Game Vector Operating Instructions For video instructions go to www.game-vector.com Page 1 Finding Your Game 1. Allow adequate time for the game to expire before perusing. One half hour to overnight is often required. Game that is “pushed” may be very difficult if not impossible to find. 2. Practice good traditional tracking techniques 3. Knowing the general direction of the game, set up a search pattern. Either walk or drive the pattern until the game is found. Note: Because of varying terrain and other obstructions the signal may be detected differently from different directions. Moving in a pattern and scanning in all directions will facilitate a quick recovery. 4. If possible walk on higher ground and scan downward. This may help create a clear signal path to the game. 5. Be sure to scan slowly with the GameVector receiver. Practice before you hunt We recommend that you familiarize yourself with the operation of the system before going to the field. 1. Fully insert the battery into the HideRider which activates the transmitter and the LED light in the back of the HideRider. The Hiderider will continue to blink and transmit for two minutes and then go into sleep mode. 2. Turn on the receiver. After a short “boot” period the red lights on the receiver will illuminate indicating the presence of a signal from the HideRider. 3. To simulate the HideRider being shot from the bow: While the HideRider is in sleep mode swing it in your hand much like you would swing a golf club. The transmitter will be activated and continue to transmit until the battery is disconnected. The receiver will again detect the signal. 4. Play with the system and have some fun with it. Place the HideRider in various locations and practice finding it. Important Information 1. The system is designed to be used on most arrow shafts with the exception of the micro shafts on the market today. 2. The system is NOT designed for use in a crossbow. Practice Capsules and Field tip The HideRider adds 65 grains of weight to your arrow. The Practice capsule is the same weight and similar aerodynamic design as the HideRider Transmitter. Use the practice capsule before hunting to insure accuracy. It is also recommended that you shoot the HideRider itself before going afield. Fig 1 To attach the practice capsule Fig 1. 1. Remove the target point or broadhead from the arrow shaft. 2. Slide the practice capsule onto the shaft. 3. Insert the spacer onto the practice point or broadhead 4. Reattach the practice point or broadhead to the arrow shaft. 5. Slide the practice capsule toward the practice point or broadhead until it clicks in place on the spacer. Fig 2. 6. After shooting, remove the arrow from the target; slide the practice capsule back onto the spacer. Fig 2 HideRider Transmitter When the HideRider is affixed to your arrow it begins to transmit when shot and attaches to the hide of the animal where it stays until recovery. It comes complete with the battery module. To activate the HideRider simply insert the battery module until it is firmly seated into the HideRider. Peel the backing from the black sticker and tightly wrap it around the HideRider/Battery housing. The LED in the back of the HideRider will blink indicating the transmitter is activated. After a two-minute period the unit will enter its sleep mode and the blinking will stop. The transmitter is only slightly active while in sleep mode. The unit is now asleep and ready to be shot from your bow. Upon releasing the arrow from your bow, the HideRider is automatically activated and will begin to blink and transmit. To turn the unit off, simply remove the battery module. It is recommended that when you receive your GameVector you activate the HideRider transmitter and practice using the receiver. After the initial two minute transmit period and the HideRider enters sleep mode it can be activated by swinging it in your hand much like you would swing a golf club. Note: When the battery is fully inserted and the HideRider is asleep the battery life is approximately four weeks. Once the HideRider is shot from the bow and in transmit mode, the battery life is approximately 48-72 hours. It is recommended that you replace the battery after a week of sleep time to assure there is ample battery power remaining after the shot. Although the battery has an extended shelf life, up to 10 years, we recommend you change the batteries annually to assure a full charge. Caution: There must be a minimum of 1 1/4 inches between the back of the broadhead or point and your arrow rest to accommodate the HideRider. To test, draw an arrow in your bow and have someone mark the arrow where it meets the front of the arrow rest. Place the HideRider on the arrow as explained below. Assure that the HideRider battery module does not extend back past the mark. If there is not adequate length, in full draw, the HideRider will hit the arrow rest pulling the nock off of the bow string resulting in a possible dry fire of the bow. Spacer Practice Capsule Practice capsule Spacer Game Vector Operating Instructions For video instructions go to www.game-vector.com Page 2 Fig.3 Fig 4 To attach the HideRider: Fig.3& 4. 1. Remove the broadhead from the arrow shaft. 2. Insert the retainer with O-Ring as shown. Fig 3. 3. Re-attach the broadhead. 4. Place the HideRider around the shaft. 5. Push the HideRider forward until it snaps into the retainer. 6. Make sure the needle is positioned on top of the shaft when placed in the bow as shown. Fig 4. 7. Assure the barbed needle is lined up between the blades of the broadhead so the barbed needle latches onto the hide as opposed to following the blade into an area of cut hide. Fig 4. To operate HideRider: 1. Fully insert the battery module (LED will flash and transmitter is activated for two minutes until it enters sleep mode) 2. Peel the backing from the black sticker and tightly wrap it around the HideRider/Battery housing. This assures the battery is held securely when …

Text truncated - open the document above for the full version.

Page 1 of 2 July 26, 2014 Timco Engineering Inc. 849 NW State Road 45 Newberry, FL 32669 Applicant: Iron Mountain Products LLC 849 North 1909 Road LeCompton, KS 66050 Re: Confidentiality for submittal information regarding FCC ID number QXJHIDERIDE200 PRODUCT: Low power Transmitters operated under paragraph 15.249. Dear Sirs: Iron Mountain Products LLC requests that the material in the Schematics, Block Diagram, and Operational Description be withheld from public disclosure pursuant to Sections 0.457 and 0.459 of the Commission’s Rules following grant of the application. In support of this request, Iron Mountain Products LLC submits the following information. CONFIDENTIAL FILES Conf BlkDia HIDERIDE200.pdf Conf OpDes HIDERIDE200.pdf Conf Schem HIDERIDE200.pdf 1. Identification of the specific information for which confidential treatment is sought: The materials set forth in the Operational Description, block diagram, parts list, and Schematics, which are segregated, from the non-confidential exhibits of the application, are those for which confidentiality is sought. 2. Identification of the Commission proceeding in which the information was submitted or a description of the circumstances giving rise to the submission: The proceeding is that involving the application for equipment authorization (certification) under FCC ID No: QXJHIDERIDE200 3. Explanation of the degree to which the information is commercial or financial, or contains a trade secret or is privileged: This material includes a detailed theory of operation, circuit diagrams, and schematic. As such, this material is treated as highly confidential business information. ROGERS LABS, INC. 4405 West 259 th Terrace Louisburg, KS 66053 913 837-3214 Page 2 of 2 4. Explanation of the degree to which the information concerns a service that is subject to competition: The material for which confidentiality is sought is employed in the design and manufacture of this transmitting equipment that is offered on a highly competitive basis. Customers for this equipment have a variety of competing sources. 5. Explanation of how disclosure of the information could result in substantial competitive harm: Disclosure would, in effect, give away the fruits of the labors of Iron Mountain Products LLC’s engineering personnel, who have designed the equipment and the manufacturing process. Disclosure would also offer competitors additional unwarranted insight into the state of the product development, thereby allowing competitors an advantage, not available to Iron Mountain Products LLC 6. Identification of any measures taken by the submitting party to prevent unauthorized disclosure: The information for which confidential treatment is sought is kept confidential by Iron Mountain Products LLC and not made available to third parties except pursuant to non-disclosure agreements. 7. Identification of whether the information is available to the public and the extent of any previous disclosure of the information to third parties: To the knowledge of those preparing this application, the information has not been disclosed publicly heretofore. While the general theory of operation of this equipment has been the subject of numerous disclosures in industry and standards groups as well as in rule making proceedings of the FCC, the protection sought is narrowly drawn and pertains to certain specific implementations of this radio technology. 8. Justification of the period during which the submitting party asserts that the material should not be available for public disclosure: This material should not be disclosed for at least 25 years. While improvements in design are made relatively frequently, disclosure of the design information would lead to insights into both design and manufacturing techniques that could have an adverse competitive effect for many years to come. As such, it is important that the design not be made available to unauthorized persons who might attempt to use knowledge of the design to compromise the applications for which the equipment will be employed. Should you require any further information, please contact the undersigned. Thank you for your consideration in this matter. Sincerely, Scot Rogers

July 26, 2014 Timco Engineering Inc. 849 NW State Road 45 Newberry, FL 32669 Applicant: Iron Mountain Products LLC Equipment: FCC ID: QXJHIDERIDE200 849 North 1909 Road CORES number: 0022 15 5600 LeCompton, KS 66050 FCC Rules: Parts 2 and 15.249 To Whom It May Concern: The form 731 and application have been electronically submitted and any attachments will be up loaded to your web site for use in obtaining a grant of certification. Confidentiality is requested as outlined below. The user manual is currently in development so manufacturer has supplied attestation letter containing compliance statements, which will be included in manual and/or product literature. Permanent Iron Mountain Products LLC requests that the material in the Schematics, Block Diagram, and Operational Description be withheld from public disclosure pursuant to Sections 0.457 and 0.459 of the Commission’s Rules following grant of the application. A statement of confidentiality will be attached with the application at the time of submittal. Exhibit File Schematics Conf Schem HIDERIDE200.pdf Block diagram Conf BlkDia HIDERIDE200.pdf Operational Description Conf OpDes HIDERIDE200.pdf Should you require any further information, please contact the undersigned. Thank you for your consideration in this matter. Sincerely, Scot Rogers Rogers Labs, Inc. Enclosures ROGERS LABS, INC. 4405 West 259 th Terrace Louisburg, KS 66053 Phone / Fax (913) 837-3214

Rogers Labs, Inc. Iron Mountain Products LLC 4405 W. 259th Terrace Model: HideRider TX-200 FCC ID#: QXJHIDERIDE200 Louisburg, KS 66053 Test #: 140702 SN: ENG1 Phone/Fax: (913) 837-3214 Test to: CFR47 (15.249), RSS-210 Date: July 29, 2014 Revision 1 File: ExtPho HideRide200 Page 1 of 2 External photographs of equipment under test Rogers Labs, Inc. Iron Mountain Products LLC 4405 W. 259th Terrace Model: HideRider TX-200 FCC ID#: QXJHIDERIDE200 Louisburg, KS 66053 Test #: 140702 SN: ENG1 Phone/Fax: (913) 837-3214 Test to: CFR47 (15.249), RSS-210 Date: July 29, 2014 Revision 1 File: ExtPho HideRide200 Page 2 of 2

FCC ID: QXJHIDERIDE 200 Label to be placed on the outside of the battery compartment unit,visible to the user.

Rogers Labs, Inc. Iron Mountain Products LLC 4405 W. 259th Terrace Model: HideRider TX-200 FCC ID#: QXJHIDERIDE200 Louisburg, KS 66053 Test #: 140702 SN: ENG1 Phone/Fax: (913) 837-3214 Test to: CFR47 (15.249), RSS-210 Date: July 29, 2014 Revision 1 File: IntPho HideRide200 Page 1 of 2 Internal Photographs Rogers Labs, Inc. Iron Mountain Products LLC 4405 W. 259th Terrace Model: HideRider TX-200 FCC ID#: QXJHIDERIDE200 Louisburg, KS 66053 Test #: 140702 SN: ENG1 Phone/Fax: (913) 837-3214 Test to: CFR47 (15.249), RSS-210 Date: July 29, 2014 Revision 1 File: IntPho HideRide200 Page 2 of 2

NVLAP Lab Code 200087-0 Rogers Labs, Inc. Iron Mountain Products LLC 4405 W. 259th Terrace Model: HideRider TX-200 FCC ID#: QXJHIDERIDE200 Louisburg, KS 66053 Test #: 140702 SN: ENG1 Phone/Fax: (913) 837-3214 Test to: CFR47 (15.249), RSS-210 Date: July 26, 2014 Revision 1 File: Iron Mntn HideRide200 TstRpt 140702 Page 1 of 24 Application For Grant of Certification FOR FOR Model: HIDERIDER TX-200 916 MHz Low Power Transmitter FCC ID: QXJHIDERIDE200 FOR Iron Mountain Products LLC 849 North 1909 Road LeCompton, KS 66050 Test Report Number: 140718 Authorized Signatory: Scot D. Rogers NVLAP Lab Code 200087-0 Rogers Labs, Inc. Iron Mountain Products LLC 4405 W. 259th Terrace Model: HideRider TX-200 FCC ID#: QXJHIDERIDE200 Louisburg, KS 66053 Test #: 140702 SN: ENG1 Phone/Fax: (913) 837-3214 Test to: CFR47 (15.249), RSS-210 Date: July 26, 2014 Revision 1 File: Iron Mntn HideRide200 TstRpt 140702 Page 2 of 24 Engineering Test Report For Grant of Certification Application FOR CFR 47, PART 15C - Intentional Radiators CFR 47 Paragraph 15.249 and Industry Canada RSS-210 License Exempt Intentional Radiator For Iron Mountain Products LLC 849 North 1909 Road LeCompton, KS 66050 Model: HIDERIDER TX-200 Low Power Transmitter Frequency Range 916 MHz FCC ID#: QXJHIDERIDE200 Test Date: July 18, 2014 Certifying Engineer: Scot D. Rogers Rogers Labs, Inc. 4405 West 259 th Terrace Louisburg, KS 66053 Telephone/Facsimile: (913) 837-3214 This report shall not be reproduced except in full, without the written approval of the laboratory. This report must not be used by the client to claim product certification, approval, or endorsement by NVLAP, NIST, or any agency of the Federal Government. ROGERS LABS, INC. 4405 West 259 th Terrace Louisburg, KS 66053 Phone / Fax (913) 837-3214 NVLAP Lab Code 200087-0 Rogers Labs, Inc. Iron Mountain Products LLC 4405 W. 259th Terrace Model: HideRider TX-200 FCC ID#: QXJHIDERIDE200 Louisburg, KS 66053 Test #: 140702 SN: ENG1 Phone/Fax: (913) 837-3214 Test to: CFR47 (15.249), RSS-210 Date: July 26, 2014 Revision 1 File: Iron Mntn HideRide200 TstRpt 140702 Page 3 of 24 Table Of Contents TABLE OF CONTENTS .................................................................................................. 3 REVISIONS ..................................................................................................................... 4 FORWARD ..................................................................................................................... 5 OPINION / INTERPRETATION OF RESULTS ............................................................... 5 EQUIPMENT TESTED .................................................................................................... 5 EQUIPMENT FUNCTION AND CONFIGURATION........................................................ 6 Equipment Configuration.................................................................................................................................... 6 APPLICATION FOR CERTIFICATION ........................................................................... 7 APPLICABLE STANDARDS & TEST PROCEDURES .................................................. 8 EQUIPMENT TESTING PROCEDURES ........................................................................ 8 AC Line Conducted Emission Test Procedure .................................................................................................. 8 Radiated Emission Test Procedure ..................................................................................................................... 8 Diagram 1 Test arrangement for Conducted emissions ....................................................................................... 9 Diagram 2 Test arrangement for radiated emissions of tabletop equipment ...................................................... 10 Diagram 3 Test arrangement for radiated emissions tested on Open Area Test Site (OATS) ........................... 11 TEST SITE LOCATIONS .............................................................................................. 11 LIST OF TEST EQUIPMENT ........................................................................................ 12 UNITS OF MEASUREMENTS ...................................................................................... 13 ENVIRONMENTAL CONDITIONS................................................................................ 13 INTENTIONAL RADIATORS ........................................................................................ 13 Antenna Requirements ...................................................................................................................................... 13 Restricted Bands of Operation .......................................................................................................................... 13 Table 1 Radiated Emissions in Restricted Frequency Bands Data .................................................................... 14 Summary of Results for Radiated Emissions in Restricted Bands ................................................................ 14 AC Line Conducted EMI Procedure ................................................................................................................ 14 General Radiated Emissions Procedure ........................................................................................................... 15 NVLAP Lab Code 200087-0 Rogers Labs, Inc. Iron Mountain Products LLC 4405 W. 259th Terrace Model: HideRider TX-200 FCC ID#: QXJHIDERIDE200 Louisburg, KS 66053 Test #: 140702 SN: ENG1 Phone/Fax: (913) 837-3214 Test to: CFR47 (15.249), RSS-210 Date: July 26, 2014 Revision 1 File: Iron Mntn HideRide200 TstRpt 140702 Page 4 of 24 Table 2 General Radiated Emissions from EUT Data ....................................................................................... 15 Summary of Results for General Radiated Emissions ......................................................................…
