GameVector Operating Instructions GameVector Receiver HideRider Transmitter with battery The GameVector system consists of two components, the HideRider transmitter and the GameVector Receiver. HideRider Transmitter The HideRider comes complete with the battery module inserted. To activate, press on the back of the battery module and insert completely into the HideRider. The LED in the back of the HideRider will blink and the transmitter is activated. After a two minute period unit enters the sleep mode, the blinking stops and the transmitter is turned off. The unit is now asleep and ready to be shot from the bow. Upon release from the bow, the HideRider is automatically activated and will begin to blink and transmit. To turn the unit off, simply slide the battery back about 1/8 inch to the off position. Note: When the battery is fully inserted and the HideRider is asleep the battery life is aprox. two weeks. Once the Hiderider is shot from the bow and in transmit mode, the battery life is approximately 72 hours. It is recommend to replace the battery after 100 hours of sleep time to assure there is ample battery power remaining after the shot. To attach the HideRider 1. Remove the broad head from the arrow shaft 2. Insert the HiderRider retainer as shown 3. Reattach the broadhead 4. Close the HideRider around the shaft 5. Push the HideRider forward until it snaps into the retainer 6. Assure the barbed needle is lined up between the blades of the broadhead To operate the HideRider 1. Fully insert the battery (LED will flash and transmitter is activated for two minutes then enters sleep mode) 2. To deactivate the HideRider and stop all battery consumption simply slide the battery back about 1/8 inch to the off position. To Change the HideRider battery 1. Remove the HideRider from the arrow or bolt shaft 2. With the point of a pocket knife lift the small tab on the inside if the HideRider 3. Slide Battery out 4. Replace with new battery GameVector Receiver The GameVector receiver is made up of two parts, the GameVector receiver gun and the two piece antenna. Once the antenna is attached to the receiver gun the unit functions as a directional receiver. To Insert the batteries 1. Remove the screw holding the battery cover 2. Insert two AA batteries as shown inside the battery compartment 3. Replace battery cover To attach the antenna to the gun 1. Assemble the red antenna as shown. The orientation of the two antenna sections is not important but make sure that the two pieces are completely forced together before tightening the thumb screws 2. Attach the antenna to the gun by placing the protrusion on the top of the gun through the slot in the antenna. 3. Slide the antenna back until it stops 4. Carefully line up the antenna connector with the connector receptacle in the top of the gun and insert. Make sure the connector is fully inserted and the Velcro is engaged. Receiver Operation (see diagram) Power on/off Signal strength Volume down Volume Up Power/low batt Range indicator Battery Cover Protrusion Antenna Connector The receiver Operation Once the arrow or bolt is shot the HideRider is attached to the animal and is transmitting. Wait at least one to two hours before pursuing the animal and if it is believed the shot was a marginal hit wait long enough for the animal to expire. 1. Turn the transmitter on by pressing and releasing the power button 2. Check the “Power/Low Batt” indicator light to verify the unit has power. The light blinks to indicate low battery in which case replace the batteries with new AA batteries. 3. Insert standard ear bud into head phone jack if desired. (this is optional and not necessary as tracking is easily accomplished using the signal strength lights) 4. Hold the receiver out in front of you as you would a hand gun and point in the most likely direction to find the animal. Sweep the receiver steadily and very slowly 360 degrees. The receiver is searching for the transmitter signal. When the receiver antenna is pointed toward the animal the signal strength will be indicated by the signal strength lights. The range indicator light indicates weather you are far away far away from the animal 3.5mm Headphone jack Picatinny Rail for flashlight attachment Antenna (Blue/cold), in mid range (Green) or in close range (Red/Hot). The signal strength indicator lights indicate the signal strength within each range. One light indicates a weak signal and more lights indicate a stronger signal. When far away from the Animal and the unit is receiving a very weak signal, the range indicator light will be blue (cold) and the one signal strength light will be on. As you progress closer and continue to point the antenna at the animal the more signal strength lights will be lit. As you progress even closer the range indicator light will change from blue to green and even closer the indicator light will turn to Red. At this point you are very close to the animal, generally within 100 to 200 yards. Keep sweeping the receiver to find the strongest signal as you move through the woods and progress toward the animal. Please note that by turning the receiver from a horizontal to a vertical position can change the signal strength. Changes or modifications not expressly approved by Iron Mountain Products, LLC could void the user's authority to operate this equipment. This device complies with CFR47 Part 15 of the FCC rules. Operation is subject to the following two conditions: · This device may not cause harmful interference. · This device must accept any interference received, including interference that may cause undesired operation. Iron Mountain Products, LLC. 849 North 1909 Road, LeCompton, KS 66050 P: 1-866-535-8009 f: 1-866-535-8009 www.ironmountainproducts.com
Page 1 of 2 November 12, 2012 Timco Engineering Inc. 849 NW State Road 45 Newberry, FL 32669 Applicant: Iron Mountain Products LLC 849 North 1909 Road LeCompton, KS 66050 Re: Confidentiality for submittal information regarding FCC ID number QXJHIDERIDE100 PRODUCT: Low power Transmitters operated under paragraph 15.249. Dear Sirs: Iron Mountain Products LLC requests that the material in the Schematics, Block Diagram, and Operational Description be withheld from public disclosure pursuant to Sections 0.457 and 0.459 of the Commission’s Rules following grant of the application. In support of this request, Iron Mountain Products LLC submits the following information. CONFIDENTIAL FILES Conf BlkDia TX100.pdf Conf OpDes TX100.pdf Conf Schem TX100.pdf 1. Identification of the specific information for which confidential treatment is sought: The materials set forth in the Operational Description, block diagram, parts list, and Schematics, which are segregated, from the non-confidential exhibits of the application, are those for which confidentiality is sought. 2. Identification of the Commission proceeding in which the information was submitted or a description of the circumstances giving rise to the submission: The proceeding is that involving the application for equipment authorization (certification) under FCC ID No: QXJHIDERIDE100 3. Explanation of the degree to which the information is commercial or financial, or contains a trade secret or is privileged: This material includes a detailed theory of operation, circuit diagrams, and schematic. As such, this material is treated as highly confidential business information. ROGERS LABS, INC. 4405 West 259 th Terrace Louisburg, KS 66053 913 837-3214 Page 2 of 2 4. Explanation of the degree to which the information concerns a service that is subject to competition: The material for which confidentiality is sought is employed in the design and manufacture of this transmitting equipment that is offered on a highly competitive basis. Customers for this equipment have a variety of competing sources. 5. Explanation of how disclosure of the information could result in substantial competitive harm: Disclosure would, in effect, give away the fruits of the labors of Iron Mountain Products LLC’s engineering personnel, who have designed the equipment and the manufacturing process. Disclosure would also offer competitors additional unwarranted insight into the state of the product development, thereby allowing competitors an advantage, not available to Iron Mountain Products LLC 6. Identification of any measures taken by the submitting party to prevent unauthorized disclosure: The information for which confidential treatment is sought is kept confidential by Iron Mountain Products LLC and not made available to third parties except pursuant to non-disclosure agreements. 7. Identification of whether the information is available to the public and the extent of any previous disclosure of the information to third parties: To the knowledge of those preparing this application, the information has not been disclosed publicly heretofore. While the general theory of operation of this equipment has been the subject of numerous disclosures in industry and standards groups as well as in rule making proceedings of the FCC, the protection sought is narrowly drawn and pertains to certain specific implementations of this radio technology. 8. Justification of the period during which the submitting party asserts that the material should not be available for public disclosure: This material should not be disclosed for at least 25 years. While improvements in design are made relatively frequently, disclosure of the design information would lead to insights into both design and manufacturing techniques that could have an adverse competitive effect for many years to come. As such, it is important that the design not be made available to unauthorized persons who might attempt to use knowledge of the design to compromise the applications for which the equipment will be employed. Should you require any further information, please contact the undersigned. Thank you for your consideration in this matter. Sincerely, Scot Rogers
November 15, 2012 Timco Engineering Inc. 849 NW State Road 45 Newberry, FL 32669 Applicant: Iron Mountain Products LLC 849 North 1909 Road LeCompton, KS 66050 Job number: 2950UC12 FCC ID: QXJHIDERIDE100 Men: Please accept this information as our response and explanation to your request for information for the above referenced application. Please find below a copy of the request with response. Based upon our review of this application we have the following issues: 1. Please explain, somewhere in the filing, whether the Receiver Unit is approved/tested according to Certificate or DoC procedure. Response 1. The receiver was tested and found in compliance with regulations for Receiver DoC. Please proceed with review and Grant of Certification process. The response to your request has been uploaded to your site. Please review the information and continue with the grant of certification process. Should you require any further information, please contact the undersigned. Thank you for your consideration in this matter. Sincerely, Scot Rogers Rogers Labs, Inc. Enclosures ROGERS LABS, INC. 4405 West 259 th Terrace Louisburg, KS 66053 Phone / Fax (913) 837-3214
November 12, 2012 Timco Engineering Inc. 849 NW State Road 45 Newberry, FL 32669 Applicant: Iron Mountain Products LLC Equipment: FCC ID: QXJHIDERIDE100 849 North 1909 Road CORES number: 0022 15 5600 LeCompton, KS 66050 FCC Rules: Parts 2 and 15.249 To Whom It May Concern: The form 731 and application have been electronically submitted and any attachments will be up loaded to your web site for use in obtaining a grant of certification. Confidentiality is requested as outlined below. The user manual is currently in development so manufacturer has supplied attestation letter containing compliance statements, which will be included in manual and/or product literature. Permanent Iron Mountain Products LLC requests that the material in the Schematics, Block Diagram, and Operational Description be withheld from public disclosure pursuant to Sections 0.457 and 0.459 of the Commission’s Rules following grant of the application. A statement of confidentiality will be attached with the application at the time of submittal. Exhibit File Schematics Conf Schem TX100.pdf Block diagram Conf BlkDia TX100.pdf Operational Description Conf OpDes TX100.pdf Should you require any further information, please contact the undersigned. Thank you for your consideration in this matter. Sincerely, Scot Rogers Rogers Labs, Inc. Enclosures ROGERS LABS, INC. 4405 West 259 th Terrace Louisburg, KS 66053 Phone / Fax (913) 837-3214
Rogers Labs, Inc. Iron Mountain Products LLC: 4405 West 259 th Terrace Model: HideRider TX-100 FCC ID: QXJHIDERIDE100 Louisburg, KS 66053 Test #:121101 SN: E1 Phone/Fax: (913) 837-3214 Test to: FCC CFR 47 15.249 Date: November 12, 2012 Revision 1 File: ExtPho TX100 Page 1 of 1 External photographs of equipment under test
Rogers Labs, Inc. Iron Mountain Products LLC 4405 West 259 th Terrace Model: HideRider TX-100 FCC ID: QXJHIDERIDE100 Louisburg, KS 66053 Test #:121101 SN: E1 Phone/Fax: (913) 837-3214 Test to: FCC CFR 47 15.249 Date: November 12, 2012 Revision 1 File: LabelSmpl TX100 Page 1 of 1 ID label and location
Rogers Labs, Inc. Iron Mountain Products LLC 4405 West 259 th Terrace Model: HideRider TX-100 FCC ID: QXJHIDERIDE100 Louisburg, KS 66053 Test #:121101 SN: E1 Phone/Fax: (913) 837-3214 Test to: FCC CFR 47 15.249 Date: November 9, 2012 Revision 1 File: IntPho TX100 Page 1 of 1 Internal Photographs
Rogers Labs, Inc. Iron Mountain Products LLC 4405 West 259 th Terrace Model: HideRider TX-100 FCC ID: QXJHIDERIDE100 Louisburg, KS 66053 Test #:121101 SN: E1 Phone/Fax: (913) 837-3214 Test to: FCC CFR 47 15.249 Date: November 9, 2012 Revision 1 File: TunPro TX100 Page 1 of 1 Transmitter tune-up procedure Each unit is tested for functionality during production against pass/fail criteria. Units passing inspection and in compliance proceed through production. Non-compliant units are removed from production for evaluation or disposal. No tuning options are available to end user.
