Surbox 918 Quick Start Guide Surbox is a TV connected Internet access media box aims to transform a regular TV into a smart TV . The functions include Internet surfing Media Player: Browser and software suites Google android OS and its increasing application resources (e.g Google Play) HD 1080P high definition multimedia capability to play video and music Package includes: Surbox AC-DC power adaptor User manual HDMI cable (optional add on ) IR remote Feltouch remote- wireless touchpad keyboard mouse and USB dongle (optional add-on) Human interface-HID peripherals Any regular USB keyboard and mouse can be used as Surbox input device. Feltouch touchpad is a recommended remote control device for improved experience in gaming, keyboard input and multi-touch gestures (as remote controls) Power button Power button is located on right hand side of the device. Turn on the power button when first connected to TV. The power LED at the front of the device will turn Blue, indicating the device is now under normal operation. When not in use, you can use the power button on the IR remote or Bonepad SQ to turn off the machine in standby mode. LED goes to Red. Now the device is in standby rest mode. The Home page of the device will be cleared from the TV screen. To wake up the device, press the power button on either remote once more. Connecting to TV or Monitor: HDMI cable connection (AV OUT connection) Connects between the device and the screen (TV, monitor etc). HDMI port is located at the back of the device, next to the USB slot. We have also make available AV OUT port for older TVs without HDMI port. Internet connectivity Wireless connectivity 1. Supported by WIFI 802.11/b/g with embedded antenna 2. Select correct AP (access point/host device) from the list of available networks available from the drop down list in [Settings] LAN /Ethernet connectivity 1. In [Settings], connect Ethernet cable to Surbox 2. If DHCP server is available, Surbox will automatically completes setup 3. If DHCP server is not available in LAN, user needs to setup information before accessing network Storage and external device: SD/USB Slot/Cloud storage 1x SD slot is on the right hand side of the device. 2x USB slot is located on front of the device and 1x USB slot at the back of the device. Mass storage can be completed through external connection via the USB 2.0 host interface or insertion of SD card (up to 32G) or upload to Cloud storage DC adaptor The device is powered by 5V DC. The adaptor comes with the package and is connected to the back of the device. Changes or modification to this unit not authorized by the party responsible for compliance is at the personal risk of the user. The supplier does not guarantee the operation of the device in the use of other adaptors not provided by the manufacturer. Product Specification Functions Details Hardware Processor Rockchip RK 2908 1GHz RAM/NAND flash DDRIII 1GHz/ 4GB Ethernet/WiFi 802.11b/g (embedded antenna) USB/SD MMC 3x USB 2.0 Host slots/ 1x SDHC support DC power connector DC 5V input from AC Dimensions 170mmx111xxx30mm Outputs HDMI video output HDMI resolution upto 1080p Human interface IR remote control Power On/Off, menu selection buttons RF remote control Feltouch touch remtote(2.4GHZ RF and USB) –menu,home,power remote Software OS Google Android 4.0 Adobe Flash 11.1 Feltouch Input Virtual keyboard for multi language input upto 20 countries Home Screen The user interphase design of Surbox 918 has been made friendly for many who are used to Android Tablets and Smart Phones. With simple point and clicks, you know exactly where how-to-use and where-to find with minimal learning required. It is that easy. When device is powered on, the standard Home screen shows Menu list: 1. Browser 2. YouTube 3. Video ( Local Media Player) Video: supports video format : AVI,FLV, 3GP, 3GPP,MOV,DAT,MPEG,MPE,MPG,M2V,ISO,VOB, 3G2,MKV,TS,M2TS,M3TS,M4TS,M5TS,MTS,M4V,FLC 4. Music Player MP1,MP2,MP3,WMA,OGG,OGA,FLAC,ALAC,APE,ACC M4A 5. Gallery ( digital photo display) JPEG,GIF,BMP,PNG 6. Android apps 7. Settings Settings This is where you start before using the device: connect device to internet connections language set up to your preference managing your applications setting viewing displays etc Browser Once connectivity is configured correctly with successful link to Internet through Ethernet or WiFi, user is able to access Internet resources at great internet speed. User opens the browser by tapping the browser icon from Home Screen. The browser page is set to Google search webpage for quick access Youtube This is a short cut to Youtube URL. Online video streaming on Youtube allows users to view videos that have been uploaded by Youtube members. The device must be in an active WiFi or internet connection status to access Youtube Apps Users can tap into Google Play icon preinstalled on the device to access android apps with categories ranging from movies, games to entertainment. Preinstalled apps include: Google map, Explorer, Skype, Google search FCC Caution: Any changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate this equipment. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. This equipment should be installed and operated with minimum distance 20cm between the radiator and your body. NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in …
Text truncated - open the document above for the full version.
Date: 2012-10-30 FCC ID: QXISURBOX918 Subject: Ad Hoc Mode Function Declaration To Whom it may concern, This device is acting as slave and operating in the 2.4 GHz (2412 – 2462 MHz) band. Ad Hoc function is supported but not able to operate on non-US frequencies. Please contact the one signed below or the authorized agent for this filing. Thank you. Regards, Yours sincerely, Signatory Signature Name: Sherry Lai Title: PM Tel: 0 21-64285069 Company:Hanson Technology Limited Add: Room 1307, No.1698, Yi Shan Road, Shanghai
FCC Confidentiality Request To the FCC and FCC TCB handling this application for certification Pursuant to 47 CFR Section 0.459(a) & (b), we, (the applicant / grantee) Company name Hanson Technology Limited Addresss Rm1503, Kun Yang Building, No. 798, Zhao Jia Bang Rd City Shanghai Country China request non-disclosure and confidential treatment for our certification under: Grantee Code Product Number FCC ID: QXI SURBOX918 of the following materials submitted within this certification application: (please cross what is applicable, or add other documents) Operational Description Block Diagrams Schematics Diagrams Turn up produrce Above materials contain secrets, proprietary and technical information, which would customarily be guarded from competitors under 47 CFR, section 0.457(d)(2). Disclosure or publication or any portion of this company confidential material to other parties could cause substantial competitive harm and provide unjustified benefits for competitors. We understand that pursuant to 47 CFR section 0.457(d)(1)(ii) disclosure of the applicant and all accompanying documentation will not be made before the date of the grant. Attestation: City and Country: Date:Name: (this must be a person) Function:Signature: (or official company stamp) Shanghai 2012/11/2 Sherry Lai PM
Date:2012-10-30 FCC ID: QXISURBOX918 Subject: Attestation Letter “Declaration of Conformity” Dear Sirs, Our products with the above FCC ID are defined as composite device. The transmitter is authorized under the “Certification” procedure. The device is also defined as “PC Periphery” acc to §15.101 Equipment authorization of unintentional radiators, where we hereby declare, that we apply and follow the “Declaration of Conformity” procedure. If you have any questions, please feel free to contact me at the address shown below. Yours sincerely, Signatory Signature Name: Sherry Lai Title: PM Tel: 0 21-64285069 Company:Hanson Technology Limited Add: Room 1307, No.1698, Yi Shan Road, Shanghai
APPENDIX-PHOTOGRAPHS OF EUT CONSTRUCTIONAL DETAILS Photo 1 Photo 2 Photo 3 Photo 4 Photo 5 Photo 6 Photo 7 Photo 8
Photo 9 Photo 10 Photo 11 Photo 12 Photo 13 Photo 14 Antenna Photo 15
FCC ID: QXISURBOX918 RF EXPOSURE TEST Applied procedures / limit These devices are not exempted from compliance does not exceed the Commission’s RF exposure guidelines.Unless a device operates at substantially low power levels,with a low gain antenna(s),supporting information is generally needed to establish the various potential operating configurations and exposure conditions of a transmitter and its antenna(s) in order to determine compliance with the RF exposure guidelines. In order to demonstrate compliance with MPE requirement(see Section 2.1091),the following information is typically needed: Calculation that estimates the minimum separation distance(20 cm or more)between an antenna and persons required to satisfy power density limits defined for free space. Antenna installation and device operating instructions for installers(professional/unskilled users),and the parties responsible for ensuring compliance with the RF exposure requirement Any caution statements and/or warming labels that are necessary in order to comply with the exposure limits Any other RF exposure related issues that may affect MPE compliance. FCC 1.1310: The criteria listed in the following table shall be used to evaluate the environmental impact of human exposure to radio-frequency(RF) radiation as specified in 1.1307(b). (A) Limits for Occupational / Controlled Exposure Frequency Range (MHz) Electric Field Strength (E) (V/m) Magnetic Field Strength (H) (A/m) Power Density (S) (mW/ cm 2 ) Averaging Time |E| 2 ,|H| 2 or S (minutes) 0.3-3.0 614 1.63 (100)* 6 3.0-30 1842 / f 4.89 / f (900 / f)* 6 30-300 61.4 0.163 1.0 6 300-1500 F/300 6 1500-100,000 5 6 (B) Limits for General Population / Uncontrolled Exposure Frequency Range (MHz) Electric Field Strength (E) (V/m) Magnetic Field Strength (H) (A/m) Power Density (S) (mW/ cm 2 ) Averaging Time |E| 2 ,|H| 2 or S (minutes) 0.3-1.34 614 1.63 (100)* 30 1.34-30 824/f 2.19/f (180/f)* 30 30-300 27.5 0.073 0.2 30 300-1500 F/1500 30 1500-100,000 1.0 30 Note: f = frequency in MHz ; *Plane-wave equivalent power density FCC ID: QXISURBOX918 MPE CALCULATION METHOD Calculation Method of RF Safety Distance: P :power input to the antenna in Mw EIRP :Equivalent(effective) isotropic radiated power. S :power density mW/ cm 2 G ;numeric gain of antenna relative to isotropic radiator R :distance to centre of radiation in cm FCC radio frequency exposure limits may be exceeded at distances closer than r cm from the antenna of this device EIRP=10 ( Antenna Gain+Peak Output Power/10) Note: 1. s=1.0 mW /cm 2 for limits for General Population/Uncontrolled Exposures. 2. The time averaged power over 30 minutes will be equaled Output Power. 3. The Power Density at a distance of 20cm calculated from the formula is far below the limit of 1MW/ cm 2 FCC ID: QXISURBOX918 TEST RESULTS Operating Mode:802.11 b Operating Mode:802.11 g NOTE: (For mobile or fixed location transmitters, the maximum power density is 1.0mW/cm 2 even if the calculation indicates that the power density would be larger) Channal (MHz) PK output power (dBm) Output power to antenna (mW) Antenna Gain (numeric) Power Density (S) (mW/ cm 2 ) Limit of Power Density (S) (mW/ cm 2 ) Result 2412 17.93 62.08 1.58(2dBi) 0.0195 1 Pass 2437 17.74 59.42 1.58(2dBi) 0.0186 1 Pass 2462 17.52 56.49 1.58(2dBi) 0.0177 1 Pass Channal (MHz) PK output power (dBm) Output power to antenna (mW) Antenna Gain (numeric) Power Density (S) (mW/ cm 2 ) Limit of Power Density (S) (mW/ cm 2 ) Result 2412 15.86 38.54 1.58(2dBi) 0.0121 1 Pass 2437 15.23 33.26 1.58(2dBi) 0.0104 1 Pass 2462 15.25 33.49 1.58(2dBi) 0.0105 1 Pass
FCC RADIO TEST REPORT Prepared For Hanson Technology Limited Product Name: Android TV box Trade Name: Surbox Model Name : Surbox 918 FCC ID: QXISURBOX918 Prepared By DongGuan Precise Testing Service Co.,Ltd. Room 203-204, 2F, Xinye Building, No.67 Shijing,Guanzhang Road, Dongguan, China Report No. PTS2012102859F Test Date: Oct. 20 ~ Oct 31, 2012 Date of Report : Oct 31, 2012 Page 2 of 58 Report No.: PTS2012102859F VERIFICATION OF COMPLIANCE Applicant: Hanson Technology Limited Address Room 1307, No.1698, Yi Shan Road, Shang hai Manufacturer Name: Hanson Technology Limited Address: Room 1307, No.1698, Yi Shan Road, Shang hai Product Description: Android TV box Brand Name: Surbox Model Name: Surbox 918 Model difference: N/A Test procedure ANSI C63.4-2003, KDB558074 Standards FCC Part15.247 Prepared by : Assistant Reviewer : Supervisor Approved & Authorized Signer : Jack y Ou / Manager Page 3 of 58 Report No.: PTS2012102859F Table of Contents Page 1 . SUMMARY OF TEST RESULTS 5 1.1 TEST FACILITY 6 1.2 MEASUREMENT UNCERTAINTY 6 2 . GENERAL INFORMATION 7 2.1 GENERAL DESCRIPTION OF EUT 7 2.2 DESCRIPTION OF TEST MODES 9 2.3 BLOCK DIGRAM SHOWING THE CONFIGURATION OF SYSTEM TESTED 10 2.4 DESCRIPTION OF SUPPORT UNITS(CONDUCTED MODE) 11 2.5 EQUIPMENTS LIST FOR ALL TEST ITEMS 12 3 . EMC EMISSION TEST 13 3.1 CONDUCTED EMISSION MEASUREMENT 13 3.1.1 POWER LINE CONDUCTED EMISSION LIMITS 13 3.1.2 TEST PROCEDURE 14 3.1.3 DEVIATION FROM TEST STANDARD 14 3.1.4 TEST SETUP 14 3.1.5 EUT OPERATING CONDITIONS 14 3.1.6 TEST RESULTS 15 3.2 RADIATED EMISSION MEASUREMENT 17 3.2.1 RADIATED EMISSION LIMITS 17 3.2.2 TEST PROCEDURE 18 3.2.3 DEVIATION FROM TEST STANDARD 18 3.2.4 TEST SETUP 19 3.2.5 EUT OPERATING CONDITIONS 20 3.2.6 TEST RESULTS (BETWEEN 9KHZ – 30 MHZ) 21 3.2.7 TEST RESULTS (BETWEEN 30MHZ – 1GHZ) 22 3.2.8 TEST RESULTS (ABOVE 1000 MHZ) 24 4 . POWER SPECTRAL DENSITY TEST 44 4.1 APPLIED PROCEDURES / LIMIT 44 4.1.1 TEST PROCEDURE 44 4.1.2 DEVIATION FROM STANDARD 44 4.1.3 TEST SETUP 44 4.1.4 EUT OPERATION CONDITIONS 44 4.1.5 TEST RESULTS 45 5 . BANDWIDTH TEST 49 Page 4 of 58 Report No.: PTS2012102859F Table of Contents Page 5.1 APPLIED PROCEDURES / LIMIT 49 5.1.1 TEST PROCEDURE 49 5.1.2 DEVIATION FROM STANDARD 49 5.1.3 TEST SETUP 49 5.1.4 EUT OPERATION CONDITIONS 49 5.1.5 TEST RESULTS 50 6 . PEAK OUTPUT POWER TEST 54 6.1 APPLIED PROCEDURES / LIMIT 54 6.1.1 TEST PROCEDURE 54 6.1.2 DEVIATION FROM STANDARD 54 6.1.3 TEST SETUP 54 6.1.4 EUT OPERATION CONDITIONS 54 6.1.5 TEST RESULTS 55 7 . ANTENNA REQUIREMENT 56 7.1 STANDARD REQUIREMENT 56 7.2 EUT ANTENNA 56 8 . EUT TEST PHOTO 57 APPENDIX-PHOTOGRAPHS OF EUT CONSTRUCTIONAL DETAILS Page 5 of 58 Report No.: PTS2012102859F 1. SUMMARY OF TEST RESULTS Test procedures according to the technical standards: FCC Part15 (15.247) , Subpart C Standard Section Test Item Judgment Remark 15.207 Conducted Emission PASS 15.247 (a)(2) 6dB Bandwidth PASS 15.247 (b) Peak Output Power PASS 15.247 (c) Radiated Spurious Emission PASS 15.247 (d) Power Spectral Density PASS 15.205 Band Edge Emission PASS 15.203 Antenna Requirement PASS NOTE: (1)” N/A” denotes test is not applicable in this Test Report Page 6 of 58 Report No.: PTS2012102859F 1.1 TEST FACILITY NTEK Testing Technology Co., Ltd Add. : 1/F, Building E, Fenda Science Park, Sanwei Community, Xixiang Street, Bao’an District, Shenzhen P.R. China. FCC Registration No.:238937; IC Registration No.:9270A-1 1.2 MEASUREMENT UNCERTAINTY The reported uncertainty of measurement y ± U,where expended uncertainty U is based on a standard uncertainty multiplied by a coverage factor of k=2,providing a level of confidence of approximately 95 %。 No. Item Uncertainty 1 Conducted Emission Test ±1.38dB 2 RF power,conducted ±0.16dB 3 Spurious emissions,conducted ±0.21dB 4 All emissions,radiated(<1G) ±4.68dB 5 All emissions,radiated(>1G) ±4.89dB 6 Temperature ±0.5°C 7 Humidity ±2% Page 7 of 58 Report No.: PTS2012102859F 2. GENERAL INFORMATION 2.1 GENERAL DESCRIPTION OF EUT Equipment Android TV box Trade Name Surbox Model Name Surbox 918 Serial Model N/A Model Difference N/A Product Description The EUT is a Android TV box Operation Frequency: 2412~2462 MHz Modulation Type: CCK/OFDM/DBPSK/DAPSK Bit Rate of Transmitter 802.11b:11/5.5/2/1 Mbps 802.11g:54/48/36/24/18/12/9/6 Mbps Number Of Channel 11 CH, Please see Note 2. Antenna Designation: Please see Note 3. Output Power(Conducted): 802.11b: 17.93 dBm (Max.) 802.11g: 15.86 dBm (Max.) Antenna Gain (dBi) 2.0dbi Based on the application, features, or specification exhibited in User's Manual, the EUT is considered as an ITE/Computing Device. More details of EUT technical specification, please refer to the User's Manual. Channel List Please refer to the Note 2. Adapter Battery N/A Connecting I/O Port(s) Please refer to the User's Manual Note : 1. For a more detailed features description, please refer to the manufacturer’s specifications or the User's Manual. Page 8 of 58 Report No.: PTS2012102859F 2. Channel List for 802.11b/g Channel Frequency (MHz) Channel Frequency (MHz) Channel Frequency (MHz) Channel Frequency (MHz) 01 2412 04 2427 07 2442 10 2457 02 2417 05 2432 08 2447 11 2462 03 2422 06 2437 09 2452 3. Table for Filed Antenna Ant . Brand Model Name Antenna Type Connector Gain (dBi) NOTE A N/A N/A FPCB antennaN/A 2.0 N/A Page 9 of 58 Report No.: PTS2012102859F 2.2 DESCRIPTION OF TEST MODES To investigate the maximum EMI emission characteristics generates from EUT, the test system was pre-scanning tested base on the consideration of following EUT operation mode or test configuration mode which possible have effect on EMI emission level. Each of these EUT operation mode(s) or test configuration mode(s) mentioned above was evaluated respectively. Pretest Mode Description Mode 1 802.11b CH1/ CH6/ CH11 Mode 2 802.11g CH1/ CH6/ CH11 Mode 3 Link Mode For Conducted Emission Final Test Mode Description Mode 3 Link Mode For Radiated Emission Final Test Mode Description Mode 1 802.11b CH1/ CH6/ CH11 Mode 2 802.11g …
Text truncated - open the document above for the full version.
Page 57 of 58 Report No.: PTS2012102859F 8. EUT TEST PHOTO Radiated Measurement Photos Page 58 of 58 Report No.: PTS2012102859F Conducted Measurement Photos
| # | Rule Parts | Frequency Range | Power Output |
|---|---|---|---|
| 1 | 15C | 2.41 GHz - 2.46 GHz | 62.10 mW |

BINS
Equipment Class
DTS - Digital Transmission System
