. Agent Information: Name: Music Tribe Commercial NV Inc. U.S. Agent FRN: 0033426594 Address: 122 E. 42nd St.1, 8th Floor, New York, USA Contact Person: Chase McKnight Tel.: 702-389-6913 Email: [email protected] Sincerely, Music Tribe Commercial MY Sdn. Bhd. Music Tribe Commercial NV Inc. Kane Xin Chase McKnight [Insert Applicant signature] [U.S. Agent signature]

Rev 1/26/2023 Music Tribe Commercial MY Sdn. Bhd. Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 USA Date: 08-21-2023 Ref: Attestation Statements Part 2.911(d)(5)(i) Filing FCC ID: QWHXTM1-35 Music Tribe Commercial MY Sdn. Bhd. (“the applicant”) certifies that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. Sincerely, Kane Xin Rev 1/26/2023 Music Tribe Commercial MY Sdn. Bhd. Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 USA Date: 08-21-2023 Ref: Attestation Statements Part 2.911(d)(5)(ii) Filing FCC ID: QWHXTM1-35 Music Tribe Commercial MY Sdn. Bhd. (“the applicant”) certifies that, as of the date of the filing of the application, the applicant is not identified on the Covered List (as a specifically named entity or any of its subsidiaries or affiliates) as an entity producing “covered” equipment. Sincerely, Kane Xin

Music Tribe Commercial MY Sdn. Bhd. Declaration of Authorization We Name: Music Tribe Commercial MY Sdn. Bhd. Address: 1-17-02, Suntech @ Penang Cybercity, LinTang Mayang Pasir 3, City: Bayan Baru, Pulau Pinang Country: Malaysia Declare that: Name Representative of agent: Ms. Rose Liu Agent Company name: BTL Inc. Address: No.3 Jinshagang 1 st Road, Shixia, Dalang Town City: Dong Guan Country: China is authorized to apply for Certification and signing related documents of the following product(s), including 731 form(s): Product description: UHF Wireless System with Handheld Microphone Type designation: XTM1-35 DUAL VOCAL SET, XTM1-35 VOCAL SET Trademark: Behringer FCC ID: QWHXTM1-35 on our behalf. Date: 2023-08-21 City: Bayan Baru, Pulau Pinang Name: Kane Xin Function: Innovation Compliance Leader Signature: -----------------------------------------

Rev 11/20/07 Music Tribe Commercial MY Sdn. Bhd. Federal Communications Commission Authorization and Evaluation Division Confidentiality Request regarding application for certification of FCC ID: (QWHXTM1-35). Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, we hereby request confidential treatment of information accompanying this application as outlined below: Exhibit Type File Name Schematics, Block Diagram, Operational Description, 4. Schematics 5. Block Diagram 6. Operational Description The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Section 0.457 of the Rules, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. It is our understanding that all measurement test reports, FCC ID label format and correspondence during the certification review process cannot be granted as confidential documents and this information will be available for public review once the grant of equipment authorization is issued. (signature) Kane Xin

Music Tribe Commercial MY Sdn. Bhd. Model Declaration Letter We, the undersigning company Company Name: Music Tribe Commercial MY Sdn. Bhd. Address: 1-17-02, Suntech @ Penang Cybercity, LinTang Mayang Pasir 3, Bayan Baru, Pulau Pinang, Malaysia Hereby confirm that the following products: Product description: UHF Wireless System with Handheld Microphone Type designation: XTM1-35 DUAL VOCAL SET, XTM1-35 VOCAL SET Trademark: Behringer That The difference as below: XTM1-35 DUAL VOCAL SET is UHF Wireless System with 2 Handheld Microphones and Dual-Channel Receiver. XTM1-35 VOCAL SET is UHF Wireless System with Handheld Microphone and Single-Channel Receiver. Date: 2023-08-21 Name: Kane Xin Telephone: +86-15818554545 E-mail: [email protected] Signature:

Page 1 of 4 Report No.: STS23 APPENDIX-PHOTOGRAPHS OF EUT CONSTRUCTIONAL DETAILS Model: XTM1-35 DUAL VOCAL SET Photo 1 Photo 2 Page 2 of 4 Report No.: STS23 Photo 3 Photo 4 Page 3 of 4 Report No.: STS23 Photo 5 Photo 6 Page 4 of 4 Report No.: STS23 Photo 7

Page 1 of 4 Report No.: STS2307014 APPENDIX-PHOTOGRAPHS OF EUT CONSTRUCTIONAL DETAILS Model: XTM1-35 DUAL VOCAL SET Photo 1 Photo 2 Microphone Antenna Page 2 of 4 Report No.: STS2307014 Photo 3 Photo 4 Page 3 of 4 Report No.: STS2307014 Photo 5 Photo 6 Page 4 of 4 Report No.: STS2307014 Photo 7

Any reproduction of this document must be done in full. No single part of this document may be reproduced without permission from STS, all test data presented in this report is only applicable to presented test sample. Shenzhen STS Test Services Co., Ltd. A 1/F, Building B, Zhuoke Science Park, No.190 Chongqing Road, HepingShequ, Fuyong Sub-District, Bao’an District, Shenzhen, Guang Dong, China TEL: +86-755 3688 6288 FAX: +86-755 3688 6277 E-mail:[email protected] RADIO TEST REPORT Report No: STS2305074H01 Issued for Music Tribe Commercial MY Sdn. Bhd. 1-17-02, Suntech @ Penang Cybercity, LinTang Mayang Pasir 3, Bayan Baru, Pulau Pinang, Malaysia Product Name: UHF Wireless System with Handheld Microphone Brand: Behringer Model Number: XTM1-35 DUAL VOCAL SET Series Model(s): XTM1-35 VOCAL SET FCC ID: QWHXTM1-35 Test Standard: FCC 47CFR §2.1091 S T L A B S Page 2 of 9 Report No.: STS2305074H01 Test Report Certification Applicant’s Name .................. : Music Tribe Commercial MY Sdn. Bhd. Address ................................... : 1-17-02, Suntech @ Penang Cybercity, LinTang Mayang Pasir 3, Bayan Baru, Pulau Pinang, Malaysia Manufacturer's Name ........... : Music Tribe Commercial MY Sdn. Bhd. Address ................................... : 1-17-02, Suntech @ Penang Cybercity, LinTang Mayang Pasir 3, Bayan Baru, Pulau Pinang, Malaysia Product Description Product Name ......................... : UHF Wireless System with Handheld Microphone Brand ..................................... : Behringer Model Number ........................ : XTM1-35 DUAL VOCAL SET Series Model(s) ....................... : XTM1-35 VOCAL SET Standards .............................. : FCC 47CFR §2.1091 447498 D04 Interim General RF Exposure Guidance v01 This report shall not be reproduced except in full, without the written approval of STS, this document only be altered or revised by STS, personal only, and shall be noted in the revision of the document. Date of Test .............................................. : Date of receipt of test item ....................... : 11 May 2023 Date (s) of performance of tests .............. : 11 May 2023 ~ 14 June 2023 Date of Issue............................................. : 14 June 2023 Test Result ................................................. : Pass Testing Engineer : (Chris Chen) Technical Manager : (Sean she) Authorized Signatory : (Bovey Yang) Page 3 of 9 Report No.: STS2305074H01 TABLE OF CONTENTS 1. GENERAL INFORMATION 5 1.1 GENERAL DESCRIPTION OF THE EUT 5 1.2 TEST FACTORY 5 2. FCC 47CFR §2.1093 REQUIREMENT 6 2.1 TEST STANDARDS 6 2.2 LIMIT 6 2.3 TEST RESULT 9 Page 4 of 9 Report No.: STS2305074H01 Revision History Rev. Issue Date Report No. Effect Page Contents 00 14 June 2023 STS2305074H01 ALL Initial Issue Page 5 of 9 Report No.: STS2305074H01 1. GENERAL INFORMATION 1.1 GENERAL DESCRIPTION OF THE EUT Product Name UHF Wireless System with Handheld Microphone Brand Behringer Model Number XTM1-35 DUAL VOCAL SET Series Model(s) XTM1-35 VOCAL SET Model Difference XTM1-35 DUAL VOCAL SET is UHF Wireless System with 2 Handheld Microphones and Dual-Channel Receiver. XTM1-35 VOCAL SET is UHF Wireless System with Handheld Microphone and Single-Channel Receiver. USA and Australia versions: XTM1-35 VOCAL SET:(584 - 608MHz) XTM1-35 DUAL VOCAL SET:(584 - 608MHz) EU and UK versions: XTM1-35 VOCAL SET:(863 - 865MHz) XTM1-35 DUAL VOCAL SET:(823 - 832MHz & 863 - 865MHz) Frequency tuning in the software is different Product Description The EUT is UHF Wireless System with Handheld Microphone. Operation Frequency: 584 - 608 MHz Modulation Type: FM Antenna gain: -1.5dBi Antenna Designation: Auger-type Rating UHF Wireless System Input: DC 12V,600mA Handheld Microphone Input: DC 3V Adapter Input: 100-240V~50/60Hz 0.6A Output:12.0V⎓0.6A, 7.2W Hardware Version N/A Software Version N/A 1.2 TEST FACTORY SHENZHEN STS TEST SERVICES CO., LTD Add. : A 1/F, Building B, Zhuoke Science Park, No.190 Chongqing Road, HepingShequ, Fuyong Sub-District, Bao’an District, Shenzhen, Guang Dong, China FCC test Firm Registration Number: 625569 IC test Firm Registration Number: 12108A A2LA Certificate No.: 4338.01 Page 6 of 9 Report No.: STS2305074H01 2. FCC 47CFR §2.1093 REQUIREMENT 2.1 TEST STANDARDS Follow the maximum permissible exposure (MPE) limits specified in 447498 D04 Interim General Radio Frequency Exposure Guidelines v01. The gain of the antenna used in the product was extracted from the supplied antenna data sheet and the maximum total power input to the antenna was also measured. Calculate the distance from the product to the MPE limit by the formula. 2.2 LIMIT For single RF sources (i.e., any single fixed RF source, mobile device, or portable device, as defined in paragraph (b)(2) of this section): A single RF source is exempt if: (A) The available maximum time-averaged power is no more than 1 mW, regardless of separation distance. This exemption may not be used in conjunction with other exemption criteria other than those in paragraph (b)(3)(ii)(A) of Part 1.1307. Medical implant devices may only use this exemption and that in paragraph (b)(3)(ii)(A); (B) Or the available maximum time-averaged power or effective radiated power (ERP), whichever is greater, is less than or equal to the threshold Pth (mW) described in the following formula. This method shall only be used at separation distances (cm) from 0.5 centimeters to 40 centimeters and at frequencies from 0.3 GHz to 6 GHz (inclusive). Pth is given by: Page 7 of 9 Report No.: STS2305074H01 (C) Or using below table and the minimum separation distance (R in meters) from the body of a nearby person for the frequency (f in MHz) at which the source operates, the ERP (watts) is no more than the calculated value prescribed for that frequency. For the exemption in Table 1 to apply, R must be at least λ/2π, where λ is the free-space operating wavelength in meters. If the ERP of a single RF source is not easily obtained, then the available maximum time…

Text truncated - open the document above for the full version.

Any reproduction of this document must be done in full. No single part of this document may be reproduced without permission from STS, All Test Data Presented in this report is only applicable to presented Test sample. Shenzhen STS Test Services Co., Ltd. A 1/F, Building B, Zhuoke Science Park, No.190 Chongqing Road, HepingShequ, Fuyong Sub-District, Bao’an District, Shenzhen, Guang Dong, China TEL: +86-755 3688 6288 FAX: +86-755 3688 6277 E-mail:[email protected] FCC TEST REPORT Report No: STS2305074W01 Issued for Music Tribe Commercial MY Sdn. Bhd. 1-17-02, Suntech @ Penang Cybercity, LinTang Mayang Pasir 3, Bayan Baru, Pulau Pinang, Malaysia Product Name: UHF Wireless System with Handheld Microphone Brand: Behringer Model Number: XTM1-35 DUAL VOCAL SET Series Model(s): XTM1-35 VOCAL SET FCC ID: QWHXTM1-35 Test Standard: FCC Part 15.236 S T L A B S Page 2 of 34 Report No.: STS2305074W01 TEST RESULT CERTIFICATION Applicant’s Name ................. : Music Tribe Commercial MY Sdn. Bhd. Address .................................. : 1-17-02, Suntech @ Penang Cybercity, LinTang Mayang Pasir 3, Bayan Baru, Pulau Pinang, Malaysia Manufacturer's Name ........... : Music Tribe Commercial MY Sdn. Bhd. Address .................................. : 1-17-02, Suntech @ Penang Cybercity, LinTang Mayang Pasir 3, Bayan Baru, Pulau Pinang, Malaysia Product Description Product Name ........................ : UHF Wireless System with Handheld Microphone Brand .................................... : Behringer Model Number ........................ : XTM1-35 DUAL VOCAL SET Series Model(s) ...................... : XTM1-35 VOCAL SET Test Standards...................... : FCC Part 15.236 Test Procedure ....................... : ANSI C63.10-2013 This device described above has been tested by STS, the test results show that the equipment under test (EUT) is in compliance with the FCC requirements. And it is applicable only to the tested sample identified in the report. This report shall not be reproduced except in full, without the written approval of STS, this document only be altered or revised by STS, personal only, and shall be noted in the revision of the document. Date of Test ............................................. : Date of receipt of test item ....................... : 11 May 2023 Date of performance of tests .................... : 11 May 2023 ~ 14 June 2023 Date of Issue ........................................... : 14 June 2023 Test Result .............................................. : Pass Testing Engineer : (Chris Chen) Technical Manager : (Sean she) Authorized Signatory : (Bovey Yang) Page 3 of 34 Report No.: STS2305074W01 Table of Contents Page 1. SUMMARY OF TEST RESULTS 5 1.1 TEST FACTORY 6 1.2 MEASUREMENT UNCERTAINTY 6 2. GENERAL INFORMATION 7 2.1 GENERAL DESCRIPTION OF THE EUT 7 2.2 DESCRIPTION OF THE TEST MODES 9 2.3 BLOCK DIAGRAM SHOWING THE CONFIGURATION OF SYSTEM TESTED 9 2.4 DESCRIPTION OF NECESSARY ACCESSORIES AND SUPPORT UNITS 10 2.5 TEST EQUIPMENT 11 3. PART 15.236 REQUIREMENTS 12 3.1 RADIATED SPURIOUS EMISSION 12 3.2 EMISSION MASK 12 3.3 FREQUENCY STABILITY VS. TEMPERATURE & VOLTAGE 24 3.4 OCCUPIED BANDWIDTH 28 3.5 RADIATED POWER 31 PHOTOS OF TEST SETUP 34 Page 4 of 34 Report No.: STS2305074W01 Revision History Rev. Issue Date Report NO. Effect Page Contents 00 14 June 2023 STS2305074W01 ALL Initial Issue Page 5 of 34 Report No.: STS2305074W01 1. SUMMARY OF TEST RESULTS Test procedures according to the technical standards: The EUT has been tested according to FCC CFR 47: Part 15.236: Operation of wireless microphones in the bands 54-72 MHz, 76-88 MHz, 174-216 MHz, 470-608 MHz and 614-698 MHz. Emission Standard Item Limit Result FCC 15.236(g) Radiated Spurious Emission Refer to 300 422-1 V1.4.2 (8.4) PASS FCC 15.236(d)(1) EIRP ≤50 mW PASS FCC 15.215 Occupied Bandwidth -- PASS FCC 15.236(f)(3) Frequency tolerance ±0.005% PASS FCC 15.236(g) Necessary Bandwidth (Mask) Refer to 300 422-1 V1.4.2 (8.3) PASS NOTE: (1) “N/A” denotes test is not applicable in this Test Report. Page 6 of 34 Report No.: STS2305074W01 1.1 TEST FACTORY SHENZHEN STS TEST SERVICES CO., LTD Add. : A 1/F, Building B, Zhuoke Science Park, No.190 Chongqing Road, HepingShequ, Fuyong Sub-District, Bao’an District, Shenzhen, Guang Dong, China FCC test Firm Registration Number: 625569 IC test Firm Registration Number: 12108A A2LA Certificate No.: 4338.01 1.2 MEASUREMENT UNCERTAINTY The reported uncertainty of measurement y ± U, where expended uncertainty U is based on a standard uncertainty multiplied by a coverage factor of k=2, providing a level of confidence of approximately 95 %. No. Item Uncertainty 1 RF output power, conducted ±1.197dB 2 Unwanted Emissions, conducted ±2.896dB 3 All emissions, radiated 9K-30MHz ±3.84dB 4 All emissions, radiated 30M-1GHz ±3.94dB 5 All emissions, radiated 1G-6GHz ±4.59dB 6 All emissions, radiated>6G ±5.22dB 7 Conducted Emission (9KHz-150KHz) ±2.14dB 8 Conducted Emission (150KHz-30MHz) ±2.54dB Page 7 of 34 Report No.: STS2305074W01 2. GENERAL INFORMATION 2.1 GENERAL DESCRIPTION OF THE EUT Product Name: UHF Wireless System with Handheld Microphone Brand: Behringer Model Number: XTM1-35 DUAL VOCAL SET Series Model(s): XTM1-35 VOCAL SET Model Difference description: XTM1-35 DUAL VOCAL SET is UHF Wireless System with 2 Handheld Microphones and Dual-Channel Receiver. XTM1-35 VOCAL SET is UHF Wireless System with Handheld Microphone and Single-Channel Receiver. USA and Australia versions: XTM1-35 VOCAL SET:(584 - 608MHz) XTM1-35 DUAL VOCAL SET:(584 - 608MHz) EU and UK versions: XTM1-35 VOCAL SET:(863 - 865MHz) XTM1-35 DUAL VOCAL SET:(823 - 832MHz & 863 - 865MHz) Frequency tuning in the software is different Emission Bandwidth: 32.291KHz Rating: UHF Wireless System Input: DC 12V,600mA Handheld Microphone Input: DC 3V Adapter: Input: 100-240V~50/60Hz 0.6A Output:12.0V⎓0.6A, 7.2W Operation Frequency Range 584 - 608 MHz Antenna Type Auger-type Antenna Gain -1.5dBi Maximum Transmitter Power: 0.00959W…

Text truncated - open the document above for the full version.

Handheld microphone soldering antenna TECHNICAL INDEX Electrical performance model MD‐13 Frequency range( MHz) 584‐‐608 Antenna type a…

Text truncated - open the document above for the full version.
