QWLM105Wireless Transaction Terminal with CDPD Modem

M M P P o o w w e e r r i i n n g g W W i i r r e e l l e e s s s s C C o o m m m m e e r r c c e e U U s s e e r r G G u u i i d d e e TM TM MobileScape TM User GuideCommerciant | M Powering Wireless Commerce Revision 1.12 Welcome page.... Welcome – you’ve made the right choice! The MobileScape TM System was designed to be user friendly and efficient while giving you the power to do mobile credit card processing anytime anywhere. We know you are eager to start using your MobileScape TM terminal right away and this guide is designed to help you do just that. To start using your MobileScape TM terminal immediately, see the sections marked “Getting to know your new MobileScape TM terminal” and “Basic functions”. These two sections were designed to be a quick start guide to using your MobileScape TM terminal. For a more in-depth guide to using your MobileScape TM terminal see the section labeled “Advanced functions”. This section was designed to go into detail about using all of the functions of your new MobileScape TM terminal. The remaining parts of the guide will give you information about caring for your new MobileScape TM terminal, accessories and more. MobileScape TM User GuideCommerciant | M Powering Wireless Commerce Revision 1.13 Table of contents... Welcome Letter2 Getting To Know Your New MobileScape TM Terminal5 Display Indicators 7 What’s in the box 8 Menus explained - navigation Basic Functions 9 Turning Your MobileScape TM Terminal On And Off9 Using The Stylus 9 Charging The Battery 9 Capturing An Electronic Signature 9 Printer Door Operation 10 Paper Loading 10 Antenna Position 11 FCC Statement 11 Swiped Credit Card Transaction 12 Advanced Functions 13 Swiped Credit Card Transaction 13 Manual Entry Credit Card Transaction 14 Void Transaction 15 Credit Return 16 Pre-Authorization 17 Force 18 Caring For Your MobileScape TM Terminal19 General Considerations 19 Battery Considerations 19 MobileScape TM User GuideCommerciant | M Powering Wireless Commerce Revision 1.14 Performance and safety20 Signal Strength 20 Understanding Sleep Mode 20 Following Safety Guidelines 20 Troubleshooting21 My Terminal Keeps Turning Off21 My Screen Is Frozen Or Not Responding 21 My Screen Is Blank 22 My Screen Is Not Responding Properly To Touch 22 My Signature Is Not Working 22 My Wireless Signal Is Weak Or Not Working23 My Printer Is Not Working Properly23 My Magnetic Stripe Reader Is Not Working 23 Important Numbers 24 Commerciant Customer Service24 American Express24 Discover 24 Diner’s Club 24 JCB International 24 Menu Explanation And Navigation Chart 25 Accessories 28 Hardware Specifications 29 Index 30 MobileScape TM User GuideCommerciant | M Powering Wireless Commerce Revision 1.15 G G e e t t t t i i n n g g t t o o k k n n o o w w y y o o u u r r n n e e w w M M o o b b i i l l e e S S c c a a p p e e T T M M t t e e r r m m i i n n a a l l ... ... 1. 2. 3. 6. 4. 7. 12. 11. 8. 9. 5. 10. “Top View” “Bottom/Back View” “Side View 2” “Side View 1” MobileScape TM User GuideCommerciant | M Powering Wireless Commerce Revision 1.16 1. Printer Compartment:Compartment for your thermal paper roll for printing receipts. See Page 10 for proper paper installation. 2. Magnetic Card Reader Slot: Slot for swiping credit cards. Swipe credit card through this slot with the magnetic strip down and toward the printer compartment. 3. LCD Touch Screen:Display and touch screen for menu navigation and writing signature. Note: Only use the stylus when navigating or writing on the touch screen. 4. Power Light: Lights up green when unit is powered on. 5. Power Button: Depress to turns your MobileScape TM terminal on. 6. Signal Light:For Future Use. 7. Antenna:Sends and receives wireless communication signals. Rotate antenna counter- clockwise to the antenna stop before processing transactions. To maintain compliance with FCC RF exposure requirements, a 1.5cm separation distance must be maintained between the antenna and the user's/bystander's body, and the antenna must placed in the appropriate operating position as shown on page 11 of this manual. 8. Docking Connector:Debug port for connecting to a PC during factory testing only. 9. Reset Button:The reset button performs a hard reset to the MobileScape TM terminals incase of system lockup. Depress this button with the tip of the stylus, and then press the power button to restart the terminal. 10. Stylus: Serves as pointing and writing device for navigating through menus and writing signatures. To use the stylus, slide it out of its storage slot and hold it as you would a pencil. The stylus is specialized plastic and should be the only device used on the touch screen. 11. Audio Connector: For Future Use. 12. Car and Wall Charger Connector:Connector to plug your supplied car or wall charger in for recharging the battery. MobileScape TM User GuideCommerciant | M Powering Wireless Commerce Revision 1.17 D D i i s s p p l l a a y y i i n n d d i i c c a a t t o o r r s s ... ... D D i i f f f f e e r r e e n n t t i i n n d d i i c c a a t t o o r r s s a a r r e e d d i i s s p p l l a a y y e e d d a a t t t t h h e e b b o o t t t t o o m m o o f f t t h h e e L L C C D D s s c c r r e e e e n n . . R R e e f f e e r r t t o o t t h h e e f f o o l l l l o o w w i i n n g g c c h h a a r r t t f f o o r r a a d d e e s s c c r r i i p p t t i i o o n n o o f f e e a a c c h h i i n n d d i i c c a a t t o o r r . . I I n n d d i i c c a a t t e e s s w w h h e e n n y y o o u u h h a a v v e e e e x x t t e e r r n n a a l l p p o o w w e e r r p p l l u u g g g g e e d d i i n n t t o o y y o o u u r r t t e e r r m m i i n n a a l l . . I I n n d d i i c c a a t t e e s s y y o o u u r r b b a a t t t t e e r r y y v v o o l l t t a a g g e e . . S S y y m m b b o o l l c c h h a a n n g g e e s s a a s s b b a a t t t t e e r r y y l l i i f f e e g g o o e e s s u u p p o o r r d d o o w w n n . . M M e e a a s s u u r r e e s s y y o o u u r r c c u u r r r r e e …

Text truncated - open the document above for the full version.

AT Command Set Reference Guide for Expedite Wireless IP Modem PS-01016529 Revision 1 April 7, 1999 REVISION HISTORY REV#ECO#EFF. DATEDESCRIPTIONPREPAREDAPPROVED 199007990407Initial release. D. BarberS. Smilar NOVATEL WIRELESS TECHNOLOGIES LTD. 3 NOVATEL WIRELESS TECHNOLOGIES LTD. Calgary, Alberta TITLE: AT Command Set Reference for Expedite Wireless IP Modem DOCUMENT NO.: PS-01016529 SHEET: 3 of 100 REV: 1 The information disclosed herein is the exclusive property of NOVATEL WIRELESS TECHNOLOGIES LTD. and is not to be disclosed without the written consent of NOVATEL WIRELESS TECHNOLOGIES LTD. No part of this publication may be reproduced or transmitted in any form or by any means including electronic storage, reproduction, execution or transmission without the prior written consent of NOVATEL WIRELESS TECHNOLOGIES LTD. The recipient of this document by its retention and use, agrees to respect the security status of the information contained herein. The information disclosed herein is the exclusive property of Novatel Wireless Technologies Ltd. and is not to be disclosed without the written consent of Novatel Wireless Technologies Ltd. No part of this publication may be reproduced or transmitted in any form or by any means including electronic storage, reproduction, execution or transmission without the prior written consent of Novatel Wireless Technologies Ltd. The recipient of this document by its retention and use, agrees to respect the security status of the information contained herein. This document is intended for limited circulation. The information contained in this document is subject to change without notice and should not be construed as a commitment by NOVATEL WIRELESS TECHNOLOGIES LTD. unless such commitment is expressly given in a covering document. © Copyright NOVATEL WIRELESS TECHNOLOGIES LTD. (1999) NOVATEL WIRELESS TECHNOLOGIES LTD. 4 NOVATEL WIRELESS TECHNOLOGIES LTD. Calgary, Alberta TITLE: AT Command Set Reference for Expedite Wireless IP Modem DOCUMENT NO.: PS-01016529 SHEET: 4 of 100 REV: 1 Table of Contents INTRODUCTION.............................................................................................................................................6 Scope................................................................................................................................................................6 PHYSICAL INTERFACE.................................................................................................................................7 Protocol.........................................................................................................................................................7 Software Interface...........................................................................................................................................8 AT Command Mode....................................................................................................................................8 Command format.........................................................................................................................................8 Result format................................................................................................................................................8 Data Mode Description................................................................................................................................9 Internal Stack Description.........................................................................................................................11 UDP Mode Description..............................................................................................................................12 TCP Mode Description..............................................................................................................................13 DTR Control Description...........................................................................................................................15 Push Technology.......................................................................................................................................16 Slip Mode....................................................................................................................................................17 Point to Point Protocol (PPP)...................................................................................................................18 Data Transmission Mode..........................................................................................................................19 Data Reception Mode................................................................................................................................20 Sleep Mode Description............................................................................................................................21 Sleep Mode Feature Enable/Disable.......................................................................................................22 Power-up Default Mode.............................................................................................................................23 Set Hardware Configuration......................................................................................................................24 Profile Configuration Commands.............................................................................................................25 Program Mode...........................................................................................................................................26 Local Echo..................................................................................................................................................27 Response Format........................................................................................................................…

Text truncated - open the document above for the full version.

American Telecommunications Certification Body Inc. 6731 Whittier Ave, McLean, VA 22101 May 1, 2003 RE: FCC ID: QWLM105 Attention: Jon Hughes I have a few comments on this Application. 1. You have not provided the tune up procedure for this application. Even though the end user cannot ‘tune’ the device, the FCC requires that all licensed devices provide the factory tune up procedure in the application. Please provide the factory tune up procedure for this device. 2. FYI – Since the device is to obtain its own ID number, there is no need to put the “Contains TX FCC ID:xxxx” on the label. This would be needed if the EUT were going to rely on the FCC ID of the modem itself and not obtain its own ID. Also, please note that the original grant and PC2 for the FCC ID:NBZNRM-6832 specifically restricts the use of the modem to mobile devices or devices used solely in mobile configurations. This application shows the device used in a body worn configuration. This voids the grant on the modem consequently making it improper to place the “Contains TX FCC ID:xxx” on the device. (i.e. referring to a device that is not granted for the purpose used.) 3. FYI – no action needed. Your EMC report refers to a section in 22.917 that no longer exists (see page 4 of the EMC report). Part 22.917 has changed and the paragraph numbering is different. Please review the latest Part 22 as of Feb 18, 2003 for reference. 4. The original report for the modem showed the proper frequencies of 824.04 and 848.97 allowing compliance at 824 and 849. Please look at your band edge compliance data shown on the OBW plots. While your report states that the device operates at 824.04 MH and 848.97 MHz for the radiated spurious emissions, the plots suggest that the device is apparently operating on the band edges. Please confirm band edge compliance of the device. (i.e. you may want to show band edge compliance using the reduced 1% of OBW in 22.917(b). Alternately, provide evidence from the original filing that the device is compliant at the band edges). Dennis Ward mailto:[email protected] The items indicated above must be submitted before processing can continue on the above referenced application. Failure to provide the requested information may result in application termination. Correspondence should be considered part of the permanent submission and may be viewed from the Internet after a Grant of Equipment Authorization is issued. Please do not respond to this correspondence using the email reply button. In order for your response to be processed expeditiously, you must submit your documents through the AmericanTCB.com website. Also, please note that partial responses increase processing time and should not be submitted. Any questions about the content of this correspondence should be directed to the sender.

Celltech Labs Inc. 1955 Moss Court, Kelowna, B.C. Canada V1Y 9L3 Tel. 250-448-7047 • Fax. 250-448-7046 • e-mail: [email protected] www.celltechlabs.com April 29, 2003 American Telecommunications Certification Body, Inc. 6731 Whittier Avenue, Suite C110 McLean, VA 22101 SUBJECT: COMMERCIANT L.P. FCC ID: QWLM105 Part 22.901(d) - Certification On behalf of Commerciant L.P. is a Part 22.901(d) Certification application for M105 Wireless Transaction Terminal with internal CDPD Modem Model: Expedite manufactured by Novatel Wireless Technologies, Ltd. (FCC ID: NBZNRM-6832, originally granted April 14, 1999). Model Name: M Model No.: M105 Equipment Class: Licensed Non-Broadcast Station Transmitter (TNB) Equipment Type: Wireless Transaction Terminal with internal CDPD Modem Modulation: GMSK Emission Designator: 28K8FXW Tx Freq. Range: 824.04 - 848.97 MHz Rx Freq. Range: 869.04 - 893.97 MHz Conducted Power Tested: 28.0 dBm Max. RF Output Power: 0.287 Watts (ERP) Max. SAR Measured: 1.14 W/kg (1g average) Antenna Type(s): External Dipole Attached is the confidentiality request, Part 22.901(d) EMC measurement report data and photographs, RF exposure SAR measurement report data & photographs, FCC ID label and location, internal and external photographs, block diagrams (confidential), circuit diagram(s) (confidential), parts list (confidential), tune-up procedure (confidential), operational description (confidential), antenna specifications (confidential), and the user's manual with RF exposure warning statement. If you have any questions or comments concerning the above, please contact the undersigned. Sincerely, Jonathan Hughes General Manager Celltech Labs Inc. cc: Commerciant L.P.

© 2003 Celltech Labs Inc. Commerciant L.P. FCC ID: QWLM105 (Model: M105) Wireless Transaction Terminal with CDPD Modem (824-849MHz) EXTERNAL EUT PHOTOGRAPHS Bottom of EUT Front of EUT © 2003 Celltech Labs Inc. Commerciant L.P. FCC ID: QWLM105 (Model: M105) Wireless Transaction Terminal with CDPD Modem (824-849MHz) EXTERNAL EUT PHOTOGRAPHS Right Side of EUT Left Side of EUT Bottom End of EUT Top End of EUT © 2003 Celltech Labs Inc. Commerciant L.P. FCC ID: QWLM105 (Model: M105) Wireless Transaction Terminal with CDPD Modem (824-849MHz) EXTERNAL EUT PHOTOGRAPHS Antenna – Extended Position

© 2003 Celltech Labs Inc.Commerciant L.P. FCC ID: QWLM105 (Model: M105) Wireless Transaction Terminal with CDPD Modem (824-849MHz) INTERNAL EUT PHOTOGRAPHS © 2003 Celltech Labs Inc.Commerciant L.P. FCC ID: QWLM105 (Model: M105) Wireless Transaction Terminal with CDPD Modem (824-849MHz) INTERNAL EUT PHOTOGRAPHS © 2003 Celltech Labs Inc.Commerciant L.P. FCC ID: QWLM105 (Model: M105) Wireless Transaction Terminal with CDPD Modem (824-849MHz) INTERNAL EUT PHOTOGRAPHS © 2003 Celltech Labs Inc.Commerciant L.P. FCC ID: QWLM105 (Model: M105) Wireless Transaction Terminal with CDPD Modem (824-849MHz) INTERNAL EUT PHOTOGRAPHS Lithium-ion Battery Lithium-ion Battery © 2003 Celltech Labs Inc.Commerciant L.P. FCC ID: QWLM105 (Model: M105) Wireless Transaction Terminal with CDPD Modem (824-849MHz) INTERNAL EUT PHOTOGRAPHS

Test Report S/N: 101502-294QWL Test Date(s): February 13, 2003 FCC SAR Evaluation © 2003 Celltech Labs Inc.1 of 20 Celltech Labs Inc. declares under its sole responsibility that this device was found to be in compliance with the Specific Absorption Rate (SAR) RF exposure requirements specified in FCC 47 CFR §2.1093. The device was tested in accordance with the measurement standards and procedures specified in FCC OET Bulletin 65, Supplement C, Edition 01-01 for the General Population / Uncontrolled Exposure environment. I attest to the accuracy of data. All measurements were performed by me or were made under my supervision and are correct to the best of my knowledge and belief. I assume full responsibility for the completeness of these measurements and vouch for the qualifications of all persons taking them. This test report shall not be reproduced partially, or in full, without the prior written approval of Celltech Labs Inc. The results and statements contained in this report pertain only to the device(s) evaluated. Russell Pipe Senior Compliance Technologist Celltech Labs Inc. DECLARATION OF COMPLIANCE SAR EVALUATION Test Lab CELLTECH LABS INC. Testing and Engineering Lab 1955 Moss Court Kelowna, B.C. Canada V1Y 9L3 Phone: 250-448-7047 Fax: 250-448-7046 e-mail: [email protected] web site: www.celltechlabs.com Applicant Information COMMERCIANT L.P. 2901 Wilcrest, #250 Houston, TX 77042 Rule Part(s):FCC 47 CFR §2.1093 Test Procedure(s):FCC OET Bulletin 65, Supplement C (01-01) Device Classification:Licensed Non-Broadcast Station Transmitter (TNB) Device Type:Wireless Transaction Terminal with internal CDPD Modem (Novatel Wireless Technologies Ltd. Model: Expedite) FCC ID:QWLM105 Model Name:M Model No.:M105 Modulation:GMSK Tx Frequency Range:824.04 - 848.97 MHz Max. RF Output Power Tested: 28.0 dBm (Conducted) Antenna Type(s):External Dipole Battery Type(s):Lithium-ion 4.2V (1800 mAh) Max. SAR Measured:1.14 W/kg (1g average) Test Report S/N: 101502-294QWL Test Date(s): February 13, 2003 FCC SAR Evaluation © 2003 Celltech Labs Inc.2 of 20 TABLE OF CONTENTS 1.0INTRODUCTION..................................................................... 3 2.0DESCRIPTION OF EUT............................................................ 3 3.0SAR MEASUREMENT SYSTEM ............................................... 4 4.0MEASUREMENT SUMMARY..................................................... 5 5.0DETAILS OF SAR EVALUATION............................................... 6 6.0EVALUATION PROCEDURES................................................... 7 7.0SYSTEM PERFORMANCE CHECK............................................ 8 8.0EQUIVALENT TISSUES........................................................... 9 9.0SAR LIMITS........................................................................... 9 10.0SYSTEM SPECIFICATIONS......................................................10 11.0PROBE SPECIFICATION.........................................................11 12.0SAM PHANTOM......................................................................11 13.0PLANAR PHANTOM................................................................11 14.0DEVICE HOLDER....................................................................11 15.0TEST EQUIPMENT LIST...........................................................12 16.0MEASUREMENT UNCERTAINTIES............................................13 17.0REFERENCES.......................................................................14 APPENDIX A - SAR MEASUREMENT DATA............................................15 APPENDIX B - SYSTEM CHECK DATA....................................................16 APPENDIX C - SYSTEM VALIDATION.....................................................17 APPENDIX D - PROBE CALIBRATION....................................................18 APPENDIX E - MEASURED FLUID DIELECTRIC PARAMETERS................19 APPENDIX F - SAR TEST SETUP PHOTOGRAPHS...................................20 Test Report S/N: 101502-294QWL Test Date(s): February 13, 2003 FCC SAR Evaluation © 2003 Celltech Labs Inc.Commerciant L.P. FCC ID: QWLM105 (Model: M105)3 of 20 Wireless Transaction Terminal with CDPD Modem (824-849MHz) 1.0 INTRODUCTION This measurement report demonstrates that the Commerciant L.P. Model: M105 Wireless Transaction Terminal FCC ID: QWLM105 with internal CDPD Modem (Novatel Wireless Technologies Ltd. Model: Expedite) complies with the RF exposure requirements specified in FCC 47 CFR §2.1093 (see reference [1]) for the General Population / Uncontrolled Exposure environment. The test procedures described in FCC OET Bulletin 65, Supplement C, Edition 01-01 (see reference [2]) were employed. A description of the product, operating configuration, detailed summary of the test results, methodology and procedures used in the evaluation, equipment used, and the various provisions of the rules are included within this test report. 2.0 DESCRIPTION of Equipment Under Test (EUT) FCC Rule Part(s) 47 CFR §2.1093 Test Procedure(s) FCC OET Bulletin 65, Supplement C (01-01) FCC Device Classification Licensed Non-Broadcast Station Transmitter (TNB) Device Type Wireless Transaction Terminal with CDPD Modem (Novatel Wireless Technologies Ltd. Model: Expedite) FCC ID QWLM105 Model Name M Model No. M105 Serial No. Pre-production Modulation GMSK Tx Frequency Range 824.04 - 848.97 MHz Max. RF Output Power Tested 28.0 dBm (Conducted) Antenna Type(s) External Dipole Battery Type(s) Lithium-ion 4.2V (1800 mAh) Test Report S/N: 101502-294QWL Test Date(s): February 13, 2003 FCC SAR Evaluation © 2003 Celltech Labs Inc.Commerciant L.P. FCC ID: QWLM105 (Model: M105)4 of 20 Wireless Transaction Terminal with CDPD Modem (824-849MHz) 3.0 SAR MEASUREMENT SYSTEM Celltech Research SAR measurement facility utilizes the Dosimetric Assessment System (DASY™) manufactured by Schmid & Partner Engineering AG (SPEAG™) of Zurich, Switzerland. The DASY system is comprised of the robot controller, computer, near-field…

Text truncated - open the document above for the full version.

Test Date(s): February 14,17, 2003 Test Report S/N: 101502-293QWL FCC Part 22 EMC Measurements © 2003 Celltech Labs Inc.1 of 15 This equipment has been shown to be capable of compliance with the applicable technical standards as indicated in the measurement report and was tested in accordance with the measurement procedures specified in FCC 47 CFR §22.901(d), §2, and ANSI TIA/EIA-603-A-2001. I attest to the accuracy of data. All measurements reported herein were performed by me or were made under my supervision and are correct to the best of my knowledge and belief. I assume full responsibility for the completeness of these measurements and vouch for the qualifications of all persons taking them. This test report shall not be reproduced partially, or in full, without the prior written approval of Celltech Labs Inc. The results and statements contained in this report pertain only to the device(s) evaluated. Russell Pipe Senior Compliance Technologist Celltech Labs Inc. DECLARATION OF COMPLIANCE FCC PART 22.901(d) EMC MEASUREMENTS Test Lab CELLTECH LABS INC. Testing and Engineering Services 1955 Moss Court Kelowna, B.C. Canada V1Y 9L3 Phone:250-448-7047 Fax:250-448-7046 e-mail:[email protected] web site:www.celltechlabs.com Applicant Information COMMERCIANT L.P. 2901 Wilcrest, #250 Houston, TX 77042 FCC Rule Part(s):47 CFR §22.901(d), §2 Test Procedure(s):FCC 47 CFR §22.901(d), §2; ANSI TIA/EIA-603-A-2001 FCC Device Classification:Licensed Non-Broadcast Station Transmitter (TNB) Device Type:Wireless Transaction Terminal with Novatel Expedite CDPD Modem FCC ID: QWLM105 Model Name:M Model No.:M105 Modulation:GMSK Tx Frequency Range:824.04 - 848.97 MHz Rx Frequency Range:869.04 - 893.97 MHz Max. RF Output Power:0.287 Watts (ERP) Conducted Power Tested:28.0 dBm Emission Designator(s):28K8FXW Frequency Tolerance(s):± 0.00025 % Antenna Type:External Dipole Battery Type:Lithium-Ion 4.2V (1800mAh) Test Date(s): February 14,17, 2003 Test Report S/N: 101502-293QWL FCC Part 22 EMC Measurements © 2003 Celltech Labs Inc.2 of 15 TABLE OF CONTENTS 1.1SCOPE3 1.2GENERAL INFORMATION - §2.1033(a)3 2.1MEASUREMENT PROCEDURES4 2.2RF Output Power - §2.10464 2.3Spurious Emissions at Antenna Terminal - §2.10514 2.4Receiver Spurious Emissions - §22.917(f)4 2.5Occupied Bandwidth - §2.1049, §22.9174 2.6Field Strength of Spurious Radiation - §2.10535 2.7Effective Radiated Power Output - §22.9135 2.8Radiated Measurement Test Setup5 2.9Frequency Stability / Temperature Variation - §2.10556 3.1TEST DATA7 3.2Effective Radiated Power Output - §22.9137 3.3Field Strength of Spurious Radiation-§2.10538-10 3.4Frequency Stability / Temperature Variation - §2.105511 4.1LIST OF TEST EQUIPMENT12 5.1CONCLUSION13 APPENDIX A - TEST PLOTS14 APPENDIX B - RADIATED TEST SETUP PHOTOGRAPHS15 Test Date(s): February 14,17, 2003 Test Report S/N: 101502-293QWL FCC Part 22 EMC Measurements © 2003 Celltech Labs Inc.COMMERCIANT L.P. FCC ID: QWLM105 (Model: M105)3 of 15 Wireless Transaction Terminal with internal CDPD Modem APPLICANT COMMERCIANT L.P. 2901 Wilcrest, #250 Houston, TX 77042 FCC PART 22.901(d) EMC MEASUREMENT REPORT 1.1 SCOPE Measurement and determination of electromagnetic emissions (EME) from radio frequency devices for compliance with the technical rules and regulations of the Federal Communications Commission. 1.2 GENERAL INFORMATION - §2.1033(a) FCC ID QWLM105 Model(s) M105 Serial No. Pre-production EUT Type Wireless Transaction Terminal with Novatel Wireless Technologies Model: Expedite internal CDPD Modem FCC Rule Part(s) 47 CFR §22.901(d), §2 FCC Classification Licensed Non-Broadcast Station Transmitter (TNB) Tx Frequency Range 824.04 - 848.97 MHz Rx Frequency Range 869.04 - 893.97 MHz Max. RF Output Power0.287 Watts (ERP) RF Conducted Output Power Tested 28.0 dBm Emission Designator 28K8FXW Frequency Tolerance ± 0.00025 % Modulation GMSK Battery Type Lithium-Ion 4.2V (1800 mAh) Antenna Type External Dipole (Length: 137 mm) Test Date(s): February 14,17, 2003 Test Report S/N: 101502-293QWL FCC Part 22 EMC Measurements © 2003 Celltech Labs Inc.COMMERCIANT L.P. FCC ID: QWLM105 (Model: M105)4 of 15 Wireless Transaction Terminal with internal CDPD Modem 2.1 MEASUREMENT PROCEDURES 2.2 RF OUTPUT POWER MEASUREMENT - §2.1046 The peak conducted power levels were measured with a Gigatronics 8650A Universal Power Meter in Continuous Wave mode. An offset was entered into the power meter to correct for the losses of the attenuator and cable installed before the sensor input. The transmitter terminal was coupled to the power meter and the EUT was placed into test mode via internal software. All subsequent tests were performed using the same tune-up procedures. 2.3 SPURIOUS EMISSIONS AT ANTENNA TERMINAL - §2.1051 The EUT was placed in test mode via internal software at a full rated power. The conducted power was measured with a Gigatronics 8650A Universal Power Meter. An offset was entered into the power meter to correct for all losses of the attenuator and cable installed before the sensor input. The level of the carrier and the various conducted spurious frequencies were measured by means of a calibrated spectrum analyzer. The resolution bandwidth and video bandwidth were set to 1MHz. The spectrum was scanned from 10MHz to 20GHz at the low, mid, and high channels. The radio transmitter was operating at maximum output power. The antenna output terminal of the EUT was connected to the input of a 50Ω spectrum analyzer through a matched 30dB attenuator and coaxial cable. The reported emissions were below the specified limit of -13dBm. 2.4 RECEIVER SPURIOUS EMISSIONS - §22.917(f) Conducted spurious emissions were measured at the antenna terminal of the EUT using a spectrum analyzer. The transmitter of the EUT was placed into full power and the frequency span of the spectrum analyzer was set to the receiving band of the device. The recorded spurious emissions at the antenna terminal must be attenuated to a level not to exceed -80dBm. 2.5 OCCU…

Text truncated - open the document above for the full version.
